Operating Instructions

Please read this manual before using and save this manual for future reference.

Network Camera

Panasonic Network Camera Website: http://www.panasonic.com/netcam

for customers in the USA or Puerto Rico

Model No.

BB-HCM381A

Operating Instructions

Main Features

IPv6*1 Network Camera

Your Panasonic Network Camera supports IPv6 (Internet Protocol Version 6), IPv6

was created to address the additional IP addresses that will be needed as the

Internet continues to expand. Since the camera also supports IPv4 that's currently

used, it is "dual stack" design will seamlessly operate while IPv6 is phased in. For

more information in IPv6 you wish to visit http://www.ipv6.org/. See page 15 for

more information.

Audio 2-way Communication*2 (Walkie-talkie Type)

2-way audio communication is now possible between your Network Camera and

PC. By connecting a user-supplied microphone and speaker*3 to both the camera

and to the PC, you will be able to speak to and hear anyone within range of the

camera.

For example, the camera can be used in the following various locations:

• In the baby's room, to hear if the baby is crying.

• At the front door, to see and hear who is at the door.

• In the children's play room, to see and hear if they are safe.

Note

PLEASE NOTE that under certain circumstances, audio/video recording may

be PROHIBITED by law. This device should be used only in compliance with

all applicable federal, state and local statutes.

Better Image Quality

The CCD sensor and the color night view mode provides better image quality and

low light performance.

• The CCD sensor gives you clear image.

• You can monitor live video (Motion JPEG) that refreshes its image 30 frames

per second.

• Color night view mode allows you to monitor the camera in low illuminance.

*1 To connect in IPv6, subscribe to the ISP's "IPv4/IPv6 Dual-Stack" or "IPv6 over IPv4

Tunneling" service. The camera does not work in IPv6-only network.

*2 Audio feature does not work well on cell phones. Talk button and Listen button cannot be used

simultaneously. In consequence of traffic and network environments, the audio may be

delayed or may break up.

*3 The speaker connected to the camera requires a built-in amplifier.

Operating Instructions

[For assistance, please call: 1-800-272-7033] 3

Remote Pan/Tilt/Zoom/Focus

The following features allow you to operate Network Camera from web browser on

your PC. High speed Pan/Tilt operation can move the lens horizontally from -175°

to +175° and vertically from -120° to 0° in mounting on the table and from 0° to +90°

in mounting on the ceiling. This movable lens allows you to view a wide range of

perspective from a distant place. Network Camera has a 42x magnifying capacity:

a 21x optical zoom and a 2x digital zoom. Automatic and Manual Focusing features

provide you with detailed and distinct images. Additionally, the following control

features are available to easily and quickly monitor the camera.

Video Output

Network Camera has an analog composite output terminal. You can view images

from Network Camera on TV and record them on videotapes.

SD Memory Card*1 Recording

The camera has an SD memory card slot. You can record camera images to the

SD memory card. If you enable alarm buffer/transfer, you can record the image at

the timing of signal detection of door sensor or light. About 58,000 images (320 x

240 resolution and standard quality) can be recorded to 1 GB SD memory card. If

you enable 1-minute interval timer buffer/transfer, you can record the images for

about 41 days.

Enhanced Multi-Camera Page

Multi-Camera page displays up to 4 cameras while supporting each audio 2-way

communication. The previous model displays only 4 cameras, but this camera can

switch 3 sets of 4 cameras. Additionally, the camera can displays maximum 12

cameras on a page in a static image.

Supporting Viewnetcam.com service

Viewnetcam.com service allows you to access the camera over the Internet with

your favorite domain name (e.g. bob.viewnetcam.com) instead of a global IP

address.

Click to Center ......... When you click a certain point on the camera image, the

point is centered on the image.

Preset Position ......... You can register 8 preset positions. When you click each

button, the image switches to its position.

Output Control ......... You can control the external devices (Open or Short to

GND) (E.g., turning the light on or ringing a buzzer).

*1 SD memory card is sold separately. The camera supports 1 GB, 512 MB, 256 MB, 128 MB or

64 MB Panasonic SD memory card.

Operating Instructions

Multi-Language Display

Top page, Single Camera and Multi-Camera page can be displayed in English,

French, German, Italian, Spanish, Russian, Simplified Chinese or Japanese. The

Setup, Maintenance and Support pages are displayed only in English or Japanese.

Operating Instructions

[For assistance, please call: 1-800-272-7033] 5

How to Use This Documentation

The camera includes the following 2 manual types.

•Installation/Troubleshooting

Installation/Troubleshooting provides explanations for accessories included

with the camera, the initial configuration, and troubleshooting tips. The

Installation/Troubleshooting helps you to easily configure the camera.

•Operating Instructions (This manual)

Operating Instructions explains about operations, settings, features and the

cleaning method when using the camera.

Abbreviations

• UPnP is the abbreviation for Universal Plug and Play.

• "Network Camera" is called "Camera" in this Operating Instructions.

Trademarks

• Adobe, Acrobat and Reader are either registered trademarks or trademarks of

Adobe Systems Incorporated in the United States and/or other countries.

• Microsoft, Windows, Hotmail and ActiveX are either registered trademarks or

trademarks of Microsoft Corporation in the United States and/or other

countries.

• Pentium is a trademark or registered trademark of Intel Corporation or its

subsidiaries in the United States and other countries.

• SD mark is a trademark of the SD Card Association.

• Screen shots reprinted with permission from Microsoft Corporation.

• All other trademarks identified herein are the property of their respective

owners.

Operating Instructions

System Requirements for your PC

Your PC (Personal Computer) and network must meet the following technical

specifications for the camera to work properly.

For IPv4 Connection

Item Description

Operating

System

Microsoft®Windows®XP, Microsoft®Windows®2000

Microsoft®Windows®Me, Microsoft®Windows®98SE

CPU •For viewing single camera

Pentium®III (800 MHz or greater is recommended.)

•For viewing multiple cameras

Pentium 4 (1.8 GHz or greater is recommended.)

Protocol TCP/IP protocol (HTTP, TCP, UDP, IP, DNS, ARP, ICMP)

Interface 10/100 Mbps network card installed

Web Browser Internet Explorer 6.0 or later (Not included on the Setup CD-

ROM)

Audio Audio input/output feature (Microphone or speaker)

Operating Instructions

[For assistance, please call: 1-800-272-7033] 7

Note

See Panasonic Network Camera support website at

http://panasonic.co.jp/pcc/products/en/netwkcam/ for the latest

information about web browser.

For IPv6 Connection

Item Description

Operating

System

Microsoft®Windows®XP Service Pack 1 or later

CPU •For viewing single camera

Pentium III (800 MHz or greater is recommended.)

•For viewing multiple cameras

Pentium 4 (1.8 GHz or greater is recommended.)

Protocol TCP/IP protocol (HTTP, TCP, UDP, IP, DNS, ICMPv6, NDP)

Interface 10/100 Mbps network card installed

Web Browser Internet Explorer 6.0 or later (Not included on the Setup CD-

ROM)

Audio Audio input/output feature (Microphone or speaker)

Operating Instructions

IMPORTANT SAFETY INSTRUCTIONS

When using this unit, basic safety precautions should always be followed to reduce

the risk of fire, electric shock, or personal injury.

1. Read and understand all instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. After taking away the sand or the dust on the lens, wipe the lens with lens

cleaning paper.

6. Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

7. Do not install near any heat sources such as radiators, heat registers, stoves,

or other devices (including amplifiers) that produce heat.

8. Protect the AC adaptor cord and AC cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where they exit

from the unit.

9. The AC cord is used as the main disconnect device, ensure that the socket-

outlet is located/installed near the equipment and is easily accessible.

10. Only use attachments/accessories such as stand specified by the

manufacturer.

11. Do not touch the unit or the AC adaptor cord and AC cord during lightning

storms.

12. Unplug the unit when unused for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when

the unit has been damaged in any way, such as the AC adaptor cord, AC cord

or plug is damaged, the unit does not operate normally, or has been dropped.

14. The attached AC adaptor and AC cord is intended for indoor use only. Both AC

adaptor and AC cord must be waterproofed for outside use.

15. Keep the SD memory card (customer-provided) out of reach of children to

prevent swallowing.

SAVE THESE INSTRUCTIONS

Operating Instructions

[For assistance, please call: 1-800-272-7033] 9

User Name and Password Protection

The use of a unique User Name and secret Password is an important tool that

will help limit unauthorized individuals from accessing the camera. If you

choose to disable this tool, and choose not to limit access by use of a User

Name and Password, this may result in access to the camera by

unauthorized individuals. (see page 77)

Operating Instructions

Table of Contents

1 Camera Monitoring .....................................................13

1.1 Accessing the Camera................................................................. 13

1.1.1 To Access the Camera in IPv6................................................................. 15

1.2 Viewing Single Camera page....................................................... 17

1.2.1 Auto Centering the Image (Click to Center)............................................. 21

1.2.2 Capturing a Still Image ............................................................................ 22

1.2.3 Using Operation Bar ................................................................................ 23

1.2.4 Zooming In and Out................................................................................. 25

1.2.5 Automatic and Manual Focusing.............................................................. 26

1.2.6 Setting Home Position/Alarm Position/Preset Button .............................. 28

1.3 Listening to Camera Audio—Talking to the Camera .................... 32

1.4 Viewing Multi-Camera page......................................................... 34

1.5 Viewing Buffered Image page ...................................................... 36

1.5.1 Deleting Buffered Images ........................................................................ 38

1.6 Viewing Still Images on Your Cell Phone ..................................... 39

2 Various Camera Features ...........................................41

2.1 Using Camera Features............................................................... 41

2.2 Connecting the Camera to Your IPv4 Network ............................ 44

2.3 Connecting the Camera to Your IPv6 Network ............................ 49

2.4 What is IPsec? ............................................................................. 53

2.5 Encrypt the Camera Image in Transport Mode ............................ 56

2.6 Encrypt the Camera Image in Tunnel Mode................................. 59

2.7 Using UPnP™ (Universal Plug and Play) .................................... 63

2.8 Registering with the Viewnetcam.com service ............................ 65

2.9 Setting Date and Time ................................................................. 67

2.10 Changing Camera Settings.......................................................... 69

2.11 Adjusting Audio ............................................................................ 75

2.12 Changing Authentication Setting and Administrator User Name and

Password ..................................................................................... 77

2.13 Logging in to the Camera............................................................. 80

2.14 Creating, Modifying or Deleting General Users ........................... 81

Autres manuels pour BB-HCM381A - Network Camera

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Caméra de sécurité

Panasonic

Panasonic Advidia A-46-F Manuel utilisateur

Panasonic

Panasonic WV-SPW531AL Manuel d'utilisation

Panasonic

Panasonic Super Dynamic III WV-CW484S Manuel utilisateur

Panasonic

Panasonic Super Dynamic III WV-CS950 Manuel utilisateur

Panasonic

Panasonic WVCW474S - COLOR CCTV CAMERA Manuel utilisateur

Panasonic

Panasonic WVCW244F - COLOR CAMERA Manuel utilisateur

Panasonic

Panasonic KX-HCM8 - Network Camera - Position Manuel utilisateur

Panasonic

Panasonic WVBLR730 - CCTV Manuel utilisateur

Panasonic

Panasonic aw-he40 series Manuel utilisateur

Panasonic

Panasonic K-EF134L03E Manuel utilisateur

Panasonic

Panasonic WV-SW396 Manuel utilisateur

Panasonic

Panasonic BL-C30A - Wireless 802.11 b/g Network Camera Mode d’emploi

Panasonic

Panasonic WV-SW158 Manuel utilisateur

Panasonic

Panasonic BL-C230A Manuel utilisateur

Panasonic

Panasonic OneHome BB-HCM311A Manuel utilisateur

Panasonic

Panasonic KX-TG5779C Manuel utilisateur

Panasonic

Panasonic WVCLR830 - COLOR CCTV CAMERA Manuel utilisateur

Panasonic

Panasonic BL-VT164W Manuel utilisateur

Panasonic

Panasonic BL-C20A - Network Camera Manuel utilisateur

Panasonic

Panasonic WV-CS850B Manuel utilisateur

Panasonic

Panasonic WV-SFV130 Manuel utilisateur

Panasonic

Panasonic BB-HCM580A Manuel utilisateur

Panasonic

Panasonic BB-HCM511A Manuel utilisateur

Panasonic

Panasonic WVCP460 - COLOR CCTV CAMERA Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
