★ This is to explain the procedure for adding another AW-HE40 camera as CAM4 to an existing system that consists

of three AW-HE40 cameras and one AW-R 50 controller.

1. Connect AW-HE40 LAN port and the hub using a LAN cable. (AW-HE40 can automaticall recognize whether

it is a cross or straight cable.)

* LAN Cable: Category 5 or higher, Up to 100m (Category 5e or higher if connected via a oE+ compatible hub)

2. B [1] CAMERA CTL setting, select [No Asign] for the CAMERA No. ou want to add.

① ress MENU button. - (Fig. 1-A)

② ress [10] SYSTEM button. - (Fig. 1-B) * “[1] CAMERA CTL” will be displayed on the LCD screen. - (Fig. 2)

* If it is not displayed, turn F1 dial to make “[1] CAMERA CTL” appear.

③ While “[1] CAMERA CTL” is displayed on the LCD screen, press F1 dial. - (Fig. 1-C)

④ Turn F1 dial to make [CAM4] appear. - (Fig. 2)

⑤ Turn F2 dial to select [No Asign], then press F2 dial to determine the setting. - (Fig. 1-D)

Turn F2 ⇒ Select “No Asign” ⇒ ress F2 to determine

Adding Another AW-HE40 Camera to Existing S stem

MENU ON ⇒ Select [10]

［1］CAMERA CTL

ress F1

1. CAM1

Network

2. CAM2

Network

3. CAM3

Network

Installed & Set Alread

4. CAM4

No Asign

Turn F1

（A）

（B）

（C）

（D）

(Figure 1)

(Figure 2)

3. B [5] AUTO SET IP setting, execute the automatic assignment of IP addresses. (RENEW IP ADR)

① In the state of the above-mentioned 2.-②, turn F1dial to select [5] AUTO SET I .

② ress F1 dial to make [RENEW I ADR] appear on the lower half of the LCD screen.

* If it does not appear, turn F2 dial to make [RENEW I ADR] appear.

③ While [RENEW I ADR] is displayed, press F2 dial. The number of units that AW-R 50 has newly

detected and the number of units that it currently manages (all the remote cameras and switchers) will

be displayed on the upper half of the LCD screen.

④ [NO] will be displayed on the lower half of the LCD screen. So, turn F2 dial to select [YES] and then

press F2 dial.

⑤ When [COM LETE] is displayed on the lower half of the LCD screen, the setting-up is completed.

After setting up, LED button 4 (CAM4) at <CAMERA STATUS / SELECTION> on the AW-R 50 operation panel lights

up in a few seconds according to the camera’s power status. If the camera is in STANDBY mode (power OFF:

factory default), the button lights up in orange. If in OWER ON mode (power ON), it lights up in green.

* When the camera is in STANDBY mode, the ower-ON operation needs to be done.

For the procedure, please refer to “3. Turn AW-HE40 on” of the Manual 【Controlling AW-HE40 Camera via

AW-R 50 Controller】.

(AW-R 50: CAMERA STATUS/SELCTION Area)

[5] AUTO SET IP

［1］CAMERA CTL

MENU ON ⇒ Select [10]

Turn F1

ress F1

1. AUTO SET

RENEW IP ADR

C:001/004 S：0/1

NO ↓

C:001/004 S：0/1

YES

↓

C:001/004 S：0/1

COMPLETE

Turn F2

ress F2

After setting up, this lights up

according to the camera’s

power status.

* If it does not light up, please check the following points.

① Check the connection state of LAN cable or whether you are using a cable that meets the specifications.

② Check that the LAN cable is connected to “LAN port”, not to “RS422 port”.

③ Double-check that there is no error in setting up the connection.
