Operating Instructions

Replacement lamp unit Commercial Use

Model No. ET-LAL330

ET-LAL340

TQZJ559-2

Thank you for purchasing this Panasonic product.

■Please read these operating instructions and the projector operating in-

structions carefully, and then use this product correctly.

■Beforeusingthisproduct,besuretoread[Readthisrst!](Page2).

■Please save this manual for future use.

ET-LAL330 ET-LAL340

2-ENGLISH

Read this rst! Always follow these precautions

Notice (for USA only)

Hg-LAMP CONTAINS MERCURY, Manage in Accord with Disposal Laws,

See: www.lamprecycle.org or 1-888-411-1996

This lamp is used in projectors.

It is not intended to be used for indoor lighting of ordinary homes.

2009/125/EC

WARNING:

JDo not remove any screws other than those indicated when

replacing the lamp unit.

If this is not observed, electric shocks, burns or other injuries may occur.

JDo not disassemble the lamp unit.

If the lamp breaks, it could cause injury.

JLamp replacement

The lamp has high internal pressure. If improperly handled, an explosion and severe

injury or accidents will result.

•The lamp can easily explode if struck against hard objects or dropped.

•Before replacing the lamp, be sure to disconnect the power plug from the wall out-

let. Electric shocks or explosions can result if this is not done.

•When replacing the lamp, turn the power off and allow it to cool for at least 1 hour

before handling it otherwise it can cause burns.

CAUTION:

JDo not use the old lamp unit.

If used it could cause lamp explosion.

JIf the lamp has broken, ventilate the room immediately.

Do not touch or bring your face close to the broken pieces.

Failure to observe this will cause the user to absorb the gas which was released

whenthelampbrokeandwhichcontainsnearlythesameamountofmercuryasuo-

rescent lamps, and the broken pieces will cause injury.

•If you believe that you have absorbed the gas or that the gas has got into your eyes

or mouth, seek medical advice immediately.

•Ask your dealer about replacing the lamp unit and check the inside of the projector.

Illustrations in these operating instructions

Illustrations contained in these operating instructions that show the projector may dif-

fer from the actual objects they depict.

ENGLISH - 3

English

Manufactured by: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japan

Importer: Panasonic Connect Europe GmbH

Authorized Representative in EU: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Germany

Importer for UK:

Panasonic Connect UK,

a branch of Panasonic Connect Europe GmbH,

Maxis2,WesternRoad,Bracknell,Berkshire,RG121RT

Français Fabriqué par: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japon

Importateur: Panasonic Connect Europe GmbH

Représentant autorisé dans l’UE: Panasonic Testing Centre

Winsbergring15,22525Hambourg,Allemagne

Español Fabricado por: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japón

Importador: Panasonic Connect Europe GmbH

Representante Autorizado para la UE: Panasonic Testing Centre

Winsbergring15,22525Hamburgo,Alemania

Deutsch Hergestellt von: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japan

Importeur: Panasonic Connect Europe GmbH

Vertretungsberechtigter in der EU: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Deutschland

Italiano Fabbricato da: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Giappone

Importatore: Panasonic Connect Europe GmbH

Rappresentante autorizzato nell’UE: Panasonic Testing Centre

Winsbergring15,22525Amburgo,Germania

Български Производител: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Япония

Вносител: Panasonic Connect Europe GmbH

Упълномощен представител в ЕС: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Германия

4 - ENGLISH

Čeština Vyrobil: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japonsko

Dovozce: Panasonic Connect Europe GmbH

Oprávněný zástupce v EU: Panasonic Testing Centre

Winsbergring15,22525Hamburk,Německo

Dansk Fremstillet af: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japan

Importør: Panasonic Connect Europe GmbH

Autoriseret repræsentant i EU: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Tyskland

Eesti Tootja: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Jaapan

Maaletooja: Panasonic Connect Europe GmbH

Volitatud esindaja ELis: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Saksamaa

Ελληνικά Κατασκευάστηκε από: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Ιαπωνία

Εισαγωγέας: Panasonic Connect Europe GmbH

Εξουσιοδοτημένος αντιπρόσωπος στην ΕΕ: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Γερμανία

Hrvatski Proizvodi: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japan

Uvoznik: Panasonic Connect Europe GmbH

Ovlašteni zastupnik u EU-u: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Njemačka

Latviešu Ražotājs: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japāna

Importētājs: Panasonic Connect Europe GmbH

Ociālais pārstāvis ES: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Vācija

Lietuvių Gamintojas: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japonija

Importuotojas: Panasonic Connect Europe GmbH

Įgaliotasis atstovas ES: Panasonic Testing Centre

Winsbergring15,22525Hamburgas,Vokietija

ENGLISH -5

Magyar Gyártotta: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japán

Importőr: Panasonic Connect Europe GmbH

Hivatalos képviselő az EU-ban: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Németország

Nederlands Geproduceerd door: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japan

Importeur: Panasonic Connect Europe GmbH

Bevoegde vertegenwoordiger in de EU: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Duitsland

Norsk Produsert av: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japan

Importør: Panasonic Connect Europe GmbH

Autorisert representant i EU: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Tyskland

Polski Wyprodukowano przez: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japonia

Importer: Panasonic Connect Europe GmbH

Upoważniony przedstawiciel w UE: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Niemcy

Português Fabricado por: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japão

Importador: Panasonic Connect Europe GmbH

Representante Autorizado na UE: Panasonic Testing Centre

Winsbergring15,22525Hamburgo,Alemanha

Română Fabricat de: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japonia

Importator: Panasonic Connect Europe GmbH

Reprezentant autorizat în UE: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Germania

Slovenčina Výrobca: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japonsko

Dovozca: Panasonic Connect Europe GmbH

Autorizovaný zástupca v EÚ: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Nemecko

6 - ENGLISH

Slovenščina Proizvaja: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japonska

Uvoznik: Panasonic Connect Europe GmbH

Pooblaščeni zastopnik v EU: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Nemčija

Suomi Valmistaja: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japani

Maahantuoja: Panasonic Connect Europe GmbH

Valtuutettu edustaja EU:ssa: Panasonic Testing Centre

Winsbergring15,22525Hampuri,Saksa

Svenska Tillverkad av: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japan

Importör: Panasonic Connect Europe GmbH

Auktoriserad representant i EU: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Tyskland

Türkçe Tarafından Üretilmiştir: Panasonic Connect Co., Ltd.

4-1-62Minoshima,Hakata-ku,Fukuoka812-8531,Japonya

İthalatçı: Panasonic Connect Europe GmbH

AB Yetkili Temsilcisi: Panasonic Testing Centre

Winsbergring15,22525Hamburg,Almanya

ENGLISH - 7

Thefollowingaccessories(2xlter/bagged)areincluded.

Airlter(longerlterwith5rowsofintakevents)x1

Airlter(shorterlterwith3rowsofintakevents)x1

Attention

zDispose of the packaging materials properly after unpacking the product.

JNotes on replacing the lamp unit

•The light source lamp is a glass component. If it is hit on a hard object or dropped,

breakage may occur.

Be careful when handling a light source lamp.

•A Phillips screwdriver is necessary when carrying out replacement.

Holdthescrewdriverrmly.

•Grip the handle when you remove the lamp unit. Some parts of the lamp unit are

sharpened and may cause injury.

•Do not disassemble or modify the lamp unit.

•The lamp may be ruptured. Care should be taken not to scatter pieces of the broken

lamp glass when replacing the lamp unit. Pieces of the broken lamp may fall from the

lamp unit especially when the projector is mounted on the ceiling, so when replacing

the lamp unit do not stand directly underneath it or position your face close to it.

•Thelampcontainsmercury.Contactthelocalgovernmentofceordistributorforthe

correct disposal of the old lamp unit.

Attention

zWhen the projector is mounted on a ceiling, do not work with your face close to the

projector.

zAttach the lamp unit and the lamp cover securely.

zWhenyouexperiencedifcultyininstallingthelamp,removeitandtryagain.Ifyou

use force to install the lamp, the connector may be damaged.

zBesuretousethelampunitspecied.

zDo not loosen other than designated screws.

zPleasereplacetheairlterstogetherwhenreplacingthelampunit.

zAfter replacing the lamp unit, make sure to reset the usage time in the [Clear Lamp

Hours]menu.

Replacing the Lamp unit & Air lters

Accessories

8 - ENGLISH

J Replacement procedure

1) Turn off the Power and then remove the AC power plug from the wall outlet.

Wait at least 1 hour and make sure the lamp unit and surroundings are cool.

2) Use a Phillips screwdriver to loosen the Lamp cover screw (x1) and open the

lamp cover.

zOpen the lamp cover by pulling it slowly toward the direction of the arrow.

3) Use a Phillips screwdriver to loosen the lamp unit screws (x2) until the screws

turn freely. Pull up the handle, and pull it gently from the projector.

4) Insert the unused lamp unit in correct direction. Tighten the lamp unit screws

(x2) securely with a Phillips screwdriver.

5) Close the lamp cover, and tighten the lamp cover screw (x1) securely with a

Phillips screwdriver.

6) Clean up the dust on the left and right air vents.

7) Pull out the air lters straight and slowly with grabbing the knobs.

Lamp cover screw

Handle

Lamp unit screws

Lamp cover

Airlter(shorterlterwith3

rowsofintakevents)

Airlter(longerlterwith5

rowsofintakevents)

Protrusion

Knob

ENGLISH - 9

8) Install the unused air lters (Replacement air lters).

zHoldtheairlterswiththeprotrusionuptowardsthetoppanelasshowninthepictureand

insert them until you hear a "click" sound.

zMakesurethedirectionofltersareproperly.Failuretodosowillresultininstallation

failed.

9) Connect the power plug to the power outlet and then turn on the Power. Press

<MENU> button to display main menu.

10) Press ▲▼ to select [Options] and then press ► to display sub menu.

11) Press ▲▼ to select [Lamp Settings] and then press ► to display the setting

dialog box.

12) Press ▲▼ to select [Clear Lamp Hours] and then

press ► to display adjusting

box.

13) Press

▲▼

to select [Yes] and then press ►.

zThe lamp usage time is reset.

14) Press <MENU> button to return to sub menu.

15) Press ▲▼ to select

[Dust Filter Reminder]

and then

press ► to display the

setting dialog box.

16) Press ▲▼ to select

[Cleaning up Reminder]

and then

press ► to display the

adjusting dialog box.

17) Press

▲▼

to select [Yes] and then press ►.

zTheairlterusagetimeisreset.

Attention

zAfterreplacingtheairlters,makesuretoresettheusagetimeinthe[Cleaningup

Reminder]menu.

zTheairltersmustalwaysbeinstalledintheprojector.Failuretodosowillresultin

malfunctions due to foreign materials, such as dust, entering the projector.

CO0713JG2062 -PT

Printed in China

Disposal of Old Equipment

Only for European Union and countries with recycling systems

Thissymbolontheproducts,packaging,and/oraccompanyingdocuments

means that used electrical and electronic products must not be mixed with

general household waste.

For proper treatment, recovery and recycling of old products, please take them

to applicable collection points in accordance with your national legislation.

By disposing of them correctly, you will help to save valuable resources and

prevent any potential negative effects on human health and the environment.

For more information about collection and recycling, please contact your local

authority.

Penalties may be applicable for incorrect disposal of this waste, in accordance

with national legislation.

Product information (for Turkey only)

AEEEYönetmeliğineUygundur

WebSite:https://panasonic.net/cns/projector/

©PanasonicConnectCo.,Ltd.2022

Panasonic Connect Co., Ltd.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Accessoires pour projecteur

Panasonic

Panasonic ET-D3LEW60C Manuel utilisateur

Panasonic

Panasonic ET-LAD40 Mode d’emploi

Panasonic

Panasonic ET-LAV200 Manuel utilisateur

Panasonic

Panasonic ET-SFD320C Manuel utilisateur

Panasonic

Panasonic ET-DLE020 Manuel utilisateur

Panasonic

Panasonic ET-DLE050 Manuel du système

Panasonic

Panasonic ET-D3QW200 Manuel utilisateur

Panasonic

Panasonic ET-LAD60A Manuel utilisateur

Panasonic

Panasonic PressIT TY-WP2B1W Mode d'emploi

Panasonic

Panasonic ET-LAL500 Manuel utilisateur

Panasonic

Panasonic ET-LAEF100C Manuel utilisateur

Panasonic

Panasonic ET-PFD465 Manuel utilisateur

Panasonic

Panasonic ET-D75LE8 Manuel du système

Panasonic

Panasonic ET-LAD510 Manuel utilisateur

Panasonic

Panasonic ET-LAD10000 Manuel utilisateur

Panasonic

Panasonic ET-LAD57 Mode d’emploi

Panasonic

Panasonic ET-LAB50 Mode d’emploi

Panasonic

Panasonic ET-D75MRS10 Manuel utilisateur

Panasonic

Panasonic ET-LAE200 Manuel utilisateur

Panasonic

Panasonic PressIT TY-WPS1W Mode d'emploi

Panasonic

Panasonic ET-LAC100 Manuel utilisateur

Panasonic

Panasonic ET-LAV100 Manuel utilisateur

Panasonic

Panasonic TY-FB10WPE Manuel utilisateur

Panasonic

Panasonic ET-EMF320 Manuel utilisateur

Manuels Accessoires pour projecteur populaires d'autres marques

Optoma

Optoma BX-AL133B Manuel utilisateur

PEERLESS

PEERLESS PE 1120 Mode d’emploi

Osram

Osram SIRIUS HRI Series Manuel

Presentation Switchers

Presentation Switchers PS111 Manuel utilisateur

Kramer

Kramer VIA GO Manuel utilisateur

Yamaha

Yamaha PJL-112 Manuel de la liste des pièces

Swedstyle

Swedstyle CL23AA02ZA25E Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric 236CB Manuel du propriétaire

Epson

Epson BrightLink 475Wi Manuel utilisateur

Acer

Acer WP100 Manuel utilisateur

i3 i3board Manuel utilisateur

CHIEF

CHIEF HB-43E Manuel utilisateur

Biamp

Biamp Modena Hub Manuel de service

NEC

NEC MP10RX Manuel utilisateur

Panamorph

Panamorph DCR-S3 Manuel utilisateur

Exact solutions

Exact solutions FRAME-EVO-P10 Manuel utilisateur

CHIEF

CHIEF VCM103S Manuel utilisateur

InFocus

InFocus LP70+ Mode d’emploi
