Operating Instructions

(Household) Sonic Vibration Toothbrush

Model No. EW‑DE92

Thank you for purchasing this Panasonic product.

Before operating this unit, please read these instructions completely and save them for future use.

Safety precautions..................3

Parts identication ..........................6

Storing and charging the toothbrush

...........................................................7

Before cleaning your teeth .............8

Using the toothbrush ....................10

Tips on usage ................................11

How to clean ..................................13

Frequently Asked Questions

(Ion lamp) .......................................14

Troubleshooting ............................15

Battery life ......................................17

Removing the built-in rechargeable

battery

.............................................17

Specications ................................17

Changing the brush head

(Sold separately)............................18

Contents

EW-DE92_US.indb 1 2013/12/27 10:48:34

IMPORTANT SAFEGUARDS

When using electrical products when children are

present, basic safety precautions should always

be followed including the following:

READ ALL INSTRUCTIONS BEFORE USING

DANGER

In order to reduce the risk of electrocution:

1. Do not place or store the charger where it can

fall or be pulled into a tub or sink.

Do not place the charger in water or other liquid.

3. Do not reach for a charger that has fallen into

water. Unplug immediately.

4. Do not wash the charger.

5. Do not use while bathing.

WARNING

To reduce the risk of burns, electrocution, ﬁre

or injury to persons:

1. This appliance is not intended for use by

children or persons with reduced physical or

mental capabilities, unless they are supervised

by a person responsible for their safety.

Use this product only for its intended use as

described in this manual. Do not use attachments

not recommended by the manufacturer.

3. Keep cord away from heated surfaces.

4. Never drop the appliance or insert any object

into any opening of the appliance.

5. Never operate this product if it has been

dropped or damaged, or if it is not working

properly. If any of these occur, please contact a

service center and return the product for

examination and repair.

6. If the product is dropped, the brush head

should be replaced before the next use even if

no damage is visible.

7. This appliance is provided with a charger with

integrated Safety Extra Low Voltage power

supply. Periodically check the charger for

damage. A damaged or non‑functioning

appliance should no longer be used. Take it to a

service center.

8. Never use while drowsy.

9. Do not use outdoors or operate where aerosol

(spray) products are being used or where

oxygen is being administered.

IMPORTANT

1. Do not touch the power plug with wet hands.

This can cause an electric shock.

2. When unplugging, always hold the power plug

instead of the cord.

EW-DE92_US.indb 2 2013/12/27 10:48:34

3. Do not modify the product. Do not disassemble

or repair. This may cause ﬁre, electric shock or

injury. Consult your dealer for repairs or contact

a service center. Do not disassemble the

product except when disposing of the battery.

4. When taking out the battery for disposal, use

caution not to short the positive (+) and

negative (–) terminals.

5. This product is not intended for use by children.

CAUTION

If you are undergoing treatment for any oral care

condition, consult your dental professional prior to use.

SAVE THESE INSTRUCTIONS

Safety precautions

To reduce the risk of injury, loss of life, electric shock, ﬁre,

malfunction, and damage to equipment or property, always

observe the following safety precautions.

Explanation of symbols

The following symbols are used to classify and describe the level

of hazard, injury, and property damage caused when the

denotation is disregarded and improper use is performed.

DANGER Denotes a potential

hazard that will result in

serious injury or death.

WARNING Denotes a potential

hazard that could result

in serious injury or death.

CAUTION

Denotes a hazard that

could result in minor injury.

The following symbols are used to classify and describe the type

of instructions to be observed.

This symbol is used to alert users to a speciﬁc operating

procedure that must not be performed.

This symbol is used to alert users to a speciﬁc operating

procedure that must be followed in order to operate the

unit safely.

EW-DE92_US.indb 3 2013/12/27 10:48:34

DANGER

To prevent the potential risk of interference, do not

use this toothbrush near the vicinity of electronic

medical devices or home electrical therapy devices

such as the following:

•Pacemakers and other electronic medical devices

implanted in the body

•Heart-lung machines and other life-supporting

electronic medical devices

•Wearable electronic medical devices, such as

electrocardiographs and intravenous drip equipment

This product has a built-in rechargeable battery. To

prevent the risk of overheating, ignition or explosion,

do not throw into ﬁre, apply heat, or charge, use, or

leave in a high temperature environment.

WARNING

To prevent the risk of personal injury, electric shock

or ﬁre, immediately stop use and unplug the charger

from the wall outlet if you observe some abnormality

in the product. Have the product inspected by an

authorized service center if the toothbrush or

charger is deformed of abnormally hot, there is

smell of burning or abnormal sound.

To prevent the risk of electric shock or ﬁre, fully

insert the power plug.

To prevent the risk of ﬁre due to insulation failure

by humidity, clean the power plug once every six

months. Disconnect the power plug and wipe dust

off with a dry cloth.

To prevent the risk of accident or injury due to

accidental ingestion of removable parts, do not

store within the reach of children or infants. Do not

let them use it.

This toothbrush releases minute amount of weak

current. To prevent accidents or cause them to feel

unwell, do not use during pregnancy and within one

month after giving birth.

To prevent risk of electric shock or ﬁre, do not

damage, modify, forcefully bend, pull, twist, or bundle

cord. Do not wrap the cord around the charger when

storing.

To prevent the risk of burns or ﬁre, use the supplied

charger only and do not charge any other product

with the supplied charger.

CAUTION

To prevent the risk of injury or damage to teeth and

gum, do not use this toothbrush if you have severe

gum disease, have teeth being treated, or are

concerned about symptoms in your mouth. Consult

a dentist before using this toothbrush.

EW-DE92_US.indb 4 2013/12/27 10:48:34

CAUTION

To prevent the risk of injury or damage to teeth and

gum, do not use toothpaste that contains a high

abrasive content, such as toothpaste for removing tar

or for whitening. Do not apply the brush head strongly

against teeth or gums, or use it continuously on same

spot. Do not apply the plastic part of the main unit or

brush head to teeth.

To prevent risk of burns, do not place a metallic

object such as a coin or a clip on top of the charger.

►Notes

When you ﬁrst begin using the toothbrush, you may experience slight

bleeding of the gums even though your gums may be healthy. This is

because your gums are receiving stimulation by the toothbrush for

the ﬁrst time. The bleeding should stop after one or two weeks of use.

Bleeding that persists for more than two weeks may be indication of

an abnormal condition of your gums, such as pyorrhea. In this case,

stop using the toothbrush and consult your dentist.

EW-DE92_US.indb 5 2013/12/27 10:48:34

Parts identiﬁcation

   

 









































A Main unit

1 Ion panel

2 Toothbrush shaft

3 Waterproof rubber seal

4 Ion lamp

5 Power switch [0/1]

6 Mode selector

7 Mode indicator

8 Charge status lamp ( )

9 Battery capacity lamp ( )

B Ionic stain care brush

 Tongue cleaner

 Identiﬁcation ring

 Extra ﬁne side bristles

 High‑density bristles

 Brush head electrode section

C Ionic two-way silicone brush

D Point brush

E Charger (RE8-52)

 Cord

 Power plug

 Charger base

 Charging section

 Main unit guide

 Brush head storage

Accessories

F Brush stand

G Travel case

Characteristics of brush bristles ()

The bristles in the center (high‑density bristles) are arranged in a diamond shape, which is designed for stain care.

EW-DE92_US.indb 6 2013/12/27 10:48:34

Storing and charging the toothbrush

•If the toothbrush stops operating when ﬁrst using it (immediately

after purchasing it, or after not using it for 3 months or more) or

during use, charge the main unit.

•Adequate ambient temperature for charging is 5 °C – 35 °C

(41 °F – 95 °F).

The battery may not charge properly or not at all under extreme

low or high temperatures.

•You can keep the main unit attached on the charger when not in

use to maintain the full battery capacity. It will not overcharge the

main unit.

•The main unit may become warm during use and charging.

However, this is normal.

1Place the charger on a stable

horizontal surface such as

countertop.

2Align the main unit so it is

facing forward, and set it

straight into the charging

section.

3Insert the power plug into the

household outlet.

•The charge status lamp glows and

the charging will start.

•Charging cannot start when the main

unit is tilted or the bottom of the main

unit is not in contact with the charging

section.

If not charging constantly

•You can fully charge the toothbrush in approx. 17 hours.

The charging time may decrease depending on the charging

capacity.

•

A full charge will supply enough power for approx. 90 minutes use.

•

Disconnect the power plug when the charge status lamp turns off.

►About storage

Use the main unit guide to store the main unit and the brush head.

Slide and remove the main unit guide, and

place it on horizontal and stable place.

2. Store the main unit and the brush head.

EW-DE92_US.indb 7 2013/12/27 10:48:34

About the lamp

When the battery

capacity is low While charging After charging is

completed

The battery

capacity lamp

blinks.

The charge status

lamp glows. The charge status

lamp turns off

•The toothbrush may not charge even if the charge status lamp

turns on when a charger other than the supplied charger is used.

Before cleaning your teeth

The brush head of this sonic vibration toothbrush vibrates at a

high speed.

Therefore:

•You only need to lightly press the bristles against your teeth for

brushing.

•When ﬁrst using this appliance, some may experience a tickling

or tingling sensation caused by the high‑speed vibrations. The

sensation should subside after you use the toothbrush several

more times.

•When in use, the main unit of this toothbrush emits a very weak

electric current (ionic current) in the oral cavity.

•Touching the ion panel with your hand when you hold the main

unit to brush your teeth causes a very weak electric current (ionic

current) to ﬂow between your teeth and the brush head.









a Brush head (negative

electrode)

b Ion panel (positive

electrode)

c Very weak electric current

d Mechanism that generates

very weak electric current

•The ion lamp on the mechanism that generates the very weak

electric current (see ﬁgure above) turns on or blinks to indicate

whether ionic power is being applied to the teeth.

EW-DE92_US.indb 8 2013/12/27 10:48:34

•You can easily see the lamp status if you use a mirror while

brushing.

•Ionic power is not employed with the point brush. (The ion lamp

blinks.)

Pressing the power switch

Putting the brush in your mouth

Activates the mechanism that

generates the very weak

electric current, and the ion

lamp blinks on and off.

Passes a very weak electric

current in the oral cavity, ionic

power is activated and the ion

lamp turns on.

Notes

•Recommended ambient temperature for using is 5 °C – 35 °C

(41 °F – 95 °F).

•Do not allow hair products (e.g., gel or oil) or hand lotion to come

in contact with the unit as they may damage its surface.

•Do not forcefully turn the brush head with the brush head

attached to the main unit. Doing so may cause the brush head or

main unit to become damaged.

►About uses and operating modes

Brush head Use Mode Description

Brushing

(dental

plaque

removal)

WHITE

•Recommended for

removing plaque and

stain care with normal

tooth brushing

SOFT

•Recommended when

you feel the WHITE

mode is too powerful

•Recommended for

tongue cleaning

SENSITIVE

•

Recommended for

brushing carefully

between the teeth and

gums

Gum care GUM CARE •Uses rhythmical

vibrations to care for

your gums.

Point

brushing

WHITE

•Recommended for

removing dental plaque

from between teeth and

areas where teeth are

misaligned

SOFT •Recommended when

you feel the WHITE

mode is too powerful

SENSITIVE

•Particularly

recommended when

brushing to care for

areas between teeth

•Stains refer to discoloration on the surface of the teeth due to

food and drink such as coffee, wine and tea.

EW-DE92_US.indb 9 2013/12/27 10:48:35

•

It is not possible to whiten the color of teeth beyond their original

color, yellowing teeth due to aging, or discolored teeth.

►About soft start function (For WHITE mode only)

The toothbrush will gradually reach the selected speed and

vibration approximately 2 seconds after it starts operating.

►About the 30-second brushing notiﬁcation timer function

The timer will signal once at 30‑second intervals to indicate the

brushing time for each part of your mouth. It will signal twice at

2‑minute intervals to indicate the recommended total brushing time.

It is important to brush each area in the same sequence and with

the same amount of time, every time you brush, to uniformly brush

and clean your teeth.

Use the 30‑second brushing notiﬁcation timer function wisely so

there will be no missed spot in your mouth.

•Divide your teeth into 4 parts (upper

and lower, left and right), and brush

one part in order such as “(1) front of

the teeth”, “(2) biting plane of the

teeth”, and “(3) back of the teeth”

spending 30 seconds at each part.

Brush the other parts in the same

manner, and brush your whole mouth

in about 2 minutes.

(1)(2)(3)

►About mode storage function

This function stores the previously selected mode of operation,

allowing the same mode to be used again.

Mode storage is reset if the unit has discharged and has been

unused for a long period of time, or if the battery has been

completely drained.

After charging, the product starts in WHITE mode, however this is

not a malfunction.

Using the toothbrush

•If dried toothpaste or water stains have adhered to the ion panel,

the very weak electric current may be unable to pass into the oral

cavity. Please clean the ion panel.

1Place the brush head ﬁrmly onto

the toothbrush shaft.

•As shown in the picture, align the front of

the electrode section of the ionic stain

care brush or silicone brush with the main

unit.

•Attaching or removing diagonally or while

twisting may cause the brush head or the

main unit to become damaged.

•The toothbrush shaft will move when a

force is applied. This is required for

operation, and is not a malfunction.

•There will be a small gap between the

brush head and the main unit.

2Grasp the main unit.

•The very weak electric current

may not pass into the oral

cavity if the toothbrush is held

in the same way as a pen so

that your hand does not touch

the ion panel.

Please grasp the main unit as

shown in the ﬁgure, so that

your hand comes in contact

with the ion panel.

EW-DE92_US.indb 10 2013/12/27 10:48:35

Autres manuels pour EW?DE92

Table des matières

Autres manuels Panasonic Brosse à dents électrique

Panasonic

Panasonic Sonic Vibration Toothbrush Manuel utilisateur

Panasonic

Panasonic ER-CTB1 Manuel utilisateur

Panasonic

Panasonic EW-DL75 Manuel utilisateur

Panasonic

Panasonic EW-DS32 Manuel utilisateur

Panasonic

Panasonic EW?DE92 Manuel utilisateur

Panasonic

Panasonic EW-DS13 Manuel utilisateur

Panasonic

Panasonic ER-CBL1 Manuel utilisateur

Panasonic

Panasonic EW-DS90 Manuel utilisateur

Panasonic

Panasonic EW-DL34 Manuel utilisateur

Panasonic

Panasonic EW?DE92 Manuel utilisateur

Panasonic

Panasonic EW-DC12 Manuel utilisateur

Panasonic

Panasonic EW-DL83 Manuel utilisateur

Panasonic

Panasonic EW-DC12 Manuel utilisateur

Panasonic

Panasonic EW-DL75 Manuel utilisateur

Panasonic

Panasonic EW1000W Operating Manuel utilisateur

Panasonic

Panasonic EW?DL82 Manuel utilisateur

Panasonic

Panasonic EW-TDEF4 Manuel utilisateur

Panasonic

Panasonic EW-PDA52 Manuel utilisateur

Panasonic

Panasonic EW-DC12 Manuel utilisateur

Panasonic

Panasonic EW-DL40 Manuel utilisateur

Panasonic

Panasonic EW-DS11 Manuel utilisateur

Panasonic

Panasonic EW-DS13 Manuel utilisateur

Panasonic

Panasonic EW-DS32 Manuel utilisateur

Panasonic

Panasonic EW-DL83 Manuel utilisateur

Manuels Brosse à dents électrique populaires d'autres marques

Omron

Omron Colgate ProClinical C600 Manuel utilisateur

Philips

Philips sonicare 3000 Series Manuel utilisateur

Philips

Philips Sonicare Airfloss HX8181 Manuel utilisateur

Dentle

Dentle One Plus Manuel utilisateur

Philips

Philips Sonicare HX6211/04 Manuel utilisateur

SPORT ELEC

SPORT ELEC Smilyss HC5305C Manuel utilisateur

Philips

Philips Sonicare 1000 Series Manuel utilisateur

Philips

Philips ESSENCE + Manuel utilisateur

Kompernass

Kompernass dentalux DAZ 2.4 A1 Manuel utilisateur

ONE

ONE PERSONAL OSEB001-W Manuel utilisateur

Philips

Philips Sonicare FlexCare+ HX6972 Manuel utilisateur

Jula

Jula 804-193 Manuel utilisateur

Braun

Braun OC17525 Manuel utilisateur

Philips

Philips HX6932/34 Manuel utilisateur

Waterpik

Waterpik Sensonic Professional Plus SR-3000 Manuel utilisateur

TrueLife

TrueLife SonicBrush T100 Manuel utilisateur

Braun

Braun Oral-B 450 Manuel utilisateur

Braun

Braun Oral-B Professional Care 7000 Manuel utilisateur
