Panasonic BL-WV10A Manuel utilisateur

This guide will help you install and configure the BL-WV10A Wireless Camera

Monitoring System and your Network Cameras (sold separately).

Included Items

Confirm that the following items are included in the product box.

Additional pieces can be ordered by calling 1-800-332-5368.

BL-WV10A AC adaptor AC cord Ethernet cable

Part no.

PQLV202Y

Cord length: 3 m

(10 ft.)

Part no.

PSJA1069Z

Length: 1.8 m

(5 ft. 11 in.)

Part no.

PQJA10138Z

(Cat. 5 straight

cable)

Length: 1 m

(3 ft. 3 in.)

Video cable Stand Remote control Batteries (2 AA

size)

Part no.

PSJP01R02Z

Length: 1.5 m

(5 ft.)

Part no.

PSYLWV10N

Part no.

PSWEWV10A

Part no.

R6DW/2ST

• Setup Guide (this manual)

• Operating Instructions

•Warranty

Setup Guide

Wireless Camera

Monitoring System

Model No.

BL-WV10A

IMPORTANT SAFETY INSTRUCTIONS

When using this product, basic safety precautions should always be followed to

reduce the risk of fire, electric shock, or personal injury.

1. Read and understand all instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not install this product near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that produce heat.

6. Protect the AC adaptor cord and AC cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where they exit

from this product.

7. The AC cord is used as the main disconnect device. Ensure that the AC outlet

is located/installed near the product and is easily accessible.

8. Use only the included Panasonic AC adaptor and AC cord.

9. The AC adaptor must remain connected at all times. (It is normal for the

adaptor to feel warm during use.)

10. To prevent the risk of fire or electrical shock, do not expose this product to rain

or any type of moisture.

11. Do not touch the product or the AC adaptor and AC cord during lightning

storms.

12. Unplug this product when unused for a long period of time.

13. Refer all servicing to qualified service personnel. Servicing is required when

the unit has been damaged in any way, such as when the AC adaptor, AC cord

or plug is damaged, the unit does not operate normally, or after the unit has

been dropped.

14. Certain Network Cameras are intended for indoor use only. Never use an

indoor camera outdoors.

15. Unplug this unit from power outlets if it emits smoke, an abnormal smell or

makes unusual noise. These conditions can cause fire or electric shock.

Confirm that smoke has stopped and contact an authorized service center.

SAVE THESE INSTRUCTIONS

Notice Regarding Battery Safety

1. Do not open or mutilate the batteries. Released electrolyte from the batteries

is corrosive and may cause burns or injury to the eyes or skin. The electrolyte

may be toxic if swallowed. If electrolyte comes in contact with the eyes, flush

eyes with water.

2. Do not mix old and new batteries.

3. Do not heat or expose to flame.

4. Do not take apart or short circuit.

5. Do not attempt to recharge alkaline or manganese batteries.

6. Remove if the remote control is not going to be used for a period of time. Store

in a cool, dark place.

7. Use only non-rechargeable AA batteries. When replacing the batteries, we

recommend using the same type of Panasonic batteries that are included with

this product.

Notice Regarding Wireless Communications

1. To avoid wireless communication interference and instability, do not use this

product near the following devices.

• Wireless transmitters (radio transmitters, cellular transmitters, etc.)

• Wireless devices which operate at 2.4 GHz (security equipment, POS

systems, cordless telephones, etc.)

•Microwaveovens

2. Wireless communication range and quality may be affected if the following

types of objects are located between or near this product and other wireless

devices connected to this product. In the event that images do not refresh at

a regular rate, become cut off, etc., relocate this product, the other wireless

devices, or the obstacles (if possible) for more stable wireless

communications.

• Metal door shutters

• Walls made of concrete, stone, or brick, or walls which contain aluminium-

based heat insulation

• Multiple walls

• Fire doors and glass

• Steel racks or shelves

3. Place cameras and this product at least 2 m (6.5 ft.) away from radios. Do not

connect cameras and this product to a power outlet used by a radio.

Recommended Accessories (sold separately)

Compatible router:

• Panasonic BB-HGW700A Network Camera Management System

Compatible Network Cameras:

• Panasonic BL-C10A, BL-C30A (firmware version 1.22 or higher)

• HCM series (firmware version 1.08 or higher, however, some features

cannot be used; see “Camera Compatibility” on page 4 of the Operating

Instructions for more information on compatibility).

• Note that the following HCM series cameras are not supported by the BL-

WV10A:

-KX-HCM8

-KX-HCM10

-KX-HCM230

-KX-HCM250

-KX-HCM270

-KX-HCM280

For the latest firmware, visit http://panasonic.co.jp/pcc/products/en/netwkcam/

Setup Overview

1. Insert the batteries in the remote control.

2. Connect the BL-WV10A to the power outlet and to the TV.

3. Use the BL-WV10A's Basic Setup utility to configure the BL-WV10A.

4. Connect the cameras (and an optional BB-HGW700A Network Camera

Management System, if you are using one).

5. Use the BL-WV10A's Quick Setup utility to configure the cameras.

6. Confirm that camera images are viewable on the TV.

7. Place the cameras where you plan to use them.

Preparing the Remote Control

The remote control included with the BL-WV10A is required for most operations.

Insert the included batteries as shown below.

Using the Remote Control

The remote control’s navigator

keys are used to navigate

through the BL-WV10A’s on-

screen menus and to select on-

screen items. The [RETURN]

button is used to return to the

previous menu. The [ENTER]

button is used to select a menu

item or parameter.

When using the remote control

with the BL-WV10A, make sure

you aim the remote control

toward the unit’s remote control

sensor.

Insert the batteries,

positioning the and

poles as indicated.

While pulling the cover

toward you, lift it up.

Align the cover and

press down until it

snaps into place.

[RETURN]

Navigator

keys

[ENTER]

Remote control sensor

Connecting the BL-WV10A

There are 3 ways to connect your cameras to the BL-WV10A. Determine which

method you will use, and refer to the pages listed below.

Connecting cameras directly to the BL-WV10A

To connect cameras directly to the BL-WV10A, see page 8.

Connecting cameras using an optional BB-HGW700A Camera Control Unit

To connect a BB-HGW700A, see page 12.

Note

Only 1 BB-HGW700A can be connected to the BL-WV10A wirelessly.

BL-WV10A

Internet

BB-HGW700A

BL-WV10A

Connecting cameras using a router

To connect to a router, see “Connecting Cameras Using a Router” on page 42 of

the Operating Instructions.

Note

• The only wireless router that can be used with the BL-WV10A is the

Panasonic BB-HGW700A. All other routers will require a wired

connection.

Internet

Router

BL-WV10A

Using the BL-WV10A Only

1. Connect the BL-WV10A to your TV using the included video cable.

2. Turn the TV on and set the TV's input switch to the external video input

("VIDEO", "EXT", "INPUT 1", etc.)

3. Set the mode switch on the rear of the BL-WV10A to [SETUP].

4. Connect the DC cord to the AC adaptor and to the power outlet.

5. Turn on the BL-WV10A by connecting the DC cord to the unit.

• The startup screen appears on the TV screen.

6. Use an Ethernet cable to connect the camera to one of the LAN jacks on the

BL-WV10A.

• If connecting a BL-C30A, set the camera's mode switch to [WIRED].

7. Connect the camera to the power outlet.

Rear panel

of BL-

WV10A

To T V

Video cable

(included)

AC adaptor

(included)

AC cord

(included)

DC plug

Ethernet cable

(included)

Rear panel

of camera

LAN jacks

DC IN jack

Video input terminal

Bottom of

BL-C30A

Basic Setup (Using the BL-WV10A Only)

After the BL-WV10A starts up for the first time, the [Basic Setup] screen is

displayed. For most installations, these parameters do not need to be changed. For

information regarding Basic Setup settings, see “Setting the User Name and

Password” on page 34 of the Operating Instructions.

1. Use the navigator keys to select [Finished], then press [ENTER].

2. When the dialog is displayed, select [Yes] then press [ENTER] to start Quick

Setup.

• The BL-WV10A restarts.

Quick Setup (Using the BL-WV10A Only)

To use the BL-WV10A with your cameras, you will need to configure the BL-

WV10A and your cameras. The BL-WV10A's Quick Setup utility can help you

configure the devices easily.

1. After the unit restarts, wait while the Quick Setup utility scans for network and

wireless settings.

• When the BL-WV10A has been configured, "Finished" is displayed and

the buzzer sounds.

• With this connection setup, it is normal for no router or wireless router to

be found.

2. Wait while the Quick Setup utility restarts the camera, then configures and

registers the camera.

• When the camera has been configured and registered, "Finished" is

displayed next to the camera name ("CAM1") and the buzzer sounds.
