Before use, please read these instructions completely.

Please also refer to Operating

Instructions (PDF format)

recorded on the CD-ROM

containing the Operating Instructions

(supplied).

You can learn about advanced operation methods

and check the Troubleshooting.

GN VQT2F49

Basic

Operating Instructions

Digital Camera

Model No. DMC-ZR1

until

2009/8/3

DMC-ZR1GN-VQT2F49_eng.book 1 ページ２００９年７月２２日　水曜日　午前１１時７分

VQT2F49 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic Digital

Camera. Please read these Operating Instructions carefully and keep them handy for

future reference. Please note that the actual controls and components, menu items, etc. of

your Digital Camera may look somewhat different from those shown in the illustrations in

these Operating Instructions.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast material for purposes

other than your own private use may infringe copyright laws. Even for the purpose of private

use, recording of certain material may be restricted.

Information for Your Safety

IF THE POWER CORD OF THIS EQUIPMENT IS DAMAGED, IT MUST BE REPLACED

WITH AN ELECTRICALLY APPROVED POWER CORD.

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long period of

time with doors and windows closed.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE,

•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR

SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,

SHALL BE PLACED ON THE APPARATUS.

•USE ONLY THE RECOMMENDED ACCESSORIES.

•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE EQUIPMENT AND

SHALL BE EASILY ACCESSIBLE.

Product Identification Marking is located on the bottom of units.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the manufacturer. Dispose of used batteries

according to the manufacturer’s instructions.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC or incinerate.

DMC-ZR1GN-VQT2F49_eng.book 2 ページ２００９年７月１５日　水曜日　午後３時３３分

(ENG) VQT2F49

∫About the battery charger

•The battery charger is in the standby condition when the AC power supply cord is connected.

The primary circuit is always “live” as long as the power cord is connected to an electrical

outlet.

∫Cautions for Use

•Always use a genuine Panasonic AC adaptor (DMW-AC5G; optional).

•When using an AC adaptor, use the AC cable supplied with the AC adaptor.

•Do not use any other AV cables except the supplied one.

•Do not use any other cables except a genuine Panasonic component cable (DMW-HDC2;

optional).

•Do not use any other USB connection cables except the supplied one.

In the event of abnormal operation (e.g. if the unit emits smoke or an unusual smell),

immediately stop operating the unit and consult the Panasonic Customer Care Centre on

132600.

Keep the camera as far away as possible from electromagnetic equipment (such as

microwave ovens, TVs, video games etc.).

•If you use the camera on top of or near a TV, the pictures and sound on the camera may be

disrupted by electromagnetic wave radiation.

•Do not use the camera near cell phones because doing so may result in noise adversely

affecting the pictures and sound.

•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields

created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely affect the

camera, disturbing the pictures and sound.

•If the camera is adversely affected by electromagnetic equipment and stops functioning

properly, turn the camera off and remove the battery or disconnect AC adaptor (DMW-AC5G;

optional). Then reinsert the battery or reconnect AC adaptor and turn the camera on.

Do not use the camera near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures and sound may

be adversely affected.

CAUTION!

•DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN CABINET OR IN

ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO PREVENT

RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT

CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION

VENTS.

•DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH NEWSPAPERS,

TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.

•DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED CANDLES, ON

THE UNIT.

•DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY MANNER.

DMC-ZR1GN-VQT2F49_eng.book 3 ページ２００９年７月１５日　水曜日　午後３時３３分

VQT2F49 (ENG)

∫Care of the camera

•Do not touch the lens or the sockets with dirty hands. Also, be careful not to allow

liquids, sand and other foreign matter to get into the space around the lens, buttons etc.

•Do not touch the lens barrier A. (Doing so may damage the

camera. Be careful when taking the camera out of a bag etc.)

•If the lens gets dirty, turn on the power and deploy the lens

barrel. Then hold the lens barrel between your fingers and

lightly wipe the lens surface with a soft dry cloth. (If you leave

fingerprints on or otherwise dirty the lens, the pictures you

take may look whiter than normal.)

(B: Camera ON/OFF switch)

•Do not leave the camera with the lens facing the sun.

•Do not strongly shake or bump the camera by dropping or

hitting it. Do not subject to strong pressure.

The camera may malfunction, recording pictures may become

impossible, or the lens, the LCD monitor or the external case may be damaged.

•We strongly recommend you do not leave the camera in your trousers pocket when you sit

down or forcefully insert it into a full or tight bag etc.

Damage to the LCD monitor or personal injury may result.

•Do not attach any other items to the hand strap that’s included with your camera. While being

stored, that item can rest against the LCD monitor and damage it.

•Be particularly careful in the following places as they may cause this unit to

malfunction.

–Places with a lot of sand or dust.

–Places where water can come into contact with this unit such as when using it on a rainy day

or on a beach.

•This camera is not waterproof. If water or seawater splashes on the camera, use a dry

cloth to wipe the camera body carefully.

If the unit does not operate normally, please contact the dealer where you purchased the

camera or the repair service centre.

∫About Condensation (When the lens is fogged up)

•Condensation occurs when the ambient temperature or humidity changes. Be careful of

condensation since it causes lens stains, fungus and camera malfunction.

•If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will

disappear naturally when the temperature of the camera becomes close to the ambient

temperature.

DMC-ZR1GN-VQT2F49_eng.book 4 ページ２００９年７月１５日　水曜日　午後３時３３分

(ENG) VQT2F49

∫About cards that can be used in this unit

You can use an SD Memory Card and SDHC Memory Card.

•When the term card is used in these operating instructions this refers to the following types of

Memory Cards.

–SD Memory Card (8 MB to 2 GB)

–SDHC Memory Card (4 GB to 32 GB)

More specific information about memory cards that can be used with this unit.

•You can only use an SDHC Memory Card if using cards with 4 GB or

more capacity.

•A 4 GB (or more) Memory Card without an SDHC logo is not based on

the SD Standard and will not work in this product.

Please confirm the latest information on the following website.

http://panasonic.jp/support/global/cs/dsc/

(This Site is English only.)

•Keep the Memory Card out of reach of children to prevent swallowing.

DMC-ZR1GN-VQT2F49_eng.book 5 ページ２００９年７月１５日　水曜日　午後３時３３分

VQT2F49 (ENG)

-If you see this symbol-

Information on Disposal in other Countries outside the European Union

This symbol is only valid in the European

Union.

If you wish to discard this product, please

contact your local authorities or dealer and

ask for the correct method of disposal.

DMC-ZR1GN-VQT2F49_eng.book 6 ページ２００９年７月１５日　水曜日　午後３時３３分

(ENG) VQT2F49

Contents

Information for Your Safety................................................................................................. 2

Before Use

Standard Accessories ......................................................................................................... 8

Names of the Components ................................................................................................. 9

Preparation

Charging the Battery ......................................................................................................... 11

Inserting and Removing the Card (optional)/the Battery................................................... 13

Setting Date/Time (Clock Set) .......................................................................................... 14

• Changing the clock setting.......................................................................................... 14

Setting the Menu............................................................................................................... 15

• Setting menu items ..................................................................................................... 15

Selecting the [REC] Mode ................................................................................................ 17

Basic

Taking pictures using the automatic function

(ñ:Intelligent Auto Mode)................................................................................................ 18

• Scene detection .......................................................................................................... 19

• AF Tracking Function.................................................................................................. 19

Taking pictures with your favourite settings

(·: Normal Picture Mode)............................................................................................... 20

• Focusing .....................................................................................................................20

Playing back Pictures ([NORMAL PLAY]) ........................................................................ 21

Deleting Pictures...............................................................................................................22

• To delete a single picture............................................................................................ 22

• To delete multiple pictures (up to 50) or all the pictures ............................................. 22

Others

Reading the Operating Instructions (PDF format) ............................................................ 23

Specifications.................................................................................................................... 24

DMC-ZR1GN-VQT2F49_eng.book 7 ページ２００９年７月１５日　水曜日　午後３時３３分

VQT2F49 (ENG)

Before Use

Standard Accessories

Check that all the accessories are included before using the camera.

Product numbers correct as of July 2009. These may be subject to change.

1 Battery Pack

(Indicated as battery pack or battery in

the text)

Charge the battery before use.

2 Battery Charger

(Indicated as battery charger or

charger in the text)

3 AC Cable

4 USB Connection Cable

5AVCable

6 CD-ROM

•Software:

Use it to install the software to your PC.

7 CD-ROM

•Operating Instructions

8 Hand Strap

9 Battery Case

•SD Memory Card and SDHC Memory Card

are indicated as card in the text.

•The card is optional.

You can record or play back pictures on the

built-in memory when you are not using a

card.

•Consult the dealer or your nearest Service

Centre if you lose the supplied accessories.

(You can purchase the accessories

separately.)

DMW-BCG10E

K1HA08CD0020

K2CJ29A00002

VFC4297

DE-A66A

K1HA08AD0003

VFF0525

VGQ0E45

DMC-ZR1GN-VQT2F49_eng.book 8 ページ２００９年７月１５日　水曜日　午後３時３３分

(ENG) VQT2F49

Before Use

Names of the Components

1Flash

2Lens

3 Self-timer indicator

AF assist lamp

4 LCD monitor

5 Status indicator

6 [MENU/SET] button

7 [DISPLAY] button

8 [Q.MENU]/Delete button

9 [REC]/[PLAYBACK] selector switch

10 [E.ZOOM] button

11 Cursor buttons

A:3/Exposure compensation/Auto

Bracket/White balance fine

adjustment

B:4/Macro Mode

AF Tracking

C:2/Self-timer button

D:1/Flash setting button

In these operating instructions, the cursor buttons are described as shown in the

figure below or described with 3/4/2/1.

e.g.: When you press the 4(down) button

or Press 4

123

5786

DMC-ZR1GN-VQT2F49_eng.book 9 ページ２００９年７月１５日　水曜日　午後３時３３分

VQT2F49 (ENG)

Before Use

12 Camera ON/OFF switch

13 Zoom lever

14 Speaker

15 Microphone

16 Shutter button

17 Mode dial

18 Hand strap eyelet

•Be sure to attach the hand strap when

using the camera to ensure that you will

not drop it.

19 Lens barrel

20 [COMPONENT OUT] socket

21 [AV OUT/DIGITAL] socket

22 Tripod receptacle

•When you use a tripod, make sure the

tripod is stable when the camera is

attached to it.

23 Card/Battery door

24 Release lever

25 DC coupler cover

•When using an AC adaptor, ensure that

the Panasonic DC coupler (DMW-DCC5;

optional) and AC adaptor (DMW-AC5G;

optional) are used.

•We recommend you use a battery with

sufficient battery power or the AC adaptor

when recording motion pictures.

•If while recording motion pictures using the

AC adaptor the power supply is cut off due

to a power cut or if the AC adaptor is

disconnected etc., the motion picture being

recorded will not be recorded.

14 15 16

12 13





22 23

2425

DMC-ZR1GN-VQT2F49_eng.book 10 ページ２００９年７月１５日　水曜日　午後３時３３分

Autres manuels pour Lumix DMC-ZR1

Table des matières

Autres manuels Panasonic Appareil photo numérique

Panasonic

Panasonic LUMIX DMC-FZ1000P Manuel utilisateur

Panasonic

Panasonic DMC-FS42 Lumix Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FZ2 Manuel utilisateur

Panasonic

Panasonic DMC-ZS25K Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix DMC-LC1PP Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FH4PC Manuel utilisateur

Panasonic

Panasonic DMC-FH7K Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix DMC-GF3KPP Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FZ1000 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FZ300 Manuel utilisateur

Panasonic

Panasonic Lumix DC-ZS80D Manuel utilisateur

Panasonic

Panasonic Lumix VQT2F10 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-ZS19 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FH25 Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix DMC-FZ150 Instructions d'installation et d'entretien

Panasonic

Panasonic DMC-F7A Manuel utilisateur

Panasonic

Panasonic Lumix DMC-SZ7P Manuel utilisateur

Panasonic

Panasonic Lumix DMC-SZ10 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-GX1K Instructions d'installation et d'entretien

Panasonic

Panasonic LUMIX DMC-TZ7 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FZ8 Manuel utilisateur

Panasonic

Panasonic LUMIX DC-G95D Manuel utilisateur

Panasonic

Panasonic LUMIX DC-G9M Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-LC1GN Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
