SQT0627

M0115KZ0

Basic Operating Instructions

Digital Camera

Model No. DMC-TZ70

Please read these instructions carefully before using this product, and

save this manual for future use.

More detailed instructions on the operation of this camera

are contained in “Operating Instructions for advanced

features (PDF format)” in the supplied CD-ROM.

2 SQT0627 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic

Digital Camera. Please read these Operating Instructions carefully and keep

them handy for future reference. Please note that the actual controls and

components, menu items, etc. of your Digital Camera may look somewhat

different from those shown in the illustrations in these Operating Instructions.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast

material for purposes other than your own private use may infringe copyright

laws. Even for the purpose of private use, recording of certain material may

be restricted.

Information for Your Safety

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or

splashing.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to

qualified service personnel.

The socket outlet shall be installed near the equipment and shall be

easily accessible.

■Product identification marking

Product Location

Digital camera Bottom

(ENG) SQT0627 3

■About the battery pack

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace

only with the type recommended by the manufacturer.

• When disposing of the batteries, please contact your local

authorities or dealer and ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a

long period of time with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above

60 °C or incinerate.

■About the AC adaptor (supplied)

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

• The unit is in the standby condition when the AC adaptor is connected. The

primary circuit is always “live” as long as the AC adaptor is connected to an

electrical outlet.

4 SQT0627 (ENG)

■Cautions for Use

• Do not use any other USB connection cables except the supplied one or a

genuine Panasonic USB connection cable (DMW-USBC1: optional).

• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

• Use a “High Speed HDMI micro cable” with the HDMI logo. Cables that do not

comply with the HDMI standards will not work.

“High Speed HDMI micro cable” (Type D-Type A plug, up to 2 m long)

Keep this unit as far away as possible from electromagnetic equipment

(such as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this

unit may be disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise

adversely affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation may adversely affect this unit, disturbing the

pictures and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops

functioning properly, turn this unit off and remove the battery or disconnect AC

adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn

this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded

pictures and/or sound may be adversely affected.

(ENG) SQT0627 5

Contents

Information for Your Safety .... 2

Before use................................ 6

Standard accessories ............. 7

Names and Functions

of Main Parts............................ 8

Inserting and removing the

battery or SD memory card

(optional) ................................ 11

Charging the battery ............. 12

Setting the clock.................... 14

Setting the menu ................... 15

Holding the camera ............... 16

Recording pictures using

the viewfinder ........................ 16

Taking pictures with

automatic settings

[Intelligent Auto] Mode.......... 17

Recording motion pictures... 20

Using the control ring/

control dial ............................. 22

Registering preferred

functions to the

[Fn1] / [Fn2] button................ 24

Taking pictures with the

composition determined

[Composition Guide]............. 24

Viewing your pictures ........... 25

Deleting pictures ................... 25

What you can do with the

Wi-Fi®function/

NFC function.......................... 26

Using the camera by

connecting it to a

smartphone/tablet ................. 27

Reading the Operating

Instructions (PDF format) ..... 31

Storing recorded still

pictures and motion pictures

on your PC ............................. 32

Copying still pictures and

motion pictures...................... 33

Troubleshooting .................... 34

Specifications ........................ 36

Limited Warranty

(ONLY FOR AUSTRALIA) ...... 40

6 SQT0627 (ENG)

Before use

■Camera handling

●Keep the camera away from excessive vibration, force, or pressure.

●The camera is not dust resistant, splash resistant, or waterproof.

Avoid using the camera in places with excessive dust or sand, or where

water can come into contact with the camera.

●Do not allow camera to come into contact with pesticides or volatile

substances (can cause surface damage or coating to peel).

■

Condensation (When the lens, the LCD monitor or the viewfinder is fogged up)

●

Condensation may occur when the camera is exposed to sudden changes of

temperature or humidity. Avoid these conditions, which may make the lens,

the LCD monitor or the viewfinder dirty, cause mould, or damage the camera.

●If condensation does occur, turn off the camera and wait about two hours

before using it. Once the camera adjusts to the surrounding temperature,

the fogging will clear naturally.

■Caring for your camera

●Before cleaning the camera, remove the battery or disconnect the power

plug from the outlet.

●Do not press the LCD monitor with excessive force.

●Do not press the lens with excessive force.

●Do not keep rubber or plastic products in contact with the camera for a long

period of time.

●Do not use solvents such as benzine, thinner, alcohol, kitchen detergents,

etc., to clean the camera, since it may deteriorate the external case or the

coating may peel off.

●Do not leave the camera with the lens facing the sun, as rays of light from

the sun may cause it to malfunction.

●Do not extend the supplied cord or cable.

●While the camera is accessing the card or built-in memory (for an operation

such as picture writing, reading, deleting, or formatting), do not turn off the

camera or remove the battery, card, AC adaptor (supplied).

●The data on the built-in memory or the card may be damaged or lost due to

electromagnetic waves, static electricity or breakdown of the camera or the

card. We recommend storing important data on a PC etc.

●Do not format the card on your PC or other equipment. Format it on the

camera only to ensure proper operation.

(ENG) SQT0627 7

Standard accessories

Check that all the accessories are supplied before using the camera. Part

numbers are as of January 2015. These may be subject to change.

Battery pack

DMW-BCM13E

• Charge the battery

before use.

Battery pack is indicated as

battery pack or battery in the text.

AC adaptor

VSK0776

Hand strap

VFC4297

USB connection cable

K1HY08YY0031

CD-ROM

SFM0067

• Software:

Use it to install the software on

your PC.

• Operating Instructions for

advanced features

• SD Memory Card, SDHC Memory Card and SDXC Memory Card are

indicated as card in the text.

• Cards are optional. You can record or play back pictures on the built-in

memory when you are not using a card.

•Compatible memory cards (optional)

The following SD standard-based cards (Panasonic brand recommended) can

be used.

SD Memory Card (8 MB to 2 GB) / SDHC Memory Card (4 GB to 32 GB) /

SDXC Memory Card (48 GB, 64 GB)

• Consult the dealer or your nearest Service Centre if you lose the supplied

accessories. (You can purchase the accessories separately.)

• Please dispose of all packaging appropriately.

• Keep small parts in a safe place out of the reach of children.

• The illustrations and screens in this manual may differ from the actual product.

• SILKYPIX Developer Studio SE is not provided on the supplied CD-ROM.

Download this software from the website and install it on your computer to

use. (→33)

8 SQT0627 (ENG)

Names and Functions of Main Parts

1 2 345678 11

910

(Top)

16 17 18 20

(Bottom)

22 23 24

15 2119

(ENG) SQT0627 9

1 Flash

2 Self-timer indicator/

AF Assist Lamp

3 Control ring

4 Lens barrel

5 Lens

• Do not touch the lens barrier.

6 Viewfinder (LVF)

7 Diopter adjustment dial

• Adjusts the focus in the viewfinder.

8 Eye sensor

• The display is automatically switched

to viewfinder when your eye or an

object moves close to the viewfinder.

9 [LVF] button/[Fn2] button

• Use this to switch display between

viewfinder and LCD monitor.

10 Charging lamp (Red)/

Wi-Fi®connection lamp (Blue)

• The colour of the lamp differs

depending on the function.

11 Strap eyelet

• We recommend using the supplied

hand strap to avoid dropping the

camera.

12 Monitor

13 [HDMI] socket

• Do not connect any other cables

except the HDMI micro cable. Doing

so may cause malfunction.

14 [AV OUT/DIGITAL] socket

• This socket is also used when

charging the battery.

15 Speaker

16 Microphones

17 Mode dial

• Use this to select the recording mode.

18 Shutter button

19 Zoom lever

20 Motion picture button

21 Camera [ON/OFF] button

22 Tripod mount

• Do not attach this unit to tripods that

have screws with a length of 5.5 mm

or more. Doing so may damage

this unit.

• If you are not holding the camera

while using zoom, such as during

self-timer recording, [Time Lapse

Shot] recording, or remote recording,

the camera could tilt when the lens

barrel extends, so be sure to secure

the camera in place on a tripod or by

other means.

• It may not be possible to attach

certain types of tripods properly.

23 Card/Battery door

24 Release lever

25 [Wi-Fi] antenna

26 NFC antenna

27 [Wi-Fi] button

28 Playback button

• Use this to select the recording mode

or playback mode.

29 [MENU/SET] button

30 [Q.MENU/ ] / [ ] button

• You can display the Quick Menu and

erase pictures.

31 [DISP.] button

• Use this to change display.

32 Control dial

• Turn the dial to select setting items

and change setting values.

33 [Fn1] button

34 Cursor button

10 SQT0627 (ENG)

Names and Functions of Main Parts

[MENU/SET] button / Cursor button

[MENU/SET] button

• Use this button to display the menus, enter the settings, etc.

Cursor button

• This button is used to move the cursor on the menu screens and for

other functions.

• In this manual, the button that is to be used is indicated by .

You can perform the following operations while recording.

[ ] button ( )

• Exposure Compensation

- Corrects the exposure when there is a backlight or when the subject is too dark or too

bright.

[ ] button ( )

• Flash

[ ] (Drive Mode∗1) button ( )

• Burst∗2

- A burst of still pictures can be recorded while the shutter button is pressed fully.

• Auto Bracket∗2

- Records 3 pictures in continuous succession while exposure is changed automatically.

After exposure adjustment, the adjustment value is set as the standard.

• Self-timer∗2

- This is effective for preventing jitter when pressing the shutter button, by setting the self-

timer to 2 seconds.

∗1You can switch the operation to be performed when you press the shutter button.

∗2To cancel the setting, select [ ] or [ ].

[ ] button ( )

• Macro recording

- When you want to enlarge the subject, setting to [AF Macro] ([ ]) enables you to take

pictures at an even closer distance than the normal focus range (up to 3 cm for max.

Wide).

• Manual Focus

- Manual Focus is convenient when you want to lock the focus to take pictures or when it is

difficult to adjust focus using Auto Focus.

Autres manuels pour Lumix DMC-TZ70

Table des matières

Autres manuels Panasonic Appareil photo numérique

Panasonic

Panasonic Lumix DMC-TS4 Manuel utilisateur

Panasonic

Panasonic DMC-GX1 Lumix Instructions d'installation et d'entretien

Panasonic

Panasonic LUMIX DC-GH5M2GN Manuel utilisateur

Panasonic

Panasonic Lumix DMW-MCFT3 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-TZ40 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-LX100 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FT4 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FZ1000 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-TZ5; Lumix DMC-TZ4 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FX8GN Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FZ48 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-GF2C Caractéristiques techniques

Panasonic

Panasonic Lumix DC-S1 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-TZ2 Manuel utilisateur

Panasonic

Panasonic AWE300SP - COLOR CAMERA Manuel utilisateur

Panasonic

Panasonic AW-UE80 Manuel d'utilisation et d'entretien

Panasonic

Panasonic Lumix DMC-LZ1GN Manuel utilisateur

Panasonic

Panasonic DMCGF2 - DIGITAL CAMERA-ADV FEATURES Mode d’emploi

Panasonic

Panasonic Lumix DMC-GX8A Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-SZ10 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-LX7 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FH2P Manuel utilisateur

Panasonic

Panasonic Lumix DC-ZS220 Manuel du propriétaire

Panasonic

Panasonic DMC-FT25GN Caractéristiques techniques

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
