Operating Instructions

Digital Camera

Model No.DMC-LC80GN

DMC-LC70GN

DMC-LC50GN

Before use, please read these

instructions completely.

VQT0M82

LC80GN.book 1 ページ２００４年６月１７日　木曜日　午前１０時１８分

Safety

Dear Customer,

We would like to take this opportunity to

thank you for purchasing this Panasonic

Digital Camera. Please read these

Operating Instructions carefully and

keep them handy for future reference.

Information for Your

Safety

Carefully observe copyright laws.

Recording of pre-recorded tapes or

discs or other published or

broadcast material for purposes

other than your own private use may

infringe copyright laws. Even for the

purpose of private use, recording of

certain material may be restricted.

• Please note that the actual controls

and components, menu items, etc. of

your Digital Camera may look

somewhat different from those shown

in the illustrations in these Operating

Instructions.

• SD Logo is a trademark.

• Other names, company names, and

product names printed in these

instructions are trademarks or

registered trademarks of the

companies concerned.

• The screens in these instructions are

displayed as illustrated in DMC-LC70.

IF THE POWER CORD OF THIS

EQUIPMENT IS DAMAGED, IT MUST

BE REPLACED WITH AN

ELECTRICALLY APPROVED POWER

CORD.

WARNING

TO REDUCE THE RISK OF FIRE

OR SHOCK HAZARD AND

ANNOYING INTERFERENCE,

USE ONLY THE RECOMMENDED

ACCESSORIES AND DO NOT

EXPOSE THIS EQUIPMENT TO

RAIN OR MOISTURE. DO NOT

REMOVE THE COVER (OR

BACK); THERE ARE NO USER

SERVICEABLE PARTS INSIDE.

REFER SERVICING TO

QUALIFIED SERVICE

PERSONNEL.

THE SOCKET OUTLET SHALL BE

INSTALLED NEAR THE

EQUIPMENT AND SHALL BE

EASILY ACCESSIBLE.

CAUTION

Danger of explosion if batteries are

incorrectly replaced. Replace only

with the same or equivalent type

recommended by the manufacturer.

Dispose of used batteries according

to the manufacturer’s instructions.

LC80GN.book 2 ページ２００４年６月１７日　木曜日　午前１０時１８分

Safety

Extremely high precision technology

is employed to produce the LCD

monitor screen. The result is more

than 99.99% effective pixels with a

mere 0.01% of the pixels inactive or

always lit. However, this is not a

malfunction and does not affect the

recorded pictures.

LC80GN.book 3 ページ２００４年６月１７日　木曜日　午前１０時１８分

Contents

Safety

Information for Your Safety ................. 2

Preparation

Standard Accessories ......................... 6

Names of the Components ................. 7

Quick Guide ........................................ 9

Charging the Batteries ...................... 10

About the Battery .............................. 11

Inserting/Removing the Batteries ...... 16

About the Card .................................. 17

Inserting/Removing the Card ............ 18

Setting the Date/Time (Clock Set)..... 19

Setup Menu....................................... 20

Using the LCD Monitor...................... 23

Recording pictures (basic)

Taking Pictures ................................. 25

Taking Pictures in Simple Mode........ 29

Checking the Recorded Picture

(Review) ........................................ 32

Using the Optical Zoom..................... 33

Taking Pictures using

the Built-in Flash............................ 34

Compensating the Exposure............. 36

Taking Pictures using

Auto Bracket.................................. 37

Taking Pictures with the Self-timer.... 38

Taking Pictures using Burst Mode .... 39

Playback (basic)

Playing Back Pictures ....................... 40

9 Pictures Multi Playback .................. 41

Using the Playback Zoom ................. 42

Deleting Pictures............................... 43

Recording pictures

(advanced)

Using the Mode Dial.......................... 45

• Taking Pictures using

Economy Mode ....................... 45

• Taking Pictures using

Macro Mode ............................46

• Taking Pictures using

Portrait Mode........................... 47

• Taking Pictures using

Landscape Mode.....................47

• Taking Pictures using

Night Portrait Mode ................. 48

• Recording Motion Images ..........49

Using [REC] mode menu................... 51

• Setting the White Balance..........51

• Setting ISO Sensitivity ...............53

• Changing the Picture Size .........53

• Changing the Quality ................. 54

• Taking Pictures using

Spot Mode...............................54

• Taking Pictures with Audio

(DMC-LC80/DMC-LC70)......... 55

• Using the AF Trigger

(DMC-LC80/DMC-LC70)......... 55

• Using the Digital Zoom...............57

• Using the Colour Effect..............58

• Adjusting the Quality

of the Picture

(Picture Adjustment)................58

• Creating Flip Animation

(DMC-LC80/DMC-LC70)......... 58

LC80GN.book 4 ページ２００４年６月１７日　木曜日　午前１０時１８分

Playback (advanced)

Playing Back Pictures with Audio

(DMC-LC80/DMC-LC70) ............... 62

Playing Back Motion Images............. 63

Rotating the Picture........................... 64

Setting the Picture to be Printed

and the Number of Prints

(DPOF Print Setting)...................... 65

Preventing Accidental Erasure

of the Picture ................................. 69

Playing Back with Slide Show........... 71

Adding Audio to Recorded Pictures

(Audio Dubbing)

(DMC-LC80/DMC-LC70) ............... 73

Resizing the Pictures ........................ 74

Trimming the Pictures ....................... 76

Formatting the Card .......................... 78

Playing Back Pictures

with a TV Screen ........................... 79

Before Connecting with

USB Connection Cable.................. 80

Connecting to a PC........................... 82

Connecting to a Printer ..................... 84

Others

Screen Display.................................. 88

Cautions for Use ............................... 91

Approximate number of recordable

pictures and the size...................... 94

Message Display............................... 95

Troubleshooting ................................ 96

Specifications.................................... 98

LC80GN.book 5 ページ２００４年６月１７日　木曜日　午前１０時１８分

Preparation

Standard Accessories

Before using your camera, check the contents.

∫SD Memory Card (16 MB)

RP-SD016B

(In the text, it is indicated as “Card”)

∫Batteries

AA Ni-MH (nickel-metal hydride)

∫Battery Charger

DE-894A

∫AC Cable

K2CJ2DA00002 or K2CJ2DA00011

∫AV Cable (DMC-LC80/DMC-LC70)

K1HB08CD0003

∫Video Cable (DMC-LC50)

K1HB08CD0006

∫USB Connection Cable

K1HB08CD0008

∫CD-ROM

∫Strap

VFC4057

LC80GN.book 6 ページ２００４年６月１７日　木曜日　午前１０時１８分

Preparation

Names of the Components

1 Strap Eyelet

2 Self-timer Indicator (P38)

3Flash

4 Lens

5 Lens Cover

6 LCD Monitor (P23, 88)

7 Optical Finder

8 Power Indicator (P26)

9 Status Indicator

(P17, 26, 35)

10 Mode Dial (refer to next page)

11 Single/Burst Mode Button (P39)

12 Cursor buttons

2/Self-timer Button (P38)

4/REVIEW/SET Button (P32)

1/Flash Mode Button (P34)

3/Exposure Compensation (P36)/

Auto Bracket (P37)/White Balance

Fine Adjustment (P52) Button

13 [MENU] Button (P20)

14 [DISPLAY] Button (P23, 68)

15 Delete (P43)/[FOCUS] (P55) Button

(DMC-LC80/DMC-LC70)

Delete Button (P43) (DMC-LC50)

16 Lens Barrel (P27)

17 Microphone (P49, 55)

(DMC-LC80/DMC-LC70)

18 Zoom Lever (P33, 57)

19 Shutter Button (P25)

20 Power Switch (P25)

13 4

15 14 13 12

67 8 910 11

16 17 18

LC80GN.book 7 ページ２００４年６月１７日　木曜日　午前１０時１８分

Preparation

21 Terminal Cover

22 [DC IN] Socket *

23 [DIGITAL] (P82, 84) / [AV OUT]

(P79) Socket (DMC-LC80/

DMC-LC70)

[DIGITAL] (P82, 84) / [V.OUT] (P79)

Socket (DMC-LC50)

24 Card Door (P18)

* When you use the AC adaptor

(optional, DMW-AC2), do not extend

the DC cable connected to the

camera.

25 Tripod Receptacle

26 Battery Door (P16)

25 26

(DMC-LC50) (DMC-LC70)(DMC-LC50)

(DMC-LC80)

(DMC-LC70)

(DMC-LC50)

ªThe Mode Dial

Select the desired recording mode for

the scene, then turn the mode dial to set

to the mark of the mode.

: Normal Picture mode (P25)

: Economy mode (P45)

: Macro mode (P46)

: Portrait mode (P47)

: Landscape mode (P47)

: Night portrait mode (P48)

: Motion image mode (P49)

: Simple mode (P29)

: Playback mode (P40)

LC80GN.book 8 ページ２００４年６月１７日　木曜日　午前１０時１８分

Preparation

Quick Guide

• This is the summary of operations for recording on the camera.

• Refer to the corresponding pages for each operation in detail.

1Check the batteries and the card.

• Insert the supplied batteries or new

batteries. (P16)

(When using the Ni-MH (nickel-metal

hydride) batteries, insert the batteries

after charge.)

• Insert the Memory Card. (P18)

• Read page 11 for the batteries.

2Turn the camera on.

• The power indicator 1blinks.

• When the card is not inserted.

• When there is no remaining

capacity and time on the card.

• When the remaining power is low

(blinking slowly).

3Take pictures.

• Set the clock. (P19)

1 Set the mode dial to the Normal

recording mode [ ].

2 Press the shutter button and take a

picture. (P25)

• Do not cover the photo flash with your

finger or other items. (P26)

4Play back the recorded picture.

1 Set the mode dial to the Playback

mode [ ].

2 Press 2or 1, and select the desired

picture. (P40)

LC80GN.book 9 ページ２００４年６月１７日　木曜日　午前１０時１８分

Preparation

Charging the Batteries

• Charge the batteries before use (when using Ni-MH batteries).

Insert the batteries into the battery

charger.

2Connect the AC cable to the

charger and AC socket.

• The charge lamp 1 lights and charge

starts.

• The AC cable does not fit entirely into

the socket. A gap will remains shown

3Charge is completed when the

charge lamp is no longer

illuminated.

• Charging takes in about 6 hours.

• Confirm that batteries are inserted

properly.

• Disconnect the charger from the

electrical outlet after the charging is

completed.

• Use Panasonic AA Ni-MH batteries

(nickel-metal hydride) (supplied).

ª Environment/charge error

• Charge in a place with a surrounding

temperature of 0 – 40oC (also

temperature of the battery).

• When charging starts, the charge

lamp lights.

If after charging starts the charge lamp

blinks, it indicates a charge error.

In this case, remove the charger from

the electrical outlet, take out batteries,

check whether the surrounding

temperature or the batteries are too

hot or cold, and charge again. An error

cannot be cancelled by turning the

power off/on.

If after charging again

the charge lamp still blinks, consult

your nearest servicentre.

LC80GN.book 10 ページ２００４年６月１７日　木曜日　午前１０時１８分

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Appareil photo numérique

Panasonic

Panasonic Lumix DMC-ZS35 Manuel utilisateur

Panasonic

Panasonic DMC-G1K - Lumix Digital Camera Manuel utilisateur

Panasonic

Panasonic Lumix DMC-LX3 Mode d’emploi

Panasonic

Panasonic Lumix DMC-GH4A Caractéristiques techniques

Panasonic

Panasonic DMC-ZR3S Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FZ30GN Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FH24 Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix S5 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-LX3 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-LS80 Manuel utilisateur

Panasonic

Panasonic DMC-ZS45 Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix DMC-L1 Manuel utilisateur

Panasonic

Panasonic Lumix G G1 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-SZ1 Instructions d'installation et d'entretien

Panasonic

Panasonic H-HS043PP Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-FX500 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FS22 Manuel utilisateur

Panasonic

Panasonic Lumix DC-TZ220D Manuel utilisateur

Panasonic

Panasonic Lumix DMC-F1A Manuel utilisateur

Panasonic

Panasonic Lumix DMC-ZS9 Manuel utilisateur

Panasonic

Panasonic PalmCam PV-DC1080 Manuel utilisateur

Panasonic

Panasonic DMC FX10 - Lumix Digital Camera Mode d’emploi

Panasonic

Panasonic Lumix DMC-LZ20 Instructions d'installation et d'entretien

Panasonic

Panasonic DMC FS7G - Lumix Digital Camera Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
