Panasonic DMC-ZS20W Instructions d'installation et d'entretien

VQT4B72

M0112KZ0

Basic Owner’s Manual

Digital Camera

Model No. DMC-ZS20

DMC-ZS19

Before connecting, operating or adjusting this product,

please read the instructions completely.

More detailed instructions on the operation of

this camera are contained in “Owner’s Manual

for advanced features (PDF format)” in the

supplied disc. Install it on your PC to read it.

For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,

2 VQT4B72 (ENG)

Dear Customer,

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products

on the market today. Used properly, we’re sure it will bring you and your

family years of enjoyment. Please take time to fill in the information below.

The serial number is on the tag located on the underside of your camera.

Be sure to retain this manual as your convenient camera information

source.

Date of Purchase Dealer Phone No.

Dealer Purchased From Model No.

Dealer Address Serial No.

Please note that the actual controls and components, menu items, etc.

of your Digital Camera may look somewhat different from those shown in

the illustrations in this Owner’s Manual.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast material

for purposes other than your own private use may infringe copyright laws. Even

for the purpose of private use, recording of certain material may be restricted.

A lithium ion battery that is recyclable powers

the product you have purchased. Please call

1-800-8-BATTERY for information on how to recycle

this battery.

(ENG) VQT4B72 3

Information for Your Safety

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or splashing.

•Do not place objects filled with liquids, such as vases, on this

unit.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to qualified

service personnel.

The socket outlet shall be installed near the equipment and shall be

easily accessible.

■Product identification marking

Product Location

Digital camera Bottom

4 VQT4B72 (ENG)

FCC Note:

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, follow the attached

installation instructions and use only shielded interface

cables with ferrite core when connecting to computer or

peripheral devices.

Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

this equipment.

Declaration of Conformity

Trade Name: Panasonic

Model No.: DMC-ZS20 / DMC-ZS19

Responsible Party: Panasonic Corporation of

North America

One Panasonic Way,

Secaucus, NJ 07094

Support Contact: Panasonic Consumer

Marketing Company of

North America

1-800-211-PANA (7262)

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following

two conditions: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operation.

DMC-ZS20

DMC-ZS19

(ENG) VQT4B72 5

■About the battery pack

CAUTION

Battery pack (Lithium ion battery pack)

• Use the specified unit to recharge the battery pack.

• Do not use the battery pack with equipment other than the specified unit.

• Do not get dirt, sand, liquids, or other foreign matter on the terminals.

• Do not touch the plug terminals (+ and −) with metal objects.

• Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes,

wash it off thoroughly with water.

If any electrolyte should come into contact with your eyes, never rub

the eyes. Rinse eyes thoroughly with water, and then consult a doctor.

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace only

with the type recommended by the manufacturer.

• When disposing the batteries, please contact your local authorities or

dealer and ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a

long period of time with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above

60 °C (140 °F) or incinerate.

6 VQT4B72 (ENG)

■About the AC adaptor (supplied)

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

AC adaptor

This AC adaptor operates on AC between 110V and 240V.

But

• In the U.S.A. and Canada, the AC adaptor must be connected to a

120V AC power supply only.

• When connecting to an AC supply outside of the U.S.A. or Canada,

use a plug adaptor to suit the AC outlet configuration.

(ENG) VQT4B72 7

■Cautions for Use

• Do not use any other USB connection cables except the supplied one.

• Always use a genuine Panasonic HDMI mini cable

(RP-CDHM15, RP-CDHM30: optional).

Part numbers: RP-CDHM15 (1.5 m) (4.9 feet), RP-CDHM30 (3.0 m) (9.8 feet)

• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

Keep this unit as far away as possible from electromagnetic equipment (such

as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this unit

may be disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise

adversely affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation generated by microprocessors may adversely

affect this unit, disturbing the pictures and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops

functioning properly, turn this unit off and remove the battery or disconnect AC

adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn

this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded pictures

and/or sound may be adversely affected.

For information about the software used for this product, press [MENU/SET] and

select [Setup] to display [Version Disp.] before pressing [MENU/SET] again.

This product is licensed under the AVC patent portfolio license for the personal

and non-commercial use of a consumer to (i) encode video in compliance with

the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded

by a consumer engaged in a personal and non-commercial activity and/or was

obtained from a video provider licensed to provide AVC Video. No license is

granted or shall be implied for any other use. Additional information may be

obtained from MPEG LA, LLC.

See http://www.mpegla.com.

8 VQT4B72 (ENG)

Contents

Information for Your Safety .......3

Before use ...................................9

Standard accessories ..............10

Names and Functions of

Main Parts .................................11

Touch operations ......................12

Inserting and removing the

card (optional)/the battery .......13

Charging the battery ................14

Setting the clock .......................15

Setting the menu ......................17

Taking pictures .........................18

Taking motion pictures ............19

Viewing your pictures

[Normal Play] ............................20

Deleting pictures ......................20

GPS and map functions

DMC-ZS20 ....................................21

Reading the Owner’s Manual

(PDF format) ..............................25

Installing supplied software ....26

Specifications ...........................27

Digital Camera Accessory

System .......................................30

Digital Camera Accessory

Order Form ................................31

Limited Warranty

(ONLY FOR U.S.A. AND

PUERTO RICO) .........................32

●When operation or other information is more or less the same between models,

DMC-ZS20 is used as examples for the instructions provided in this manual.

●The operations, procedures, or functions that differ among models are indicated

separately, together with the relevant model number.

(Example) DMC-ZS20

DMC-ZS19

(ENG) VQT4B72 9

Before use

■Camera handling

●Keep the camera away from excessive vibration, force, or pressure.

●The camera is not dust resistant, splash resistant, or waterproof.

Avoid using the camera in places with excessive dust or sand, or

where water can come into contact with the camera.

■Condensation (When the lens or the LCD monitor is fogged up)

●Condensation may occur when the camera is exposed to sudden

changes of temperature or humidity. Avoid these conditions, which

may make the lens or LCD monitor dirty, cause mold, or damage the

camera.

●If condensation does occur, turn off the camera and wait about two

hours before using it. Once the camera adjusts to the surrounding

temperature, the fogging will clear naturally.

10 VQT4B72 (ENG)

Standard accessories

Check that all the accessories are supplied before using the camera. Part

numbers are as of January 2012.

Battery pack

DMW-BCG10PP

• Charge the battery

before use.

Battery pack is indicated as

battery pack or battery in the

text.

AC adaptor

VSK0768

Hand strap

VFC4297

USB connection

cable

K1HY08YY0025

DMC-ZS20

DVD

VFF0974

• Software:

Use it to install the software

on your PC.

• Map data

• Owner’s Manual for

advanced features

DVD is indicated as disc in

the text.

DMC-ZS19

CD-ROM

VFF0999

• Software:

Use it to install the software

on your PC.

• Owner’s Manual for

advanced features

CD-ROM is indicated as disc

in the text.

• SD Memory Card, SDHC Memory Card and SDXC Memory Card are

indicated as card in the text.

• Memory cards are optional. You can record or play back pictures on the

built-in memory when you are not using a card.

• For information about optional accessories, refer to the “Digital Camera

Accessory System”.

• If any accessories are lost, customers should contact Panasonic’s parts

department at 1 800 833-9626 for further information about obtaining

replacement parts.

• Please dispose of all packaging appropriately.

• Keep small parts in a safe place out of the reach of children.

• The illustrations and screens in this manual may differ from the actual

product.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Appareil photo numérique

Panasonic

Panasonic Lumix DMC-LZ30P Manuel utilisateur

Panasonic

Panasonic Lumix DMC-TZ330 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-ZS8 Instructions d'installation et d'entretien

Panasonic

Panasonic lumix DMC-FT6 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-GH1KPP Manuel utilisateur

Panasonic

Panasonic AW-E860L Manuel utilisateur

Panasonic

Panasonic DMC-ZS30 Caractéristiques techniques

Panasonic

Panasonic LUMIX DMC-FZ28 Caractéristiques techniques

Panasonic

Panasonic LUMIX DMC-GX85K Caractéristiques techniques

Panasonic

Panasonic VARICAM LT Guide de référence rapide

Panasonic

Panasonic Lumix DMC-FZ1A Manuel utilisateur

Panasonic

Panasonic Lumix DMC-LX15 Caractéristiques techniques

Panasonic

Panasonic AU-VREC1 Manuel d'utilisation et d'entretien

Panasonic

Panasonic Lumix DC-TZ96D Manuel du propriétaire

Panasonic

Panasonic Lumix DC-ZS200 Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix DMC-FZ5GN Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-TZ82 Manuel utilisateur

Panasonic

Panasonic DMC-SZ7K Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-FZ100 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-G10W Manuel utilisateur

Panasonic

Panasonic DMC-SZ9P Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-FX500 Manuel utilisateur

Panasonic

Panasonic Lumix DC-ZS80 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FZ1000 Instructions d'installation et d'entretien

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
