Basic Operating Instructions

Digital Camera

Model No. DMC-TZ110/DMC-ZS110

DMC-TZ80/DMC-ZS60

DMC-TZ110/DMC-ZS110 DMC-TZ80/DMC-ZS60

Please read these instructions carefully before using this product, and

save this manual for future use.

More detailed operating instructions are available in “Operating

Instructions for advanced features (PDF format)”. To read it, download

it from the website. (→45)

GA GH

2SQT1184 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic

Digital Camera. Please read these Operating Instructions carefully and keep them

handy for future reference. Please note that the actual controls and components,

menu items, etc. of your Digital Camera may look somewhat different from those

shown in the illustrations in these Operating Instructions.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast

material for purposes other than your own private use may infringe copyright

laws. Even for the purpose of private use, recording of certain material may be

restricted.

Information for Your Safety

WARNING:

To reduce the risk of fire, electric shock or product damage,

• Do not expose this unit to rain, moisture, dripping or splashing.

• Use only the recommended accessories.

• Do not remove covers.

• Do not repair this unit by yourself. Refer servicing to qualified service

personnel.

The socket outlet shall be installed near the equipment and shall be easily

accessible.

■ Product identification marking

Product Location

Digital camera Bottom

SQT1184 (ENG)

■ About the AC adaptor (supplied)

CAUTION!

To reduce the risk of fire, electric shock or product damage,

• Do not install or place this unit in a bookcase, built-in cabinet or in

another confined space. Ensure this unit is well ventilated.

• The unit is in the standby condition when the AC adaptor is connected. The

primary circuit is always “live” as long as the AC adaptor is connected to an

electrical outlet.

■ About the battery pack

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace only with the

type recommended by the manufacturer.

• When disposing of the batteries, please contact your local authorities or dealer

and ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period

of time with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 °C or

incinerate.

4SQT1184 (ENG)

■ Cautions for Use

• Use a “High Speed HDMI micro cable” with the HDMI logo. Cables that do not

comply with the HDMI standards will not work.

“High Speed HDMI micro cable” (Type D-Type A plug, up to 2 m (6.6 feet) long)

Keep this unit as far away as possible from electromagnetic equipment (such

as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this unit

may be disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise

adversely affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong

magnetic fields created by speakers or large motors.

• Electromagnetic wave radiation may adversely affect this unit, disturbing the

pictures and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops

functioning properly, turn this unit off and remove the battery or disconnect

AC adaptor (supplied)/AC adaptor (DMW-AC10G: optional). Then reinsert the

battery or reconnect AC adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded pictures

and/or sound may be adversely affected.

SQT1184 (ENG)

For Singapore only

Complies with

IDA Standards

DB01017

For Thailand only

This telecommunication equipment conforms to NTC/NBTC technical requirement.

6SQT1184 (ENG)

Contents

■

Information for Your Safety ...................... 2

Preparations

■

Before use.................................................. 7

■

Standard accessories ............................... 8

■

Names and Functions of Main Parts ....... 9

■

Inserting and removing the battery

or SD memory card (optional) ................ 12

■

Charging the battery ............................... 13

■

Setting the clock ..................................... 15

Basics

■

Basic operations ..................................... 16

■

Setting the menu ..................................... 23

Recording

■

Taking pictures with automatic settings

(Intelligent Auto Mode) ........................... 24

■

Recording 4K photos .............................. 25

■

[Post Focus] ............................................ 28

■

Recording motion pictures .................... 31

■

[4K Live Cropping] .................................. 34

Playback

■

Viewing your pictures ............................. 36

■

[Light Composition] ................................ 37

Wi-Fi

■

What you can do with the

Wi-Fi® function ........................................ 39

■

Operating the camera by connecting

it to a smartphone ................................... 40

Others

■

Downloading software ............................ 43

■

Reading the Operating Instructions

(PDF format) ............................................ 45

■

List of monitor/viewfinder displays ....... 47

■

Menu list ................................................... 50

■

Q&A Troubleshooting ............................ 53

■

Specifications .......................................... 55

■

Digital Camera Accessory System ........ 61

In this manual, examples use illustrations and screens of DMC-TZ110/DMC-ZS110

unless otherwise indicated.

■ About the symbols in the text

Indicates that the menu can be set by pressing [MENU/SET] button.

In this Operating Instructions, steps for setting a menu item are described as

follows:

→ [Rec] → [Quality] → [ ]

SQT1184 (ENG)

Preparations Preparations

Before use

■ Camera handling

● Keep the camera away from excessive vibration, force, or pressure.

● The camera is not dust resistant, splash resistant, or waterproof.

Avoid using the camera in places with excessive dust or sand, or where water can come

into contact with the camera.

● Do not allow camera to come into contact with pesticides or volatile substances (can cause

surface damage or coating to peel).

■ Condensation (When the lens, the monitor or the viewfinder is

fogged up)

● Condensation may occur when the camera is exposed to sudden changes of temperature

or humidity. Avoid these conditions, which may make the lens, the monitor or the viewfinder

dirty, cause mould, or damage the camera.

● If condensation does occur, turn off the camera and wait about two hours before using it.

Once the camera adjusts to the surrounding temperature, the fogging will clear naturally.

■ Caring for your camera

● To clean your camera, remove the battery, the DC coupler (DMW-DCC11: optional) or a

card, or disconnect the power plug from the outlet, and wipe with a soft, dry cloth.

● Do not press the monitor with excessive force.

● Do not press the lens with excessive force.

● Do not keep rubber or plastic products in contact with the camera for a long period of time.

● Do not use solvents such as benzine, thinner, alcohol, kitchen detergents, etc., to clean the

camera, since it may deteriorate the external case or the coating may peel off.

● Do not leave the camera with the lens facing the sun, as rays of light from the sun may

cause it to malfunction.

● Do not extend the supplied cord or cable.

● While the camera is accessing the card (for an operation such as picture writing, reading,

deleting, or formatting), do not turn off the camera or remove the battery, card, AC adaptor

(supplied)/AC adaptor (DMW-AC10G: optional) or DC coupler (DMW-DCC11: optional).

● The data on the card may be damaged or lost due to electromagnetic waves, static

electricity or breakdown of the camera or the card. We recommend storing important data

on a PC etc.

● Do not format the card on your PC or other equipment. Format it on the camera only to

ensure proper operation.

Preparations

SQT1184 (ENG)

Standard accessories

Check that all the accessories are supplied before using the camera. Part numbers

are as of January 2016. These may be subject to change.

Battery pack

DMW-BLG10E

• Charge the battery before

use.

• Battery pack is indicated as battery

pack or battery in the text.

AC adaptor

SAE0012D

(DMC-TZ110GA/DMC-TZ80GA)

SAE0012F

(DMC-ZS110GH/DMC-ZS60GH)

Hand strap

VFC4297

USB connection cable

K1HY04YY0106

TZ110/ZS110

Shoulder strap adaptor

(2)

SYQ0694

• Use when attaching a shoulder strap

(commercially available). For details, refer

to “Operating Instructions for advanced

features (PDF format)”.

• Cards are optional. (SD Memory Card, SDHC Memory Card and SDXC

Memory Card are indicated as card in the text.)

– This unit is compatible with UHS- UHS Speed Class 3 standard SDHC/SDXC

memory cards.

– The following SD standard-based cards (Panasonic brand recommended) can

be used. Operation has been confirmed when using a Panasonic brand card.

SD Memory Card (512 MB to 2 GB)/SDHC Memory Card (4 GB to 32 GB)/

SDXC Memory Card (48 GB to 128 GB)

– Depending on recording conditions, the required card differs.

• Consult the dealer or your nearest Service Centre if you lose the supplied

accessories. (You can purchase the accessories separately.)

• Please dispose of all packaging appropriately.

•

TZ110/ZS110

Keep the shoulder strap adaptors out of reach of children to prevent swallowing.

• The illustrations and screens in this manual may differ from the actual product.

SQT1184 (ENG)

Preparations

Names and Functions of Main Parts

1 2 3

4 5 6

9 10

15 17

18 19 20 13

33 34 35 36 37 32

TZ110/ZS110

Preparations

SQT1184 (ENG)

TZ80/ZS60

1 2

5 4

9 10

16 17

34 35 36 37

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Appareil photo numérique

Panasonic

Panasonic Lumix DMC-LS1PP Manuel utilisateur

Panasonic

Panasonic Lumix DC-G110 Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-FP1 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-GM5 Manuel utilisateur

Panasonic

Panasonic DMC-F5EG Manuel utilisateur

Panasonic

Panasonic DMC-GH1K - Lumix Digital Camera Manuel utilisateur

Panasonic

Panasonic DMC-LZ40 Instructions d'installation et d'entretien

Panasonic

Panasonic lumix DMC-SZ8 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FT20 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FT4EB Manuel utilisateur

Panasonic

Panasonic lumix DC-TZ90 Manuel du propriétaire

Panasonic

Panasonic DMC-SZ3V Manuel utilisateur

Panasonic

Panasonic DMCFX700 - DIGITAL STILL CAMERA Mode d’emploi

Panasonic

Panasonic Lumix DMC-TS20 Mode d’emploi

Panasonic

Panasonic Lumix DMC-FX700P Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FZ60 Manuel du propriétaire

Panasonic

Panasonic LUMIX DMC-FS11EB Manuel utilisateur

Panasonic

Panasonic DMC-FT2EB Manuel utilisateur

Panasonic

Panasonic Lumix DMC-ZS50 Manuel utilisateur

Panasonic

Panasonic DMC-FX35P Manuel utilisateur

Panasonic

Panasonic Lumix DMC-SZ5 Manuel d'instructions

Panasonic

Panasonic Lumix DMC-FX01 Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-ZX3 Caractéristiques techniques

Panasonic

Panasonic DMC-ZS15K Instructions d'installation et d'entretien

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
