Operating Instructions

Marine Case

Model No.

DMW-MCTZ3

VQT1F25

Before connecting, operating or

adjusting this product, please read

the instructions completely.

For USA assistance, please call: 1-800-272-7033 or send e-mail to : [email protected]

For Canadian assistance, please call: 1-800-99-LUMIX (1-800-995-8649) or

send e-mail to: [email protected]

DMW-MCTZ3.book 1 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

Contents

Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Handling and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

What is the O-ring? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Preparation -Setting the O-ring- . . . . . . . . . . . . . . . . . 10

Preparation -Checking the Case is Waterproof- . . . . . 14

Preparation -Attaching the Digital Camera- . . . . . . . . 15

Taking Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Tips for Taking Pictures in the Water . . . . . . . . . . . . . 19

After Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Cleaning and Storing . . . . . . . . . . . . . . . . . . . . . . . . . 21

Caution for Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Spanish Quick Use Guide/

Guía rápida en español. . . . . . . . . . . . . . . . . . . . . . . . 28

DMW-MCTZ3.book 2 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

Before Use

≥This Marine Case is designed for Panasonic Digital Camera.

You can enjoy taking pictures underwater at depths up to 40 m/130 feet.

≥In the case of water leakage due to insufficient care, Matsushita is in no

way liable for damage to any products (digital camera, batteries, card etc.)

inside this Case, photography costs or any other expenses.

≥Matsushita also offers no compensation for accidents resulting in injury or

damage to property.

≥Read the operating instructions for your digital camera.

≥Before attaching the digital camera, submerge the case in water for

about 3 minutes or more to check that there is no water leakage.

∫About handling this Case

≥Use under the following conditions.

• Water depth: Up to 40 m/130 feet

• Ambient temperature: 0 °C

40 °C/32 °F

104 °F

≥Do not use the Case in water over 40 °C/104 °F. The heat may damage the Case or

cause water leakage.

≥The Case is made of impact resistant polycarbonate however be careful when you

are using it. It can be easily scratched when taking pictures in rocky places etc. and

can be damaged by the impact if dropped etc. When travelling, pack the Case

carefully to prevent any direct impact if it is dropped etc. and do not leave the digital

camera in the Case. Only attach the digital camera to the case if you are

transporting it a short distance such as from the airport to the diving spot. (You

cannot reuse the material the Case was packed in at the time of purchase to

transport it.)

≥When boarding a plane, the change in atmospheric pressure may cause the inside

of the Case to expand causing damage to the Case. Remove the O-ring before

boarding a plane.

≥Do not leave the digital camera in the Case for a long period of time in a car, a

ship, exposed to direct sunlight etc. The Case is an airtight device so the

temperature inside the Case will become very high and the digital camera may

stop operating properly. Do not let the temperature inside the Case become

too high.

DMW-MCTZ3.book 3 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

Before Use (continued)

∫Using the Case in high or low temperatures

≥If you open or close the Case where it is humid or hot and then move to a place that

is cold or dive underwater, condensation may appear inside the Case, the glass

surface may become cloudy and the digital camera may be damaged.

≥If you suddenly move the Case from a cold place or cold water to a warm place, the

glass surface may become cloudy. Wait until the Case becomes close to the air

temperature before taking pictures.

∫About preparation

≥Do not open or close the Case where it may be splashed by water or sand may

get in it. We recommend opening or closing the Case indoors.

≥Replace the battery, card etc. and attach the digital camera indoors where there is

little moisture.

≥If you must open or close the Case at the diving spot to replace the battery or

the card, be sure to follow the steps below.

• Select a place where the Case will not be splashed by water and sand will not get

in it.

• Blow off any drops of water in the gap between the rear case and the front case

and on the buckle. Thoroughly wipe off any remaining drops of water with a dry

cloth.

• Thoroughly wipe off any drops of water on your body or hair.

• Be particularly careful about any water coming from the sleeves of your thermal

suit.

• Do not touch the digital camera if your hands are wet from sea water. Wet a towel

with fresh water and place it in a polyester bag beforehand. Use this towel to wipe

off any drops of water or sand on your hands or body.

≥This Case does not absorb shock. If you place a heavy object on the Case or cause

shock to it, the digital camera may be damaged. Be careful when you are using the

case.

DMW-MCTZ3.book 4 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

Accessories

When you first open the package, check that the Case and all the

accessories are included and that there has been no damage to the

Case or any of the accessories during distribution or

transportation. If you find something unusual, consult your dealer

before using the Case.

Do not use any accessories except those specified below.

O-ring

VMG1798

Silica Gel (Desiccant)

(1 g /5 pieces)

VZG0371

Grease (for O-ring)

VZG0372

Hand Strap

VFC4190

Weight (2)

VMP8844

Weights attachment

screw

VHD1930

Diffuser

VYK2D90

≥You can remove this diffuser when not using it

Attach as shown in the diagram.

Removing Attaching

DMW-MCTZ3.book 5 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

Handling and Care

≥Do not place the Case where it may fall.

• If the Case falls on your head or foot, it will injure you and cause the Case to

malfunction.

≥Never alter the Case.

• If water leaks into the digital camera because the Case was altered, the digital

camera may be damaged beyond repair.

• If you continue to use the digital camera after water has leaked into it, this may

cause a fire.

≥Do not use the Case while scuba diving without proper training.

• You should only operate the Case while scuba diving if you have been properly

trained and certified for this sport.

≥Never place the Case, grease, silica gel or O-ring within the reach of

infants.

• If any part of an infant’s body is caught in the Case, it may cause an injury.

• Infants may accidentally swallow the grease, silica gel or O-ring.

• Consult a doctor immediately if you think an infant may have swallowed the

grease, silica gel or O-ring.

≥Do not hang the strap around your neck underwater.

• It may become wound around your neck causing suffocation or other serious

injuries.

≥Thoroughly wash off any grease on your hands.

• Do not allow the grease on your hands to come into contact with your mouth or

eyes.

≥If water leaks into the case, stop using it immediately.

• This may cause an electric shock, burning or a fire.

• Consult your dealer.

≥If anything abnormal occurs while using the Case underwater, please

follow all necessary procedures and guidelines for decompressing

when you ascend.

• If you ascend too quickly, you may get caisson disease.

≥If smoke or abnormal heat, smells or sounds come from the Case,

stop using it immediately.

• These may cause an electric shock, burning or fire.

• Remove the digital camera from the Case and then immediately remove the

battery from the digital camera.

• Consult your dealer.

≥Be careful when opening the Case after water leakage.

• The leaked water may blow out or the rear case may flip.

DMW-MCTZ3.book 6 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

≥Do not leave the Case where the temperature is high.

• The temperature inside the Case becomes very high particularly when it is

exposed to direct sunlight on a beach, a ship etc. or when it is left in an airtight car

in the summer. The heat may damage the Case or its inner parts.

• If a digital camera is attached to the Case, it may also be damaged.

• If you use the attached digital camera when the temperature inside the Case is

very high, it may cause leakage, short-circuiting or insulation failure resulting in

fire or malfunction.

≥Do not handle the digital camera or the battery with wet hands.

• This may cause an electric shock or malfunction.

∫When taking pictures with the flash

≥When taking pictures with the flash, the corners of the picture may be vignetted or

the picture may not be lit evenly.

≥When taking pictures with the flash, the available flash range is less underwater

than on land.

DMW-MCTZ3.book 7 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

Components

1. Zoom Lever

2. Strap Eyelet

(for attaching the supplied hand

strap and diffuser)

3. Shutter Button

4. Mode Dial

5. Front Case

6. Diffuser (supplied)

7. Front Glass

8. Camera ON/OFF Switch

9. 3/Exposure Compensation/

Auto Bracket/White Balance

Fine Adjustment/Backlight

Compensation In Simple

Mode Button

10. 1/Flash Setting Button

11. [MENU/SET] Button

12. [FUNC]/Delete Button

13. 4/[REV] Button

14. [DISPLAY/LCD MODE]

Button

15. 2/Self-timer Button/AF Lock

16. Rear Case

17. Buckle

18. Lock Release Lever

12 3 4 5

13141516

DMW-MCTZ3.book 8 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

What is the O-ring?

≥The O-ring is a waterproofing packing used for underwater cameras, watches and

diving equipment.

≥The O-ring keeps the Case waterproof by sealing the gap between the rear case

and the front case.

∫How the O-ring keeps the Case waterproof

The gum comes into contact with the sides of the Case making the

Case waterproof and stopping water from entering from the gap.

When water pressure acts on the O-ring, the surface of the O-ring

expands and the Case is sealed more tightly.

The O-ring prevents water leakage by coming into uniform

contact with the sides of the Case. Therefore, good care of the

O-ring is very important. Incorrect care of the O-ring may

cause water leakage.

O-ring

Digital Camera

Front Case

Rear Case

O-ring O-ring

Water Water

pressure

DMW-MCTZ3.book 9 ページ２００７年２月６日　火曜日　午後１時２１分

VQT1F25

Preparation -Setting the O-ring-

Be sure to set the O-ring before attaching a digital camera.

Thoroughly wash and dry your hands before handling the O-ring. Place

the O-ring where there is no sand or dust.

Loosen the O-ring with your fingers to remove it.

≥Loosen part of the O-ring with the tips of two fingers and then lift the loosened

part. Be careful not to scratch the O-ring with your fingernails.

∫Note

≥Do not use a pointed object to remove the O-ring. This may scratch the O-ring.

O-ring

MARINE BODY.fm 10 ページ２００７年２月７日　水曜日　午後３時３１分

Table des matières

Autres manuels Panasonic Accessoires pour appareils photo

Panasonic

Panasonic LUMIX DMW-MCTZ3E Manuel utilisateur

Panasonic

Panasonic WV7230 - CCTV ACCESSORIES Manuel utilisateur

Panasonic

Panasonic PUM8 Manuel utilisateur

Panasonic

Panasonic Videolarm POD9CW Manuel utilisateur

Panasonic

Panasonic AKHVF931P - VF FOR AKHC930 Manuel utilisateur

Panasonic

Panasonic DMC-G1K - Lumix Digital Camera Manuel utilisateur

Panasonic

Panasonic AW-PB309P/E Manuel utilisateur

Panasonic

Panasonic AWPH360N - PAN/TILT HEAD Manuel utilisateur

Panasonic

Panasonic Micro-Imagechecker AX30 Manuel utilisateur

Panasonic

Panasonic AJHVF21G - HD EVF - MULTI-LANG Manuel utilisateur

Panasonic

Panasonic YAX800G Manuel utilisateur

Panasonic

Panasonic H-FSQ 14045 Manuel utilisateur

Panasonic

Panasonic AW-PB504N Manuel utilisateur

Panasonic

Panasonic VW-BTA1 Manuel utilisateur

Panasonic

Panasonic WV-Q160C Manuel utilisateur

Panasonic

Panasonic LC-R127R2P Manuel utilisateur

Panasonic

Panasonic VIDEOALARM PODV7CPNS Manuel utilisateur

Panasonic

Panasonic WV-Q122AS Manuel utilisateur

Panasonic

Panasonic AJ-VF15BP Manuel utilisateur

Panasonic

Panasonic HHR370AH Manuel utilisateur

Panasonic

Panasonic ML614 Manuel utilisateur

Panasonic

Panasonic DMW-USBC1 Manuel utilisateur

Panasonic

Panasonic DVCPRO AJ-CA901 Manuel utilisateur

Panasonic

Panasonic AK-HRP150 Manuel utilisateur

Manuels Accessoires pour appareils photo populaires d'autres marques

Viltrox

Viltrox EF-NEX Instructions d'installation

Calumet

Calumet 7100 Series CK7114 Manuel utilisateur

Ropox

Ropox 4Single Series Manuel utilisateur

Cambo

Cambo Wide DS Digital Series Mode d'emploi

Samsung

Samsung SHG-120 Manuel utilisateur

Ryobi

Ryobi BPL-1820 Manuel d'utilisation

Aegis

Aegis ABL-36020P Manuel utilisateur

Pentax

Pentax Data Back Fc Manuel utilisateur

Fantasea

Fantasea EyeGrabber F Series Manuel utilisateur

Honeywell

Honeywell HDZ20HD Manuel utilisateur

EGO

EGO BA1400T Manuel utilisateur

Sima

Sima SRW-62 Manuel utilisateur

Shape

Shape A7SSMKIT Manuel utilisateur

Slide Kamera

Slide Kamera HST-2 Manuel utilisateur

Power works

Power works 2902613 Manuel utilisateur

SES

SES SE-2047-2 Manuel utilisateur

Olympus

Olympus PT-EP05L Manuel utilisateur

Starlite

Starlite OctoDome nxt Manuel utilisateur
