Panasonic KX-TG2200B Manuel utilisateur

2.4GHz FHSS Cordless Answering System

Model No. KX-TG2200B

Pulse-or-tone-dialing capability

Operating Instructions

Charge the battery for about 8 hours before initial use.

PLEASE READ BEFORE USE AND SAVE.

Contents:

Location of controls 2

Installation 5

Handset battery charge 10

Making/Answering calls with the base unit 11

Making/Answering calls with

the cordless handset 12

Caller ID Service 13

Voice Mail System 13

Automated Attendant System 14

Answering System 15

Listening to messages 16

Important Safety Instructions 17

FCC and other information 19

–2–

Please read IMPORTANT SAFETY

INSTRUCTIONS on page 17 before use.

Read and understand all instructions.

Location of controls

■Base Unit

LINE1 Button and Indicator

LINE2 Button and Indicator

LINE3 Button and Indicator

LINE4 Button and Indicator

CONF (Conference)

Button

HOLD Button

STOP Button

VOICE MAIL Button

INTERCOM/

TRANSFER Buttons

DIGITAL SP-PHONE

(Speakerphone)/HEADSET

Button and Indicator

MIC (microphone)

ANSWER ON Buttons

–3–

■Base Unit

REDIAL Button

BATTERY Indicator

PAUSE/EDIT Button

CALL WAIT/FLASH

Button

FUNCTION Button

EXIT Button

Navigator Key ( , , , )

ENTER Button

CLEAR Button

TONE Button

Antenna

Display

Headset Jack

–4–

■Cordless Handset

Antenna

Display

Headset Jack

CLEAR Button

ENTER/ (Voice Mail)

Button

CONF (Conference)

Button

INTERCOM/HOLD/

TRANSFER Button

Charge Contacts

LINE Buttons

TALK Button

FUNC (Function)/

EXIT Button

TONE Button

REDIAL/PAUSE/

EDIT Button

CALL WAIT/FLASH

Button

Navigator Key

( , , , )

–5–

Installation

■Installing the backup battery in the base unit

A rechargeable Ni-Cd battery works as emergency power during a power

failure. The fully charged backup battery provides the base unit with 20

minutes operation. The battery is charged in the base unit while the AC

adaptor is connected. It takes 10 hours to charge fully.

Install the backup battery in the battery compartment, and close the cradle

cover.

•The battery cannot be overcharged.

■Charger

Attention:

The product you have purchased is powered by a nickel

cadmium battery which is recyclable.

At the end of its useful life, under various state and local laws, it

is illegal to dispose of this battery into your municipal waste

stream. Please call 1-800-8-BATTERY for information on how to

recycle this battery.

CHARGE

Charge Contacts

CHARGE Indicator

–6–

■Connect the handset to the base unit

Handset

■Connect the AC adaptor to the base unit

Raise the antenna.

Power Outlet

(AC 120 V, 60 Hz)

•USE ONLY WITH Panasonic AC ADAPTOR PQLV12.

•The AC adaptor must remain connected at all times. (It is normal for the

adaptor to feel warm during use.)

Handset Cord

AC Adaptor

•Use only a Panasonic Handset for the KX-TG2200B.

–7–

■Connecting the telephone line cord to 2 two-line telephone jack

LINE 1

LINE 2

Two-Line Telephone

Jacks (RJ14C)

4-Wired Telephone

Line Cords

LINE 3

LINE 4

–8–

■Connecting the telephone line cords to four single-line telephone

jacks

For this connection, please purchase two Panasonic T-adaptors and two

2-wired telephone line cords.

LINE 1

Single-Line

Telephone

Jacks (RJ11C)

4-Wired Telephone

Line Cords

LINE 2

LINE 3

LINE 4

2-Wired Telephone

Line Cords

2-Wired Telephone

Line Cords

T-Adaptor

–9–

■Connecting the AC Adaptor to the charger

•USE ONLY WITH Panasonic AC ADAPTOR TCA1.

•The AC adaptor must remain connected at all times. (It is normal for the

adaptor to feel warm during use.)

Power Outlet

(AC 120 V, 60 Hz)

AC Adaptor

CHARGE

–10–

Handset battery charge

■Recharge

Recharge the battery when:

–" " flashes on the display, or

–the handset beeps every minute while it is in use.

•Clean the charge contacts of the handset and charger with a soft dry

cloth once a month. Clean more often if the unit is subject to grease,

dust or high humidity. If not, the battery may not charge properly.

•If the battery is fully charged, you do not have to place the handset on the

charger until " " flashes. This will maximize the battery life.

•The battery cannot be overcharged.

To power the cordless handset, charge the battery.

Place the handset on the charger for about 8 hours before initial use.

•The CHARGE indicator lights.
