Panasonic KX-TG2386 Manuel utilisateur

– 1 – PQQW13469ZA F0504-0 D

2.4 GHz Digital Cordless Answering System

Model No. KX-TG2386

Quick Set-Up Guide

Please read the Operating Instructions for further details.

Step 1 Setting Up the Base Unit

• USE ONLY WITH Panasonic AC ADAPTOR PQLV1.

• Use only the telephone line cord included in the unit.

• Make sure that the AC adaptor and telephone line cords are plugged into the unit

properly.

• If the unit is connected to a telephone line with DSL service, see page 9 in the

Operating Instructions.

Step 2 Setting Up the Handset

Install the battery.

Insert the battery (1), and

press it down until it snaps

into the compartment (2).

Close the cover.

Charge the battery

for 6 hours before initial use.

• The unit beeps once, the CHARGE indicator lights, and

“Charging” is displayed.

• When the battery is fully charged, “Charge

completed” is displayed.

Telephone Line Cord

AC Adaptor

Fasten the cords to prevent

them from being disconnected.

CHARGE Indicator

PQQW13469ZA.fm 1 ページ２００４年６月７日　月曜日　午後２時２３分

– 2 –

Step 3 Setting Date and Time

1Press [MENU].

2Scroll to “Date and time” by

pressing [

]or [

], then press

the soft key (Select).

31Enter 2 digits each for the

month, day, and year. (Ex.

To set May. 15, 2004, enter

“05 15 04”.)

2Enter 4 digits for the time

(hour and minute). (Ex. To set

9:30, enter “0930”.)

• To move the cursor, press [

]or

[

4Select “AM” or “PM” by pressing

the soft key (AM/PM).

5Press the soft key (Save), then

press [OFF].

•To confirm the date and time,

repeat steps 1 and 2.

(The current date and time are

displayed.) When finished, press

[OFF].

Step 4 Recording Your Own Greeting (Optional)

You can record a personal greeting message of up to 2 minutes. If you do not record

your own message, one of two pre-recorded greetings will be played for callers.

For details, see pages 23 – 25 in the Operating Instructions.

123

Press

[GREETING REC]

twice.

After the long beep,

talk into the MIC.

When finished,

press

[GREETING REC]

or [STOP].

Date and time

Back Select

Example

Date:

12.31.2004

Time:12:00 AM

AM/PM Save

Date:

05.15.2004

Time:09:30 AM

AM/PM Save

Date:

05.15.2004

Time:09:30 AM

AM/PM Save

PQQW13469ZA.fm 2 ページ２００４年６月７日　月曜日　午後２時２３分

– 3 –

Step 5 Subscription Service

In order to use Caller ID, Call Waiting or Call Waiting Caller ID, you must first

subscribe to the desired service.

For more information, contact your telephone company.

If you want to use the Call Waiting Caller ID feature, but it does not

function at all.

You may need to contact your telephone company to activate this specific service, even

if you already subscribed to both Caller ID and Call Waiting with Caller ID services

(CWID).

If you subscribe to a flat rate bundle service including Caller ID, Call

Waiting, Voice Mail and unlimited local/regional/long distance calls,

please read the following.

a) To use the Voice Mail service provided by the telephone company rather

than the unit’s Answering System, please turn off the Answering System by

pressing [ANSWER ON] on the base unit.

• This unit does not have an indicator to indicate if there are new messages

in your mailbox service.

b) To keep using the Answering System rather than the Voice Mail service

provided by your telephone company, please contact your telephone

company to deactivate the Voice Mail service in your bundle service.

If the telephone company cannot do that, please set the number of rings so

that the telephone answering system can answer calls prior to Voice Mail

service. It is necessary to check the “Number of Rings” required to activate

the Voice Mail service provided by your telephone company before

changing this setting.

As an example to set Number of Rings to “2”:

Press [MENU] [0] [6] [1]. When “Number of rings” is displayed,

press [2] soft key (Save).

(Refer to page 75 in the Operating Instructions, if you need to set to the

different number.)

PQQW13469ZA.fm 3 ページ２００４年６月７日　月曜日　午後２時２３分

– 4 –

Location of Controls

Base unit

Handset

[MESSAGE/SLOW TALK]

Press once to playback messages.

Press during playback to slow down

playback speed.

[ANSWER ON]

Press to turn on/off the Answering System.

[GREETING REC]

(Record)

Press twice to record a

greeting message.

[GREETING CHECK]

Press to check the

greeting message.

[ERASE]

–Individual message:

Press during playback.

–All messages:

Press twice.

–Greeting:

Press after pressing

[GREETING CHECK].

[REDIAL]

Press to redial.

[FLASH/CALL WAIT]

Press to answer another incoming

call.

[MUTE]

Press to mute a conversation.

[SP-PHONE]

Press to begin or end a hands-free

phone conversation.

[C](TALK)

Press to make/answer calls.

[s](Speakerphone)

Press to turn on,

to begin a hands-free

phone conversation.

[FLASH/CALL WAIT]

Press to answer another

incoming call. [REDIAL]

Press to redial.

[OFF]

Press to end calls or exit

programming/phone book/

Caller List.

Navigator Key

Microphone

Soft keys

[MENU]

Press to enter programming

mode.

Display

Ringer/Message Alert

Indicator

PQQW13469ZA.fm 4 ページ２００４年６月７日　月曜日　午後２時２３分

– 5 –

Handset soft keys

• When a function name does not appear above a soft key, the soft key has no function.

Handset navigator key

Two soft keys are used to select functions displayed directly

above each key. Functions displayed above the keys will

change depending on the state of use.

On this sample display, “ (VE)” and “Mute ” are displayed

above soft keys.

Scrolls up [

]and down [

]the function menu, the Caller List

and the phone book.

Increases [

]or decreases [

]the handset ringer and receiver/

speaker volumes.

Throughout this guide, the navigator key is indicated by the arrows [

]or [

Using Phone Book

a) Storing Names and Numbers

Press the soft keys (Phone book) and (Add), then enter a name and

phone number using dialing buttons (0–9), navigator keys (

) and

soft keys by following display.

(Refer to page 44 in the Operating Instructions for details.)

b) Dialing from the Phone Book

Press the soft keys (Phone book) and (Search). Search for the desired

item by pressing [

] or [

], then press [

] or [

(Refer to page 46 in the Operating Instructions for details.)

c) Chain Dial

You can dial a combination of phone book or manual key pad entries while

making a call. This feature can be used, for example, to first automatically

dial a calling card access number that you have stored in the phone book,

then manually or automatically dial your PIN and then automatically dial the

destination number from the phone book.

Press [MENU] while you are on a call. Search for the desired item by

pressing [

] or [

], then press the soft key (Call).

• If required, repeat steps for any remaining numbers.

(Refer to page 48 in the Operating Instructions for details.)

Talk

00-00-32

(VE) Mute

KL KL

Pressing the right soft key selects mute “Mute

”.

Pressing the left soft key selects Voice Enhancer “ (VE)

”.

PQQW13469ZA.fm 5 ページ２００４年６月７日　月曜日　午後２時２３分

– 6 –

Using Caller List

Please make sure that you have already subscribed to Caller ID service.

a) Viewing the Caller List

Press the soft key (Rcvd calls), then press [

] to search the Caller

List.

(Refer to page 38 in the Operating Instructions for details.)

b) Calling Back from the Caller List

Press [

] or [

] while you are viewing a phone number to call back.

If you need to edit a phone number before calling back, press the soft

key (Select). You can delete “1” or “1 with area code” by pressing the

soft key (Edit) repeatedly.

(Refer to page 39 in the Operating Instructions for details.)

c) Caller ID Number Auto Edit

Once you call back an edited number (see above), this unit can

automatically edit incoming phone numbers from the same area code in the

Caller List and each time you receive a call.

You need to turn on this feature. (*Factory preset is on.)

(Refer to page 41 in the Operating Instructions for details.)

Using One-Touch Dialer

a) Storing Names and Numbers

Press the soft keys (Phone book) and (Search), then search for the

desired item using navigator keys (

) then press [MENU], [1], and

soft keys by following display.

(Refer to page 50 in the Operating Instructions for details.)

b) Dialing from the One-Touch Dialer

Press and hold the desired registration number using dialing button

(0–9), then press [

] or [

(Refer to page 51 in the Operating Instructions for details.)

PQQW13469ZA.fm 6 ページ２００４年６月７日　月曜日　午後２時２３分

– 7 –

Listening to Messages

a) Playing Back New Message

When the NEW MESSAGE indicator FLASHES on the

base unit, press [MESSAGE/SLOW TALK].

b) Playing Back Old Message

When the NEW MESSAGE indicator DOES NOT FLASH,

press [MESSAGE/SLOW TALK].

Using Other Useful Features

a) Message Alert

The Ringer/Message Alert indicator on the handset will flash slowly

when you have new messages in the Answering System.

You need to turn on this feature to use.

(Refer to page 28 in the Operating Instructions for details.)

To turn on Message Alert : Press [MENU] [0] [#] [1] soft key (Save).

b) Talking Caller ID

The handset and base unit will announce the displayed name every ring if

name-and-number Caller ID is available.

You need to subscribe to Caller ID service to use this feature.

And you need to turn on this feature. (*Factory preset is on.)

(Refer to pages 36 and 37 in the Operating Instructions for details.)

Other Operation and Information

For information on other functions, refer to the following pages in the

Operating Instructions.

Adjusting Receiver/Speaker Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 30

Selecting Ringer Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 18, 19

Caller ID Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 35

Phone Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 44

One-Touch Dialer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 50

Answering System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 23, 61

Changing Number of Rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 26

Remote Operation from a Touch Tone Phone . . . . . . . . . . . . . . . . . . . . . . . p. 67

Call Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 62

Voice Enhancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 32

Direct Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 74, 75

PQQW13469ZA.fm 7 ページ２００４年６月７日　月曜日　午後２時２３分

IMPORTANT!

If your product is not working properly. . .

1. Read this Quick Set-Up Guide or Operating Instructions

2. Visit our website: http://www.panasonic.com/support

3. Contact us via the web at: http://www.panasonic.com/contactinfo

4. Call us at: 1-800-211-PANA(7262)

To order battery, 1-800-332-5368

http://www.panasonic.com/batterystore

PQQW13469ZA.fm 8 ページ２００４年６月７日　月曜日　午後２時２３分

Autres manuels pour KX-TG2386

Table des matières

Autres manuels Panasonic Répondeur

Panasonic

Panasonic KX-TG2721AL Manuel utilisateur

Panasonic

Panasonic KX-TG6841BXB Manuel utilisateur

Panasonic

Panasonic KX-TG7862NZ Manuel utilisateur

Panasonic

Panasonic KX-TG2248S - 2.4 GHz Digital Cordless Phone Answering... Instructions d'utilisation et d'installation

Panasonic

Panasonic KX-TG6481FX Manuel utilisateur

Panasonic

Panasonic KX-TG2257S - 2.4 GHz Digital Cordless... Manuel utilisateur

Panasonic

Panasonic KX-TG6631 Manuel utilisateur

Panasonic

Panasonic KX-TC1891B Manuel utilisateur

Panasonic

Panasonic KX-TG633SK Manuel utilisateur

Panasonic

Panasonic kx-tg5438c Manuel utilisateur

Panasonic

Panasonic KX-TM85B Manuel utilisateur

Panasonic

Panasonic KXTCC936B - CORDLESS 900 ANALOG Manuel utilisateur

Panasonic

Panasonic KX-TCD775E Manuel utilisateur

Panasonic

Panasonic KX-TG9372C Manuel utilisateur

Panasonic

Panasonic KX-TG5871AL Manuel utilisateur

Panasonic

Panasonic KX-T8100 Manuel utilisateur

Panasonic

Panasonic KX-TGE820E Manuel utilisateur

Panasonic

Panasonic KX-TG2570F Manuel utilisateur

Panasonic

Panasonic KX-TG6591T Manuel utilisateur

Panasonic

Panasonic KX-TG2680N Manuel utilisateur

Panasonic

Panasonic KX-TS620W Manuel utilisateur

Panasonic

Panasonic KX-TGE240B Manuel utilisateur

Panasonic

Panasonic X-TG9385BX Manuel utilisateur

Panasonic

Panasonic KX-TG9391 Manuel utilisateur

Manuels Répondeur populaires d'autres marques

Radio Shack

Radio Shack TAD-795 Manuel utilisateur

AT&T

AT&T 2455 Manuel utilisateur

BellSouth

BellSouth GH9488 Guide de sécurité

GE 2-9985 Manuel utilisateur

Krown

Krown PortaPrinter 2000STD Manuel utilisateur

AT&T

AT&T 1717 Manuel utilisateur

Alcatel

Alcatel TEMPORIS 55-CE Manuel utilisateur

AT&T

AT&T E2562 Manuel utilisateur

Telstra

Telstra Monitor 420 Manuel utilisateur

Kortex

Kortex IAM V90 Manuel utilisateur

Philips

Philips VOIP8551B/05 Manuel utilisateur

Topcom

Topcom LUCCA Answering Machine Manuel utilisateur

TIPTEL

TIPTEL Ergophone 307 Manuel utilisateur

Conairphone

Conairphone TAD2012 Manuel utilisateur

AT&T

AT&T 1738 Manuel d'utilisation

Philips

Philips SE6554B/05 Manuel utilisateur

Lucent Technologies

Lucent Technologies Definity System 75 Manuel utilisateur

Sony

Sony TAM-2000 Manuel utilisateur
