Panasonic KX-TG7180E Manuel utilisateur

PQQW15294ZA DC0806PM0

Digital Cordless Answering System

Model No. KX-TG7160E

KX-TG7180E

1Connections

2Battery installation/

Battery charge (Initial charge: 7 hours)

Note:

LUse only the included rechargeable batteries.

Quick Guide

(220–240 V, 50 Hz)

To telephone network

Hook

Use only the included AC adaptor

and telephone line cord.

The pictured model is KX-TG7160.

Charge

contact

TG7160_7180E(e)_QG.fm Page 1 Thursday, July 27, 2006 12:08 PM

–2 –

3Bone conduction earpiece (KX-TG7180 only)

Note:

LThe effectiveness of the bone conduction earpiece will vary by the type and degree of

hearing loss of the user.

4Symbols used in these operating instructions

Date and time

1{j/OK}

2Press {^} or {V} to select “Handset Setup”. i{>}

3Press {^} or {V} to select “Time Settings”. i{>}

4Press {^} or {V} to select “Set Date & Time”. i{>}

5Enter the current day, month, and year.

6Enter the current hour and minute.

7{j/OK}i{ih}

5Accessibility

Caller ID announce

When you receive an outside call which has phone number information, the handset

announces the displayed phone number from the handset speaker.

LTo announce outside caller’s phone number, you must first subscribe to Caller ID service.

Consult your service provider/telephone company for details.

List announce

The handset announces phone numbers from the handset speaker while you are viewing the

redial list, caller list, and phonebook.

The handset features a

bone conduction

earpiece that uses

vibrations to create

sound during your

telephone

conversations.

Place the bone conduction

earpiece against your face

(not your ear).

Try different locations to

find which location works

best. Start with the temple

area.

Symbol Meaning

{j/OK}Press {j/OK}.

iProceed to the next operation.

“ ” Select the words in quotations shown on the display (e.g., “Handset

Setup”) by pressing {^} or {V}.

Bone conduction

earpiece

TG7160_7180E(e)_QG.fm Page 2 Thursday, July 27, 2006 12:08 PM

–3 –

6Basic operations

Answering system

Feature Operation

Making a call Dial the phone number. i{C}/{s}

Answering a call {C}

Hanging up {ih}

Receiver/speaker volume Press {^} or {V} while on a call.

Last number redial {R} i{C}

Making a call with redial list {R} iPress {^} or {V} to select the desired

number. i{C}

Handset phonebook: storing an

entry (name and phone

numbers)

{k} i{j/OK}i“New Entry” i{>}i

Enter the party’s name (16 characters max.). i

{j/OK}iEnter the party’s phone number (24 digits

max.). i{j/OK}i“Save” i{>}i{ih}

LTo enter a name, see the character table in the

operating instructions.

Handset phonebook: making a

call

{k} iPress {^} or {V} to display the desired entry.

i{C}

Handset ringer volume {j/OK}i“Handset Setup” i{>}i

“Ringer Setup” i{>}i“Ringer Volume” i

{>}iPress {^} or {V} to select the desired volume.

i{>}i{ih}

Changing ringtone

(outside calls)

{j/OK}i“Handset Setup” i{>}i

“Ringer Setup” i{>}i“Ext. Ringtone” i

{>}iSelect the desired ringtone. i{>}i

{ih}

Feature Operation

Answering on/off {j/OK}i“Answer System” i{>}i

“Answer On” or “Answer Off” i{>}i{ih}

Listening to messages {j/OK}i“Answer System” i{>}i“Play

New Msg.” or “Play All Msg.” i{>}

TG7160_7180E(e)_QG.fm Page 3 Thursday, July 27, 2006 12:08 PM

–4 –

7Frequently asked questions

Question Cause & solution

What kind of power outlet

should I connect the AC

adaptor to?

LConnect the AC adaptor to a 220–240 V outlet.

Why is wflashing? LThe handset is too far from the base unit. Move closer.

LThe AC adaptor is not connected. Check the

connections.

LYou are using the handset or base unit in an area with

high electrical interference. Place the handset and base

unit away from interference sources, such as antennas

and mobile phones.

LThe handset is not registered to the base unit. Register it.

{j/OK}i“Handset Setup” i{>}i

“Registration” i{>}i“Register H.set” i

{>}iPress and hold {x} on the base unit for about 3

seconds, until the registration tone sounds. iWait until

“Enter Base PIN” is displayed. iEnter the base unit

PIN (default: “0000”). i{j/OK}

Why is the handset display

blank?

LThe handset is not turned on. To turn the power on, press

{ih} for about 1 second.

What should I do when the

handset does not turn on?

LMake sure that the batteries are installed correctly.

LFully charge the batteries.

LClean the charge contacts and charge again.

How long should I charge new

batteries?

LCharge the batteries for about 7 hours.

How long is the battery

operating time?

LWhen you are using fully-charged Ni-MH batteries

(included batteries)

;

In continuous use: 12 hours max. (KX-TG7160)/10 hours

max. (KX-TG7180)

In continuous standby mode: 150 hours max.

– It is normal for batteries not to reach full capacity at the

initial charge. Maximum battery performance is

reached after a few complete cycles of charge/

discharge (use).

– Actual battery performance depends on a combination

of how often the handset is in use and how often it is

not in use (standby).

Can I keep the handset on the

base unit or charger when I

am not using it?

LEven after the handset is fully charged, the handset can

be left on the base unit or charger without any ill effect on

the batteries.

TG7160_7180E(e)_QG.fm Page 4 Thursday, July 27, 2006 12:08 PM

–5 –

8Optional service (Caller ID)

If you subscribe to Caller ID service, you can:

9Sales and support information

When should I replace the

batteries?

LIf the batteries are fully charged until 1is displayed,

but 3is displayed after a few calls, replace the

batteries with new ones.

What is a PIN? LThe PIN is a 4-digit number that must be entered in order

to change certain base unit settings. The default PIN is

“0000”.

What do I need to do to

display caller information?

LYou need to subscribe to Caller ID service. Consult your

service provider/telephone company for details.

LThe message “You must first subscribe to

Caller ID.” will be displayed until you receive caller

information after subscribing to Caller ID service.

– display caller information

– announce the caller’s phone number (Caller ID announce)

Customer Care Helpline Tel. No.: U.K. 08700 100 076 / R.O.I. 01289 8333

Question Cause & solution

Tom

012345

Customer Care Centre

LFor customers within the UK: 08700 100 076

LFor customers within the Republic of Ireland: 01289 8333

LVisit our website for product information: www.panasonic.co.uk

LE-mail: customer.care@panasonic.co.uk

Direct Sales at Panasonic UK

LOrder accessory and consumable items for your product with ease and confidence by

phoning our Customer Care Centre Monday - Thursday 9:00am - 5:30pm, Friday 9:30am

- 5:30pm (Excluding public holidays).

Or go on line through our Internet Accessory ordering application at

www.panasonic.co.uk

Most major credit and debit cards accepted.

All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd.

It couldn t be simpler!

Also available through our Internet is direct shopping for a wide range of finished products,

take a browse on our website for further details.

TG7160_7180E(e)_QG.fm Page 5 Thursday, July 27, 2006 12:08 PM

IMPORTANT

If you have problems setting up or

operating this product please call

the Panasonic DECT Helpline

08700 100 076 (UK)

01289 8333 (Repl of Ireland)
