Panametrics C-RL Manuel utilisateur
panametrics.com
Copyright 2021 Baker Hughes company.
This material contains one or more registered trademarks of Baker Hughes Company and its subsidiaries
in one or more countries. All third-party product and company names are trademarks of their respective
holders.
Flow
Model C-RL
Ultrasonic Flow Transducer
Installation Guide
916-062 B
July 2021
ii
[no content intended for this page]
Model C-RL User’s Manual iii
Information Paragraphs
Note:
These paragraphs provide information that provides a deeper understanding of the situation, but is not
essential to the proper completion of the instructions.
IMPORTANT: These paragraphs provide information that emphasizes instructions that are essential to proper setup
of the equipment. Failure to follow these instructions carefully may cause unreliable performance.
Safety Issues
Auxiliary Equipment
Local Safety Standards
The user must make sure that he operates all auxiliary equipment in accordance with local codes, standards,
regulations, or laws applicable to safety.
Working Area
CAUTION! This symbol indicates a risk of potential minor personal injury and/or severe damage to
the equipment, unless these instructions are followed carefully.
WARNING! This symbol indicates a risk of potential serious personal injury, unless these
instructions are followed carefully.
WARNING! It is the responsibility of the user to make sure all local, county, state and national
codes, regulations, rules and laws related to safety and safe operating conditions are
met for each installation.
WARNING! For installations in potentially hazardous areas, be sure to read the Certification and
Safety Statements document at the end of this manual before beginning the
installation.
WARNING! Auxiliary equipment may have both manual and automatic modes of operation. As
equipment can move suddenly and without warning, do not enter the work cell of this
equipment during automatic operation, and do not enter the work envelope of this
equipment during manual operation. If you do, serious injury can result.
WARNING! Make sure that power to the auxiliary equipment is turned OFF and locked out before
you perform maintenance procedures on the equipment.
iv Model C-RL User’s Manual
Qualification of Personnel
Make sure that all personnel have manufacturer-approved training applicable to the auxiliary equipment.
Personal Safety Equipment
Make sure that operators and maintenance personnel have all safety equipment applicable to the auxiliary
equipment. Examples include safety glasses, protective headgear, safety shoes, etc.
Unauthorized Operation
Make sure that unauthorized personnel cannot gain access to the operation of the equipment.
Environmental Compliance
Waste Electrical and Electronic Equipment (WEEE) Directive
GE Measurement & Control is an active participant in Europe’s
Waste Electrical and Electronic Equipment
(WEEE)
take-back initiative, directive 2012/19/EU.
The equipment that you bought has required the extraction and use of natural resources for its production. It may
contain hazardous substances that could impact health and the environment.
In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the
natural resources, we encourage you to use the appropriate take-back systems. Those systems will reuse or recycle
most of the materials of your end life equipment in a sound way.
The crossed-out wheeled bin symbol invites you to use those systems.
If you need more information on the collection, reuse and recycling systems, please contact your local or regional
waste administration.
Visit www.bakerhughesds.com/health-safetyand-environment-hse for take-back instructions and more information
about this initiative.
Model C-RL Installation Guide v
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
2 Transducer Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
3 Dampening Material. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4 Installing the C-RL Transducers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.1 Choosing an Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.2 Obtaining the Transducer Spacing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.3 Installing the V Series Clamping Fixtures and Transducers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.4 What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
4.5 Installing the PI Fixture and Transducers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.6 What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
4.7 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
4.8 Transducer Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Contents
vi Model C-RL Installation Guide
Model C-RL Installation Guide 1
1 Introduction
The C-RL clamp-on ultrasonic flow transducers are used exclusively with the Panametrics Measurement & Control
line of ultrasonic flowmeters. These transducers are used to measure the flow of various gases through pipes having
diameters from 3/4 in. (20 mm) to 30 in. (750 mm). Such measurements are independent of the pipe material. This
manual provides details on the following topics:
• Transducer construction
• Dampening material
• Installation
• Maintenance
• Specifications
2 Transducer Construction
A transducer assembly includes a 316 stainless steel housing with a plastic wedge attached and a BNC-type
electrical connector. The transducer features both integral 3/4” NPT-M threads for mounting a junction box and
integral 5/8-24 UNEF threads for mounting a submersible connector if desired (see
Figure 1
below).
Figure 1: Transducer Assembly (Ref. dwg. 752-163)
5/8-14 UNEF Thread
Stainless Steel Housing
3/4” NT Thread
Plastic
BNC Connector
3”
4”
Wedge
2 Model C-RL Installation Guide
3 Dampening Material
Panametrics Measurement & Control strongly recommends applying DMP dampening material in all permanent
clamp-on applications to help eliminate noise. The following dampening materials are available:
•DMP-1 is a self-adhesive sheet for applications up to 200°F (93°C): The material comes as two 9.5-in. (24 cm)
wide sheets cut in sufficient length for your application. (Length twice the circumference of the pipe at the
installation site.)
•DMP-3 is a compound for applications over 150°F (65oC). The compound is applied to the pipe with a putty
knife.
• The
Pipe Dampening Jacket
(PDJ) is a sheath/jacket with DMP-3 pre-applied to the inside and is also used for
applications over 150oF (65oC). The PDJ is available for pipes 4”, 6”, 8”, 10” and 12” (100, 150, 200, 250 and 300
mm) in diameter.
At a minimum, you should consider applying dampening material if you have any of the following conditions:
• The distance from the nearest butt weld or pipe flange is less than 10 ft (3 m).
• The pipe size is under 16 in. (400 mm) diameter and the gas pressure is 200 psig (1378 kPa) or lower.
• The pipe is deformed (non-circular).
• The pipe is old, with a history of scaling or rust.
• The pipe experiences constant condensation on the outside.
Note:
Consult a Panametrics flowmeter applications engineer or sales engineer if you have any questions
regarding dampening material.
Details for properly installing the dampening material are discussed later in this manual.
