PairGain HTC-439 Manuel utilisateur

HIGAIN TEST CARD

PAIRGAIN TECHNOLOGIES, INC.

ENGINEERING SERVICES TECHNICAL PRACTICE

SECTION 150-101-100-02

Model List Number Part Number CLEI Code

HTC-439 1 150-1559-01 T1DQAB1J

150-101-100-02, Revision 02

ii June 8, 1999 HTC-439 List 1

Revision History of This Practice

PairGain and HiGain are registered trademarks of PairGain Technologies, Inc.

Information containedin thisdocumentis company privateto PairGain Technologies,Inc.,

and shall not be modified, used, copied, reproduced or disclosed in whole or in part without

the written consent of PairGain.

Other product names mentioned in this practice are used for identification purposes only

and may be trademarks or registered trademarks of their respective companies.

Revision Release Date Revisions Made

01 November 10, 1997 Initial Release

02 June 8, 1999 Reversed Tip and Ring pin assignments

150-101-100-02, Revision 02 Using This Technical Practice

HTC-439 List 1 June 8, 1999 iii

USING THIS TECHNICAL PRACTICE

Two types of messages, identified by icons, appear in the text.

DOCUMENTATION

If you have comments on this PairGain document, send an email to

technical_publications@pairgain.com. Type the product name and the

section number of the document in the subject area of the email message.

INSPECTING THE SHIPMENT

Upon receipt of the equipment:

•Unpack each container and visually inspect the contents for signs of

damage. If the equipment has been damaged in transit, immediately

report the extent of damage to the transportation company and to

PairGain. Order replacement equipment, if necessary.

•Check the packing list to ensure complete and accurate shipment of each

listed item. If the shipment is short or irregular, contact PairGain as

described inthe Warranty located inside the backcover. If you must store

the equipment for a prolonged period, store the equipment in its original

container.

Notes contain information about special circumstances.

Cautions indicate the possibility of equipment damage or

the possibility of personal injury.

Table of Contents 150-101-100-02, Revision 02

iv June 8, 1999 HTC-439 List 1

TABLE OF CONTENTS

Overview________________________________________________1

Features ....................................................................................1

Test Card ..................................................................................2

Installation ______________________________________________3

Testing a Circuit__________________________________________3

Appendix A - Specifications ________________________________6

Appendix B - Glossary_____________________________________7

Appendix C - Product Support______________________________8

Technical Support.....................................................................8

World Wide Web......................................................................8

Returns......................................................................................9

Certification and Warranty __________________Inside Back Cover

LIST OF FIGURES

Figure 1. HTC-439 List 1 Test Card.......................................................2

Figure 2. HTC-439 List 1 Test Connections...........................................5

LIST OF TABLES

Table 1. Test Connections ......................................................................4

150-101-100-02, Revision 02 Overview

HTC-439 List 1 June 8, 1999 1

OVERVIEW

This practice describes the PairGainHiGainTest Card HTC-439 List 1.

The HTC-439 provides a convenient method of testing Central Office (CO)

and Field Tip and Ring transmit and receive pairs from any standard T1-239

repeater slot.

FEATURES

•Four-position slider switch (S1) that allows you to select the kind of test

you wish to perform on the transmit (XMT) and receive (RCV) Tip and

Ring pairs on CO and field circuits:

–Open

–Short

–Loop Thru

–Loop Back (metallic)

•Test points that provide access to Tip and Ring circuits (CO and field)

and to frame ground.

•Miniature210jacks locatedwithinthe J1block thatprovide accesstoCO

and field Tip and Ring circuit sides.

•Designed to extend beyond the front plane of the shelf or enclosure into

which the HTC-439 is inserted to permit easy access to its test points.

Overview 150-101-100-02, Revision 02

2 June 8, 1999 HTC-439 List 1

TEST CARD

Test points on the HTC-439 (Figure 1) provide access to each circuit under

test as well as to frame ground. The four-position test slider switch (S1)

selects which test (Open, Short,Loop Thru, or Loop Back) is to be performed

on CO and field circuits. The Open switch position effectively provides a

splitting-type access to one pair of the CO and field sides and the 210 jacks.

The Loop Back or Loop Thru switch positions allow you to use the two

miniature 210 jacks located within the J1 block. All tests are run on both side

1 and side 2. Refer to “Testing a Circuit” on page 3 for further information.

Figure 1. HTC-439 List 1 Test Card

SIDE 1

TP5

TP6

TP9

TP8

TP3

TP4

TP12

TP11 TP1

FIELD

OPEN

SHORT

LOOP THRU

LOOP BACK

FIELD

SIDE 2

PairGain

S1 switch

positions Circuit schematic

Conector pins

Miniature

210 jacks

Test points

150-101-100-02, Revision 02 Installation

HTC-439 List 1 June 8, 1999 3

INSTALLATION

1Insert the HTC-439 into the shelf slot for the channel you want to test.

2Push the card all the way into the slot until the card is firmly seated.

TESTING ACIRCUIT

Use the HTC-439 to test circuits, as follows:

1Set the slider switch S1 to the type of test you want to perform (Open,

Short, Loop Thru, or Loop Back).

2Connect to test points as applicable. The connections of Tip and Ring

pairs of CO and field circuits for each setting of the switch are listed in

Table 1 on page 4 and illustrated in Figure 2 on page 5. (Pin numbers

correspond to the edge connector pins for each circuit.)

3Perform the selected test.

4Monitor the circuits at the corresponding test points on the card.

5Repeat steps 1 through 4 as required.

All wiringexternal to the productshould followthe provisions

of the current edition of the National Electrical Code.

Testing a Circuit 150-101-100-02, Revision 02

4 June 8, 1999 HTC-439 List 1

Table 1. Test Connections

Connect Pin Number To Pin Number

Loopback - This switch position connects the following circuits

CO Tip 6CO Tip 9

CO Ring 5CO Ring 8

Field Tip 4Field Tip 12

Field Ring 3Field Ring 11

Loopthru - This switch position connects the following circuits

CO Tip 6Field Tip 4

CO Ring 5Field Ring 3

CO Tip 9Field Tip 12

CO Ring 8Field Ring 11

Short - This switch position connects the following circuits

CO Tip 6CO Ring 5

CO Tip 9CO Ring 8

Field Tip 4Field Ring 3

Field Tip 12 Field Ring 11

Open - This switch position removes all connections between the circuits

150-101-100-02, Revision 02 Testing a Circuit

HTC-439 List 1 June 8, 1999 5

Figure 2. HTC-439 List 1 Test Connections

SIDE 1

TP5

TP6

TP9

TP8

TP3

TP4

TP12

TP11 TP1

FIELD

OPEN

SHORT

LOOP THRU

LOOP BACK

FIELD

SIDE 2

PairGain

To/From

CO Equipment

TP1

Test point 6

(TP6)

LOOP THRU TIP

TIP

RING

SIDE 1

SIDE 2

TIP

RING

SHORT TIP

TIP

RING

SIDE 1

SIDE 2

TIP

RING

OPEN TIP

TIP

RING

SIDE 1

SIDE 2

TIP

RING

To/From

Field

Equipment

FRAME GND

LOOP BACK TIP

TIP

RING

SIDE 1

SIDE 2

TIP

RING

TP6 TP4

TP5 TP3

TP9 TP12

TP8 TP11

Appendix A - Specifications 150-101-100-02, Revision 02

6 June 8, 1999 HTC-439 List 1

APPENDIX A - SPECIFICATIONS

Mounting Any T1-239 repeater mechanics slot

Environmental

Operating Temperature: 40 °F to + 149 °F (-40 °C to + 65 °C)

Operating Humidity: 5% to 95% (non condensing)

Dimensions and Weight

Height: 3.1 in. (7.87 cm)

Width: 0.6 in. (1.52 cm)

Depth: 8.4 in. (21.34 cm)

Weight: 0.30 lb. (0.66 kg)
