Overland Storage SnapServer 210 Manuel utilisateur

Snap Server™ 210

Snap Server™ 110

Quick Start Guide

and User CD

Kurzanleitung und Benutzer-CD

Guía de iniciación rápida y CD del usuario

Guide de mise en route rapide et CD de l’utilisateur

Guida rapida all’uso e CD utente

Р у к о в о д с т в о п о б ы с т р о й у с т а н о в к е и

компакт-диск User CD

Hardware Features

1 Power button 9 USB ports (4)

2 Reset button 10 Service connector

3 Power LED 11 Ethernet port

4 Status LED 12 Ethernet cable

5 Network LED 13 Power supply

6 Disk LED 14 Power connector retention clip

7 Kensington Lock connector 15 Power cables (1 US, 1 UK, 1 EU))

8 Power connector 16 Quick Start Guides and User CDs (3)

Note

The USB connectors on the back of the Snap Server cannot be used for administrative purposes. Snap Servers

are managed via the browser-based Administration tool.

3456

10 11

15 16

Quick Start Guide

and User CD

Kurzanleitung und Benutzer-CD

Guía de iniciación rápida y CD del usuario

Guide de mise en route rapide et CD de l’utilisateur

Guida rapida all’uso e CD utente

Руководство по быстрой установке и

компакт�диск User CD

Quick Start Guide

and User CD

Kurzanleitung und Benutzer-CD

Guía de iniciación rápida y CD del usuario

Guide de mise en route rapide et CD de l’utilisateur

Guida rapida all’uso e CD utente

Руководство по быстрой установке и

компакт�диск User CD

Quick Start Guide

and User CD

Kurzanleitung und Benutzer-CD

Guía de iniciación rápida y CD del usuario

Guide de mise en route rapide et CD de l’utilisateur

Guida rapida all’uso e CD utente

Руководство по быстрой установке и

компакт�диск User CD

About This Guide

This guide shows you how to connect your Snap Server 110 or 210 to your network and conﬁgure it using the

Guardian OS. The instructions consist of 5 steps:

Step 1: Verify the contents of your shipping package.•

Step 2: Connect power and network cables.•

Step 3: Turn on the Snap Server.•

Step 4: Connect to the Snap Server for the ﬁrst time.•

Step 5: Start Using your Snap Server.•

Step 1: Verify the Contents of the Shipping Package

Before you begin installation, check the contents of your Ship Kit to make sure you have all the components

described in the

Hardware Features

section.

Step 2: Connect Power and Network Cables

1 Use the provided ethernet cable to connect your Snap

Server to the network.

2 Insert the retention clip into the divets above the power

connector (see illustration).

3Connect the power supply to the server, inserting the cord

into the retention clip.

4Connect the power cord to a UPS and/or electrical

outlet.

Note: Snap Servers are designed to work with an APC-

brand, USB- or network-based UPS device to automatically

shut down cleanly in the event of an extended power failure.

You must conﬁgure the APC unit in the Administration Tool and in the APC user interface.

Step 3: Turn on the Snap Server

To turn on the server, press the power button on the front of the server.

The server will take a few minutes to initialize. When the Status light

begins to blink steadily (about once per second), your Snap Server is

operational.

Power

Step 4: Connect to the Snap Server for the First Time

Your Snap Server is preset to get an IP Address automatically. If your network does not assign IP Addresses

automatically, use the Connect Using Snap Server Manager procedure below to assign one manually.

1 Find the server name. The default server

name is SNAPnnnnnn, where nnnnnn is the

server number. The server number is a unique,

numerics-only string that appears on a label on

the underside of the server chassis.

2 In a Web browser, enter the following URL:

http://SNAPnnnnnn (where SNAPnnnnnn is

the server name)

3 Press Enter. The Web View screen opens.

Note If the Web View screen does not open,

use the Connect Using SSM procedure below.

4 Log into the Administration Tool. Click the

Administration link. In the login dialog box,

enter admin as the user name and admin as

the password, then click OK.

5 Complete the setup procedure using the Initial

Setup Wizard.

Connect Using Snap Server Manager (SSM)

Use this procedure if your network does not assign IP addresses automatically or cannot resolve the server name

to an IP address.

1 Install SSM. Double-click the Install_SnapServerTools.html ﬁle on your Snap Server User CD. Be sure to install

SSM on a computer residing on the same network segment as your Snap Server.

2Launch SSM. SSM will discover all Snap Servers on the local

network segments, and will display IP addresses for servers

with IP assignments and 10.10.10.10 for servers with no IP.

3If you need to assign an IP address, right-click the server name

and select Set IP Address. Enter an IP address and a subnet

mask, then click OK.

4Launch the Administration Tool. Right-click the server name and

select Launch Web Administration, as shown in the illustration.

5 Click the Administration link. In the login dialog box, enter

admin as the user name and admin as the password, then

click OK.

6Complete the setup procedure using the Initial Setup Wizard.

Step 5: Use your Snap Server

Once installed on your network, the Snap Server appears as a server with shared folders. You can use it to

organize and store ﬁles in the same way you use the folders on your local hard disk. By default, there are no

security restrictions when accessing the server, but you can conﬁgure your access and security settings through the

GuardianOS. See the User’s Guide for the Snap Server 110 and 210 for more information.

User CD

Warranty

Garantie

Garantía

Garantie

Garanzia

Гарантийные

обязательства

To obtain service or technical support for

your Snap Server, please visit our Web site at

http://www.snapserver.com, or call 1-888-343-SNAP. For immediate

response to a service inquiry, you can submit a question to our technical support

department using our Expert Knowledge Base System

http://www.snapserver.com/kb

Technischen Service

Sie finden den technischen Service oder Kundendienst für Ihren Snap Server auf unserer Website. Wenn Kunden

sofortige Antworten auf eine Serviceanfrage wünschen, können sie mit Hilfe unseres Expert Knowledge Base System

http://www.snapserver.com/kb

Obtención de servicio de asistencia

Para obtener servicio o asistencia técnica para su Snap Server, visite nuestro sitio Web. Para obtener respuesta inmediata a su solicitud de

asistencia, envíelas en la forma de preguntas a nuestro Sistema experto de base de conocimiento en

http://www.snapserver.com/kb

Obtention d‘un entretien

Pour un entretien ou une assistance technique concernant votre Snap Server, vérifiez notre site web. Pour obtenir une réponse immédiate à

une demande de service, vous pouvez envoyer une question à notre service d‘assistance technique en utilisant notre système de base de

connaissances experte

http://www.snapserver.com/kb

Richiesta di assistenza tecnica

Per informazioni su come richiedere assistenza o supporto tecnici sulle unità Snap Server, visiti il nostro website. Per assistenza

immediata su un problema, è possibile inviare una richiesta al reparto di assistenza tecnica tramite il sistema Expert

Knowledge Base, disponibile all’indirizzo

http://www.snapserver.com/kb

Сервисное обслуживание

Сведения о сервисном обслуживании серверов Snap Server посетите наше веб-узле.

Для быстрого получения ответа на технические вопросы от службы поддержки

их можно размещать в базе знаний Expert Knowledge Base System

по адресу

http://

www.snapserver.com/kb

70990872-003 Rev A

worldwide. All other product names or company names are the

property of their respective owners.

vorbehalten. Alle anderen Produktnamen und Firmennamen sind

Eigentum der jeweiligen Unternehmen.

derechos en el ámbito internacional. Todos los otros nombres

de productos o de compañías son propiedad de susrespectivos

priopietarios.

dans le monde entier. Tous les autres noms de produit ou de

société appartiennent à leurs détenteurs respectifs.

tutti i paesi del mondo. Tutti i nomi di prodotti e società sono di

proprietà dei rispettivi proprietari.

всех странах. Прочие названия изделий и компаний являются

собственностью соответствующих владельцев.

Locating your Snap Server

In this Operating System Go to...

Microsoft ® Windows

Network Neighborhood, My Network Places, or Network (under

Workgroup)

Macintosh ® Chooser, Network Browser, or Connect to Server menu

NFS Mount the desired Snap Server share

www.snapserver.com 1-888-288-4206
