Orlight LUMENFLEX-TOP Manuel utilisateur
FROM SOURCE TO SITE
Installation instructions
LUMENFLEX-TOP - Flexible LED Strip
www.orlight.com | 01923 851 890
www.orlight.com | 01923 851 890
24mm
17mm
SELF-LOCKING
50MM CLIP
Recomended spacing
<500mm
CORRECT BENDING
NOT SUITABLE FOR HANGING INSTALLATION MINIMUM BEND DIAMETER
24mm
17mm
SELF-LOCKING
PROFILE
14mm
22mm
STANDARD
PROFILE
Light Surface
Light Surface
Ò
Ò
Ò
Ò
Light Surface
Recommened Use
Light SurfaceLight Surface
Light Surface
Ò
120mm
light
Aluminium Profile
c d
InstallationSurface
a
Screwb
SELF-LOCKING PROFILE
INSTALLATION
InstallationSurface
a
Screw
STANDARD PROFILE
INSTALLATION
b
FROM SOURCE TO SITE
www.orlight.com | 01923 851 890
V 2.01RFX-T
We recommend that this product is installed by a competent person in accordance with the latest edition of
the IET Wiring Regulations BS 7671 “Requirements for Electrical Installations” and the Buildings Regulations,
as may be applicable subject to the location and country of the job or installation.
For more information and installation guide lines please refer to “Guide on Lighting Risks and Regulations”
which can be downloaded from the website:
http://media.orlight.com/media/downloads/Orlight_guide_on_lighting_risks.pdf
* Please note, all information contained within this instruction manual is provided in good faith. We will not
be held responsible for any losses incurred as a result of any inaccuracies contained within this document.
