Rainbow Clock with 8 Soothing Sounds and FM Radio

Model: RRM902 / RRM902U / RRM902A

USER MANUAL

OVERVIEW

FRONT VIEW

1. SNOOZE · SOUND: activate snooze alarm; turn

soothing sound on / off; select soothing sound

2. :clock signal reception indicator

3. ZONE: time zone offset

4. : external audio device successfully connected

5. : radio is on

6. : soothing sound is on

7. : radio station selected (user can set up to 8

stations); soothing sound selected for alarm option

8. Name of soothing sound selected is displayed

9. OFF Zz: sleep function enabled (ZZ) / disabled (OFF ZZ)

10. : remote sensor reception indicator

11. : daily alarm is on

12. VOL: volume level is displayed

BACK VIEW

1. : activate / deactivate alarm function; set alarm;

view alarm status (when radio is on)

2. : toggle station number (when radio is on); save

radio frequency

3. : turn radio on / off

4. TUNE +/-: auto search / adjust radio frequency

5. °C / °F: user selectable temperature units

6. DIMMER: select display brightness

7. COLOUR (OFF·PROGRAM·LOOP): activate /

deactivate color-changing light show; select pre-

programmed (sound speciﬁc) light show or rainbow

loop effect

8. : set clock

9. ZZ: activate sleep timer; adjust timer settings (120, 90,

60, 30, 15, 0)

10. VOL+ / VOL-: increase / decrease value

of the setting; increase / decrease volume

11. RESET: reset unit to default settings

12. SEARCH: initiate sensor search

13. PAUSE: select a speciﬁc color lighting; restart color-

changing effect

14. Socket for audio line-in

BOTTOM VIEW

1. Adapter socket

2. Battery compartment

REMOTE SENSOR

1. LED status indicator

2. Wall mount hole

3. Battery compartment

4. RESET hole: reset unit to default settings

5. CHANNEL switch: select Channel 1

GETTING STARTED

POWER SUPPLY

Adapter

The adapter powers the unit. Plug adapter into socket,

making sure the adapter is not obstructed and is easily

accessible to the unit.

To completely disconnect from power, the adapter should be

disconnected from the main unit.

NOTE The main unit and adapter should not be exposed to

wet conditions. No objects ﬁlled with liquid, such as vases,

should be placed on the main unit and adapter.

1 x CR2032 battery for memory back-up

To insert batteries:

1. Remove the battery compartment cover.

2. Insert the battery, matching the polarities.

3. Press RESET after each battery change.

LOCATION MEANING

Clock area Main unit batteries low

Outdoor temperature

area Sensor batteries low

REMOTE SENSOR

To set up the remote sensor:

1. Slide open the battery compartment.

2. Slide channel switch to select channel 1.

3. Insert the battery, matching the polarities.

4. Press RESET after each battery change.

5. Close the battery compartment.

6. Press and hold SEARCH on main unit to initiate search

and start receiving time and temperature data from the

sensor.

7. Place the sensor within 30 m (98 ft) of the main unit

using the table stand or wall mount.

TIP The transmission range may vary depending on many

factors. You may need to experiment with various locations

to get the best results.

NOTE Use alkaline batteries for longer usage and consumer

grade lithium batteries in temperatures below freezing.

SENSOR DATA TRANSMISSION

Outdoor sensor:

The sensor reception icon in the remote sensor area shows

the status:

ICON DESCRIPTION

Main unit is searching

for sensor(s)

A channel has been

found

The sensor cannot be

found

NOTE If the sensor is not found, check the batteries,

obstructions and remote unit location. Press and hold

SEARCH to force another sensor search.

For best results:

• Place the sensor out of direct sunlight and moisture.

• Position the sensor so that it faces the main unit,

minimizing obstructions such as doors, walls and

furniture.

• Place the sensor in a location with a clear view to the

sky, away from metallic / electronic objects.

• Position the sensor close to the main unit during cold

winter months as below-freezing temperatures may

affect battery performance and signal transmission.

TIP Ideal placements for the sensor would be in any

location on the exterior of the home at a height of not more

than 1.5m (5 ft) and which can shield it from direct sunlight

or wet conditions for an accurate reading.

CLOCK

CLOCK RECEPTION

This product is designed to synchronize its clock

automatically with a clock signal.

RRM902: EU: DCF-77 signal: within 1500km (932 miles) of

Frankfurt, Germany.

RRM902U: UK: MSF-60 signal: within 1500km (932 miles)

of Anthorn, England.

RRM902A: US: WWVB-60 signal: within 3200km (2000

miles) of Fort Collins, Colorado.

To enable / disable signal reception:

Press and hold VOL+ to enable, or VOL- to

disable signal reception.

NOTE Reception takes 2-10 minutes. If the signal is weak,

it can take up to 24 hours to get a valid signal.

If signal reception is unsuccessful, place your unit next to

a window, press and hold VOL+ to force another

signal search.

Clock signal reception indicator:

STRONG SIGNAL WEAK / NO SIGNAL

MANUALLY SET CLOCK

To set the clock manually, disable the clock signal reception

ﬁrst.

1. Press and hold .

2. Press VOL+ or VOL- to change the

settings.

3. Press to conﬁrm.

The setting order is: time zone offset, 12/24-hour format,

hour, minute.

RMR902 / RMR902U: Time zone offset sets the clock +/-

23 hours from the received clock signal time. If you have

deactivated the clock signal reception, do not set a value

for time zone.

NOTE If you enter +1 in the time offset setting, this will

give you your local time plus one hour. If you are in the US

(RRM902A) set the clock to:

0 for Paciﬁc time +1 for Mountain time

+2 for Central time +3 for Eastern time

AUDIO OPTIONS

SOOTHING SOUNDS

To activate / deactivate soothing sounds:

• Place ﬁnger on SNOOZE·SOUND for 2 seconds.

To toggle soothing sounds:

• Touch SNOOZE · SOUND repeatedly to select desired

sound (1-8).

The selected sound name and will be displayed.

NOTE This will automatically turn off the radio.

RADIO

To activate / deactivate radio:

• Press to turn radio ON / OFF.

The radio station selected with corresponding

frequency and will be displayed when radio is on.

NOTE This will automatically turn off the soothing sound.

To set radio station:

1. Press to turn radio on.

2. Press repeatedly to navigate to desired station

storage location (1-8).

3. Press and hold TUNE+ / TUNE- to auto search or press

TUNE+ / TUNE- to manually select frequency. Station

number will disappear

4. Once desired frequency has been found, press and hold

to save. Station number (e.g., ) indicates

where it has been stored.

5. Repeat steps 2 – 4 for all storage locations.

For your convenience, the volume and radio frequency will

be stored in memory for the next time radio is turned on.

To view alarm display (when radio is on):

• Press .

MUSIC FROM EXTERNAL AUDIO DEVICE

Using a cable, plug one end to your music storage device

and one end to audio line-in socket ( ) located at the

back of unit.

When cable has been successfully connected, will

be displayed on the LCD screen and sound will emit from

speakers.

NOTE

• To play music from external audio device, ensure

soothing sound and radio is turned off.

• Connecting / disconnecting of external audio device will

turn the alarm off.

VOLUME CONTROL

• Press VOL+ or VOL-.

ALARM

To set the alarm:

1. Press and hold .

2. Press VOL+ or VOL- to change the

settings.

3. Press to conﬁrm.

The setting order is: Hour, minute, alarm option (

soothing sound / beep or Radio), sound type (1-8:

soothing sound, 9: beep) or radio station, volume (cannot

be adjusted for beep alarm).

To toggle alarms ON / OFF:

1. Press to display alarm time.

2. Press again to turn alarm ON / OFF.

indicates alarm is on.

To silence the alarm:

• Touch SNOOZE · SOUND to silence it for 8 minutes

• Press any other key (except DIMMER) to turn the alarm

off and activate it again after 24 hours.

COLOR PLAY

To activate light show (looped):

• Slide COLOR switch to LOOP.

To stop light show at a particular color:

• Press PAUSE when it reaches desired color.

Press PAUSE again to restart loop.

Each soothing sound is programmed with a unique color-

changing light show which complements the music, improves

the ambience and adds a decorative touch to any room.

To start programmed light show:

• Slide COLOR switch to PROGRAM.

To deactivate light show:

• Slide COLOR switch to OFF.

SLEEP TIMER

To activate audio sleep timer:

• Press SLEEP to activate sleep timer.

Zz indicates sleep timer is on.

NOTE

• If neither soothing sound nor radio is activated when

SLEEP is pressed, the unit will automatically activate

the last audio type played.

• If either soothing sound or radio is playing when SLEEP

is pressed, the unit will start counting down sleep timer

and continue playing audio type.

To select duration:

• Press SLEEP repeatedly.

To view time remaining:

• Press SLEEP.

NOTE If external audio device is plugged in while sleep

timer is on (and radio / soothing sound is not playing),

OFFZZ will be displayed brieﬂy to indicate sleep function has

been temporarily disabled.

TEMPERATURE

To toggle temperature unit:

• Press °C / °F.

BACKLIGHT

To adjust brightness:

• Press DIMMER.

RESET

Press RESET to return to the default settings.

SPECIFICATIONS

TYPE DESCRIPTION

Main unit

L x W x H 155 x 43 x 145 mm

(6.1 x 1.7 x 5.7 in)

Weight 526 g (18.6 oz) without battery

FM 87.5 to 108 MHz

Power 4.5V adapter and 1x CR2032 for

memory back-up

Remote Sensor (THN132N)

L x W x H 92 x 60 x 20 mm

(3.6 x 2.4 x 0.8 in)

Weight 62g (2.22 oz)

Transmission

range 30m (98 ft) unobstructed

Frequency 433 MHz

Temperature

range

-30°C to 60°C

(-22°F to 140°F)

Power 1 x UM-3 (AA) 1.5V battery

PRECAUTIONS

• Do not subject the unit to excessive force, shock, dust,

temperature or humidity.

• Do not cover the ventilation holes with any items such

as newspapers, curtains etc.

• Do not immerse the unit in water. If you spill liquid over

it, dry it immediately with a soft, lint-free cloth.

• Do not clean the unit with abrasive or corrosive

materials.

• Do not tamper with the unit’s internal components. This

invalidates the warranty.

• Only use fresh batteries. Do not mix new and old

batteries.

• Images shown in this manual may differ from the actual

display.

• When disposing of this product, ensure it is collected

separately for special treatment and not as normal

household waste.

• Placement of this product on certain types of wood

may result in damage to its ﬁnish for which Oregon

Scientiﬁc will not be responsible. Consult the furniture

manufacturer's care instructions for information.

• The contents of this manual may not be reproduced

without the permission of the manufacturer.

• Do not dispose old batteries as unsorted municipal

waste. Collection of such waste separately for special

treatment is necessary.

• Please note that some units are equipped with a

battery safety strip. Remove the strip from the battery

compartment before ﬁrst use.

NOTE The technical speciﬁcations for this product and the

contents of the user manual are subject to change without

notice.

NOTE Features and accessories will not be available in all

countries. For more information, please contact your local

retailer.

ABOUT OREGON SCIENTIFIC

Visit our website (www.oregonscientiﬁc.com) to learn more

about Oregon Scientiﬁc products.

If you're in the US and would like to contact our Customer

Care department directly, please visit: www2.oregonscientiﬁc.

com/service/support.asp

For international inquiries, please visit:

www2.oregonscientiﬁc.com/about/international.asp

EU DECLARATION OF CONFORMITY

Hereby, Oregon Scientiﬁc, declares that this Rainbow Clock

with 8 Soothing Sounds and FM Radio (Model: RRM902 /

RRM902U / RRM902A) is in compliance with the essential

requirements and other relevant provisions of Directive

1999/5/EC. A copy of the signed and dated Declaration of

Conformity is available on request via our Oregon Scientiﬁc

Customer Service.

COUNTRIES RTTE APPROVAL COMPLIED

All EU countries,Switzerland CH

and Norway N

FCC STATEMENT

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) This

device must accept any interference received, including

interference that may cause undesired operation.

WARNING Changes or modiﬁcations not expressly

approved by the party responsible for compliance could void

the user's authority to operate the equipment.

NOTE This equipment has been tested and found to

comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference

in a residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee

that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

Autres manuels pour RRM902

Table des matières

Autres manuels Oregon Scientific Horloge

Oregon Scientific

Oregon Scientific BAR623PU Manuel utilisateur

Oregon Scientific

Oregon Scientific RM912E Manuel utilisateur

Oregon Scientific

Oregon Scientific RM912TCN Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR391PU Manuel utilisateur

Oregon Scientific

Oregon Scientific BAR223P Manuel utilisateur

Oregon Scientific

Oregon Scientific RM826A Manuel utilisateur

Oregon Scientific

Oregon Scientific CP100 Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR329P Manuel utilisateur

Oregon Scientific

Oregon Scientific RM329P Manuel utilisateur

Oregon Scientific

Oregon Scientific RM116E Manuel utilisateur

Oregon Scientific

Oregon Scientific WS902 Manuel utilisateur

Oregon Scientific

Oregon Scientific RMB899P Manuel utilisateur

Oregon Scientific

Oregon Scientific DP200 Manuel utilisateur

Oregon Scientific

Oregon Scientific RM822 Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR329P Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA G RRM222P Instructions d'installation

Oregon Scientific

Oregon Scientific PRYSMA B Manuel utilisateur

Oregon Scientific

Oregon Scientific RRM968P Manuel utilisateur

Oregon Scientific

Oregon Scientific RM962U Manuel utilisateur

Oregon Scientific

Oregon Scientific RM338P Manuel utilisateur

Oregon Scientific

Oregon Scientific BAR332ES Manuel utilisateur

Oregon Scientific

Oregon Scientific PROJI BAR369P Manuel utilisateur

Oregon Scientific

Oregon Scientific 983U Manuel utilisateur

Oregon Scientific

Oregon Scientific Glaze JW208 Manuel utilisateur

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

La Crosse Technology

La Crosse Technology WT-3141b Manuel

La Crosse Technology

La Crosse Technology W86531 Manuel utilisateur

Sharp

Sharp SPC900 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-50447 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur

LG LEC-005 Manuel utilisateur
