Oregon Scientific RMR682 Manuel utilisateur

Digital Thermometer with Ice Alert and

Radio-Controlled Clock

Model: RMR682

USER MANUAL

CONTENTS

Introduction ............................................................... 2

Overview .................................................................... 2

Front View .............................................................. 2

Back View .............................................................. 3

Remote Sensor (THN132N) ................................... 4

Getting Started .......................................................... 4

Power ..................................................................... 4

Remote Sensor ......................................................... 5

Sensor Data Transmission ..................................... 6

Clock .......................................................................... 6

Clock Reception ................................................... 6

Reception Signal .................................................. 6

Set Clock ............................................................... 6

Alarm ......................................................................... 7

Temperature .............................................................. 7

Temperature Trend ................................................. 8

Ice Warning ............................................................ 8

Hi / Lo Temperature Alarm ..................................... 8

Reset .......................................................................... 8

Precautions ............................................................... 8

Speciﬁcations ........................................................... 9

About Oregon Scientiﬁc ........................................ 10

EU-Declaration of Conformity ............................... 10

RMR682_M_EN_R4.indd 1 6/5/06 4:06:30 PM

INTRODUCTION

Thank you for selecting the Oregon ScientiﬁcTM Digital

Thermometer with Ice Alert and Radio-Controlled

Clock (RMR682). The main unit can support up to

3 sensors. To purchase additional sensors, please

contact your local retailer.

NOTE Please keep this manual handy as you use

your new product. It contains practical step-by-step

instructions, as well as technical speciﬁcations and

warnings you should know about.

OVERVIEW

FRONT VIEW

1. Channel number and sensor reception status

2. Sensor low battery warning

3. Maximum / minimum outdoor temperature reading

4. Indoor temperature display icon

5. Main unit low battery warning

6. Maximum / minimum indoor temperature reading

7. Alarm is set

8. AM / PM icon

9. Alarm is displayed

10. Radio-controlled clock reception icon

11. Hi / lo alarm is displayed

12. Outdoor temperature trend icon

13. Ice warning is active

14. Outdoor temperature reading

15. Indoor temperature trend icon

16. Indoor temperature reading

17. Time, alarm and date

RMR682_M_EN_R4.indd 2 6/5/06 4:06:36 PM

BACK VIEW

1. MEM: View current, maximum and minimum

temperature

2. TEMP HI / LO : Change settings or enable /

disable hi or lo temperature alarm for channel 1

3. / : Increase / decrease setting; activate /

deactivate clock reception signal

4. CHANNEL: Switch remote sensor display

5. MODE: Change settings / display

6. ALARM: View alarm status; set alarm

7. Battery compartment

8. °C / °F: Select temperature unit °C / °F

9. RESET: Reset unit to default settings

10. UK / EU switch

RMR682_M_EN_R4.indd 3 6/5/06 4:06:54 PM

GETTING STARTED

POWER

Insert batteries before ﬁrst use, matching the polarity

(+ and -).

NOTE Install batteries in the remote sensor before the

main unit. Press RESET after each battery change. Do

not use rechargeable batteries. We recommend that

you use alkaline batteries with this product for longer

usage and lithium batteries in temperatures below

freezing.

shows when batteries are low.

UNIT LOCATION

Main Indoor temperature area

Remote Outdoor temperature area

1 2 3

REMOTE SENSOR (THN132N)

1. LED indicator 1. Wall mount

2. Battery compartment

3. Battery door

4. Table stand

5. RESET hole

6. CHANNEL switch

RMR682_M_EN_R4.indd 4 6/5/06 4:07:03 PM

REMOTE SENSOR

The sensor collects temperature readings approx.

every 40 seconds and sends them to the main unit. The

main unit can collect data from up to 3 sensors.

To set up the sensor:

1. Slide open the battery door.

2. Insert the batteries, matching the polarity (+ / -).

Reset after each battery change.

3. Select a channel. Make sure you use a different

channel for each sensor.

4. Close the battery compartment.

5. Secure the sensor in the desired location using

the wall mount or table stand.

For best results:

• Place the sensor out of direct sunlight and moisture.

• Do not place the sensor more than 30 meters (100

feet) from the main (indoor) unit.

• Position the sensor so that it faces the main (indoor)

unit, minimizing obstructions such as doors, walls,

and furniture.

• Place the sensor in a location with a clear view to

the sky, away from metallic or electronic objects.

• Position the sensor close to the main unit during

cold winter months as below-freezing temperatures

may affect battery performance and signal

transmission.

The transmission range may vary depending on many

factors. You may need to experiment with various

locations to get the best results.

Standard Alkaline batteries contain signiﬁcant

amounts of water. Because of this they will freeze

in low temperatures of approximately -12°C (10°F).

Disposable Lithium batteries have a much lower

threshold for temperature with an estimated freezing

range of below -30°C(-22°F).

Wireless ranges can be impacted by a variety of factors

such as extremely cold temperatures. Extreme cold

may temporarily reduce the effective range between the

sensor and the base station. If the unit’s performance

fails due to low temperature, the unit will resume proper

functioning as the temperature rises to within the

normal temperature range (i.e. no permanent damage

RMR682_M_EN_R4.indd 5 6/5/06 4:07:09 PM

• MSF-60 generated from Rugby, England

The clock collects the radio signals whenever it is

within 1500 km (932 miles) of a signal.

NOTE Slide the EU / UK switch to appropriate position

for your location. Repeat each time you reset the unit.

NOTE Initial reception takes 2-10 minutes for ﬁrst set up

or when RESET is pressed. Once complete, the reception

icon will stop blinking. If the signal is weak, it can take up

to 24 hours to get a valid signal.

RECEPTION SIGNAL

STRONG WEAK NO SIGNAL

To enable and force a signal search:

Press and hold for 2 seconds.

To disable the signal reception:

Press and hold for 2 seconds.

SET CLOCK

If the clock signal reception is enabled and a signal is

being received the clock does not need to be manually

set.

will occur to the unit due to low temperatures).

SENSOR DATA TRANSMISSION

The reception icon in the outdoor temperature area

shows the status.

ICON DESCRIPTION

Main unit is searching for the

sensor(s)

A channel has been found and

sensor signal is being received

The sensor cannot be found.

Search for the sensor or check

batteries

To search for a sensor:

Simultaneously, press and hold MEM and CHANNEL

for 2 seconds.

NOTE If the sensor is still not found, check the

batteries, obstructions, and remote unit location.

CLOCK

CLOCK RECEPTION

This product is designed to synchronize its date and time

automatically once it is within range of a radio signal:

• DCF-77 generated from Frankfurt, Germany for

Central Europe

and “- -.-”(Outdoor

temperature area)

RMR682_M_EN_R4.indd 6 6/5/06 4:07:14 PM

To manually set the clock:

1. Press and hold MODE for 2 seconds.

2. Press and to change the settings.

3. Press MODE to conﬁrm.

4. The setting sequence is: time zone offset, 12 /

24 hour format, hour, minute, year, date / month

format, month, date, and display language.

NOTE The time zone offset can be used to set the

clock up to + / - 9 hours from the received clock signal

time. If you have disabled the clock signal reception

(i.e. manually setting the clock), do not set a value for

time zone offset.

NOTE The language options are (E) English, (F)

French, (D) German, (I) Italian, and (S) Spanish.

To switch the clock display:

Press MODE to toggle between:

• Clock with seconds

• Clock with day

• Calendar

ALARM

To set the alarm:

1. Press ALARM to view the alarm. will show on the

display.

2. Press and hold ALARM for 2 seconds.

3. Press or to change the hour / minute settings.

4. Press ALARM to conﬁrm.

To activate or deactivate the alarm:

Press ALARM when in the alarm display. appears

when the alarm is set.

To silence the alarm and reset it for the next day:

Press ALARM.

TEMPERATURE

To toggle the temperature unit:

Press °C / °F.

To view outdoor sensor temperature readings:

Press CHANNEL.

• shows which remote sensor’s data you are

viewing.

• is permanently displayed in the indoor

temperature area.

To auto-scan between sensors:

Press and hold CHANNEL for 2 seconds. Each

sensor’s data is displayed for 3 seconds.

To end auto-scan:

Press CHANNEL or MEM.

To toggle between current, minimum and maximum

records for the selected sensor:

Press MEM repeatedly.

To clear all records:

RMR682_M_EN_R4.indd 7 6/5/06 4:07:18 PM

To silence the hi / lo temperature alarm:

Press any key. The alarm resets automatically and will

resound if the hi / lo temperature selected is exceeded

again.

RESET

Press RESET to return the unit to the default

settings.

PRECAUTIONS

This product is engineered to give you years of

satisfactory service if you handle it carefully. Here are

a few precautions:

• Do not immerse the unit in water. If you spill liquid

over it, dry it immediately with a soft, lint-free cloth.

• Do not clean the unit with abrasive or corrosive

materials.

• Do not subject the unit to excessive force, shock,

dust, temperature or humidity, which may result in

malfunction, shorter electronic life span, damaged

battery and distorted parts.

• Do not tamper with the unit’s internal components.

Doing so will invalidate the warranty on the unit and

may cause unnecessary damage. The unit contains

no user-serviceable parts.

• Only use fresh batteries as speciﬁed in the user’s

instructions. Do not mix new and old batteries.

• Do not use rechargeable batteries.

• Remove batteries when storing the product for a

long time.

Press and hold MEM for 2 seconds.

TEMPERATURE TREND

Recent indoor / outdoor temperature trends are shown

by the trend icon.

RISING STEADY FALLING

ICE WARNING

If the channel 1 sensor falls between 3°C to -2°C (37°F

to 28°F), ﬂashes to warn you that the temperature is

approaching freezing.

NOTE The warning will automatically stop if the

temperature goes outside the ice-warning range.

HI / LO TEMPERATURE ALARM

An alarm can be set to sound if the sensor set to

channel 1 records above or below a temperature of

your choice.

To set alarm ON / OFF :

1. Press and hold TEMP HI / LO .

2. Use and to select high / low temperature

alarm. Press TEMP HI / LO to conﬁrm.

3. Press or to set alarm ON / OFF and press

TEMP HI / LO to conﬁrm.

4. If alarm has been activated, use or to select

the temperature.

5. Press TEMP HI / LO to conﬁrm.

RMR682_M_EN_R4.indd 8 6/5/06 4:07:23 PM

• Due to printing limitations, the displays shown in

this manual may differ from the actual display.

• The contents of this manual may not be reproduced

without the permission of the manufacturer.

• Do not dispose this product as unsorted municipal

waste. Collection of such waste separately for

special treatment is necessary.

NOTE The technical speciﬁcations for this product

and the contents of the user manual are subject to

change without notice.

SPECIFICATIONS

TYPE DESCRIPTION

Main unit

Dimensions 107 x 87 x 56 mm

(L x W x D) (4.2 x 3.4 x 2.2 in)

Weight 134 g (4.72 oz) without

battery

Remote unit

Dimensions 96 x 50 x 22 mm

(L x W x D) (3.8 x 2.0 x 0.9 in)

Weight 62 g (2.22 oz) without

battery

Temperature unit – °C / °F

Indoor range -5°C to 50°C (23°F to 122°F)

Outdoor range -30°C to 60°C

(-22°F to 140°F)

Resolution 0.1°C (0.2°F)

Remote unit

RF frequency 433MHz

Range Up to 30 m (100 ft)

with no obstructions

Transmission Approx. every 40 seconds

Channel no. 1, 2 or 3

Clock

Synchronization Auto or disabled

Clock display HH:MM

Hour format 12hr AM/PM or 24hr

Calendar DD/MM or MM/DD

Weekday in 5 (E, G, F, I, S)

languages

Alarm 2-minute alarm

Power

Main unit 2 x UM-4 (AAA) 1.5V

batteries

Remote unit 1 x UM-3 (AA) 1.5V

battery

NOTE We recommend that you use alkaline batteries

with this product for longer usage and lithium batteries

in temperatures below freezing.

RMR682_M_EN_R4.indd 9 6/5/06 4:07:24 PM

EU-DECLARATION OF CONFORMITY

Hereby, Oregon Scientiﬁc, declares that the Digital

Thermometer with Ice Alert and Radio-Controlled Clock

(Model RMR682) is in compliance with the essential

requirements and other relevant provisions of Directive

1999/5/EC.

A copy of the signed and dated Declaration of

Conformity is available on request via our Oregon

Scientiﬁc Customer Service.

COUNTRIES RTTE APPROVAL COMPLIED

All EU countries, Switzerland

and Norway

ABOUT OREGON SCIENTIFIC

Visit our website (www.oregonscientiﬁc.com) to

learn more about Oregon Scientiﬁc products such as

digital cameras; MP3 players; children’s electronic

learning products and games; projection clocks; health

and ﬁtness gear; weather stations; and digital and

conference phones. The website also includes contact

information for our Customer Care department in case

you need to reach us, as well as frequently asked

questions and customer downloads.

We hope you will ﬁnd all the information you need on

our website, however if you’re in the US and would

like to contact the Oregon Scientiﬁc Customer Care

department directly, please visit:

www2.oregonscientiﬁc.com/service/default.asp

Call 1-800-853-8883.

For international inquiries, please visit:

www2.oregonscientiﬁc.com/about/international.asp

RMR682_M_EN_R4.indd 10 6/5/06 4:07:24 PM

Table des matières

Langues :

Autres manuels Oregon Scientific Horloge

Oregon Scientific

Oregon Scientific RM888PA Manuel utilisateur

Oregon Scientific

Oregon Scientific RM913TCN Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR391P Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR939P Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA R Manuel utilisateur

Oregon Scientific

Oregon Scientific JM889NR Manuel utilisateur

Oregon Scientific

Oregon Scientific JM200 Manuel utilisateur

Oregon Scientific

Oregon Scientific RM802 Manuel utilisateur

Oregon Scientific

Oregon Scientific JM828CD Manuel utilisateur

Oregon Scientific

Oregon Scientific RM328PA Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR186 Manuel utilisateur

Oregon Scientific

Oregon Scientific PROJI Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA G Manuel utilisateur

Oregon Scientific

Oregon Scientific Jumbo JMR828A Manuel utilisateur

Oregon Scientific

Oregon Scientific RM313PU Manuel utilisateur

Oregon Scientific

Oregon Scientific JM889 Manuel utilisateur

Oregon Scientific

Oregon Scientific RM622PA Manuel utilisateur

Oregon Scientific

Oregon Scientific JMR868 Manuel utilisateur

Oregon Scientific

Oregon Scientific DP100 Manuel utilisateur

Oregon Scientific

Oregon Scientific RM968 Manuel utilisateur

Oregon Scientific

Oregon Scientific RM816P Manuel utilisateur

Oregon Scientific

Oregon Scientific RM998PS Manuel utilisateur

Oregon Scientific

Oregon Scientific Glaze JW208 Manuel utilisateur

Oregon Scientific

Oregon Scientific SENSES Aroma Clock with Brainwave Music... Manuel utilisateur

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

La Crosse Technology

La Crosse Technology WT-3141b Manuel

La Crosse Technology

La Crosse Technology W86531 Manuel utilisateur

Sharp

Sharp SPC900 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-50447 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur

LG LEC-005 Manuel utilisateur
