Oregon Scientific RM622PA Manuel utilisateur

CONTENTS

Introduction ............................................................. 2

Product Overview ................................................... 2

Front View ......................................................... 2

Back View ......................................................... 3

LCD Display ...................................................... 3

Getting Started ........................................................ 4

Batteries ............................................................ 4

AC Adaptor ....................................................... 4

Clock ........................................................................ 4

Activatin / Deactivatin the RF Si nal ............. 5

Setting the Clock Manually ....................................

The Alarm Function ................................................ 6

Displayin the Alarm Time ................................ 6

Settin / Activatin the Alarm Time ................... 6

The Snooze Function .............................................. 6

The Projector Function ........................................... 6

Adjustin the Projector ...................................... 7

Choosing Your Time Zone ..................................... 7

Indoor Temperature ................................................ 7

Resetting the Unit ................................................... 7

Safety and Care ....................................................... 7

Warnings .................................................................. 8

Troubleshooting ...................................................... 8

Specifications .......................................................... 8

Main Unit Dimensions ....................................... 8

Temperature ..................................................... 8

Clock ................................................................. 9

Power ................................................................ 9

About Oregon Scientific ......................................... 9

FCC Statement ...................................................... 10

Atomic Projection Clock

(RM622PA)

USER MANUAL

PRODUCT OVERVIEW

FRONT VIEW

1. SNOOZE / LIGHT button

2. UP and DOWN keys

3. MODE button

4. ZONE button

5. ALARM button

6. Swivel projection

7. LCD display

INTRODUCTION

Thank you for selectin the Ore on ScientificTM Atomic

Projection Clock (RM622PA). This device bundles precise

time keepin , alarm, and indoor temperature monitorin

features into a sin le tool you can use from the

convenience of your home.

In this box, you will find:

• Atomic Projection Clock

• 3.0V AC/DC adaptor with jack

Keep this manual handy as you use your new product.

It contains practical step-by-step instructions, as well as

technical specifications and warnin s you should know.

BACK VIEW

1. FOCUS knob

2. IMAGE ROTATION knob

3. Power adaptor socket

4. Battery compartment

5. PROJECTION ON switch

6. Table stand

7. RESET hole

LCD DISPLAY

1. Clock hour and minute

2. Radio frequency (RF) si nal reception

3. Alarm on icon

4. ((.)) Alarm time indicator

5. Alarm time (month / day) or calendar

6. U.S. map for time-zone selection

7. Clock seconds / lan ua e

8. Low battery indicator

9. Indoor temperature

AC ADAPTOR

The main unit has a 3.0V AC/DC adaptor with jack, which

provides continuous clock projection.

CLOCK

The clock automatically synchronizes the current time

and date when it is brou ht within ran e of the WWVB-

60 radio si nal (60 kHz) enerated from Fort Collins,

Colorado. For more information, please visit: http://www.

boulder.nist. ov/timefreq/stations/radioclocks.htm.

NOTE Initial reception takes 2-10 minutes and be ins

when you first set up the unit, and also whenever you

press RESET. Once complete, the reception icon will

stop blinkin .

GETTING STARTED

BATTERIES

Insert batteries before first use, matchin the polarity

(+ and -) as shown in the battery compartment. Press

RESET after each battery chan e.

shows on the LCD when battery power is low.

Replace batteries as soon as possible to maintain optimal

performance.

NOTE For optimal performance, use alkaline batteries

with this product and do not use rechar eable batteries.

ACTIVATING / DEACTIVATING THE RF SIGNAL

1. To activate the RF si nal, press and hold for 2

seconds.

2. To deactivate the RF clock reception, press and hold

ZONE for 2 seconds.

NOTE The RF si nal icon appears on the LCD when

it is activated and disappears when it is deactivated. If

the clock cannot recive any si nal reception, appears

instead of . See section on "Troubleshootin " for more

information.

SETTING THE CLOCK MANUALLY

The 12-hour clock automatically sets itself to the U.S.

Atomic Clock - it never needs adjustin for Dayli ht

Savin Time. The top line of the clock display shows

hours, minutes and seconds / day-of-the-week. To to le

between seconds and day-of-the-week display, press

MODE. The second line shows calendar (month and

date) / alarm time and indoor temperature.

To adjust the clock settin s manually without automatic

RF synchronization, remember to deactivate the radio

reception first.

Each of clock settin s can be adjusted in the followin

order: hour, minute, year, month, date, and lan ua e (E,

S, F).

1. Press and hold MODE for 2 seconds. The first

clock settin , the hour settin , be ins flashin .

2. Press or to adjust the hour values. To choose

the values more quickly, press and hold or

continuously.

3. To confirm and save the desired hour value, press

MODE. The next clock settin , the minute settin ,

automatically be ins flashin .

4. Repeat steps 2 and 3 to adjust the clock minute

values and the other clock settin s accordin ly.

5. After adjustin the hour and minute, you may decide

to skip adjustin the minute, year and month, and o

directly to adjust the date settin s. To skip any

settin , press MODE to navi ate throu h the items

until you reach the desired settin .

NOTE When adjustin the date on the second line of the

LCD, the correspondin day-of-the-week shown on the

LCD’s top line will chan e automatically.

NOTE The time is shown only in 12 hr AM/PM format. 24

hr format is not available in this unit.

NOTE Durin anytime you are in the middle of adjustin

a clock settin manually and is left idle for 1 minute, the

clock automatically saves the current settin chosen.

When the Snooze function is enabled, the Snooze

period will last 8 minutes before the alarm sounds a ain.

will flash coninuously on the LCD.

NOTE Pressin SNOOZE / LIGHT turns on the reen

LED backli ht that lasts for 5 seconds before automatically

turnin off. The backli ht does not turn on when any of

the other buttons are pressed.

NOTE The Snooze function will disable if the button is

pressed. The alarm time will remain activated and will

rin the followin day at the same time unless you press

a ain to turn off the alarm.

THE PROJECTOR FUNCTION

The projector displays the time via a bri ht red projection

li ht onto a wall, ceilin , or just about any surface for

easy and convenient viewin in a darkened room. The

time projected is shown as a sin le line (HH:MM) in

12-hour AM/PM format.

1. To activate the projection li ht, press SNOOZE /

LIGHT. The projector will project the time for 5

seconds before automatically turnin off.

2. To activate continuous projection, slide the

PROJECTION ON / OFF switch to ON. Note that

this function will not work unless the AC/DC adaptor

is used.

3. To deactivate continuous projection, slide the

PROJECTION ON switch to OFF.

THE ALARM FUNCTION

DISPLAYING THE ALARM TIME

By default, the second line of the unit's LCD screen

displays current month and date. To display the alarm

time instead, press once. To show the month and date

a ain, press MODE.

SETTING / ACTIVATING THE ALARM TIME

1. Press and hold for 2 seconds. The alarm hour will

flash.

2. Use or to set the hour. To choose the settin

more quickly, press and hold or continuously.

3. Press to confirm and save the desired hour settin .

The minutes will automatically flash.

4. Repeat steps 2 and 3 to set the minutes settin . The

alarm time has now been set and is automatically

activated. The alarm bell icon appears to the left of

the alarm time.

5. To deactivate the alarm, press the . The LCD no

lon er displays .

NOTE The alarm will automatically stop rin in after 2

minute. But after 8 minutes, the alarm will sound once

more unless is pressed.

THE SNOOZE FUNCTION

While the alarm is rin in , press the SNOOZE / LIGHT

to stop the alarm sound and activate the Snooze function.

NOTE If the unit is bein run on batteries, the

PROJECTION ON / OFF switch does not need to be on.

If you press SNOOZE / LIGHT, the projection li ht will

turn on anyway.

ADJUSTING THE PROJECTOR

The RM622PA allows you to adjust the projector so that

you are able to view the projection ima e with more

clarity and convenience.

• The projector head can vertically swivel 180º so that

you may view the time from different positions.

• The IMAGE ROTATION knob allows you to orient

the projected ima e (continuously from 0º to 330º

clockwise / counterclockwise) so that you can read

the time more conveniently.

• If the projected ima e is out of focus, use the ima e-

focusin knob to adjust accordin ly until the

projection is in focus.

CHOOSING YOUR TIME ZONE

The top ri ht of the RM622PA’s LCD screen shows a

U.S. map with 4 time zones: P (Pacific), M (Mountain), C

(Central) or E (Eastern). Choosin your specific time

zone makes it convenient to take the projection clock

with you and use anywhere durin your travels in the

country.

To choose your time zone, simply press ZONE repeatedly

to to le between the 4 zones and stop at the desired

settin . The time will automatically adjust accordin ly.

INDOOR TEMPERATURE

The Atomic Projection Clock monitors and displays

indoor temperature. The indoor temperature is shown in

Fahrenheit (°F) only. The unit is capable of measurin

temperatures within the +23°F to +122°F (-5°C to

+50°C) ran e.

RESETTING THE UNIT

The RESET hole is located in the main unit battery

compartment. Press RESET when you chan e the

batteries and whenever performance is not behavin as

expected (for example, unable to establish radio

frequency link). The clock will reset to its ori inal default

values.

SAFETY AND CARE

Clean the product with a sli htly damp cloth and alcohol-

free, mild deter ent. Avoid droppin the product or

placin it in a hi h-traffic location.

TROUBLESHOOTING

PROBLEM SYMPTOM REMEDY

Calendar Ille ible month / Chan e lan ua e

date

Clock Cannot adjust Disable atomic clock

clock

Cannot auto- 1. Adjust batteries

synchronize 2. Press RESET

date and time 3. Manually activate

clock feature

Temp Shows "LLL" or Temperature is out-of-

"HHH" ran e

SPECIFICATIONS

MAIN UNIT DIMENSIONS

Len th x Width x Hei ht: 5.27 x 2.04 x 3.23 in

(134 x 52 x 82 mm)

Wei ht: 5.71 oz (162 )

without battery

TEMPERATURE

Unit: °F

Indoor Ran e: +23°F to +122°F

(-5°C to +50°C)

WARNINGS

This product is desi ned to ive you years of service if

handled properly. Ore on Scientific will not be responsible

for any deviations in the usa e of the device from those

specified in the user instructions or any unapproved

alterations or repairs of the product. Observe the followin

uidelines:

• Never immerse the product in water. This can cause

electrical shock and dama e the product.

• Do not subject the main unit to extreme force, shock,

or fluctuations in temperature or humidity.

• Do not tamper with the internal components.

• Do not mix new and old batteries or batteries of

different types.

• Do not use rechar eable batteries with this product.

• Remove the batteries if storin this product for a lon

period of time.

• Do not scratch the LCD display.

NOTE The technical specifications of this product and

contents of this user manual are subject to chan e

without notice. Ima es not drawn to scale.

Resolution: 0.2°F (0.1°C)

CLOCK

RF Clock: Auto or manual (disabled)

Clock display: HH:MM:SS

Hour format: 12hr AM/PM

Calendar: MM/DD; weekday in

3 lan ua es

(En lish, Spanish, French)

Alarm: Sin le alarm with

2-minute crescendo

POWER

Main unit batteries: 2 x AA (UM-3) 1.5V

ABOUT OREGON SCIENTIFIC

Visit our website (www.ore onscientific.com) to learn

more about Ore on Scientific products such as di ital

cameras; MP3 players; children's electronic learnin

products and ames; projection clocks; health and fitness

ear; weather stations; and di ital and conference

phones. The website also includes contact information

for our customer care department in case you need to

reach us, as well as frequently asked questions and

customer downloads.

We hope you will find all the information you need on our

website, however if you'd like to contact the Ore on

Scientific Customer Care department directly, please

visit www2.ore onscientific.com/service/support OR call

949-608-2848 in the US. For international enquiries,

please visit www2.ore onscientific.com/about/

international/default.asp.

FCC STATEMENT

This device complies with Part 15 of the FCC Rules.

Operation is subject to the followin two conditions: (1)

This device may not cause harmful interference, and (2)

This device must accept any interference received,

includin interference that may cause undesired

operation.

WARNING Chan es or modifications to this unit not

expressly approved by the party responsible for

compliance could void the user's authority to operate the

equipment.

NOTE This equipment has been tested and found to

comply with the limits for a Class B di ital device,

pursuant to Part 15 of the FCC Rules. These limits are

desi ned to provide reasonable protection a ainst

harmful interference in a residential installation.

This equipment enerates, uses and can radiate radio

frequency ener y and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no uarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turnin the equipment off

and on, the user is encoura ed to try to correct the

interference by one or more of the followin measures:

• Reorient or relocate the receivin antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Consult the dealer or an experienced radio / TV

technician for help.

Autres manuels pour RM622PA

Table des matières

Autres manuels Oregon Scientific Horloge

Oregon Scientific

Oregon Scientific RM313PNFA Manuel utilisateur

Oregon Scientific

Oregon Scientific RM962U Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR500ES Manuel utilisateur

Oregon Scientific

Oregon Scientific RM602 Manuel utilisateur

Oregon Scientific

Oregon Scientific JMR868 Manuel utilisateur

Oregon Scientific

Oregon Scientific RM913TCN Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR601 Manuel utilisateur

Oregon Scientific

Oregon Scientific RM928 Manuel utilisateur

Oregon Scientific

Oregon Scientific SENSES Aroma Clock with Brainwave Music... Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuel utilisateur

Oregon Scientific

Oregon Scientific RM308PX Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR331ES Manuel utilisateur

Oregon Scientific

Oregon Scientific RM338P Manuel utilisateur

Oregon Scientific

Oregon Scientific JW108 Manuel utilisateur

Oregon Scientific

Oregon Scientific JA200 Manuel utilisateur

Oregon Scientific

Oregon Scientific RRM320P Manuel utilisateur

Oregon Scientific

Oregon Scientific rm318p Manuel utilisateur

Oregon Scientific

Oregon Scientific NR868A-01 Manuel utilisateur

Oregon Scientific

Oregon Scientific JMR818WF Manuel utilisateur

Oregon Scientific

Oregon Scientific BAR332ES Manuel utilisateur

Oregon Scientific

Oregon Scientific FSP-301 Manuel utilisateur

Oregon Scientific

Oregon Scientific JM200 Manuel utilisateur

Oregon Scientific

Oregon Scientific RRM320PU Manuel utilisateur

Oregon Scientific

Oregon Scientific BAR338PA Manuel utilisateur

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

La Crosse Technology

La Crosse Technology WT-3141b Manuel

La Crosse Technology

La Crosse Technology W86531 Manuel utilisateur

Sharp

Sharp SPC900 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-50447 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur

LG LEC-005 Manuel utilisateur
