ORBCOMM ST 9100 Manuel utilisateur

ST 9100

Installation Guide

T414, Version 0.04 BETA

Dec 2019

ST 9100 - INSTALLATION GUIDE

LEGAL NOTICE

This documentation is owned by ORBCOMM®and protected by applicable copyright laws and international treaty

provisions. Other copyrighted names used are the property of their respective owners. Therefore, you must treat this

documentation like any other copyrighted material. This publication, or any part thereof, may not be reproduced or

transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, storage in an

information retrieval system, or otherwise, without prior written permission by ORBCOMM, Inc. 395 W Passaic Street,

Suite 325, Rochelle Park, NJ 07662 USA Phone 703-433-6325. The information in this document is for information

purposes only and contains technical information and descriptions of the ORBCOMM product(s) and is subject to

change without notice. No warranty or representation, express or implied, is made with respect to its contents.

TRADEMARK NOTICE

The ORBCOMM name and the ORBCOMM logo are registered trademarks of ORBCOMM.

INMARSAT, the Inmarsat logo and IsatData Pro are trademarks of Inmarsat used under license by SkyWave (an

ORBCOMM company). Inmarsat is not responsible for the operation and regulatory compliance of the products and

services referred to in this document that connect to the Inmarsat system.

EXPORT CONTROL STATEMENT

The contents of this document, in whole or in part, shall not be exported from the United States, which export shall

include, but not be limited to, transmittal to any non-U.S. citizen wherever said person is located, except in

accordance with all United States laws and regulations relating to exports and to all administrative acts of the U.S.

Government pursuant to such laws and regulations. Diversion, re-export or transshipment of the contents of this

document, in whole or in part, contrary to U.S. law is also strictly prohibited.

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

CONTACT INFORMATION

Visit ORBCOMM Online

www.ORBCOMM.com

Contact Customer Support

support@skywave.com

+1.613.836.2222

Headquarters

395 W Passaic Street, Suite 325

Rochelle Park, NJ 07662 USA

Tel: +1-703-433-6300

Fax: 1-703-433-6400

Email: sales@orbcomm.com

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

TABLE OF CONTENTS

Legal Notice 2

Trademark Notice 2

Export Control Statement 2

Contact Information 3

Contact Customer Support 3

TABLE OF CONTENTS 4

List of Figures 6

List of Tables 6

Preface 7

Purpose 7

Notation 7

Reference 7

Battery Safety Warnings 7

1 Installation 9

1.1 Getting Started 9

1.2 Prepare for the Installation 9

1.2.1 Shipping Box Contents 9

1.2.2 Additional Materials 9

1.2.3 Required Tools 10

1.2.4 Transceiver Identification 10

1.2.5 Install the SIM Card 10

1.2.5.1 Reset Button 12

1.2.5.2 LED Location and Operation 13

1.2.5.3 LED User Control 13

1.3 Determine a Suitable Mounting Location 14

1.3.1 Standard Satellite Antenna Mounting Guidelines 14

1.3.2 Cellular Antenna Mounting Guidelines 15

1.4 Mount the Antennas 15

1.4.1 Screw Mount 15

1.4.2 Cable Tie Mount 16

1.4.2.1 Side Connector Mount 16

1.4.2.2 Bottom Connector Mount 16

1.4.3 Cellular Antenna 19

1.5 Route the Main Cable 19

1.5.1 Protect the Cables and Cable Connectors 20

1.6 Connect the Cables and Mount the ST 9100 21

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

1.6.1 Connect the Cables 21

1.6.2 Mount the Transceiver 22

1.7 Connect to Power 23

1.7.1 CAN bus Connection 24

1.8 (Optional) Attach the Terminal Shroud 24

1.8.1 Disconnect the FAKRA Connector 26

1.9 Register the Terminal 27

1.9.1 Activate the Terminal 27

1.10 API 28

APPENDIXA Troubleshooting the Terminal 29

A.1 Terminal Does Not Register or Report 29

APPENDIXB Satellite Antenna Dimensions 30

APPENDIXC Transceiver Dimensions 31

APPENDIXD Terminal Shroud Dimensions 32

APPENDIXE PIN Connections 33

APPENDIXF Cleaning Instructions 35

APPENDIXG Blunt-Cut Cable 36

APPENDIXH Field Installable Connector 38

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

LIST OF FIGURES

Figure 1: Remove SIM Card Door 11

Figure 2: Remove any Existing SIM Card 11

Figure 3: Sample SIM Card Orientation 11

Figure 4: SIM Card Installed 12

Figure 5: LED Location 13

Figure 6: Antenna Cable Bend Radius 15

Figure 7: Drill Mounting Hole 17

Figure 8: Attach Cable to Transceiver 18

Figure 9: Apply Silicone to Hole in Asset 18

Figure 10: Sample Cellular Mounting Locations – automobile example 19

Figure 11: Sample Cable Placement in a Vehicle Cab 20

Figure 12: Cable Management 21

Figure 13: Terminal Shroud 25

Figure 14: Disconnecting the FAKRA Connector from the Transceiver Unit 27

Figure 15: Transceiver Top View 31

Figure 16: Transceiver Side View Dimensions 31

Figure 17: Terminal Shroud Top View 32

Figure 18: Terminal Shroud Side View 32

Figure 19: Cable View of Connector 33

Figure 20: Cable View of Connector 36

Figure 21: Transceiver View of Connector 36

Figure 22: ST 9100 Field Installable Connector 38

Figure 23: Connector Front View 38

LIST OF TABLES

Table 1: Electrical Pin Assignment 33

Table 2: Blunt-Cut Cable Electrical Pin Assignment 37

Table 3: ST 9100 Field Installable Connector Details 38

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

PREFACE

Purpose

This document is as an overview of the installation procedures for the ST 9100 terminal.

Note: This is a Beta Trial document. Information in this document is subject to change.

Notation

A terminal consists of a transceiver unit plus antennas.

Hardware components, labels, and figures in this document might not be exactly as shown and are subject to change

without notice.

CAUTION: This safety symbol warns of possible hazards to personnel, equipment, or both. It includes hazards

that will or can cause personal injury, property damage, or death if the hazard is not avoided.

Note: A note indicates information with no potential hazard. A note indicates points of interest or provides

supplementary information about a feature or task.

Numbered lists indicate a series of steps required to complete a task or function.

Bulleted lists highlight information where order or sequence is not crucial.

Reference

The content of the following documents might be useful in conjunction with this guide. These documents are

available from the downloads section at support.skywave.com guide or from the ORBCOMMDeveloper Toolkit (ODT),

which is also available from the website.

Document names and numbers are subject to change, or be discontinued, without notice.

[N210] IsatData Pro Gateway Web Service 2 User Guide

[N206] MTWSCellular Protocol

[T404] LSF Developer Guide FW v4.x

[T405] IsatData Pro Service APIRef FW v4.x.x

[T413] ST 9100 Hardware Guide

Battery Safety Warnings

CAUTION: Do not short circuit or expose the battery to temperatures above the maximum rated temperature.

CAUTION: Always follow local disposal guidelines to properly dispose of the Lithium-ion battery and the

device.

CAUTION: Store in a cool, well ventilated area. Elevated temperatures can result in shortened battery life.

CAUTION: DO NOT replace the battery. Changing the battery without ORBCOMM’s permission could violate

regulatory conformity.

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

CAUTION: DO NOT throw the internal battery or the device into fire.

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

1 INSTALLATION

The following section contains recommended installation guidelines for the Solution Provider (SP). These

recommendations should be incorporated into installation guidelines for end users.

CAUTION: The installer is responsible for following all safety guidelines during product installation. Refer to

the Preface section for details.

The terminal uses very low power during transmission and therefore presents no radiation hazard during normal use,

installation, testing, and troubleshooting.

1.1 Getting Started

Getting the ST 9100 ready for operation requires doing the following:

1. Prepare for the installation (Section 1.2)

2. Determine a suitable mounting location (Section 1.3)

3. Mount the antennas (Section 1.4)

4. Route the main cable (Section 1.5)

5. Connect the cables and mount the ST 9100 (Section 1.6)

6. Connect to power (Section 1.7)

7. (optional) Attach the terminal shroud (Section 1.8)

8. Register the terminal (Section 1.9)

1.2 Prepare for the Installation

Check that you have the items and tools listed below before installing the terminal.

1.2.1 Shipping Box Contents

Unpack the contents of the shipping boxes, and then use the list below as a guide to check that you received the

items you ordered.

lST 9100 (p/n ST9100-D01 for use in the Americas, and ST9100-C01 for use outside of the Americas)

lPower and I/O connector (p/n ST101096) or blunt cut cable assembly (p/n ST101062-002)

lCellular antenna with FAKRA connector (p/n ST101066-001)

lSatellite antenna with FAKRA connector (p/n ST901065-AFA standard antenna, ST901066-AFA low elevation

antenna)

lTerminal shroud (optional - p/n ST101014-001)

1.2.2 Additional Materials

You might require some of the following materials to install a transceiver. These materials do not ship with the

terminal:

lSIM card (Refer to section 1.2.5 for SIM card procurement and installation)

lCable ties as a mounting option for the transceiver

If fastening the transceiver unit and the antenna to a mounting surface, you require:

T414, Version 0.04 BETA © ORBCOMM®Proprietary

ST 9100 - INSTALLATION GUIDE

lQty. 4 - #8 stainless steel fasteners (for the transceiver or the terminal shroud)

lQty. 4 - M4 stainless steel fasteners (for the satellite antenna)

Refer to APPENDIXG for details regarding the blunt cut cable.

1.2.3 Required Tools

You may require the following tools to install a terminal:

lDrill and drill bit

l#1 and #2 Philips screwdriver or Hex head socket

1.2.4 Transceiver Identification

Each transceiver has a unique mobile ID used to register it on the IsatData Pro network. This is a 15-digit

alphanumeric identifier in the format NNNNNNNNSKYXXXX for satellite-cellular transceivers or an International

Mobile Station Equipment Identity (IMEI) 15-digit identifier for cellular transceivers. The mobile ID is located on the

bottom of the transceiver and on the shipping box. The IMEI number is located near the mobile ID.

1. Record the mobile ID for future reference.

Note: ORBCOMM might activate transceivers on the network prior to or after shipping based on the

Purchaser (SP) agreement.

2. Provide the IMEI 15-digit number to your cellular Service Provider if using the cellular capabilities.

1.2.5 Install the SIM Card

The transceiver includes two embedded SIM cards and provides the option of installing a third, optional, SIM card. To

use the cellular capabilities of this transceiver you must install a SIM card. You may need to purchase a SIM card,

activated for use with a cellular network, from a Service Provider serving the area where the transceiver operates. The

SIM card must support operation on 1.8 V or 3 V. The transceiver does not support 5 V SIM cards. You might want to

record the SIM card’s ICCID number.

The SIM door has a hook that prevents removal of the door when the transceiver is mounted to an asset with screws.

1. If connected, disconnect the power connector from the power source.

CAUTION: Never insert or remove the SIM card if there is power to the transceiver. Transceivers with a

backup battery might still be powered on if the power connector is disconnected from the

transceiver. In this case, it is recommended that the transceiver be powered off locally using

the shutdown command [T405] at the shell prompt, or by sending an over-the-air powerOff

message (SIN 17, MIN 1) [T405]. The transceiver automatically wakes up when the power

connector is reconnected.

2. Remove the SIM card door (Figure 1).

Autres manuels pour ST 9100

Table des matières

Autres manuels ORBCOMM Terminal tactile

ORBCOMM

ORBCOMM ST 6100 Manuel utilisateur

Manuels Terminal tactile populaires d'autres marques

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuel utilisateur

Ingenico

Ingenico AXIUM EX4000 Manuel utilisateur

Heisei Electronics

Heisei Electronics Q-POS 815 Manuel utilisateur

Amano

Amano MTX-15 Manuel utilisateur

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuel utilisateur

Demco

Demco SP7 Manuel utilisateur

Lathem

Lathem PC600 Series Manuel utilisateur

Partner

Partner MF-2352 Manuel utilisateur

NCR

NCR RealPOS 7460-2 Manuel

Simrad

Simrad MS50 Instructions de montage

Unitech

Unitech MR350 MKII Guide de démarrage rapide

Jungheinrich

Jungheinrich WMT 210 Manuel utilisateur

Motorola

Motorola MTP850 Manuel utilisateur

YASKAWA

YASKAWA 62H-MDC0 Manuel utilisateur

MVG industries

MVG industries NeptuLink Manuel utilisateur

Price Industries Limited

Price Industries Limited FDC Manuel d'instructions

Honeywell

Honeywell TemaKey Manuel utilisateur

EBN

EBN BPC65-B-A16G Manuel utilisateur
