English 1
Usage Notice
Precautions .......................................................................................... 2
Introduction
About the Product................................................................................. 3
Package Overview ............................................................................... 4
Installation
Product Overview ................................................................................. 6
Connecting the Projection Display........................................................ 9
Powering On/Off the Projection Display................................................ 11
Adjusting the Image Size ...................................................................... 13
User Controls
User Controls ....................................................................................... 14
OSD Menus.......................................................................................... 16
Appendices
Troubleshooting .................................................................................... 22
Maintenance ......................................................................................... 25
Specifications ....................................................................................... 28
Compatibility Modes............................................................................. 29
Table of Contents
English
2
Precautions
Follow all warnings, precautions and maintenance as recommended in this
user’s manual to maximize the life of your unit.
Do:
qTurn off the product before cleaning.
qUse a soft cloth moistened with mild detergent to clean the display housing.
qDisconnect the power plug from AC outlet if the product is not being used for a
long period of time.
Don’t:
qBlock the slots and openings on the unit provided for ventilation.
qUse abrasive cleaners, waxes or solvents for your cleaning.
qUse under the following conditions:
- Extremely hot, cold or humid environment.
- In areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
- Place in direct sunlight.
Warning- Do not look into the lens. The bright light may hurt your eyes.
Warning- To reduce the risk of fire or electric shock, do not expose this
product to rain or moisture.
Warning- Please do not open or disassemble the product as this may cause
electric shock.
Warning- When changing the lamp, please allow unit to cool down and follow
all changing instruction.
Warning- This product will detect the life of the lamp itself. Please be sure to
change the lamp when it shows warning messages.
Warning- After changing a new lamp, please reset the lamp life timer from
OSD menu.
Warning- Before switching off the product, please keep the cooling fan
running for a few minutes.
Usage Notice
!
!
!
!
!
!
!
English 3
About the Product
This product, designed with a high-powered UHP lamp, is an XGA data/video
portable projection display. The outstanding feature of it are listed as follows:
G8.9 lbs. (4.0 kgs) lightweight compact design
GTrue XGA, 1024 x 768 addressable pixels
GWith SXGA compression and VGA/SVGA resizing
GMac / NEC PC-98 / FM Towns compatible
GNTSC / NTSC4.43/ PAL/ PAL-M / PAM-N / SECAM compatible
GDual Data Input
GReal plug and play with auto-image function
GUser-friendly multilingual on-screen display menu adjustment
GAdvanced electronic keystone correction function
GHard carrying case with detachable wheels and handle
Introduction
English
4
Package Overview
This projection display comes with all the items shown below. Check to make
sure your unit is complete. Contact your dealer immediately if anything is
missing.
LCD Projection Display
Hard Carrying Case
S-Video Cable RCA Audio/ Video Cable Audio-in Cable for
Computer
User’s Manual Warranty Card
Power Cord VGA Cable X 2
English 5
Battery x 3
Remote Mouse Package
Wireless Remote
Mouse Set
Remote Receiver Cable
PC PS/2
Remote Adapter
PC PS/2
Mouse Adapter
Mac
Remote Adapter
Mac
Mouse Adapter
English
6
Product Overview
MMain Unit
Installation
* There are two elevator releasing buttons and elevator feet on both sides.
* There are also two remote control receivers on the front and the rear side.
Remote Control Receiver
Carrying Handle
Projection Lens
Elevator Foot
Elevator
Releasing Button
Speakers
Panel Controls
Zoom Ring
Focus Ring
Air Filter
Power Connector
Ports
Remote Control
Receiver
100-240V50-60Hz
2.5A
English 7
MPanel Controls
Computer 2
Input Connector
Power Connector
Computer 1
Input Connector
Monitor Loop-Through
Connector
Audio Output Connector
Audio Input Connector
Audio Input
for Computer
Composite Video
Connector
S-Video
Connector
MConnection Ports
Four Directional
Select Keys
Enter
Remote Mouse
Connector
100-240V 50-60Hz
2.5A
English
8
MRemote Mouse
Freeze/Clear
Enter/Pointer
Power On/Standby
Menu
Source Selection Zoom Out / Zoom In
Keystone
Four Directional Select Keys
Volume
Right Mouse Button / Backlight Function
Left Mouse Button
Joy Stick
(Mouse Cursor Function)
Mouse Left Button Down
English 9
Connecting the Projection Display
Power Cord
Audio Cable
S-Video Cable
VGA Cable
Audio Cable
Monitor Cable
RCA Audio
Video Cable
Remote Receiver Cable
R
L
R
L
100-240V 50-60Hz
2.5A
English
10
R
L
Follow regular setup procedures. Make sure you have a 100% compatible Microsoft
Mouseand aMicrosoftMousedriver installed.
wConnecting the Remote Mouse
4Setting Up Procedure:
1. Turn off your computer.
2. Unplug the mouse from your computer.*
3. Connect the remote receiver cable to the computer and the projection display.
4. If you need an external mouse, connect the mouse with the other end of the
receiver cable.
5. Turn on your projection display first and then your computer.
6. Begin your presentation.
* If you have a Mac or PC PS/2 mouse, use the supplied matching adapters as
shown in the diagram.
RemoteReceiver Microsoft Mouse
Mac or PS/2 Mouse
Mac or PC PS/2 Adapter
Mac or PC PS/2 MouseAdapter
(Microsoft Mouse Connection)
(Mac or PC PS/2 Mouse Connection)
RemoteReceiver
