OpenVox DE115P Manuel utilisateur
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
1
OpenVox Communication Co Ltd
OpenVox DE115P/DE115E Installation
（Trixbox 2.8 & Elastix 1.5 with dahdi）
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
2
OpenVox Communication Co Ltd
OpenVox-Best Cost Effective Asterisk Cards
OpenVox Communication Co. Ltd.
Address: F/2,Building No.14,Shangsha Science & Technology Park,
No.9283,Binhe Road, Futian District,ShenZhen ,Guangdong 518048,China
TEL：0755－82535461
0755－82535095
0755－82535362
FAX：0755－82535174
Sales：[email protected]
Technical Support：[email protected]
Business Hours: 9:30AM-18:00PM from Monday-Friday, except for holidays.
（GMT＋8 Beijing）
Thank You for Choosing OpenVox Products!
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
3
Table of Contents
Chapter 1 Installing Compiling Environment..............................................................................4
Chapter 2 Installing Driver.............................................................................................................5
Chapter 3 Editing Configuration Files .........................................................................................6
Chapter 4 Loading Driver..............................................................................................................8
Chapter 5 Technical Support......................................................................................................10
Chapter 6 Reference....................................................................................................................11
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
4
Chapter 1 Installing Compiling
Environment
I. Installing trixbox 2.8 or elastix 1.5
II. Installing DE115P/DE115E
III. Starting trixbox or elastix
IV. Checking the system recognition of DE115P/DE115E
# lspci
V. Installing compiling environment
# yum install gcc
# yum install kernel-devel
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
5
Chapter 2 Installing Driver
I. Check the version of the dahdi
# modinfo /lib/modules/`uname -r`/dahdi/dahdi.ko
II. Downloading Driver
If the version of dahdi is 2.2.0 or 2.2.0-rc4, you should download
openvox_dahdi-linux-complete-2.2.0+2.2.0.tar.gz;
If it is 2.1.0.4, please download openvox_dahdi-linux-complete-2.1.0.4+2.1.0.2.tar.gz
An example of installing OpenVox DE115P/DE115E with trixbox-2.8.0.1 is as below:
# cd /usr/src
# wget
http://downloads.openvox.cn/pub/drivers/dahdi/openvox_dahdi/openvox_dahdi-linux-com
plete-2.2.0+2.2.0.tar.gz
http://downloads.openvox.cn/pub/drivers/dahdi-linux-complete/openvox_dahdi-linux-com
plete-2.2.0.2+2.2.0.tar.gz
If you want to install OSLEC with DAHDI, please download the package linux-2.6.28.tar.bz2,
copy the echo to DAHDI directory and recompile it. Please read this link for more:
http://bbs.openvox.cn/viewthread.php?tid=1063&pid=4555
III. Downloading libpri, asterisk
(Please download the right version of libpri, asterisk with the version of trixbox or
elastix )
Compilling libpri-xx
# tar –xvzf libpri-xx.tar.gz
# cd libpri-xx
# make && make install
Compilling dahdi
# tar -xzvf openvox_dahdi-linux-complete-2.2.0+2.2.0.tar.gz
# cd dahdi-linux-complete-2.2.0+2.2.0/
# make
IV. Installing Driver
# mkdir -p /lib/modules/`uname -r`/dahdi/opvxd115
# cp
/usr/src/dahdi-linux-complete-2.2.0+2.2.0/linux/drivers/dahdi/opvxd115/o
pvxd115.ko /lib/modules/`uname -r`/dahdi/opvxd115/
# depmod –a
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
6
V. Downloading Firmware
# cd /usr/src
# wget
http://downloads.openvox.cn/pub/firmwares/opvx-dahdi-fw-oct6114-032-1.07.01.tar.g
z
VI. Installing Frimware
# tar -xzvf opvx-dahdi-fw-oct6114-032-1.07.01.tar.gz
# cp dahdi-fw-oct6114-032.bin /lib/firmware/
# mkdir -p /usr/lib/hotplug/firware/
# mv dahdi-fw-oct6114-032.bin /usr/lib/hotplug/firware/
Cmpilling asterisk
# tar –xvzf asterisk-xx.tar.gz
# cd asterisk-xx
# ./configure
# make && make install
Chapter 3 Editing Configuration Files
I. Edit/usr/lib/perl5/site_perl/5.8.8/Dahdi/Chans.pm
# cd /usr/lib/perl5/site_perl/5.8.8/Dahdi
# vi Chans.pm
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
7
II. Edit/usr/lib/perl5/site_perl/5.8.8/Dahdi/Span.pm
# vi Span.pm
III. Edit /usr/lib/perl5/site_perl/5.8.8/Dahdi/Hardware/PCI.pm
# vi Hardware/PCI.pm
IV. Edit /etc/dahdi/modules
# vi modules
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
8
Chapter 4 Loading Driver
# service dahdi start
# dahdi_cfg -v
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
9
# dmesg
The picture above shows loading the EC-32 successfully.
DE115P/DE115E User Manual
OpenVox | www.openvox.cn Aug, 2009
10
Chapter 5 Technical Support
If you have any technical problems when using OpenVox products, please access the
related columns of the product in our website forum, and you can also contact us through
the following methods:
I。Submit your technical problem to our Forum.
You can submit your technical problems to our website Forum, we will reply you as soon
as possible.。
Click to enter our Forum
II。Email us
You can also send your technical problems via email to the following email address, we
will also offer you the solution in the shortest time.
support@openvox.com.cn
mark.liu@openvox.cn
