SOLAR PATH LIGHT
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference. 21c
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2020 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m a y not be i nc luded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 57680
Specifications
Bulb Type LED
Battery Type 1000mAh AA Ni-Mh
Run Time Up to 7 hr on full charge
Important Safety Information
1. THIS IS NOT A TOY; FOR
DECORATION ONLY.
2. DO NOT APPLY PRESSURE TO
GLASS LENS WHEN INSTALLING.
3. ENSURE SOLAR LIGHT IS
SECURELY STAKED INTO
THE GROUND PRIOR TO USE;
FOR OUTDOOR USE ONLY.
4. LENS IS MADE OF GLASS AND
CAN BREAK, USE CAUTION,
WATCH FOR SHARP PIECES.
5. Assemble only according to these
instructions. Improper assembly
can create hazards.
6. Wear ANSI-approved
safety goggles during setup.
7. Keep assembly area clean and well lit.
8. Keep bystanders out of the
area during assembly.
9. Do not assemble when tired
or when under the influence
of drugs or medication.
10. Position battery in proper polarity.
11. This product is not a toy. Do not allow
children to play with or near this item.
12. Use as intended only.
13. Inspect before every use; do not
use if parts are loose or damaged,
or if sharp edges are exposed.
This is fragile and sharp edges may be
exposed if weathered or damaged.
14. Maintain product labels and nameplates.
These carry important safety
information. If unreadable or missing,
contact Harbor Freight Tools
for a replacement.
15. Contains Ni-Mh battery. Battery must
be recycled or disposed of properly.
Do not open, crush or incinerate.
Setup Instructions
1. Decide where you want to place the
Solar Light. Choose a location that
receives full, direct sunlight a minimum
of 8 hours a day. The location should
not be near nighttime light sources such
as porch lights or streetlights as this will
cause the Solar Light to remain off.
2. Confirm that the location is clear
of lines, cables and conduits.
3. Pull the Stake off the Pole.
4. With a rubber mallet (not included),
gently tap the Stake into the ground.
5. Once the Stake is securely in
the ground, attach the Pole and
then attach the upper Solar Light
housing onto the top of the Stake.
6. Gently remove the Solar Light
housing from the Lens. Remove
the battery pull tab and reconnect
Solar Light housing to the Lens.
7. Set the Solar Light in sunlight
and allow at least 24 hours
charge time before first use.
Page 3For technical questions, please call 1-888-866-5797.Item 57680
Operating Instructions
Note: During the day, the Solar
Light converts sunlight into electricity,
recharging the battery. The amount of
light the Solar Light receives depends on
placement of the Solar Light, geographic
location and weather. If the weather is
cloudy and the light does not receive
a full charge, the Solar Light may not
achieve the full run time. It will catch
up after two to three days of full sun.
1. After a full 8 hours of sunlight charging,
the Solar Light will automatically
turn ON during the night.
2. After the initial charge is set, confirm
that the Light is on by viewing it at
night or in a dark location. If it not
lit, check that the Solar Light has
had full sunlight for 8 hours and its
battery pull tab has been removed.
Maintenance
1. Clean regularly with a damp towel.
Do not clean with solvent.
Do not put too much pressure
on the Solar Light or accessories
while cleaning. Dry thoroughly.
2. BEFORE EACH USE, inspect the
general condition of the tool. Check for:
• leaking, swollen, or cracked battery,
• loose hardware,
• misalignment or binding of parts,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
3. AFTER USE, wipe external surfaces
of the tool with clean cloth.
4. Replace battery every 12 months:
a. Gently remove the Solar Light
housing from the Lens.
b. Remove battery door
to access battery.
Battery Tab
Battery Door
c. Gently open the battery door.
Be careful to not pull on the wire.
d. Remove the old battery.
e. Install a new Ni-Mh battery
into the Battery Compartment.
Check that the battery is placed
according to the correct polarity.
f. Close the Battery Door. Connect
Solar Light housing to the Lens.
5. Contains Ni-Mh battery. Battery must
be recycled or disposed of properly.
Do not open, crush or incinerate.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available for this item. Reference UPC 193175421104.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Troubleshooting
Problem Possible Causes Probable Solutions
Light will
not turn on
1. Battery not allowed time for
recharging via Solar Light.
2. Solar Light is set near nighttime
light sources such as porch
lights or street lights.
3. Solar Light is dirty.
4. Battery pull tab not removed.
1. Check that Solar Light has
direct access to sunlight for
enough hours a day.
2. Move Solar Light.
3. Clean Solar Light with a soft cloth.
4. Remove battery pull tab.
