One Forall URC-3550 Manuel utilisateur

Retain For Future Reference

“SUPER EASY”

USER GUIDE & CODE BOOK

Universal Remote

URC-3550

ABOUT YOUR SUPER EASY

THE KEYPAD

INSTALLING THE BATTERIES

SETTING UP THE SUPER EASY

Setting Up Your Device 9

ADVANCED FEATURES

Reassigning the Device Keys 10

Teletext and Fastext 11

Menu Control 12

Controlling Colour and Brightness 13

Punch-Through 14

Preventing accidental code changes 14

TROUBLE-SHOOTING

Searching for Your Code 15

Code Blink Out 16

Helpful Hints 17

Consumer Help-Line 18

Quick Code Reference 19

SET-UP CODES

Televisions 20

Video Recorders 23

Satellite Receivers 25

Cable Converters 27

Table of Contents

Note: If you’re having problems operating all the

functions of your device, don’t worry, your may just need

customising for your model type. Just call our consumer

help-line and we’ll get you on the right track.

Your SUPER EASY Package contains:

Your SUPER EASY Remote

Your SUPER EASY Manual

Your manual is divided into two parts: set-up instructions and

device codes. You will need your manual to set up your new

SUPER EASY so please be sure to keep it.

Your SUPER EASY needs four new AAA/LR03 alkaline batteries.

Your SUPER EASY can operate three devices:

a Television, a Video Recorder, and a Satellite Receiver.

Or if you want, a second Television, Video or Satellite

Receiver. Your SUPER EASY can also operate Cable Converters.

About Your SUPER EASY

Setup

About Your SUPER EASY

Device

Keys

Mute

Volume-

-/-- Key

Rewind

Record

Stop

Pause

Fast Forward

Channel+

Power

LED

Number

Keys

Teletext Keys

Play

Setup

Volume+

Channel-

Key Function

LED LED

The LED (Light Emitting Diode) flashes red

to show the remote is working.

Power

The Power key controls the same function as

on your original remote.

Device Keys

The TV, VCR and SAT keys select the home

entertainment device to be controlled. For

example pressing the TV key allows the

remote to control the functions of your

Television, after pressing VCR you can

operate your Video Cassette Recorder and

the SAT key operates your Satellite Receiver

or Cable Converter.

Volume, Programme

The Volume and Programme keys control

the two most frequently used functions of

your Television and Satellite Receiver. They

operate just as those on your original remote.

These keys are also used to operate the menu

feature of your device. See page 13 for

more details.

Mute

The Mute key operates the same function it

did on your original remote.

SETUP Key

The SETUP key is used to set up your SUPER

EASY and to access special functions.

Number Keys

The Number keys (0-9, 10, 20) provide

functions just like your original remote, such

as direct access programme selection. If your

original remote uses one/two digit input

switching (-/-- symbol), this function can be

obtained by pressing the -/-- key, which is the

same as the 10 key.

The Keypad

POWER

-/--

VCR

SAT

SETUP

VOL

Key Function

Video Recorder Keys

After pressing the VCR key, the Video

Recorder keys operate the functions of your

Video Recorder. To prevent accidental

recording, the Record key must be pressed

twice to start recording.

Teletext Keys

After pressing the TV key, the Rewind and

Fast Forward keys are used to operate the

main teletext functions. The symbols below

the keys are for teletext. The Text keys are

used to access the teletext functions of your

Television. Of course, your Television must be

teletext capable. For an explanation of the

teletext symbols, please refer to page 11 of this

manual. For a detailed explanation on how

teletext works, please refer to the manual

of your Television set.

After pressing the TV key, the Video

Recorder keys marked red, green, yellow

and blue, allow you to access the fastext

functions of your television. Again, your

television must be fastext capable to

operate these functions. For a more detailed

explanation of teletext and fastext, please

refer to the manual of your television set.

The Keypad

(red)

(blue)

(yellow)

(green)

Your SUPER EASY needs four new AAA/LR03 alkaline batteries.

Remove the battery cover from the

back of your SUPER EASY

Match the batteries to the + and -

marks inside the battery case, then

insert the batteries.

Press the battery cover back into

place.

Installing the Batteries

Note: In order to avoid having to reprogramme your

SUPER EASY after you remove the batteries, you will

need to insert new batteries within 3 minutes. Also it is

best that you do not use rechargable batteries.

ONE FOR ALL

A-Mark

Admiral

Anam

Anam National

AOC

Archer

All & Howell

003

179, 180, 016, 047, 093

180

055, 161

019, 030, 052, 003, 136

003

016

030, 046, 186, 056

000

000 000, 000, 046

Important notes:

- To set up your Video Recorder or Satellite, follow the

same instructions above, only press the VCR or SAT key

during step 2.

- To set up your Cable Box, follow the instructions above

only press the SAT key during step 2.

- If your Television, Video or Satellite does not respond,

follow steps 1 through 4 with each code listed for your

brand. If none of the codes listed for your brand operate

your device, then try the search method described on

page 15, even if your brand is not listed at all.

- If you change programmes on your Television through

your Video Recorder, press VCR and not TV, before you use

the programme keys.

- If your Video’s original remote control does not have a

power key, press PLAY instead of POWER when searching

for your code.

POWER

SETUP

Setting Up Your Device

To set up the SUPER EASY for your Device:

Find your Television code in the

Set-Up Code section (starting on page

20). Codes are listed by brand name. The

most popular code is listed first. Make

sure your Television is switched on.

Press and release your SUPER EASY’s TV

key, then press and hold down the

SETUP key until the red light blinks

twice (the light will blink once then

twice).

Enter your three-digit TV code using

the number keys. The red light will blink

twice.

Now, aim the SUPER EASY at your

Television and press POWER. If your

Television switches off, your SUPER EASY

is ready to run your Television.

Write your code in the three boxes on page 19, for quick, easy

reference.

To control your Television, press TV first.

Setting Up The SUPER EASY

Advanced Features

Changing the Device Keys

If you want, you can change any of the device keys (TV, VCR

or SAT) to operate another type of device. The chart below

lists how to change the keys and to set up that device:

To Change: Press:

to SETUP*992 VCR TV,

then TV SETUP*Code

to SETUP*992 SAT TV,

then TV SETUP *Code

to SETUP*992 TV VCR,

then VCR SETUP *Code

to SETUP*992 SAT VCR,

then VCR SETUP *Code

to SETUP*992 TV SAT,

then SAT SETUP *Code

to SETUP*992 VCR SAT,

then SAT SETUP*Code

* Hold down the SETUP key until the red light blinks twice.

To reset a device key to its original function, press:

TV key *992 T V T V

VCR key *992 V C R V C R

SAT key *992 S A T S A T

* Hold down the SETUP key until the red light blinks twice.

SETUP

SAT

VCR

SAT

VCR

SAT

VCR

SAT

Note: For a more detailed explanation of teletext and

fastext, please refer to the manual of your Television.

Remember, different Televisions control teletext and fastext

features in different ways. Not all of the teletext functions

may be available for your particular model.

Teletext and Fastext

The SUPER EASY is designed to operate the basic functions of

teletext (text on and text off).

Symbol Title Description

TEXT Puts the Television in the teletext

mode.

TV Switches the Television back to

regular viewing mode. On some

Televisions, this may be done by

pressing the TEXT key several times.

The keys marked red, green, yellow and blue are used to

access the fastext functions of your TV.
