One Forall URC 7880 Manuel utilisateur

URC 7880

ENGLISH SIMPLE SET UP GUIDE

WELCOME, PREPARE YOUR

REMOTE FOR INSTALLATION

Open the battery door.

Insert 4 AAA batteries.

ENGLISH

KEY TABLE

INPUT

DEVICES – Scroll through

the devices your remote

is set up to control MAGIC – Used to set up

your remote

POWER – Power on/o

DELIMITER –

Selects Sub Channels

BACK – Back one step

in the Menu of the

current device

ACTIVITY – Scrolls

through up to 5

Activity Modes –

Watch TV, Watch

Movie, Listen to

Music, Play Game and

Custom. See Activities

for details.

EXIT – Exit from the

Menu of the current

device

VOL – Volume Up, Down

and Mute

MENU – Shows the menu

of the current device

GUIDE – TV Guide, EPG

HOME –

Select the Home Menu

+/- – Channel Up and

Down

PP – Previous

Program, Last Channel

APP Shortcut Keys –

See‘App Shortcut

Feature’

Red, Green, Yellow,

Blue – Fastext/Quick

access keys

PLAYBACK – Playback

keys for the current

device

APPS - Brings up

the Applications Menu

INPUT – Select the input

on the current device

A  SIMPLESET

SimpleSet is a quick and easy way of setting up the remote to control the most popular

brands of each device type with only a few key presses, typically in under a minute per

device. The ﬁrst step is to select which device you are going to set up. The following is a list

of Device Modes on the remote control, and the Device types that can be set up on that

mode:

Device Mode Type of device

TV TV, HDTV, LED, LCD, Plasma, Projector

STB Set Top Box, Satellite Receiver, Cable Converter,

Freeview, DVB-T, IPTV

BLU Blu-ray, DVD, DVD Home Cinema, VCR, Laser Disk

AUD Audio, AV Receiver, Ampliﬁer, Tuner

DVD DVD, DVD Home Cinema, Blu-ray, VCR, Laser Disk

GAME Game Console*, Digital Media Receiver, Streamer

MEDIA Digital Media Receiver, Streamer, Game Console*

S. BAR Sound Bar, Active Speaker System

* The One For All remote can only control games consoles operated by Infra-Red, either

directly or via an adapter. Consoles that are controlled by Bluetooth only cannot be

operated.

For each Device type, there is a list of the top brands, each with a number assigned to it,

for example 5 for a Samsung TV. Locate your device and brand in the list that follows:

Thank you for purchasing the One For All Smart Control.

Now you can control all of your Audio/Video devices with a single remote, while enjoying

extra features such as the ability to combine devices in a single Activity Mode, sending

multiple commands on a single key press (macros) and being able to customise the

remote control to your exact requirements.

There is also a handy companion app for iPhone and Android phones which will allow

you to keep your remote up to date with the latest devices and codes. It also oﬀers you an

alternative way to set up your remote.

To get started with your new remote, the ﬁrst step is to set it up to control all of your

Home Cinema devices.

HOW TO SET UP YOUR REMOTE

A  SIMPLESET

1 Hisense

2 LG

3 Panasonic

4 Philips, Magnavox

5 Samsung

6 Sharp

7 Sony

8 TCL, RCA

9 Toshiba

0 VIZIO

AUD – AV Receiver, Amp, Tuner

1 Bose

2 Denon

3 Harman/Kardon

4 Marantz, Philips

5 Onkyo, Integra

6 Pioneer

7 RCA

8 Samsung

9 Sony

0 Yamaha

STB – Sat, Cable, DVB-T

1 AT&T, DIRECTV, Sky Mexico

2 Bell, Bell MTS

3 Charter, Spectrum, Time Warner

Cable, Bright House Networks

4 Comcast, Xﬁnity

5 Cox Communications

6 DISH Network, Dish Mexico

7 Optimum, Suddenlink

8 Shaw, Shaw Direct

9 TiVo

0 Verizon, Frontier

BLU, DVD – Blu-ray, DVD

1 Insignia

2 LG

3 Panasonic

4 Philips, Magnavox

5 Pioneer

6 Samsung

7 Sharp

8 Sony

9 Toshiba

0 Yamaha

HOW TO SET UP YOUR REMOTE

To set up your device

Turn on your device (not on standby) and point the OFA remote towards it.

Hold down MAGIC until the LED under the device blinks twice.

The LED under the current mode key will stay lit.

Press the DEVICES key repeatedly until the LED for the device you

want to set up is lit.

Hold down the digit for your brand and device as listed above

(e.g. 5 for Samsung TV).

The remote will send Power every 3 seconds until your device switches oﬀ.

As soon as your device switches oﬀ, release the digit.

The LED will blink twice and go out. The remote should now operate

your device.

* If you ﬁnd one or more keys do not work as you expect, start again at step 1 – the remote will start with the next

code in the memory.

A  SIMPLESET

GAME, MEDIA – Games Consoles (5 & 8), Media Players

1 Apple

2 D-Link

3 Microsoft

4 Netgear

5 NVIDIA

6 Roku

7 Sling Media

8 TiVo

9 Western Digital

0 Xiaomi

S. BAR – Sound Bar, Speaker Systems

1 Bose

2 JBL, ZVOX

3 LG

4 Panasonic

5 Philips, Magnavox

6 Sonos, RCA

7 Samsung

8 Sony

9 VIZIO

0 Yamaha

HOW TO SET UP YOUR REMOTE

B  SET UP BY CODE

If your brand is not listed in section A, you can set up your device by trying codes

individually. To do this:

1. Turn your device on (not on standby).

2. Locate the brand of your device in the code list (included).

Codes are listed by Device Type and Brand.

3. Hold down MAGIC until the LED under the device blinks twice.

The LED under the current mode key will stay lit.

4. Press the DEVICES key repeatedly until the LED for the device you

want to set up is lit.

5. Enter the ﬁrst 4 digit code listed for your brand (e.g. 2049 for

an Insigna TV).

6. The LED will blink twice and go out.

7. Now aim the remote towards your device and press the POWER key.

8. If the device turns oﬀ, your remote is ready to use. If not, repeat steps 3-7

with the next code in the list.

* Some codes are quite similar. If you ﬁnd that one or more keys do not operate as you expect, try again from step 3

with the next code in the list.

HOW TO SET UP YOUR REMOTE

Your One For All remote control can learn any function from any other working remote

control. This can be useful if you are missing one or more functions from your original

remote control and would like to add them to the Smart Control. You can learn onto any

key except Magic, Devices or Activity.

You can also learn a complete device if you can’t ﬁnd a code.

To learn, ﬁrstly make sure you have all your original remote controls to hand, and that they

have working batteries in. To learn functions, the original remote should be

approximately 3cm from the OFA remote, pointing towards it as shown below:

1. Hold down MAGIC until the LED under the device blinks twice.The LED

under the current mode key will stay lit.

2. Using the DEVICES key, make sure the LED for the device you want to learn

functions on is lit.

3. Press 975 – the LED will blink twice.

4. Press and release the key you want to learn a function onto (for example

the A key) –The WatchTV, Listen To Music and Custom LEDs will light up.

5. Press and release the key on the original remote.

6. The LED will blink twice to indicate the key has been learned correctly.

7. Repeat steps 4 and 5 for each key you want to learn – remember you can learn from multiple

remotes, but only one function per key.

8. When you learned all the functions you require, press and hold the MAGIC

key until the LED blinks twice and turns oﬀ.

Hints

• If the LEDs shows one long blink at step 6, the function was not learned correctly, please try again

from step 4.

• If you ﬁnd one or more keys don’t work properly after set up, you can re-enter the learning mode

at any time by repeating the procedure from step 1.

LEARNING

2 - 5 CM

GUIDE

INPUT

An Activity is a grouping of two or more devices into a single mode based upon what

you’re doing while using your remote - for example TV and Set Top Box can be combined

together into a Watch TV mode. In this mode keys will control only the relevant device, so

in this example the Volume keys would control the TV, but the channel keys would control

the Set Top Box.

The OFA Smart Control features 5 Activity Modes; Watch TV, Watch Movie, Listen To Music,

Play Game and Custom. Each of these modes has a choice of devices to combine.

These are:

WATCH TV

Combination 1: TV + STB (Default)

Combination 2: TV + STB + AUD

Combination 3: TV + AUD

Combination 4: TV + S.BAR

Combination 5: TV + STB + S.BAR

WATCH MOVIE

Combination 1: TV + BLU (Default)

Combination 2: TV + BLU + AUD

Combination 3: TV + DVD

Combination 4: TV + DVD + AUD

Combination 5: TV + BLU + S.BAR

Combination 6: TV + DVD + S.BAR

LISTEN TO MUSIC

Combination 1: TV + AUD + MEDIA (Default)

Combination 2: TV + S.BAR + MEDIA

Combination 3: TV + AUD + BLU

Combination 4: AUD only

Combination 5: S.BAR only

TO DELETE A LEARNED FUNCTION, THE PROCEDURE IS:

1. Hold down MAGIC until the LED under the device blinks twice.

The LED under the current mode key will stay lit.

2. Using the DEVICES key, make sure the LED for the device you want

to delete functions from is lit.

3. Press 976 – the LED will blink twice.

4. Press the key to delete twice – the LED will blink twice.

Repeat the above procedure for each key you want to delete.

LEARNING

ACTIVITIES

PLAY GAME

Combination 1: TV + GAME (Default)

Combination 2: TV + GAME + AUD

Combination 3: TV + GAME + S.BAR

CUSTOM

Combination 1: TV + MEDIA (Default)

Combination 2: TV + MEDIA + AUD

Combination 3: TV + MEDIA + S.BAR

Combination 4: TV + GAME

Combination 5: TV + GAME + AUD

Combination 6: TV + GAME + S.BAR

If you set up the default devices for any Activity on the remote (for example a TV and STB

for Watch TV) that Activity will be set up automatically on the remote. If you would like to

change to a diﬀerent combination, the procedure is as follows:

1. Hold down MAGIC until the LED under the device blinks twice.

The LED under the current mode key will stay lit.

2. Use the ACTIVITY key to scroll through the Activities until the

one you want to set is ﬂashing.

3. Press the number of the combination you want to set – e.g 2

for TV + STB + AUD in Watch TV.

4. The LED will blink twice and go out.

To access the Activities, simply press the ACTIVITY key to scroll through until the desired

one is lit. You can return to controlling by device by using the DEVICES key.

INPUT Shift

As the INPUT key is intended to select the input on your TV and most TVs use a menu to

select from a list of inputs, when the INPUT key is pressed in an Activity, the Menu Up,

Down, Left, Right and OK keys temporarily control the TV. If the OK key is pressed, or no

key is pressed for ten seconds, these keys will revert to controlling the relevant device for

the Activity (e.g. STB in Watch TV Mode).

Power Macro

If you hold down the Power key for 2 seconds in any Activity, the remote will send the

Power function for each device contained within that Activity. So for example, holding

Power in the default setting for Watch TV will turn both the TV and Set Top Box on or oﬀ.

ACTIVITIES

PROGRAM A MACRO

You can program any key on your OFA remote (except MAGIC, DEVICES and the three App

Shortcut keys) to send multiple commands on a single press –a Macro. This can be useful

for controlling multiple devices to put them in a certain state – for instance you could put

your TV on HDMI 1 and press Play on the Blu-ray player to start watching a movie. A key

programmed with a Macro will send the same Macro regardless of the device mode, so it

is best to select a key you don’t use, or use one of the spare A, B or C keys.

To program a macro, the procedure is as follows:

1. Hold down MAGIC until the LED under the device blinks twice.

The LED under the current mode key will stay lit.

2. Press 995 – the LED will blink twice.

3. Next select the key you want to program the Macro on.

4. Now use the DEVICES key to select the device you want the ﬁrst

function of the Macro to come from, for example TV.

5. Next, press the key you want to include in the Macro, for example

the INPUT key.

6. Repeat steps 4 (if necessary), and 5 to add more keys to the Macro. You can include up

to 15 key presses.

7. To store the Macro, hold down the MAGIC key until the LED blinks

twice.

* Remember to press the keys in the same order you would using your original remotes – so if you pressed AV on the TV

remote and then Play on the Blu-ray remote to watch a movie, do it in the same order on the Smart Control.

* If the LED shows a long blink when you press a key in steps 3 or 4, you have entered too many keys, please try again.

TO DELETE A MACRO

If you want to remove a macro from a key, please perform the following:

1. Hold down MAGIC until the LED under the device blinks twice.

The LED under the current mode key will stay lit.

2. Press 995 – the LED will blink twice.

3. Press the key the macro is programmed on.

4. Now hold down the MAGIC key until the LED blinks twice –

the Macro is deleted.

MACROS

INPUT

Autres manuels pour URC 7880

Table des matières

Autres manuels One Forall Télécommande

One Forall

One Forall URC-7200 Manuel d'utilisation et d'entretien

One Forall

One Forall URC-3910 Manuel utilisateur

One Forall

One Forall URC-4110 Manuel utilisateur

One Forall

One Forall URC-6410 Guide de l'administrateur

One Forall

One Forall 6-DEVICE PVR Manuel utilisateur

One Forall

One Forall URC 1918 Manuel utilisateur

One Forall

One Forall URC-9910 Manuel utilisateur

One Forall

One Forall SAMSUNG URC-4910 Manuel utilisateur

One Forall

One Forall ONE FOR ALL URC3110 Manuel utilisateur

One Forall

One Forall URC-7140 Manuel utilisateur

One Forall

One Forall URC-4300 Manuel utilisateur

One Forall

One Forall Kameleon URC-9960 Manuel utilisateur

One Forall

One Forall URC 1916 Manuel utilisateur

One Forall

One Forall ONE FOR ALL 4080CODES Manuel utilisateur

One Forall

One Forall XSight Manuel utilisateur

One Forall

One Forall URC-5800 Cinema 5+ Manuel utilisateur

One Forall

One Forall XSight Lite Manuel utilisateur

One Forall

One Forall URC-3450 Manuel utilisateur

One Forall

One Forall URC 7115 Manuel utilisateur

One Forall

One Forall URC 8080 Manuel utilisateur

One Forall

One Forall OARP05S Manuel utilisateur

One Forall

One Forall URC 7945 Manuel utilisateur

One Forall

One Forall URC 7120 Manuel utilisateur

One Forall

One Forall URC-9040 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
