Omnimount PANA103PRO Mode d’emploi

DOCUMENTNO:IA‐PANA103PRO_REV.A1

INSTALLATIONANDASSEMBLY INSTRUCTIONS

ALLDIMENSIONS‐MM(INCH)

MODEL:PANA103PRO

MAXLOADCAPACITY:500LB(227KG)

DOCUMENTNO:IA‐PANA103PRO_REV.A1

INSTALLATIONANDASSEMBLY INSTRUCTIONS

ALLDIMENSIONS‐MM(INCH)

MODEL:PANA103PRO

MAXLOADCAPACITY:500LB(227KG)

NOTE:READENTIREINSTRUCTIONSHEETBEFOREYOUSTARTINSTALLATIONANDASSEMBLY



WARNING



•DonotbegintoinstallyourPanasonicproductuntilyouhavereadandunderstandallinstructionsand

warningscontainedinthisInstallationSheet.Ifyouhaveanyquestionsregardinganyinstructions

and/orwarningspleasecallPanasonicCustomerSupport.

•Thisproductshouldonlybeinstalledbyaqualifiedprofessional.

•Makesurethatthesupportsurfacewillsafelysupportthecombinedloadoftheequipmentandall

attachedhardwareandcomponents.

•NeverexceedtheMaximumLoadCapacityofthismount:500lbs(227kg)

•Alwaysuseanassistantormechanicalliftingequipmenttosafelyliftandpositionequipment

•Tightenscrewsfirmly,butdonotovertighten.Overtighteningcandamageitems,greatlyreducing

theirabilitytohold.



PARTSLIST

ItemDescriptionQtyPart#

ABRACKET,WALL(RIGHT)11100222‐08

BBRACKET,WALL(LEFT)11100222‐02

CBRACKET,PANEL21100222‐07

DROD,HANGING41100222‐901(PARTOFBRACKET,PANEL)

EBOLT,HANGINGROD(HF0.5‐13X3.5)492965A716(MC)

FWASHER,FLAT(1/2ID,13/8OD)1698029A033(MC)

GNUT,HANGINGROD(1/2)891581A385(MC)

HSCREW,HEXHEADLAG(1/2X3‐1/2)1691478A726(MC)

IWASHER,FLAT(16MM)498035A109(MC)

JWASHER,LOCKING(16MM)491190A590(MC)



DOCUMENTNO:IA‐PANA103PRO_REV.A1

INSTALLATIONANDASSEMBLY INSTRUCTIONS

ALLDIMENSIONS‐MM(INCH)

MODEL:PANA103PRO

MAXLOADCAPACITY:500LB(227KG)



INSTALLATIONTOTHEWALL



WARNING



•Installermustverifythatthesupportingsurfacewillsafelysupportfour(4)timesthecombinedweight

ofallattachedequipment(wallmount)andhardwarealongwithpanel.

•Mountisonlymeantforsurfacemountingtoawall.Forrecessedmountingoranyothermounting

pleasecontactOmnimountCustomerService.



•Use½”x3½”HexHeadLagScrews(H)and½”FlatWashers(F)toattachWallBrackets(A&B)towall

ineight(8)placesperWallBracket.



•DistancebetweeninsideedgesofWallBracketsmustbe46"(1167mm)andWallBracketsmustbe

levelandsquaretooneanother.



CAUTION



•IfWallBracketsarenotlevelandsquare,mountmaynotfunctionproperly.

•IfusingcustomfastenerstoattachWallBracketstowallbesurethatfastenerscansupportthe

combinedweightofallattachedequipmentincludingwallmountandpanel.



INSTALLATIONTOTHEPANEL



DOCUMENTNO:IA‐PANA103PRO_REV.A1

INSTALLATIONANDASSEMBLY INSTRUCTIONS

ALLDIMENSIONS‐MM(INCH)

MODEL:PANA103PRO

MAXLOADCAPACITY:500LB(227KG)



•Removespacersfromrearofscreen.Retainfour(4)16MMscrewsforinstallationofPanelBrackets.



•SecurePanelBrackets(C)torearofscreenbyusingtheoriginal16MMscrewsalongwithfour(4)Flat

Washers(I)andfour(4)LockingWashers(J).



CAUTION



•Ensurethateachfasteneristightandsecurepriortopreparingpaneltoliftandhanginposition.



SETTINGANDADJUSTINGTILTPOSITION(S)/VERTICALANDLATERALADJUSTMENT

DOCUMENTNO:IA‐PANA103PRO_REV.A1

INSTALLATIONANDASSEMBLY INSTRUCTIONS

ALLDIMENSIONS‐MM(INCH)

MODEL:PANA103PRO

MAXLOADCAPACITY:500LB(227KG)



WARNING



•Ensurethatalladjustmentsaremadewithpropersupportofthepanelatalltimes.Noadjustments

shouldbemadeunlessdonebyaqualifiedinstallationprofessional.



TILTADJUSTMENT



•RemovethelowerboltshowninFig.1(Factoryinstallationissetat0°tilt)

•NOTE:Retainallhardwareforinstallationaftertiltpositionisselected.

•Selecttheproperholebasedonthedesiredtiltrequirement.

•Inserttheboltbackintoposition‐ensurethatthetubefromthepanelbrackethasremainedinthe

wallbracketandhasnotmovedfromtheinstallationposition.

•Secureallhardware.



Fig.1

DOCUMENTNO:IA‐PANA103PRO_REV.A1

INSTALLATIONANDASSEMBLY INSTRUCTIONS

ALLDIMENSIONS‐MM(INCH)

MODEL:PANA103PRO

MAXLOADCAPACITY:500LB(227KG)



LATERALADJUSTMENT



•Ensurethatthepanelisproperlysupportedduringlateraladjustment.

•LiftthepanelperPanasonicliftingrequirementstoremovetheloadfromtheinstalledcomponents.

•Thepanelmaybeshiftedfromsidetosideforfinalpositioningandthensetbackintotheretaining

slotsofthewallbracket.



VERTICALADJUSTMENT



•NOTE:Verticaladjustmentshouldonlybedonebyaqualifiedinstallationprofessional.

•NOTE:Factoryinstallationispresettothelowest(bottom)position.

•Verticaladjustmentisintendedtosupportthefinallevelingprocessoftheinstallationandshouldnot

beusedinanyotherinstallationmanner.

•LocatetheverticaladjustmentfastenerontopofeachinstallationwallbracketasshowninFig.2

•Theboltmaybeusedtoeitherraiseand/orlowertheverticalpositionforeachwallbracketasneeded

tolevel.



 


