Omega BB-2A Manuel utilisateur

BB-2A

Blackbody Calibration Source

e-mail: [email protected]

For latest product manuals:

www.omegamanual.info

Shop online at

omega.com

User’s Guide

NORWALK, CT

omega.com [email protected]

The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains,

and reserves the right to alter specifications without notice.

Servicing North America:

U.S.A. Omega Engineering, Inc.

Headquarters: Toll-Free: 1-800-826-6342 (USA & Canada only)

Customer Service: 1-800-622-2378 (USA & Canada only)

Engineering Service: 1-800-872-9436 (USA & Canada only)

Tel: (203) 359-1660 Fax: (203) 359-7700

e-mail: [email protected]

For Other Locations Visit omega.com/worldwide

TABLE OF

CONTENTS

BB-2A Blackbody Reference

SECTION PAGE

Section 1 Introduction ................................................................ 1-1

1.1 General Description ................................................... 1-1

1.2 Safety Warnings and I.E.C. Symbols ....................... 1-1

Section 2 Installation..................................................................... 2-1

2.1 Unpacking and Inspection ........................................ 2-1

2.2 Mounting ..................................................................... 2-1

2.3 Power Connection ...................................................... 2-2

Section 3 Parts and Features ...................................................... 3-1

Section 4 Operation ..................................................................... 4-1

4.1 Setting Temperature .................................................. 4-1

4.2 Measuring Temperature ............................................ 4-1

Section 5 Maintenance ................................................................ 5-1

5.1 Calibration .................................................................. 5-1

5.2 Cleaning ....................................................................... 5-1

5.2.1 Main Body ....................................................... 5-1

5.2.2 Target Plate .................................................... 5-1

5.3 Fuse Replacement ....................................................... 5-1

Section 6 Specifications ............................................................. 6-1

Section 7 Troubleshooting Guide ............................................. 7-1

Section 8 Glossary of Terms ...................................................... 8-1

LIST OF

FIGURES

BB-2A Blackbody Reference

FIGURE PAGE

1 BB-2A Blackbody Source Parts ............................................. 3-1

1Introduction

1-1

Section 1 - Introduction

OMEGA’s BB-2A Series Blackbody Calibration Source has been

designed for ease of use and reliability whenever you have the need

to test or calibrate non-contact infrared temperature instruments. It is

important that you read this manual completely and follow all safety

precautions before operating this instrument.

1.1 General Description:

The Model BB-2A is a portable, rugged, bench-top, blackbody

calibration source. The calibrator is used to test and calibrate infrared

pyrometers. The front 159 mm (6.25”) square plate has a 133 mm

(5 1⁄4”) circular target area with an emissivity of 0.95 and can be set

to any temperature between 66 to 343°C (150 to 650°F). For ease of

reading, a bi-metal thermometer is included. Please note that we do not

recommend this unit to be used as a primary calibration reference.

1.2 Safety Warnings and Precautions:

• Follow all safety precautions and operating instructions outlined in

this manual.

• Never leave your calibration unattended when in use.

• Keep out of reach of all children.

• Never touch the target plate when hot.

• Never place any object within 3 inches of the plate when hot.

• Do not operate in flammable or explosive environments.

• Never operate with power cord other than the one provided with

your unit.

• Remove and or disconnect main power cord before attempting any

maintenance or fuse replacement.

• Do not connect this unit to a non-grounded, non-polarized outlet or

power source.

• The target plate should not be used as a heating plate for any type

of material or liquid.

• This unit is intended for indoor use only. Protect from moisture and

rain.

Introduction

1-2

NOTE

There are no user serviceable parts inside your unit.

Attempting to repair or service your unit may void your

warranty.

2Installation

2-1

Section 2 - Installation

2.1 Unpacking

Remove the packing list and verify that you have received all your

equipment, including the following items:

• BB-2A Blackbody Calibration Source

• Dial Temp. Thermometer, Model H

• Users Manual

If you have any questions about the shipment, please call our Customer

Service Department at

1-800-622-2378 or 203-359-1660. We can also be reached on the

Internet at omega.com

e-mail: [email protected]

When you receive the shipment, inspect the container and equipment

for any signs of damage. Note any evidence of rough handling in tran-

sit. Immediately report any damage to the shipping agent.

2.2 Mounting and Setup

Place the BB-2A Blackbody Reference on a sturdy surface in a vertical

position and allow space on all sides of the unit for ventilation.

Assemble the Dial Temperature thermometer by inserting the stem of

the thermometer into the large hole in the middle of the top surface

of the target plate. Make sure the rocker switch and the temperature

control knob is on the OFF position. (Rotate the knob counterclockwise

if necessary). Plug in the power cord into a convenient voltage outlet.

The BB-2A is designed to operate within an ambient temperature range

from 10°C to 35°C (50°F to 95°F).

NOTE

The carrier will not honor any damage claims unless all

shipping material is saved for inspection. After examining

and removing contents, save packing material and carton

in the event reshipment is necessary.

2-2

2.3 Power Connection

Standard (120 VAC~, 50/60 Hz models)

The BB-2A comes with a standard North American 3-prong AC power

cord. Do not use any other power cord other than the one provided.

This cord provides the proper grounding and has been safety tested by

the proper safety agencies.

International (240 VAC~, 50/60 Hz models)

On 240 VAC~, 50/60 Hz models a European style power cord with the

proper color code and approvals is provided with 3-prong connector.

• Line voltage variations are not to exceed ±10% of

the rated input voltage.

• Electrical connections and wiring should be performed

only by suitably trained personnel.

• To shut down the unit in an emergency, the power

cord can be disconnected from the AC outlet.

Installation

CAUTION

3Parts and Features

3-1

Section 3 - Parts and Features

The BB-2A Hot plate is a general purpose temperature reference source

intended for laboratory use with an operating temperature range from

66°C to 343°C (150°F to 650°F). The front target plate is heated by a

resistance heater, embedded in the refractory material of the bottom

plate. The plates are made of aluminum to aid in uniform surface tem-

perature distribution. The temperature of the plate is controlled by a

bimetallic thermostat sensor. The case supports the aluminum plates,

and also serves to house the electrical connections and the temperature

control components. See Figure 1 for the overall shape and the general

features of the unit.

Figure 1. Blackbody Source Parts

POWER "ON"

INDICATOR

TEMPERATURE

CONTROL KNOB

POWER "ON/OFF"

SWITCH

DIAL TEMP

THERMOMETER

TARGET PLATE

FUSE HOLDER

POWER CORD

4Operation

4-1

Section 4 - Operation

4.1 Setting Temperature:

Prior to connecting your BB-2A hot plate to your electrical supply,

be sure the rocker and the dial switches are in the OFF position. The

power is turned ON or OFF by means of the rocker switch. Push the

rocker switch to turn the unit ON. The hot plate will start heating up

when the pointer is beyond the OFF mark on the dial plate. Turn dial

clockwise to set desired temperature. Dial mark indicate approximate

surface temperature in °C. The green cycle light will illuminate when

the pointer on the dial passes the OFF mark on the dial plate.

When the temperature for a given dial setting has been reached, the

light will cycle OFF and ON to hold that temperature. If the cycle light

is off, hot plate may still be hot.

To turn OFF hot plate, turn dial switch to the fully counterclockwise

position and push the rocker switch down to off position.

4.2 Measuring Temperature:

The 5 1⁄4” target area of the plate is a near ideal blackbody source. The

emissivity of the plate is 0.95. When calibrating an IR pyrometer, hold

the pyrometer perpendicular to the target plate for optimal perfor-

mance. The proper distance between the IR pyrometer and the target

plate depends on the field of view of the pyrometer. If the pyrometer is

too far away it will scan unwanted surfaces outside of the perimeter of

the target plate. Holding the pyrometer too close could introduce unde-

sirable heat to the IR detector of the pyrometer.

WARNING

• The BB-2A’s target plate can be set to very high tempera-

tures. Exercise extreme caution when operating the unit. Keep

hands and fingers away from the target plate area. Keep

flammable products such as paper, plastics and clothing far

from the unit.

• The BB-2A is a Class II instrument. It is intended to be oper-

ated in a laboratory environment only. Never operate the unit

outside or around children.

• Nothing should come in contact with the target plate.Even

when the unit is off.

• Never unplug the unit while it is on. Let it cool down to

lower temperature before turning it off.
