PREFACE

MANUAL OBJECTIVES

This manual shows you how to set up and use the Programmable Process meter.

NOTES, WARNINGS and CAUTIONS

Information that is especially important to note is identified by three labels:

• NOTE

• WARNING

• CAUTION

• IMPORTANT

NOTE: provides you with information that is important to successfully

setup and use of the Process meter.

CAUTION or WARNING: tells you about the risk of electric shock.

CAUTION, WARNING or IMPORTANT: tells you of circumstances

or practices that can effect the meter's functionality and must refer to

accompanying documents.

Table of Contents

Section Page

SEC 1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1. Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . .

SEC 2 ABOUT THE METER. . . . . . . . . . . . . . . . . . . . . . . . . . 3

.1 Front of the Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

. Back of the Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

.3 Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

SEC 3 GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.1 Changing Configuration Jumpers. . . . . . . . . . . . . . . . . . . 7

3. Mounting the Meter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.3 Connecting Sensor Input . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.4 Connecting Main Power. . . . . . . . . . . . . . . . . . . . . . . . . 1

SEC 4 CONFIGURING THE METER . . . . . . . . . . . . . . . . . 13

4.1 Selecting the Input Range . . . . . . . . . . . . . . . . . . . . . . . 13

4. Selecting a Decimal Point Position. . . . . . . . . . . . . . . . . 14

4.3 Scaling the Meter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.3.1 Internal Scaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4.3. Live Scaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4.4 Changing the Meter’s Calibration. . . . . . . . . . . . . . . . . . 17

APPENDICES

A Checking and Changing Main Board Power Jumpers. . . 19

B Reference Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

C Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

List of Figures

Figures Page

-1 Front-Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

- Connectors (ac-Powered and dc-Powered) . . . . . . . . . . . . . . .5

-3 dc-Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

3-1 S1 - S4 Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

3- Meter - Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

3-3 Panel Cut-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

3-4 3-Wire dc Voltage Input Connections

with Internal Excitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

3-5 -Wire dc Voltage Input Connections

with External Excitation . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3-6 4- 0 mA Input Connections with External Excitation . . . . . .10

3-7 4- 0 mA Transmitter Hook-Up with Internal Excitation . . . .11

3-8 dc Current Input Connections with Current Source . . . . . . .11

3-9 Main Power Connections ac . . . . . . . . . . . . . . . . . . . . . . . . 1

3-10 Main Power Connections dc . . . . . . . . . . . . . . . . . . . . . . . .1

A-1 115Vac Jumper Wiring (default) . . . . . . . . . . . . . . . . . . . . . .19

A- 30 Vac Jumper Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0

C-1 Meter Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

List of Tables

Table Page

-1 Connector Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3-1 S1 - S4 DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3- ac Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

4-1 Meter Calibration Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

B-1 Display Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

B- Menu Configuration Displays . . . . . . . . . . . . . . . . . . . . . . . 1

B-3 Run Mode Displays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-4 Factory Preset Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iii

NOTES

SECTION 1. INTRODUCTION

1.1 UNPACKING

Remove the Packing List and verify that you have received all equipment. If

there are any questions about the shipment, use the phone numbers listed on the

back cover to contact the Customer Service Department nearest you.

Upon receipt of shipment, inspect the container and equipment for any signs of

damage. Note any evidence of rough handling in transit. Immediately report any

damage to the shipping agent.

The carrier will not honor any claims unless all shipping material is

saved for their examination. After examining and removing contents,

save packing material and carton in the event reshipment is necessary.

Verify that you receive the following items in the shipping box:

QTY DESCRIPTION

1 Programmable indicator/controller with all applicable connectors

attached.

1 Owner’s Manual

1 Quick Start Manual

If you ordered any of the available options (except the “ L” blank Lens

option), they will be shipped in a separate container to avoid any

damage to your indicator/controler.

1.2 SAFETY CONSIDERATIONS

This device is marked with the international caution symbol. It is important to

read this manual before installing or commissioning this device as it contains

important information relating to Safety and MC (Electromagnetic Compatibility).

This instrument is a panel mount device protected in accordance with EN 61010-

1:2001, electrical safety requirements for electrical equipment for measurement, con-

trol and laboratory. Installation of this instrument should be done by qualified person-

nel. In order to ensure safe operation, the following instructions should be followed.

This instrument has no power-on switch. An external switch or circuit-breaker shall

be included in the building installation as a disconnecting device. It shall be marked to

indicate this function, and it shall be in close proximity to the equipment within easy

reach of the operator. The switch or circuit-breaker shall not interrupt the Protective

Conductor (Earth wire), and it shall meet the relevant requirements of IEC 947–1 and

IEC 947-3 (International Electrotechnical Commission). The switch shall not be incor-

porated in the main supply cord.

Furthermore, to provide protection against excessive energy being drawn from the

main supply in case of a fault in the equipment, an overcurrent protection device shall

be installed.

• Do not exceed voltage rating on the label located on the top of the instrument

housing.

• Always disconnect power before changing signal and power connections.

• Do not use this instrument on a work bench without its case for safety reasons.

• Do not operate this instrument in flammable or explosive atmospheres.

• Do not expose this instrument to rain or moisture.

• Unit mounting should allow for adequate ventilation to ensure instrument does not

exceed operating temperature rating.

• Use electrical wires with adequate size to handle mechanical strain and power

requirements. Install without exposing bare wire outside the connector to minimize

electrical shock hazards.

MC Considerations

• Whenever EMC is an issue, always use shielded cables.

• Never run signal and power wires in the same conduit.

• Use signal wire connections with twisted-pair cables.

• Install Ferrite Bead(s) on signal wires close to the instrument if EMC problems

persist.

Failure to follow all instructions and warnings may result in injury!

Note ☞

SECTION 2. ABOUT THE METER

2.1 FRONT OF THE METER

Figure -1 shows each part of the front of the meter.

Figure 2-1. Front Panel

METER DISPLAY:

Digital LED display: ¡.9.9.9. or 9.9.9.9. 4-digit 7–segment, 0.56" high LED

display with programmable decimal point.

METER MODES:

Run Mode The meter is in the run mode when the display is actively

showing a process.

Configuration Mode The meter is in the configuration mode when you press the

MENU button to enable meter configurations.

METER BUTTONS

T-RST button - Clears the tare value.

£/MAX button - In the run mode, press the £/MAX button to show the

maximum value if jumper S3 is installed: the meter momentarily shows

“####”, then flashes the maximum value encountered since the last peak

reset. Press the £/MAX button to show the VALLEY value if jumper S3 is

removed: the meter momentarily shows “™™™™”, then flashes the minimum

value encountered since the last valley reset. In the configuration mode, press

the £/MAX button to change the flashing digit’s value (increments by one).

£/TARE button - In the run mode, press the £/TARE button to tare the

display value to zero. In the configuration mode, press the £/TARE button to

scroll through available choices, or to move one digit to the right.

MENU button - In the run mode, press the MENU button to enable meter

configuration changes. Refer to specific procedure for more details.

RESET button - In the run mode, press the RESET button to reset the Peak

and Valley registers: the meter momentarily shows “PrSt” or “VrSt” , then

resets both values. In the configuration mode, press the RESET button twice

quickly to escape from the configuration mode.

Autres manuels pour DP24-E

Table des matières

Autres manuels Omega Instrument de mesure

Omega

Omega DP41-W Manuel utilisateur

Omega

Omega FL500 Series Manuel utilisateur

Omega

Omega CL551 Manuel utilisateur

Omega

Omega DPG110/120 Manuel utilisateur

Omega

Omega DFG-RS5 Manuel utilisateur

Omega

Omega FHG Series Manuel utilisateur

Omega

Omega LDP63000 Manuel utilisateur

Omega

Omega THDP-10 Series Manuel utilisateur

Omega

Omega DP25B-S Manuel de l'opérateur

Omega

Omega DP41-B Series Manuel utilisateur

Omega

Omega FLOWMETER FL45200A Manuel utilisateur

Omega

Omega FMA-1600A Series Manuel utilisateur

Omega

Omega CL1000 Series Manuel utilisateur

Omega

Omega DP3001 Manuel utilisateur

Omega

Omega SP-010 Manuel utilisateur

Omega

Omega PLATINUM DP32PT Manuel utilisateur

Omega

Omega DPF700 Manuel utilisateur

Omega

Omega LVCN-40 Series Manuel utilisateur

Omega

Omega DP63100-S Manuel utilisateur

Omega

Omega FL-1210 Manuel utilisateur

Omega

Omega TCL-3M165E2 Series Manuel utilisateur

Omega

Omega Vortex FV100 Series Manuel utilisateur

Omega

Omega RH62C Manuel utilisateur

Omega

Omega HH414 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
