Olympus DSX1000 Manuel utilisateur

Optical Microscope and Accessory

Instructions

DSX1000

Digital microscope

Hardware

Notes

This instruction manual is for the Olympus Digital Microscope.

To ensure safety, obtain optimum performance and to familiarize yourself fully with the use of

this product, we recommend that you study this manual thoroughly before operating this

product, and always keep this manual at hand when operating this product.

Retain this instruction manual in an easily accessible place near the work desk for future

reference.

For details of products included in the configuration of this system, see pages from 14 to 18.

Downloaded from ManualsNet.com search engine

This product is applied with the requirements of standard IEC/EN61326-1 concerning

electromagnetic compatibility.

- EmissionClass A, applied to industrial environment requirements.

- ImmunityApplied to industrial environment requirements.

Some interference may occur if this product is used in domestic location.

NOTE:This product has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the product is operated in a commercial environment. This

product generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this product in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the product.

FCC Supplier's Declaration of Conformity

Hereby declares that the product

Product name:Optical Microscope, Optical Microscope Accessory

Model Number: DSX10-UZH, DSX10-SZH, DSX10-TF, DSX10-UF,

DSX10-RMTS, DSX10-MTS, DSX10-CSL, DSX10-CB,

DSX10-ILT, DSX10-BSW, DP74-PCIE

Conforms to the following specifications:

FCC Part 15, Subpart B, Section 15.107 and Section 15.109

Supplementary Information:

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Responsible Party Name: Olympus Scientific Solutions Americas Corp.

Address:48 Woerd Ave Waltham, MA 02453, U.S.A.

Phone Number:781-419-3900

In accordance with European Directive on Waste Electrical and Electronic Equipment, this

symbol indicates that the product must not be disposed of as unsorted municipal waste, but

should be collected separately. Refer to your local Olympus distributor in EU for return and/or

collection systems available in your country.

For Korea only

Downloaded from ManualsNet.com search engine

DSX1000

Contents

1. Concept of this instruction manual 1

1.1 Applicable user of this instruction manual 1

1.2 Configuration of instruction manuals 1

1.3 How to read this instruction manual 2

2. Product concept 3

2.1 Product outline 3

2.2 Intended use 3

2.3 Trademark 3

3. Safety precautions 4

3.1 Transportation 4

3.2 Installation and Uninstallation of the application 6

3.3 Prevention of electric shock 6

3.4 Electric safety 6

3.5 Prevention of eye injury 7

3.6 Prevention of injury 8

3.7 Safety symbols 9

4. Handling Precautions 11

4.1 Detaching the transport locks 12

4.2 General 13

4.3 Confirmation of accessories 13

5. Specifications 14

5.1 Hardware 14

5.2 Dimension and weight 17

5.3 Loading capacity of stage 18

5.4 Observable sample height 18

5.5 Rating 19

5.6 Application 19

5.7 Operating environment 19

5.8 Measures for safety and environmental law 19

6. List of combinable units 21

6.1 Correspondence table of units and observation methods 21

6.2 Combination of units 22

7. Maintenance and Storage 23

Downloaded from ManualsNet.com search engine

DSX1000

7.1 Cleaning of each part 23

7.2 Cautions after use 24

7.3 Lifetime 24

7.4 Replacement of the lens attachment 24

8. Assembly 25

8.1 Assembly diagram 25

8.2 Detachment/attachment of transport locks of microscope frame 30

8.3 Attachment/detachment of the zoom head 31

8.4 Attachment/detachment of the stage 34

8.5 Attachment/detachment of the objective 40

8.6 Attachment/detachment of the lens attachment 41

8.7 Attachment/detachment of the polarized illumination adapter 42

8.8 Attachment/detachment of the diffused illumination adapter 43

8.9 Attachment/detachment of the LED transmitted light illuminator (Optional) 44

8.10 Connection/disconnection of cables 44

8.11 Installation and Uninstallation of the application 48

8.12 Connection of the USB license key 49

8.13 Packaging of units 49

9. Proper selection of the power supply cord 51

Appendix: Units attached by Olympus 53

Attaching the PCIe interface board 53

Downloaded from ManualsNet.com search engine

DSX1000

This instruction manual describes the contents related to the whole DSX1000 system.

1.1 Applicable user of this instruction manual

This instruction manual applies to users who use this product according to "Intended use" (3 page) and Olympus

distributors.

1.2 Configuration of instruction manuals

Read all the instruction manuals supplied with the units you purchased. The following instruction manuals are prepared

for the units to be used with this product.

Manual names Main contents

DSX1000 Instruction Manual Safety Safety precautions

DSX1000 Instruction Manual Hardware

(this manual)

Safety precautions, specifications and assembly method

DSX1000 Instruction Manual Operation Observation methods, image correction, measurement and analysis

Simple Operation Guide Simple operations of the microscope

Analysis Application Instruction Manual Measurement and analysis of image data using OLS51- BSW

Installation and uninstallation of DSX10-BSW Installation and uninstallation of DSX10-BSW

DSX10-BSW Upgrades Upgrades for DSX10-BSW

Controller PC BIOS and OS Settings Controller PC settings

1. Concept of this instruction manual

1.1 Applicable user of this instruction manual1. Concept of this instruction manual

Downloaded from ManualsNet.com search engine

DSX1000

1.3 How to read this instruction manual

This instruction manual is created as follows.

Title in first layer

Title in second layer

Title in third layer

Operating procedure

, ... indicates the operating procedure and , ... indicates the portion you operate.

Cautions and references

The following symbols are used in this instruction manual.

DANGER:

Indicates an imminently hazardous situation which, if not avoided, will result in death, serious

injury or damage to the sample.

WARNING:

Indicates a potentially hazardous situation which, if not avoided, could result in death, serious

injury or damage to the sample.

CAUTION:

Indicates a potentially hazardous situation which, if not avoided, may result in minor or

moderate injury.

NOTE:

Indicates a potentially hazardous situation which, if not avoided, may result in damage to the

product or other property and/or may cause problems.

TIP:

Indicates the useful knowledge or information for use.

: Indicates the reference page of related information. Clicking the "underlined" texts allows you

to jump to the related page.

21. Concept of this instruction manual 1.3 How to read this instruction manual

Downloaded from ManualsNet.com search engine

DSX1000

2.1 Product outline

This product is a next generation digital microscope equipped with a variety of observation methods and image

processing functions, covering a wider range of magnification with just one system.

This product eliminates the annoying operations in existing optical microscopes or digital microscopes, and offers "Smart

Analysis" that allows any user to observe, measure and analyze the image quickly and easily.

2.2 Intended use

This product is designed to observe magnified images of the samples for industrial applications.

Appropriate samples include semiconductors, electronic components, molded parts or mechanical parts.

Industrial applications include observation, inspection or measurements.

Do not use this product for any purpose other than its intended use.

2.3 Trademark

Microsoft, Excel, Internet Explorer and Windows are either registered trademarks or trademarks of Microsoft Corporation in

the United States and/or other countries.

Intel and Intel Core are trademarks of Intel Corporation in the United States and/or other countries. Other company names

or product names described in this manual are either registered trademarks or trademarks of respective companies.

2. Product concept

2.1 Product outline2. Product concept

Downloaded from ManualsNet.com search engine

DSX1000

If the product is used in a manner not specified by this manual, the safety of the user may be imperiled. In addition, the

product may also be damaged. Always use the product according to this instruction manual.

3.1 Transportation

CAUTION

It is recommended to request Olympus for transporting this product or assembling units.

Be careful not to drop this product while transporting it. If the product is dropped, there is a risk of

injuring your feet or other body parts.

Weight

Zoom head (DSX10-USH/DSX10-SZH): Approx. 11 kg

Tilting frame (DSX10-TF): Approx. 19 kg

Upright frame (DSX10-UF): Approx. 16 kg

Motorized stage (DSX10-RMTS/DSX10-MTS): Approx. 6 kg

Manual stage adapter (DSX10-MSTAD): Approx. 4 kg

Disconnect the cables before carrying the microscope.

Be careful not to pinch your fingers or other body parts when placing the zoom head on the desk.

If you carry the zoom head, hold the zoom head securely with both hands.

If you carry the zoom head, do not hold the camera head .

Before carrying the microscope frame, detach the zoom head and the stage from the microscope frame. If

you carry the microscope frame attached with the zoom head or the stage, this product may be

damaged.

If you carry the microscope frame, do not hold the stage mount , but be sure to hold the rear holding

section and the front holding section .

Do not carry the microscope frame in an unstable posture.

3. Safety precautions

43. Safety precautions 3.1 Transportation

Downloaded from ManualsNet.com search engine

DSX1000

Before carrying the motorized stage, detach the stage plate and the plate (high-precision plate or black-

and-white plate).

If you carry the motorized stage, hold the surface (painted in gray) of the motorized stage .

As the connector is attached to the bottom of the motorized stage, be sure to place the motorized stage

only on the stage mount of the microscope frame. If it is placed on the desk, etc., the connector may be

damaged.

When you set up this system, detach the transport locks of the zoom head, stage and microscope frame.

As these transport locks will be used for transporting this product next time, keep them in a safe place.

If you need to package this product, such as to ship to the distant location, you need to use the

dedicated package box. In this case, be sure to contact Olympus for assistance.

If you transport and install this system overseas by yourself without prior notice to Olympus, the services

in the destination country will not be provided.

If you transport and install this product overseas, note the following:

・Use the power cord that complies with the regulations and rules of the destination countries.

・Use the controller that complies with the regulations and rules of the destination countries. Depending

on the case, you may need to purchase only the controller for local use.

・Some countries and regions may not have established the Olympus service system. In this case, the

product for repair or other purposes must be sent to Olympus in Japan.

・Note, even in countries and regions where the Olympus service system is available, the same after-

services as those in Japan may not be provided.

3.1 Transportation3. Safety precautions

Downloaded from ManualsNet.com search engine

DSX1000

3.2 Installation and Uninstallation of the application

WARNING

Do not block the air vents.

Do not use the product in tilted status. The air vents may be blocked, causing the system failure.

Secure the space of 10 cm or more around the air vents.

CAUTION

Install the product on a sturdy, level table or bench.

Do not place a mat, etc. under the product to prevent the product from overturning.

Do not install the units that generate the vibration caused by fans, such as controllers, etc. on the same

table as the microscope frame. The vibration may affect the microscope.

Unplug the power cords from the outlet when assembling, installing or adjusting the microscope.

Evaluate the system sufficiently (only when you purchased the zoom head alone).

If you attach the zoom head to your system, be sure to evaluate the system sufficiently in compliance

with your local rules and regulations.

If you attach the zoom head to your system, refer to "Attaching the zoom head DSX10-UZH / DSX10-

SZH" provided with the control box DSX10-CB.

3.3 Prevention of electric shock

WARNING

Never disassemble any part of this product.

It could cause the electric shock or failure of the product.

Do not touch the product with wet hands.

In particular, if you touch the main switch of the power unit or the power cord with wet hands, electric

shock, ignition or failure of the product may be caused.

Do not bend, pull or bundle the power cord and cables.

Otherwise, they could be damaged, causing a fire or an electric shock.

Never insert any tools or metal fragments or pour the liquid to the air vents of the product.

As the cooling fan, etc. is positioned near the air vents, the system failure or electric shock could be

caused.

If the provided tools or metal fragments enter the system through air vents or so, the system failure or

electric shock could be caused. If this occurs, stop using the system immediately, turn off the power and

contact OLYMPUS.

Do not use the power cords with condensation.

Do not pour any liquid on the power cords. The electric shock or electrical leakage could be caused.

Do not connect or disconnect the power cords with wet hands. You could get an electric shock.

The power cords must not contact any part that has a temperature higher than 70 °C.

Before connecting/disconnecting cables, turn off all main switches of the system and unplug the power

cord from the outlet.

3.4 Electric safety

CAUTION

Always use the power cord provided by Olympus

63. Safety precautions 3.2 Installation and Uninstallation of the application

Downloaded from ManualsNet.com search engine

Autres manuels pour DSX1000

Table des matières

Autres manuels Olympus Microscope

Olympus

Olympus VS120 Manuel du propriétaire

Olympus

Olympus BX63 Manuel utilisateur

Olympus

Olympus DP26 Manuel utilisateur

Olympus

Olympus SZ4045TR Manuel utilisateur

Olympus

Olympus Pom Manuel utilisateur

Olympus

Olympus CX41 Manuel utilisateur

Olympus

Olympus IX81 Manuel utilisateur

Olympus

Olympus CH30 Manuel utilisateur

Olympus

Olympus U-D7RES Manuel utilisateur

Olympus

Olympus FV1200 MPE Manuel utilisateur

Olympus

Olympus DP21-SAL Guide de l'utilisateur

Olympus

Olympus DSX510 Manuel utilisateur

Olympus

Olympus CHBS Manuel utilisateur

Olympus

Olympus VANOX Manuel utilisateur

Olympus

Olympus Fluoview FV1000 Guide d'installation

Olympus

Olympus BH2-5RE Instructions d'installation

Olympus

Olympus U-LGPS Manuel utilisateur

Olympus

Olympus MX63 Manuel utilisateur

Olympus

Olympus FV3000 Guide de l'utilisateur

Olympus

Olympus U-MDOB3 Manuel utilisateur

Olympus

Olympus SZX10 Manuel utilisateur

Olympus

Olympus Discover FV10i Manuel du propriétaire

Olympus

Olympus U-DA Manuel utilisateur

Olympus

Olympus BX51 Manuel utilisateur

Manuels Microscope populaires d'autres marques

Thermo Scientific

Thermo Scientific Nicolet iN10 Mode d’emploi

National

National DC3-163 Manuel utilisateur

KERN Optics

KERN Optics OPE-1 Manuel utilisateur

OPTIKA MICROSCOPES

OPTIKA MICROSCOPES B-150D Manuel utilisateur

Prior

Prior Lux POL Manuel utilisateur

Opitec

Opitec Smartscoop 115615 Manuel utilisateur

KERN

KERN OPO-1 Manuel utilisateur

Topcon

Topcon SP-1P Manuel utilisateur

Motic

Motic PA43 Manuel utilisateur

Leica

Leica DVM5000 Guide de l'utilisateur

MshOt

MshOt MZ62 Manuel utilisateur

KERN Optics

KERN Optics OZR-5 Manuel utilisateur

VWR

VWR VisiScope 384 Series Manuel utilisateur

Nikon

Nikon ECLIPSE E200 POL Manuel utilisateur

Leica

Leica DI C800 Manuel

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manuel utilisateur

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manuel utilisateur

Leica

Leica FL560 Manuel utilisateur
