Olympus EVOLT E-330 Manuel utilisateur

Olympus E-330 Traveller Pro Kit

The E-330 offers the comfort and flexibility of continuous live

previews directly on the LCD. This groundbreaking innovation

enables framing of shots without the need to look through the

viewfinder. Additionally, thanks to a tilting, multi-angle LCD

measuring a large 2.5"/ 6.4cm, the Olympus E-330 extends

versatility even further. It makes capturing shots from unusual

angles, such as in crowds or during macro photo sessions effortless.

The 7.5 million live MOS sensor, a fast sequence speed of 3 fps, the

professional AEL and bracketing function and last but not least the

dust reduction system for carefree shooting makes this camera a

perfect working tool for ambitious photographers.This product

comes with Traveller Pro Kit.This kit includes:E-330 Body;BLM-1

rechargeable Lithium-Ion battery;BCM-2 battery

charger;Strap;USB Cable;Video cable;Olympus Master

(Software CD-ROM);Basic Manual;Advanced Manual

(CD-ROM);Warranty Card;11-22mm 1: 2.8-3.5 lens;ED

18-180mm 1: 3.5-6.3 lens;FL-36 flash;E-System Bag Compact

SBC-1.

www.dooyoo.co.uk :: Photography :: Digital Camera :: Olympus E-330 Traveller Pro Kit

General

Product Type Digital camera - SLR

Width 14 cm

Depth 7.2 cm

Height 8.7 cm

Weight 0.5 kg

Main Features

Resolution 7.5 Megapixel

Colour Support Colour

Optical Sensor Type Live MOS

Total Pixels 7,940,000 pixels

Effective Sensor Resolution 7,500,000 pixels

Optical Sensor Size 13.0 x 17.3mm

Field of View Crop Factor 2

Sensor Dust Reduction Yes

Sensor Features Supersonic Wave Filter (SWF)

Light Sensitivity ISO 1600, ISO auto (100-400), ISO 100-400

Shooting Modes Landscape, portrait mode, macro, beach/snow,

landscape-portrait, Children, fireworks, panorama assist,

night scene, sports mode, sunset, candle, Document, high

key, night scene with portrait, underwater macro,

underwater wide, low key, reducing blur

Special Effects Black & White, Sepia, Black & White Red filter, Black &

White Yellow filter, Neutral, Vivid, Black & White Blue

filter, Black & White Orange filter, Black & White Green f

ilter, Muted

Max Shutter Speed 1/4000 sec

Min Shutter Speed 8 min

X-sync Speed 1/180 sec

Exposure Metering Multi-segment, centre-weighted, spot, highlight spot,

shadow spot

Exposure Modes Programme, bulb, automatic, manual, aperture-priority,

shutter-priority

Exposure Range EV 2-20 ( ISO 100 )

Exposure Compensation ±5 EV range, in 1/2 or 1/3 EV steps

Auto Exposure Bracketing 3 steps in 1/3, 1/2, 2/3, 1 EV steps

Exposure Metering Zones 49

White Balance Custom, automatic, presets

White Balance Presets 3000K, 4000K, 4500K, 7500K, 6600K, 6000K, 5300K

White Balance Bracketing Yes

Still Image Format JPEG, TIFF, RAW, RAW + JPEG

Continuous Shooting Speed 3 frames per second

Remote Control Optional

Memory / Storage

Supported Flash Memory CompactFlash, xD-Picture Card, Microdrive, xD-Picture

Card Type H, xD-Picture Card Type M

Image Storage RAW 3136 x 2352 - 12.9 MB ¦ TIFF 3136 x 2352 - 21.6 MB ¦

Super-fine JPEG 3136 x 2352 - 5.7 MB ¦ Fine JPEG 3136 x

2352 - 4 MB ¦ Normal JPEG 3136 x 2352 - 1.8 MB ¦ Basic

JPEG 3136 x 2352 - 1.2 MB ¦ Super-fine JPEG 2560 x 1920 -

4 MB ¦ Fine JPEG 2560 x 1920 - 2.4 MB ¦ Normal JPEG 2560

x 1920 - 1.2 MB ¦ Basic JPEG 2560 x 1920 - 0.8 MB ¦

Super-fine JPEG 1600 x 1200 - 1.4 MB ¦ Fine JPEG 1600 x

1200 - 0.9 MB ¦ Normal JPEG 1600 x 1200 - 0.5 MB ¦ Basic

JPEG 1600 x 1200 - 0.3 MB ¦ Super-fine JPEG 1280 x 960 -

0.9 MB ¦ Fine JPEG 1280 x 960 - 0.6 MB ¦ Normal JPEG 1280

x 960 - 0.3 MB ¦ Basic JPEG 1280 x 960 - 0.2 MB ¦

Super-fine JPEG 1024 x 768 - 0.6 MB ¦ Fine JPEG 1024 x

768 - 0.4 MB ¦ Normal JPEG 1024 x 768 - 0.2 MB ¦ Basic

JPEG 1024 x 768 - 0.1 MB ¦ Super-fine JPEG 640 x 480 -

0.2 MB ¦ Fine JPEG 640 x 480 - 0.1 MB ¦ Normal JPEG 640 x

480 - 0.1 MB ¦ Basic JPEG 640 x 480 - 0.1 MB

Camera Flash

Camera Flash Pop-up flash

Guide Number (m / ISO 100) 13

Flash Modes Fill-in mode, rear curtain sync, slow synchro, auto mode,

flash OFF mode, red-eye reduction

Red Eye Reduction Built-in

External Flash Name Olympus FL-36

Features AF illuminator, flash +/- compensation

Lens System

Type Zoom lens - 18 mm - 180 mm - f/3.5-6.3 Four Thirds

Focal Length 18 mm - 180 mm

Focal Length Equivalent to 35mm Camera 36 - 360mm

Focus Adjustment Automatic, manual

Auto Focus TTL phase detection

Auto Focus Points (Zones) 3

Min Focus Range 45 cm

Max View Angle 62 degree(s)

Lens Aperture F/3.5-6.3

Optical Zoom 10 x

Zoom Adjustment Manual

Lens Construction 13 group(s) / 15 element(s)

Filter Size 62 mm

Lens System Mounting Four Thirds

Features ED glass, aspherical lens

Lens System (2nd)

Type Zoom lens - 11 mm - 22 mm - f/2.8-3.5

Special Functions Wide angle, zoom

Focal Length 11 mm - 22 mm

Focal Length Equivalent to 35mm Camera 22 - 44mm

Min Focus Range 28 cm

Lens Aperture F/2.8-3.5

Focus Adjustment Automatic

Optical Zoom 2 x

Lens Construction 10 group(s) / 12 element(s)

Filter Size 72 mm

Features Floating system, aspherical lens

Additional Features

Self Timer Yes

Self Timer Delay 2sec, 12sec

Flash Terminal Hot shoe

Additional Features Direct print, USB 2.0 compatibility, RGB primary colour

filter, auto power save, digital noise reduction, DPOF

support, IR filter, display brightness control,

depth-of-field preview button, sharpness control, digital

image rotation, PRINT Image Matching, PictBridge support,

histogram display, AE lock, AF lock, resizing an image,

saturation control, built-in eyepiece shutter, LCD live

view mode, shadow point display, highlight point display,

Viewfinder

Viewfinder Type Optical - eye-level porro prism

Field Coverage 95%

Magnification 0.93x

Dioptric Correction Range -3 to +1

Viewfinder Frames Autofocus frame

LCD Display Information Shutter speed, exposure compensation, AE lock,

AF-in-focus, flash charge completion, aperture, white

balance, metering system, Exposure Mode, battery status,

record mode, frames-remaining counter

Display

Type LCD display - TFT active matrix - 2.5" - colour

Display Form Factor Rotating

Display Format 215,250 pixels

Connections

Connector Type 1 x USB ¦ 1 x composite video output

Expansion Slot(s) 1 x CompactFlash Card - type I/II ¦ 1 x xD-Picture Card

Software

Software Drivers & Utilities, Olympus Master

Miscellaneous

Carrying Case Carrying bag

Included Accessories Carrying strap, lens hood, dust cap, body cap, lens cap

Cables Included USB cable ¦ Video cable

Power

Power Device Battery charger - external

Battery

Supported Battery Olympus BLM-1

Supported Battery Details 1 x Li-ion rechargeable battery - 1500 mAh ( included )

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C

Min Storage Temperature -20 °C

Max Storage Temperature 60 °C

Humidity Range Operating 30 - 90%

Humidity Range Storage 10 - 90%
