E-PL5 1442 Kit Silver

• Next generation 16Mpixel

LiveMos sensor

• TruePic VI image processor

• ISO sensitivity up to ISO

25,600

• Ultra-fast autofocus so you

won’t miss a shot

• FAST AF + Touch operation • Wide dynamic range

• Built-in 2-axis stabilisation • 3inch 460,000 dot LCD

display for excellent visibility

Best-in-class image quality

It might be small on size and weight, but the E-PL5 is certainly big when it comes to image quality - matching that of our leading OM-

D camera in fact. As a result, it delivers stills and movies with consistently high resolution, rich gradation, low noise and wide dynamic

range. And with the incredibly fast autofocus and a touchscreen that puts focus + shoot literally at your fingertips, you never miss that

killer shot again. It’s easy to shoot from high and low angles, or unusual vantage points as well thanks to the tiltable LCD display, which

is absolutely ideal for framing self-portraits for instance. The E-PL5 has also been designed with the creativity of photographers in mind:

There are 12 striking Art Filters and 6 Art Effects for you to choose from, allowing you to create one-touch masterpieces with an artistic

wow factor. This camera also has the most advanced connectivity ever seen in a PEN: with a FlashAir card (trademark of Toshiba) you

can now automatically transfer your photos and videos to other devices like your smartphone, wherever you are. Perfect for posting

them on social networking sites without any fuss. And you even have the option of acquiring add-ons specially developed for this PEN

model, including an underwater case for diving deeper with your photos, and exchangeable grips to alter the look of your E-PL5 at will.

Specifications

Type

Body material Metal

Lens mount Micro Four Thirds

Image Sensor

Type 4/3'' Live MOS sensor

Effective pixels 16.1 Megapixels

Filter array Primary colour filter (RGB)

Aspect ratio & area 4:3 / 17.3 x 13.0mm

Full resolution 17.2 Megapixels

Engine

Type TruePic VI

Filter

Dust reduction filter Supersonic Wave Filter

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Live View

Displayed information Aperture

Shutter speed

Auto bracket

AE lock

Focus mode

Shooting mode

Battery check

My Mode

IS activating mode

Internal temperature warning

Face / Eye detection mode

Record mode

ISO

Sequential shooting mode

White Balance

Metering mode

Exposure compensation

value

AF frame display

AF confirmation mark

Shooting information

Spot metering area

Super FP

Flash status

Touch Panel Condition

Focal length

Eye-Fi condition

Flash mode

Histogram

AF type Contrast detection system

100% field of view Approx. 100%

Magnification levels 5 / 7 / 10 / 14x

Display modes Histogram

Comparison

Grid (4 types)

Standard information

Image Stabiliser

Type Sensor shift

Modes Two-dimensional, vertical or

horizontal activation

Effective Compensation Range Up to 3 EV steps

Focusing System

Method Contrast Detection AF system

(when non high-speed

contrast AF compatible lens

is used, it works as MF assist)

Focus areas 35 points / All target, Group

target (9-areas), Single target

(normal), Single target (small)

Auto selection with Face

Detection ON

800 points / Manual selection

in Magnified View Mode

AF lock Yes , Locked by first position

of shutter release button in

single AF mode, AE/AF lock

button (customised)

Modes Manual focus

Single AF

Continuous AF

Single AF + MF

AF Tracking

Touch target

AF illuminator Yes

Full time AF Yes

Manual focus Yes , With enlarged focusing

area

Face Detection extension Eye Detect AF: Off

Left side priority

Near side priority

Right side priority

Predictive AF Yes

AF tracking Yes , Available in continuous

AF mode

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Exposure System

Modes Programme automatic

Aperture priority

Shutter priority

Manual

Bulb

Time

i-Auto

Scene Modes

Art Filter

Exposure compensation +/- 3EV ( 1, 1/2, 1/3 steps )

Exposure bracketing 2 / 3 / 5 frames ( +/- 1/3, 2/3,

1 EV steps )

7 frames ( +/- 1/3, 2/3 EV

steps )

ISO bracketing 3 frames ( 1/3, 1/2, 1 EV

steps )

AE lock Yes

My Mode 4 settings storable

Enhancement function Shadow Adjustment

Technology

HDR bracketing 3 / 5 frames ( +/- 2 / 3 EV

steps )

7 frames ( +/- 2 EV steps )

Note: HDR picture can not be

made by this function.

Scene Modes

Number of scene modes 25

Modes Portrait

e-Portrait

Landscape

Landscape with Portrait

Macro

Sports

Night Scene

Night Scene with portrait

Children

High key

Low key

Digital Image Stabilisation

Nature Macro

Candle

Sunset

Documents

Panorama

Fireworks

Beach and Snow

Fisheye converter

Macro converter

3D*

Wide converter

Underwater Macro

Underwater Wide

* Only for stills and with usage

of 3D lens (H-FT012)

Multi-Exposure

Max. number of frames 2 frames (shooting)

3 frames (editing)

Auto gain control Yes

Frame assistance Live View

Light Metering

Method TTL open aperture light

metering

Zones 324 zones Multi-pattern

Sensing System

Detection range 0 - 20 EV (17mm f2.8, ISO

100)

Modes ESP light metering

Spot metering

Centre weighted metering

Highlight

Shadow

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Art Filter

Modes Pop Art

Soft Focus

Pale & Light Colour

Light Tone

Grainy Film

Pin Hole

Diorama

Cross Process

Dramatic Tone

Gentle Sepia

Key Line

Water colour

Variation / Effect Available

Sensitivity

Auto ISO 200 - 25600

(customisable, default ISO

200 - 1600)

Manual ISO 200 - 25600 in 1/3 or 1

EV ISO steps

Shutter

Shutter type Computerised focal-plane

shutter

Self timer 2s / 12s

Custom (delay

1-30sec.,shooting interval

0.5/1/2/3sec.,number of

shots 1-10)

Shutter Speeds

Shutter speed range 1/4000 - 60s (in 1/3, 1/2, 1

EV steps)

Bulb mode Up to 30 minutes (selectable

longest time in the menu,

default: 8 minutes)

White Balance

AUTO WB system Advanced detection system

with Live MOS sensor

Manual White balance (One-

Touch)

Yes

White balance bracketing 3 frames / +/- 2, 4, 6mired

steps

One-touch white balance 2 custom settings can be

registered

Custom WB 1 setting can be registered at

Kelvin temperature (2000K -

14000K)

Preset values Tungsten

Flourescent 1

Sunlight

Flash

Overcast

Shade

Underwater

Auto Flash adjustment Off / Auto WB / Flash

Keep warm colour On / Off

White balance adjustment +/- 7 in each A-B / G-M

axis (in Auto WB, preset WB

mode & one-touch WB)

Sequence Shooting

Speed (H) Approx. 8fps

Speed (L) 3.6fps (IS off) , 3.0fps

Max. number of frames 27 frames (RAW)

19 frames (JPG / Large

Normal mode)

Conditions Memory card: Toshiba SDHC

UHS-I card R95 W80 model

Premiugate series �Class 10�

8GB

When using the M.ZUIKO

DIGITAL 14-42mm II R

f3.5-5.6

Note: Depending on shooting

conditions, the sequential

shooting speed may reduce

speed during shooting.

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Image Processing

Colour space sRGB / AdobeRGB

Sharpness + Contrast 5 levels

Contrast 5 levels

Saturation 5 levels

Black & White filter Yellow, Orange, Red, Green

Black & White toning Sepia, Blue, Purple or Green

in Black & White mode

Picture mode i-Enhance, Vivid, Natural,

Portrait, Muted, Monotone,

Art Filter, Custom

Gradation 4levels (auto, high key,

normal, low key)

Engine TruePic VI

Art Filter bracketing Available

Tele converter effect 2x

Internal Flash

Modes AUTO

Manual (Full, 1/4, 1/16, 1/64)

Red-eye reduction

Slow synchronisation with

red-eye reduction

Slow synchronisation

Slow synchronisation 2nd

curtain

Fill-in

Off

Type Detachable flash (bundled)

Flash compensation +/- 3 EV ( 1/3, 1/2, 1 EV

steps )

Guide number 10 (ISO 200)

X-sync speed 1/250s / 1/4000s (Super FP

Mode)

External Flash Control

X-sync speed 1/250s / 1/4000s (Super FP

Mode)

Type TTL AUTO, AUTO, MANUAL,

FP TTL AUTO, FP MANUAL

Modes Auto

Red-eye reduction

Slow synchronisation

2nd curtain and slow

synchronisation

Fill-in for exclusive flash

Manual

Intensity +/- 3 EV ( 1/3, 1/2, 1 EV

steps )

Note: Some functions are

only available if they are

supported by the external

flash.

Wireless Flash Control

Number of channels 4 channels

Compatible external flash FL-36R, FL-50R, FL-300R,

FL-600R

Control method Triggered and controlled by

bundled flash

Group setting 4 groups

Available when used together

with cameras compatible

with the Olympus wireless RC

flash system.

Monitor

Monitor type Tiltable LCD - Touch Panel

Monitor size 7.6cm / 3.0'' (16:9)

Resolution 460000 dots

Brightness adjustment +/- 2 levels

Colour balance +/- 7 levels Vivid (default) /

Natural

Touch Control fucntions Shutter release

Enlargement

Live Guide

AF area selection

AF area enlargement

Frame forward/backward

Enlargement playback

Super Control Panel

Art Filter

Scene Modes

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Super Control Panel

Displayed information Battery indicator

Record mode

Shutter speed

Aperture value

Exposure compensation

indicator

ISO

AE bracketing

AF frame

Focus mode

AEL notification

Face detection

Number of storable frames

Metering mode

Exposure mode

Exposure level view

Flash compensation value

Colour space

Gradation

Colour saturation

compensation value

Sharpness compensation

value

Contrast compensation value

White balance

White balance compensation

value

Noise reduction

Flash mode

Drive mode

Internal temperature warning

Histogram

Recording Formats

RAW 12bit

RAW & JPEG Yes parallel recording

JPEG Yes

Aspect ratio 4:3 / 3:2 / 16:9 / 6:6 / 3:4

MPO (3D) Yes

Image Size

RAW 4608 x 3456 compressed /

17MB / frame

4608 x 3456 Fine

(compression: 1/4) / 7.5MB /

frame

4608 x 3456 Normal

(compression: 1/8) / 3.5MB /

frame

2560 x 1920 Normal

(compression: 1/8) 1.1MB /

frame

1024 x 768 Normal

(compression: 1/8) / 0.3MB /

frame

Still Image Recording

EXIF 2.2

PIM III

DPOF Yes

DCF Yes

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Movie Recording System

Recording format MOV(MPEG-4AVC/H.264),

AVI(Motion JPEG)

Image Stabilisation Mode Yes Electronical image

shifting (Digital IS)

HD Movie quality Full HD 1920 x 1080 (16:9)

30p, 20Mbps (MOV)

Full HD 1920 x 1080 (16:9)

30p, 17Mbps (MOV)

HD 1280 x 720 (16:9) 30p,

13Mbps (MOV)

HD 1280 x 720 (16:9) 30p,

10Mbps (MOV)

HD 1280 x 720 (16:9) / 30fps

(AVI Motion JPEG®)

Movie quality 640 x 480 / 30fps (AVI Motion

JPEG®)

29min (17Mbps)

14min (SD) / 7min (HD) (AVI

Motion JPEG®)*

Max. file size 4GB (AVCHD)

2GB (Motion-JPEG)

Exposure Modes Aperture priority

Art Filter

Manual

Programme automatic

Shutter priority

* Some Art Filters are

excluded

Movie effects Multi shot echo

One shot echo

Art fade

One push tele-converter

Sound Recording System

Internal microphone Stereo

Recording format Stereo PCM/16bit, 48kHz,

Wave Format Base

External microphone Optional

Image footage 30s

Speaker Yes

Microphone functions Wind Noise Reduction

Recording Volume

View Images

Modes Index

Calendar

Zoom

Slide show

Movie

Single

Light box Yes

Histogram in playback mode Yes

Shooting information Off / On

Erase / Protect / Copy Function

Erase modes Single, All, Selected

Image protect mode Single frame, Selected

frames, All Frames, Release

protect (Single/All selected)

Image Editing

RAW data edit Yes

Red-eye reduction Yes

Sepia Yes

Black & White Yes

Resize Yes

Correction of saturation Yes

Shadow Adjustment Yes

Trimming Yes

e-Portrait Yes

Menu languages in camera English, French, German,

Spanish, Italian, Russian,

Czech, Dutch, Danish,

Polish, Portuguese, Swedish,

Norwegian, Finnish, Croatian,

Slovenian, Hungarian,

Greek, Slovak, Turkish,

Latvian, Estonian, Lithuanian,

Ukrainian, Serbian

Customisation Options

Fn Button Yes

My Mode 4 settings storable (Can be

set to mode dial.)

Factory reset Full / Standard

Programmable button Yes

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Interface

Media SD Memory Card (SDHC,

SDXC, UHS-I compatible)

Class 6 is recommended for

Movie shooting

HDMI™ Yes Micro connector (Type D)

USB 2.0 High Speed Yes

Combined V & USB output Yes NTSC or PAL selectable

* �HDMI�, the HDMI logo and

�High-Definition Multimedia

Interface� are trademarks

or registered trademarks of

HDMI Licensing LLC.

Connection Accessory Port 2

Wireless connectivity FlashAir

Eye-Fi Card compatible

Bluetooth®

Power Supply

Battery BLS-5 Li-Ion battery

(included) Lithium-Ion Battery

(CR-V3 not compliant)

Sleep mode Available (1min, 3min, 5min)

Environment

Temperature 0 - 40°C operating

temperature / -20 - 60°C

storage temperature

Humidity 30 - 90% operation humidity /

10 - 90% storage humidity

Size

Dimensions (W x H x D) 110.5 x 63.7 x 38.2mm

(without protrusions)

Weight 325g (including battery and

memory card)

279g (body only)

Exterior

Grip Exchangable

Available Colours Black

Silver

White

Table des matières

Autres manuels Olympus Appareil photo numérique

Olympus

Olympus 226275 - Stylus 1010 10MP Digital Camera Guide de configuration

Olympus

Olympus T-10 Mode d’emploi

Olympus

Olympus CAMEDIA C-460 Zoom Manuel utilisateur

Olympus

Olympus SP-810UZ Manuel utilisateur

Olympus

Olympus 300 Digital - Stylus 300 3.2 MP Digital... Guide de configuration

Olympus

Olympus Stylus 1 Manuel utilisateur

Olympus

Olympus TG-860 Manuel utilisateur

Olympus

Olympus DIGITAL CAMERA TG-805 Manuel utilisateur

Olympus

Olympus C030303ZOOM Manuel utilisateur

Olympus

Olympus FE 220 - Digital Camera - Compact Manuel utilisateur

Olympus

Olympus X-840 Manuel utilisateur

Olympus

Olympus E-PL8 Manuel utilisateur

Olympus

Olympus Stylus 840 Manuel utilisateur

Olympus

Olympus SH-60 Manuel utilisateur

Olympus

Olympus Stylus Tough 8000 Blue - Stylus Tough 8000 12MP 2.7 LCD Digital... Instructions de montage

Olympus

Olympus E420 - Evolt 10MP Digital SLR Camera Guide de configuration

Olympus

Olympus SP-565 UZ Guide d'installation

Olympus

Olympus SP-310 Manuel utilisateur

Olympus

Olympus CAMEDIA C-3030 Zoom Manuel utilisateur

Olympus

Olympus Stylus 800 Guide d'installation

Olympus

Olympus IR 500 - 4MP Digital Solutions Camera Mode d’emploi

Olympus

Olympus 750-GP1 - Stylus 750 7.1 MP 5X Optical Zoom All... Instructions de montage

Olympus

Olympus CAMEDIA C-7070 Wide Zoom Manuel utilisateur

Olympus

Olympus STYLUS-5010 Instructions de montage

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
