Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

E-3

• Professional working tool • World's fastest auto focus

system*

• Fully biaxial high-speed 11

point AF system

• 5fps sequential shooting

with 17 image RAW buffer

• High-performance built-in

image stabiliser

• High Speed 10.1 Megapixel

Live MOS sensor

• Qualified image processing

with new TruePic III

• Excellent variety of digital

lenses

It’s here: The new flagship of the Four Thirds Standard-based Olympus E-System. The E-3 gives photographers a high-performance

tool that is primed for any assignment and satisfies the most stringent demands for D-SLR photography. It represents the ultimate

choice for the professional photographer and provides the highest levels of speed and image quality as well as Live View capabilities

and the ultimate in reliability.

Specifications

Type

Body material Magnesium alloy body

Lens mount Four Thirds mount

Image Sensor

Type 4/3'' Hi-Speed Live MOS

sensor

Effective pixels 10.1 Megapixels

Filter array Primary colour filter (RGB)

Aspect ratio & area 4:3 / 17.3 x 13.0mm

Full resolution 11.8 Megapixels

Engine

Type TruePic III

Filter

Dust reduction filter Supersonic Wave Filter

Viewfinder

Viewfinder type Eye-level Pentaprism type

optical viewfinder

Field of view Approx. 100%

Magnification Approx. 1.15x with a 50mm

lens set to infinity at -1

dioptre

Depth of field preview Yes Preview button

Eye point 20mm

Diopter adjustment -3.0 - +1.0 diopter / built-in

type

Focusing screen Interchangeable type

Mirror Quick return mirror

Eye piece shutter built-in type

Live View

Displayed information Focus mode

AF frame display

AF confirmation mark

Shooting information

100% field of view 100%

Magnification levels 5 / 7 / 10x

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Image Stabiliser

Type Sensor shift

Modes Two-dimensional, vertical or

horizontal activation

Effective Compensation Range Up to 5 EV steps

Focusing System

Method TTL phase difference

detection system

Focus areas 11 points / fully biaxial,

automatic and manual

selection

AF illuminator Yes , Built-in flash (external

flash available)

AF lock Yes , Locked by first position

of shutter release button in

single AF mode, AE/AF lock

button (customised)

AF tracking Yes , Available in continuous

AF mode

Detection range -2 - 19 EV (ISO 100)

Modes Manual focus

Single AF

Single AF + MF

Continuous AF

Continuous AF + MF

Exposure System

Exposure compensation +/- 5EV / 1, 1/2, 1/3 steps

Exposure bracketing 3 / 5 frames ( +/- 1/3, 2/3, 1

EV steps )

ISO bracketing 3 frames / 1/3, 1/2, 1 EV

steps

Modes Programme automatic

Aperture priority

Shutter priority

Manual

Light Metering

Method TTL open aperture light

metering

Zones 49 zones Multi-pattern

Sensing System

Detection range 1 - 20 EV (50mm, 1:2, ISO

100)

Modes ESP light metering

Spot metering

Centre weighted metering

Highlight

Shadow

Sensitivity

Auto ISO 100 - 3200

Manual ISO 100 - 3200 in 1/3 or 1 EV

ISO steps

Shutter

Shutter type Computerised focal-plane

shutter

Shutter release Soft Touch Electromagnetic

Self timer 12s / 2s

Anti Shock Yes release delay: 1 - 30s

Shutter Speeds

Shutter speed range 1/8000 - 60s (in 1/3, 1/2, 1

EV steps)

Bulb mode Up to 30 minutes (selectable

longest time in the menu,

default: 8 minutes)

Shutter speed P, Ps 1/8000 - 60s

Shutter speed A priority 1/8000 - 60s

Shutter speed S priority 1/8000 - 60s

Shutter speed scene mode 1/8000 - 60s

White Balance

AUTO WB system Hybrid detection system with

High-speed Live MOS sensor

and dedicated external

sensor

Selectable steps in Kelvin 7 steps (3000 - 7500 K)

White balance adjustment +/- 7 in each R-B / G-M axis

(in Auto WB and preset WB

mode)

Custom WB 1 setting can be registered at

Kelvin temperature (2000K -

14000K)

One-touch white balance 1 custom settings can be

registered

White balance bracketing 3 frames / +/- 2, 4, 6mired

steps

Preset values Overcast

Shade

Tungsten

Sunlight

Flourescent 1

Flourescent 2

Flourescent 3

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Sequence Shooting

Speed (H) 5fps

Speed (L) 1 - 4fps

Max. number of frames 17 frames (RAW)

Up to card capacity (JPG /

Large Normal mode)

Conditions Memory card: SanDisk

Extreme III

Image Processing

Colour space sRGB / AdobeRGB

Engine TruePic III

Sharpness + Contrast 5 levels

Saturation 5 levels

Contrast 5 levels

Black & White filter Yellow, Orange, Red, Green

Black & White toning Yellow, Orange, Red, Green

in Black & White and Sepia

mode.

Picture mode Vivid, Natural, Portrait, Muted,

Monotone, Custom (default

setting: Natural)

Gradation 4levels

Internal Flash

Guide number 13 (ISO 100)

Flash compensation +/- 3 EV / 1/3, 1/2, 1 EV

steps

Modes AUTO

Manual

Red-eye reduction

Slow synchronisation with

red-eye reduction

Slow synchronisation

Slow synchronisation 2nd

curtain

Fill-in

Off

Bracketing 3 frames / 1/3, 1/2, 1 EV

steps

External Flash Control

X-sync speed 1/250s / 1/8000s

Type TTL AUTO, AUTO, MANUAL,

FP TTL AUTO, FP MANUAL

Modes Auto

Manual

Red-eye reduction

Slow synchronisation with

red-eye reduction

Slow synchronisation

2nd curtain and slow

synchronisation

Fill-in for exclusive flash

Intensity +/- 3 EV / 1, 1/2, 1/3 EV

steps

Wireless Flash Control

Compatible external flash FL-50R, FL-36R

Control method Triggered and controlled by

built-in flash light

Modes TTL Auto (TTL pre-flash

mode)

Auto

Manual

FP TTL Auto

FP Manual

Number of channels 4 channels

Group setting 3 groups

Monitor

Monitor type Multi-angle HyperCrystal LCD

(semi-transmissive TFT colour

LCD)

Monitor size 6.4cm / 2.5''

Resolution 230000 dots

BrightCapture Yes

Brightness adjustment 15 levels

Recording Formats

RAW 12bit

RAW & JPEG Yes

JPEG Yes

JPEG compression 1/2.7, 1/4, 1/8, 1/12SHQ

1/2.7, 1/4, 1/8, 1/12HQ

1/2.7, 1/4, 1/8, 1/12SQ

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Image Size

RAW 3648 x 2736 compressed /

11MB / frame

Large 3648 x 2736 Super Fine /

6.8MB / frame

3648 x 2736 Fine

(compression: 1/4) / 4.7MB /

frame

3648 x 2736 Normal

(compression: 1/8) / 2.2MB /

frame

3648 x 2736 Basic

(compression: 1/12) /

1.5MB / frame

Middle 3200 x 2400 Super Fine /

5.3MB / frame

3200 x 2400 Fine

(compression: 1/4) / 3.7MB /

frame

3200 x 2400 Normal

(compression: 1/8) / 1.7MB /

frame

3200 x 2400 Basic

(compression: 1/12) /

1.1MB / frame

2560 x 1920 Super Fine /

3.6MB / frame

2560 x 1920 Fine

(compression: 1/4) / 2.2MB /

frame

2560 x 1920 Normal

(compression: 1/8) / 1.1MB /

frame

2560 x 1920 Basic

(compression: 1/12) /

0.7MB / frame

Small 1600 x 1200 Super Fine /

1.3MB / frame

1600 x 1200 Fine

(compression: 1/4) / 0.8MB /

frame

1600 x 1200 Normal

(compression: 1/8) / 0.5MB /

frame

1600 x 1200 Basic

(compression: 1/12) /

0.3MB / frame

1280 x 960 Super Fine /

0.8MB / frame

1280 x 960 Fine

(compression: 1/4) / 0.5MB /

frame

1280 x 960 Normal

(compression: 1/8) / 0.3MB /

frame

1280 x 960 Basic

(compression: 1/12) /

0.2MB / frame

1024 x 768 Super Fine /

0.5MB / frame

1024 x 768 Fine

(compression: 1/4) / 0.4MB /

frame

1024 x 768 Normal

(compression: 1/8) / 0.2MB /

frame

1024 x 768 Basic

(compression: 1/12) /

0.1MB / frame

640 x 480 Super Fine /

0.2MB / frame

640 x 480 Fine (compression:

1/4) / 0.2MB / frame

640 x 480 Normal

(compression: 1/8) / 0.1MB /

frame

640 x 480 Basic

(compression: 1/12) /

0.1MB / frame

Still Image Recording

EXIF Yes

PIM Yes

DPOF Yes

DCF Yes

View Images

Index 4, 9, 16, 25 frames

Calendar Yes

Zoom Yes 2 - 14x

Slide show Yes

Auto rotation Yes

Light box Yes

Histogram in playback mode Yes

Shooting information Histogram (independent

luminance / RGB available),

Highlight / Shadow point

warning, AF frame, Shooting

information

Erase / Protect / Copy Function

Erase modes Single, All, Selected

Image protect mode Single, Selected

Copy mode Single, All, Selected

Image Editing

RAW data edit Yes

Red-eye reduction Yes

Sepia Yes

Black & White Yes

Resize Yes

Correction of saturation Yes

Shadow Adjustment Yes

Aspect ratio Yes

Menu languages in camera English, French, German,

Spanish, Italian, Russian,

Czech, Dutch, Danish,

Polish, Portuguese, Swedish,

Norwegian, Finnish, Croatian,

Slovenian, Hungarian,

Greek, Slovak, Turkish,

Latvian, Estonian, Lithuanian,

Ukrainian, Serbian

Menu languages by download Additional one language

from 15 further languages by

download via the internet.

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Customisation Options

Fn Button Off, one-touch WB, test

picture, preview, Live View,

AF home setting, MF, record

format, exposure mode, My

Mode, underwater modes

Custom preset options 2

My Mode 4 settings storable

Interface

Media Dual slot for CompactFlash

card (Type I and II), Microdrive

and xD picture card

USB 2.0 High Speed Yes

Video out Yes NTSC or PAL selectable

Infrared Yes

DC input Yes

Synchro socket Yes

Power Supply

Battery BLM-1 Li-Ion battery

(included)

Battery life Approx. 610 shots with

BLM-1 under CIPA testing

standard (optical viewfinder).

Sleep mode 1, 3, 5, 10 min. and off

selectable.

Environment

Temperature 0 - 40°C operating

temperature / -20 - 60°C

storage temperature

Humidity 30 - 90% operation humidity /

10 - 90% storage humidity

Size

Dimensions (W x H x D) 142.5 x 116.5 x 74.5mm

(without protrusions)

Weight 810g (body only)

Top Display

Displayed information Activated AF points

BKT notification

B/W mode notification

Drive mode

Exposure compensation

indicator

Exposure mode

Flash mode

Focus mode

ISO

Metering mode

Number of storable frames

Record mode

White balance

White balance compensation

value

Back light timer

Super Control Panel

Displayed information Metering mode

Exposure mode

Aperture value

Shutter speed

Exposure level view

Flash compensation value

Exposure compensation

indicator

AE bracketing

ISO

Colour space

Picture mode

Gradation

Colour saturation

compensation value

Sharpness compensation

value

Contrast compensation value

White balance

White balance compensation

value

Noise reduction

AEL notification

Flash mode

Focus mode

AF frame

Drive mode

Record mode

Number of storable frames

Memory card

Battery indicator

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Super Control Panel (Flash)

Displayed information AF illuminator disactivated

notification

AEL notification

Aperture value

Bracketing

Built-in flash intensity

Colour space

Exposure compensation

indicator

Exposure mode

Flash compensation value

Group settings

Noise reduction

Shutter speed

Wireless channel setting

Autres manuels pour E-3

Table des matières

Autres manuels Olympus Appareil photo numérique

Olympus

Olympus E-M1 Manuel utilisateur

Olympus

Olympus CAMEDIA C-5500 Sport Zoom Guide d'installation

Olympus

Olympus Sylus 105 Manuel utilisateur

Olympus

Olympus FE-130/X-740 Guide d'installation

Olympus

Olympus Stylus 150 Manuel utilisateur

Olympus

Olympus CAMEDIA C-760 Ultra Zoom Manuel utilisateur

Olympus

Olympus E420 - Evolt 10MP Digital SLR Camera Guide de configuration

Olympus

Olympus C-315ZOOM Guide d'installation

Olympus

Olympus SH-25MR Manuel utilisateur

Olympus

Olympus E-500 - EVOLT Digital Camera Manuel utilisateur

Olympus

Olympus STYLUS-5010 Manuel utilisateur

Olympus

Olympus SP-620UZ Guide de configuration

Olympus

Olympus Stylus Tough 8000 Blue - Stylus Tough 8000 12MP 2.7 LCD Digital... Mode d’emploi

Olympus

Olympus SP 320 - Digital Camera - 7.1 Megapixel Guide de configuration

Olympus

Olympus FE-26 - Digital Camera - Compact Guide de configuration

Olympus

Olympus E420 - Evolt 10MP Digital SLR Camera Manuel utilisateur

Olympus

Olympus u-5000 Guide d'installation

Olympus

Olympus 226125 - Stylus 830 Digital Camera Guide de configuration

Olympus

Olympus SH-50 Manuel utilisateur

Olympus

Olympus STYLUS VERVE S Manuel utilisateur

Olympus

Olympus VH-410 Manuel utilisateur

Olympus

Olympus SP 570 - UZ Digital Camera Guide d'installation

Olympus

Olympus 8080 - CAMEDIA C Wide Zoom Digital Camera Manuel utilisateur

Olympus

Olympus CAMEDIA C-3030 Zoom Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
