UNPACKING

After unpacking the unit, inspect carefully for any

damage that may have occurred during transit. Check

for loose, missing, or damaged parts. If any damage is

observed, a shipping damage claim must be ﬁled with

the carrier. DO NOT use the OEMTOOLS™24887 4,500

CFM 3 Speed Evaporative Cooler if broken, bent,

cracked or damaged parts (including labels) are noted.

Any Evaporative Cooler that appears damaged in any

way, operates abnormally or is missing parts should

be removed from service immediately. If you suspect

that the Evaporative Cooler was subjected to shock

load (a load that was dropped suddenly, unexpectedly,

etc.), immediately discontinue use until it has been

checked by a factory authorized service center.

Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself

and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in

personal injury and/or damage to product or property. Please retain instructions for future reference.

Operating Instructions and Parts Manual 24887

1/18

2018 OEMTOOLS™

FOR CUSTOMER SERVICE

Technical Question?

CALL 1-866-458-2472

[email protected]

4,500 CFM 3 SPEED

EVAPORATIVE COOLER

Thank you very much for choosing an OEMTOOLS™Product!

For future reference, please register your new product at www.oem-tools.com and complete the owner’s record below:

Model: _______________ Purchase Date: ___________

Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product

before you begin using it. This product is designed for certain applications only. OEMTOOLS™cannot be responsible for issues arising

from modiﬁcation. We strongly recommend this product is not modiﬁed and/or used for any application other than that for which it was

designed. If you have any questions relative to a particular application, DO NOT use the product until you have ﬁrst contacted customer

service to determine if it can or should be performed on the product.

WARNING: Pursuant to California Proposition 65, this product contains chemicals known to the state of California to cause

cancer and birth defects or other reproductive harm. Wash hands after handling.

The following safety information is provided as a guideline to help you operate your Evaporative Cooler under the safest possible conditions.

Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions are not known or not followed.

The following safety instructions are to provide the user with the information necessary for safe use and operation. Please read and retain these

instructions for the continued safe use of your Evaporative Cooler. Failure to follow instructions listed below may result in serious injury. In addition,

make sure that anyone who uses the equipment understands and follows these safety instructions as well.

WARNING

EXPLANATION OF SAFETY SIGNAL WORDS

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

CAUTION: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may

result in property damage.

NOTES: Provide clarity and helpful information.

Operating Instructions and Parts Manual 24887

4,500 CFM 3 SPEED

EVAPORATIVE COOLER

1/18

2018 OEMTOOLS™

IMPORTANT INSTRUCTIONS

AND SAFETY RULES

1. Know your product. Read this manual carefully. Learn the product’s

applications and limitations, as well as potential hazards speciﬁc to it.

2. Keep work area clean and well lit. Cluttered or dark work areas invite

accidents.

3. Keep children away. All children should be kept away from the work

area. Never let a child handle tools or equipment without strict adult

supervision.

4. DO NOT operate this product if under the inﬂuence of alcohol or drugs.

Read warning labels on prescriptions to determine if your judgment or

reﬂexes are impaired while taking drugs. If there is any doubt, DO NOT

attempt to operate.

5. Use safety equipment. Eye protection should be worn at all times

when operating this tool. Use ANSI approved safety glasses. Everyday

eyeglasses are NOT safety glasses. Dust mask, non-skid safety

shoes, hard hat or hearing protection should be used in appropriate

conditions.

6. Wear proper apparel. Loose clothing, gloves, neck-ties, rings, bracelets

or other jewelry may present a potential hazard when operating this

product. Keep all apparel clear of the product.

7. DO NOT overreach. Keep proper footing and balance at all times when

operating this product.

8. Check for damage. Check equipment regularly. If part of the product

is damaged, it should be carefully inspected to make sure that it can

perform its intended function correctly. If in doubt, discontinue use of

product.

9. Keep away from ﬂammables. DO NOT attempt to operate this product

near ﬂammable materials or combustibles. Failure to comply may

cause serious injury or death.

10.Store this product out of the reach of children and untrained persons.

This product may be dangerous in the hands of untrained users.

11. Keep this product dry and clean.

12.Use only accessories that are recommended by the manufacturer for

your model. Accessories that may be suitable for one product may

become hazardous when used on another product.

13. Service must be performed only by qualiﬁed repair personnel. Service

or maintenance performed by unqualiﬁed personnel could result in a

risk of injury.

14. When servicing a product, use only identical replacement parts. Use of

unauthorized parts or failure to follow maintenance instructions may

create a risk of injury.

15. Maintain a safe working environment. Keep the work area well lit.

Make sure there is adequate surrounding workspace. Keep the work

area free of obstructions, grease, oil, trash, and other debris. Do not

use this product in a damp or wet location.

16. Maintain labels and nameplates on this product. These carry important

information. If unreadable or missing, contact OEMTOOLS™for a

replacement.

17. Keep this product dry, clean, and free from brake ﬂuid, oil, and grease.

18. Avoid accidental ﬁre. DO NOT smoke near this product.

19. The warnings, precautions, and instructions discussed in this manual

cannot cover all possible conditions and situations that may occur. The

operator must understand that common sense and caution are factors

which cannot be built into this product, but must be supplied by the

operator.

20. We believe the information contained herein to be reliable. However,

general technical information is given by us without charge and the

user shall employ such information at their own discretion and risk.

We assume no responsibility for results or damages incurred from the

use of such information in whole or in part.

21. The manufacturer declines any and all responsibility for property

damage or injury if said damage is the result of unskillful handling by

the operator or of failure to observe the basic safety rules set forth in

the instruction manual.

22.The procedures documented in this manual are to serve as guidelines

for the use of this equipment.

23.The use of this equipment is simple and straightforward if you follow

the instructions. When operating this equipment, use common sense,

and only use this equipment for its intended purpose.

PRODUCT DESCRIPTION

The OEMTOOLS™24887 4,500 CFM 3 Speed Evaporative Cooler

is designed to efficiently cool workspaces. This Evaporative Cooler

pulls hot surrounding air through wet cooling pads, where through

process of evaporation, the air is cooled. The powerful 0.25 HP fan

then pushes the cooled air at 4,500 CFM into the surrounding area—

cooling spaces up to 1,300 ft².

PRODUCT SPECIFICATIONS

Motor Power 0.25 HP

Input Voltage 110V AC, 1-Phase

Speed Settings 3

Max Air Volume 4,500 CFM

Water Capacity 14.6 Gallons

Cooling Area Up to 1,300 ft²

Run Time Up to 4 Hours

Dimensions 45"(L) x 28"(W) x 17"(H)

Dry Weight 58 Lbs.

CONTENTS

(1) Evaporative Cooler, (4) Casters, (1) Instruction Manual

SPECIFIC SAFETY INSTRUCTIONS AND WARNINGS

WARNING: Thoroughly read and understand the provided product

manual before attempting to use this product.

1. DO NOT touch the Evaporative Cooler when your hands are wet.

2. DO NOT disassemble, repair or rebuild the Evaporative Cooler. Contact

qualiﬁed personnel for any maintenance extending past the instruction

provided by this manual.

3. Unplug the Evaporative Cooler when it is not in use.

4. Unplug the Evaporative Cooler before moving it or performing

maintenance.

5. DO NOT unplug the Evaporative Cooler by holding the cord. Unplug by

holding the plug.

6. DO NOT use the Evaporative Cooler when there is damage to the cord

or plug. Discard the Evaporative Cooler or return to an authorized

service facility for examination and/or repair.

7. Avoid the use of extension cords when possible. Ensure that they

are UL listed if they must be used. DO NOT use a single extension

cord to operate more than one Evaporative Cooler. DO NOT plug the

Evaporative Cooler into any other cord-connected device (power strip,

surge protector, multiple outlet adapters, etc.).

8. DO NOT use the Evaporative Cooler close to any ﬁre or heat source.

9. DO NOT insert your hand or other objects into the rear housing when

the blade is moving.

10.To reduce the risk of ﬁre or electric shock, DO NOT use this

Evaporative Cooler with any solid-state speed control device.

11.DO NOT run cord under carpeting. DO NOT cover cord with throw rugs,

runners, or similar coverings. DO NOT route cord under furniture or

appliances. Arrange cord away from trafﬁc area and where it will not

be tripped over.

12.DO NOT submerge the Evaporative Cooler in liquids.

13.Conﬁrm the rear panel is attached prior to operation.

14.ALWAYS place the Evaporative Cooler on a ﬂat, level surface.

15.DO NOT expose electrical connections to water.

16.DO NOT touch electrically live components.

17.DO NOT open the electrical box while the product is in use.

18.Ensure adequate ventilation.

Operating Instructions and Parts Manual 24887

4,500 CFM 3 SPEED

EVAPORATIVE COOLER

1/18

2018 OEMTOOLS™

ASSEMBLY INSTRUCTIONS

The OEMTOOLS™24887 4,500 CFM 3 Speed Evaporative Cooler is pre-

assembled. Carefully remove the Evaporative Cooler from the Box. Install

the (4) casters.

PREPARING FOR OPERATION

IMPORTANT: Read and understand the provided safety instructions prior

to operation.

1. Before attempting to use, inspect the ﬁlter for dirt, dust or residues.

Cooling pads that have accumulated build-up will impede cooling

performance.

2. To operate effectively, position the unit in front of an open door or

window. Ensure the unit is placed on a ﬂat, level surface with the

casters in the locked position.

3. Open another door or window to provide proper ventilation for the unit.

MANUAL FILL

1. Depress the Fill Door located on the front of the unit below the louvers

(the Fill Door features a spring lock, and will release when pressed).

2. Fill the Water Tank using a hose or bucket. Monitor water level using

the Fill Gauge.

3. Press the Fill Door closed (the spring lock with re-engage).

AUTOMATIC FILL CONNECTION

NOTE: This unit features a ﬂoat valve and automatic shut-off function.

This allows the unit to remain connected to an open water source for a

continuous ﬂow of water. The operator may also ﬁll the Water Tank to

capacity (or desired level) prior to running the unit, and then close the

water source.

1. Attach the provided Pigtail Adapter to the Water Inlet.

2. Connect one end of the provided Coil Hose to the Pigtail Adapter.

3. Connect the other end of the Coil Hose to a water supply. Ensure that

both connections are water tight.

OPERATING INSTRUCTIONS

1. Plug the unit into a grounded 110-120V AC outlet.

NOTE: This Evaporative Cooler is equipped with a UL Ground Fault Circuit

Interrupter (GFCI) Plug. This UL GFCI Plug is designed to interrupt power

to the unit if current follows an unintended path. This feature is a safety

measure to reduce risk of electric shock to the operator and electrical

damage to the Evaporative Cooler. If the circuit is tripped, press the Reset

Button located on the plug head. If the Reset Button will not engage and

power is not restored, discontinue use, see the troubleshooting section for

further instruction.

2. Open the water source to ﬁll the Water Tank. Monitor water level using

the Fill Gauge; allow the Water Tank to reach 50% capacity.

WARNING:Water Inlet pressure should not exceed 50 PSI. Higher

pressure may lead to product failure and property damage.

3. Switch the Power to ON.

4. Switch the Pump to ON. Allow to run for 2-3 minutes to saturate the

Cooling Pads with water.

NOTE: The pump will automatically shut-off when the water level is low.

5. Switch the Fan to the ﬁrst speed setting. Allow to run at the ﬁrst speed

setting for 2-3 minutes. Increase the speed of the fan to the desired

setting: Off, Low, Medium and High.

6. To oscillate airﬂow, switch the Swing Setting to ON.

SHUTDOWN INSTRUCTIONS

1. Close the water source.

2. After the Water Tank has emptied, switch the Pump to OFF.

NOTE: See Draining Instructions if the Water Tank is not empty.

3. At the end of each day of use, allow the Fan to run for about 20

minutes to dry the Cooling Pad(s).

4. Switch the Fan to OFF.

5. Switch the Power to OFF.

6. Unplug the Power Cord from the power source.

DRAINING INSTRUCTIONS

1. Turn the Power to OFF, and ensure the unit is not plugged into a power

source.

2. Move the unit outdoors or position the unit over a drain.

3. Unscrew the Drain Cap from the Drain Assembly. Allow the water to

completely drain from the Water Tank.

4. Replace the Drain Cap to the Drain Assembly.

STORAGE

Store the Evaporative Cooler in an upright position and in a clean, dry

area. DO NOT store near ﬂammable items or open ﬂames.

DISPOSAL

At the end of the useful life of the OEMTOOLS™24887 4,500 CFM 3

Speed Evaporative Cooler, dispose of the components in accordance with

all federal, state and local regulations.

PRODUCT MAINTENANCE

WARNING:Unplug this unit from the power source before

performing product maintenance.

WARNING:DO NOT use water to clean the Fan, Electrical

Components or Control Panel.

WARNING: DO NOT attempt to perform product maintenance on

the motor or electrical systems. If there is any doubt that this unit can

perform safely, immediately discontinue use and contact customer

service.

1. Dirt and debris will settle at the bottom of the Water Tank. To optimize

performance, it is recommended that the Water Tank is cleaned

monthly.

2. To maintain high air quality, it is recommended that the water is

ﬂushed from the Water Tank daily.

3. Inspect the cooling pads prior to each use. If dirt, debris or build-up is

present, remove the cooling pad and gently wipe clean. Replace the

cooling pad to the unit.

NOTE: The Cooling Pads are constructed with a special resin impregnated

craft paper speciﬁcally designed for this evaporative cooler. If the unit

is used in accordance with this product manual, and the cooling pads

are properly maintained, they will last several years (under normal

circumstances).

PRODUCT LAYOUT

ITEM DESCRIPTION QTY. ITEM DESCRIPTION QTY.

A Control Panel 1 I Fill Gauge 1

B Oscillating Blades 11 J Cooling Pads* 2

CFan 1 K GFCI Plug* 1

DVertically Adjustable Louvers 11 L Water Inlet* 1

E Manual Fill Door 1 M Pigtail Adapter* 1

FWater Tank 1 N Coil Hose* 1

G Swivel Caster 2 O Water Drain Assembly* 1

H Locking Caster 2

*Not Shown

Operating Instructions and Parts Manual 24887

4,500 CFM 3 SPEED

EVAPORATIVE COOLER

1/18

2018 OEMTOOLS™

3580 E. Raines Road, Suite 3, Memphis, TN 38118

Tel: 1-866-458-2472

www.oem-tools.com

OEMTOOLS™90 DAY LIMITED WARRANTY

For 90 days from the original purchase of this product, OEMTOOLS™will warranty this item. If you ﬁnd any defect in material or workmanship, through

normal usage, return it to the place of purchase or to OEMTOOLS™for repair or replacement at our discretion. In order to obtain this service, send your

tool and proof of purchase, transportation pre-paid, to OEMTOOLS™Q.A. Dept., 3850 Raines Road #3, Memphis, TN 38118. We will not be responsible

for lost or damaged goods during transportation; please insure your package. If our inspection veriﬁes the defect, we will either repair or replace the

product at our election, or we may elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will return

repaired products at our expense, but if we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty,

then you must bear the cost of returning the product.

OEMTOOLS™does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™will not provide any warranty for products

subjected to abnormal use. Abnormal use includes, but is not limited to, abuse, accident, alteration, neglect, and unauthorized or unreasonable use or

repairs. This warranty does not cover bits, blades, ﬁles, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace

blades, bits, ﬁles, and batteries as necessary. OEMTOOLS™reserves the right to make any changes in construction or design at any time without any

obligation in incorporating such changes to tools or equipment previously sold.

OEMTOOLS™makes every effort to ensure that its products meet high quality and durability standards, and warrants to the original purchaser that

this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to

damage due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper

installation, normal wear and tear or to lack of maintenance.

We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or consequential damages arising from the

use of our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation of exclusion

may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF

MERCHANTABILITY AND FITNESS. This warranty gives you speciﬁc legal rights, and you may also have other rights, which vary from state to state.

Don’t forget to register your new OEMTOOLS™product at www.oem-tools.com.

PROBLEM POSSIBLE CAUSE COURSE OF ACTION

Unit does not start and power indicator light

does not illuminate

Electricity is not supplied to unit

Check power supply and outlet

- Reset breaker

- Contact a qualiﬁed electrician

Unit is experiencing motor or electrical failure Contact customer service

Unit output is irregularly low or diminished

Cooling Pad is not fully saturated

Allow Pump to run for 2-3 minutes prior to

starting the Fan

Cooling Pad is not properly inserted, assess and

correct

Cooling Pad requires a break-in period for

optimal absorption; this may take up to one

week of use

Water Tank is empty Check hose connection and water source

Pump is clogged or has malfunctioned Contact customer service

Knocking/shaking sounds from Fan or Motor Loose parts or fasteners

Tighten any visible loose fasteners on the

exterior of the unit; contact customer service if

sounds persist

Excessive water droplet output from Fan Cooling Pad is not properly inserted Assess and correct placement

Musty odor present* †

Stagnant water in Water Tank Drain water completely, clean the Water Tank

and replace with fresh water

Dirt, dust and debris are present on Cooling Pad Gently wipe and clean Cooling Pad; contact

customer service if smell persists

* If a burning smell is noticed, discontinue use and contact customer service before attempting to use.

† A slight, unpleasant odor may be noticed during the ﬁrst few uses. This is normal and a result of manufacturing processes.

TROUBLESHOOTING

Autres manuels OEM Tools Purificateur d'air

OEM Tools

OEM Tools 23974 Manuel de service

Manuels Purificateur d'air populaires d'autres marques

IKEA

IKEA UPPÅTVIND Manuel utilisateur

Nash

Nash AP-1 PureSmart Manuel utilisateur

LG PH-U450 Series Manuel utilisateur

DeLonghi

DeLonghi DDSX 220WFA Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuel utilisateur

Sharp

Sharp FU-40SE Manuel utilisateur

Philips

Philips AC2721 Manuel utilisateur

Hitachi

Hitachi EP-A3000 Manuel utilisateur

TruSens

TruSens Z-2000 Manuel utilisateur

Motorola

Motorola MBP87SN Manuel utilisateur

Beko

Beko ATP 7100I Manuel utilisateur

Carrier

Carrier INFINITY 1620 Manuel utilisateur

AtmosAir

AtmosAir P2002 Manuel utilisateur

Winix

Winix NK300 Manuel utilisateur

Friedrich

Friedrich C-90A Instructions d'utilisation et d'installation

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuel utilisateur

Base aire

Base aire 555 Pro Manuel utilisateur

Champion

Champion CP25 Manuel utilisateur
