Oakley DOUBLE TAP Manuel utilisateur

TABLE OF CONTENTS

ENGLISH 2-13

DEUTSCH 14-25

ESPAÑOL 28-40

FRANCAIS 41-53

ITALIANO 54-66

JAPANESE 67-79

MAGYAR 80-92

PORTUGUÊS 93-105

2 | DOUBLE TAP INSTRUCTION MANUAL

3 | DOUBLE TAP INSTRUCTION MANUAL

DOUBLE TAP™

The mechanical genius of military hardware inspired Double Tap,

™an array of timekeeping machines that prove the

beauty of design isn’t just how something looks -- it’s how it works. We tapped into form and function with a dual

approach that fuses the best of both, stripping down to the nuts and bolts of practical application with sculptures that

make an art of utility. Angular detailing stays low profile for purpose-driven architecture that lives up to its look, from

the intuitive dial face to the subtle highlights that include a red trigger button for activating the chronograph. Each

design in this Oakley timepiece family features surgical grade stainless steel, a locking screw-down crown and a true

sapphire crystal, and every edition is crafted with the uncompromising precision of Swiss Made movement.

4 | DOUBLE TAP INSTRUCTION MANUAL

a b

The timepiece has a locking screw-down crown for water

resistance. You must unscrew the crown before pulling it

out to the click positions that let you set the date and time.

The first click position is for setting the date. The second

click position is for setting the time.

To set the timepiece the first time (or to reset the date

and time after the battery is replaced), do the following:

1. Unscrew the crown from the case. Pull the crown out

to the first click position (a).

2. Turn the crown clockwise until yesterday’s date

appears.

3. Pull the crown out to the second click position (b).

4. Turn the hands clockwise until today’s date appears,

then continue forward until the current time is

reached. If the current time is in the afternoon or

evening, move the hour hand all the way around the

dial to pass 12 o’clock noon.

5. Push the crown back in. Gently turn the crown

clockwise while pushing it inward toward the case,

until it screws back into the case. Be careful not

to over tighten the crown, as this will damage the

mechanism.

To set the exact second, wait until the hand on the

second-counting sub dial (at the right of the main dial

face) reaches “60” before you pull out the crown to

the second click position (b). Set the time then wait

until the exact second is reached before pushing the

crown back in.

SETTING THE DATE AND TIME

Date

Crown

5 | DOUBLE TAP INSTRUCTION MANUAL

TO SET THE TIME

1. Unscrew the crown from the case.

2. Pull the crown out to the second click position (b).

3. Turn the crown until you reach the correct time.

4. Push the crown back in. Gently turn the crown

clockwise while pushing it inward toward the case,

until it screws back into the case. Be careful not

to over tighten the crown, as this will damage the

mechanism.

TO SET THE DATE

1. Unscrew the crown from the case.

2. Pull the crown out to the first click position (a).

3. Turn the crown clockwise until you reach the correct date.

If the current time is between 9 PM and midnight, set

the date to the following day. (This is necessary to

ensure the display will normally change at midnight

instead of 12 noon.)

4. Push the crown back in. Gently turn the crown

clockwise while pushing it inward toward the case,

until it screws back into the case. Be careful not to over

tighten the crown, as this will damage the mechanism.

Setting the date too quickly can result in the incorrect

date being displayed. To restore synchronization, turn

the crown clockwise to go through the range of date

settings (from 01 to 31) when performing the instructions

above.

TO ADJUST THE TIME AND DATE FOR SUBSEQUENT SETTINGS, USE THESE SHORT PROCEDURES

6 | DOUBLE TAP INSTRUCTION MANUAL

USING THE CHRONOGRAPH

The chronograph includes two separate hands:

• The large, narrow hand on the main dial face counts

seconds. One full rotation is 60 seconds.

• The sub dial at the left of the dial face counts minutes.

One full rotation is 30 minutes.

The chronograph is controlled with two push buttons:

• Button “A” starts and stops the timer.

• Button “B” has several functions. It is used to pause

the display at the current split time (also called

“intermediate time”). It is also used to make the

chronograph hands move forward to the ongoing

time being measured. Finally, it is used to reset the

chronograph hands to the zero position.

Before using the chronograph, ensure the crown is

fully screwed in against the case and not at one of the

click positions used for setting time and date. The two

chronograph hands should align precisely at the zero

position. If they do not, see the section on Adjusting the

Chronograph Hands.

Date Button B

Button A

Minute Hand

Second Hand

Chronograph

Second Counter

Crown

Chronograph

Minutes

Counter

Hour Hand

7 | DOUBLE TAP INSTRUCTION MANUAL

TO MEASURE ADDED TIME

Added time (cumulative time) is a measure of how much time

has passed without including pauses. This feature lets you

exclude the time intervals you do not want to measure.

START TIMING

• Press button “A”.

STOP TIMING TEMPORARILY

• Press button “A” to stop timing temporarily.

• Press button “A” again to continue timing.

Continue to use button “A” to add additional time

intervals to the total measure of time. When using

button “A” only, the time that passes while the

chronograph hands are not moving IS NOT ADDED to

the total measure of time. See below if you wish to

include this “split time” in the total measure of time.

RESET

• While timing is stopped, press button “B”.

TO MEASURE SPLIT TIME

Split time (intermediate time) is a measure of the current

time total, taken without stopping the timing circuit. The

hands pause so you can read them, then they catch up to the

ongoing time total.

START TIMING

• Press button “A”.

PAUSE THE HANDS BUT CONTINUE TIMING

• Press button “B” to pause the chronograph hands and

read the current time total.

Although the hands are no longer moving, time is still

being measured.

• Press button “B” again to move the hands to the

currently running time total.

Continue to use button “B” to pause the hands when

desired. Time continues to be measured.

STOP TIMING AND DISPLAY THE FINAL TIME TOTAL

• While the hands are moving, press button “A” to fully

stop timing and display the total time measured.

RESET

• While timing is stopped, press button “B”.

USING THE CHRONOGRAPH - CON’T

8 | DOUBLE TAP INSTRUCTION MANUAL

TO ADJUST THE CHRONOGRAPH HANDS

1. If the chronograph hands currently show a measured

time, use button “B” to reset them near the zero position.

Note that the hands must be stopped before using

button “B” to reset them. If necessary, use button “A”

to stop the hands.

2. Unscrew the crown from the case. Pull the crown out

to the second click position (b).

3. Push button “A” and button “B” simultaneously and

keep them pressed for at least 2 seconds.

4. Adjust the chronograph hands by doing the following:

• Press button “A” to adjust the chronograph hand

that counts seconds. (Press and hold the button for

continuous movement.)

• Press button “B” to finish with that hand and move

on to the other hands.

5. Push the crown back in. Gently turn the crown

clockwise until it screws back into the case. Be

careful not to over tighten the crown, as this will

damage the mechanism.

ADJUSTING THE CHRONOGRAPH HANDS

When the chronograph is reset with button “B,” the two chronograph hands return to the zero position. If these hands

do not align precisely with the zero position (such as after the battery is replaced), use the following procedure to

adjust them.

Date Button B

Button A

Minute Hand

Second Hand

Chronograph

Second Counter

Crown

Chronograph

Minutes

Counter

Hour Hand
