1 OVERVIEW

The NuMaker-emWin-N9H30 development board is a specific development tool based on

N9H30F61IEC IC to provide customers with a low cost and ease of development. It can be easily

customized for customers to provide their own HMI (Human Machine Interface) device server

products.

Figure 1-1 NuMaker-emWin-N9H30 Development Board (Front View)

NuMaker-emWin-N9H30

Apr. 22, 2021 Page 4of 36 Rev 2.12

NUMAKER-EMWIN-N9H30 USER MANUAL

Figure 1-2 NuMaker-emWin-N9H30 Development Board (Rear View)

NuMaker-emWin-N9H30

Apr. 22, 2021 Page 5of 36 Rev 2.12

NUMAKER-EMWIN-N9H30 USER MANUAL

2 INTRODUCTION TO NUMAKER-EMWIN-N9H30 BOARD

The NuMaker-emWin-N9H30 solution uses an outstanding CPU core ARM926EJ-S,

N9H30F61IEC IC which runs up to 300 MHz and features the embedded 64MB DDR memory,

with 16 KB I-cache, 16 KB D-cache and MMU, 56 KB embedded SRAM and 16 KB IBR (Internal

Boot ROM) for booting from SPI Flash or booting from NAND Flash.

The NuMaker-emWin-N9H30 solution integrates touchscreen display, voice input/output, rich

serial port service and I/O interface, providing multiple external storage methods. It contains two

kinds of board, including the NuMaker-emWin-N9H30 board and NuMaker-TFT-LCD7 board.

2.1 NuMaker-emWin-N9H30 Board Features

N9H30F61IEC IC: LQFP216 pin MCP package with DDR (64 MB).

SPI Flash use W25Q256JVEQ (32 MB) booting with quad mode or storage memory.

NAND Flash use W29N01HVSINA (128 MB) booting or storage memory.

Provide one Micro-SD/TF card slot served either as a SD memory card for data storage or

SDIO (Wi-Fi) device.

Provides 2 sets of COM ports.

One DB9 RS-232 port with UART_0 used 75C3232E transceiver IC can be served for

function debug and system development.

One DB9 RS-232 port with UART_2 used 75C3232E transceiver IC for user

application

22 GPIO expansion ports, including 7 sets UART function

JTAG interface provided for software development.

Microphone input and Earphone/Speaker output with 24-bit stereo audio codec

(NAU88C22) for I2S interfaces.

6 sets of user-configurable push button keys.

3 sets of LED for status indication.

Provided SN65HVD230 transceiver IC for CAN bus communication.

Provided MAX3485 transceiver IC for RS-485 device connection.

Provided one buzzer device for program application.

2 sets of RJ45 port with Ethernet 10/100Mbps MAC used IP101GR PHY IC

USB_0 that can be used as Device/HOST and USB_1 that can be used as HOST

supports pen drives, keyboards, mouse and printers.

7”resolution 800x480 4W resistive touch panel for 24bits RGB888 interface.

Provides over-voltage and over current protection used APL3211A IC

Retain RTC battery socket is for CR2032 type and ADC0 detect battery voltage.

System powered could be supplied by DC-5V adaptor or USB VBUS..

NuMaker-emWin-N9H30

Apr. 22, 2021 Page 6of 36 Rev 2.12

NUMAKER-EMWIN-N9H30 USER MANUAL

2.2 NuMaker-emWin-N9H30 Board －Front View

Figure 2-1 shows the main components and connectors from the front view of NuMaker-emWin-

N9H30 board.

NuMaker-emWin-N9H30 board and LCD panel board combination connector (CON8).

Support 4W/5W resistive touch panel for 24bits RGB888 interface

Connector

GPIO pin of N9H30

Function

CON8.1

Power 3.3V

CON8.2

Power 3.3V

CON8.3

GPD7

LCD_CS

CON8.4

GPH3

LCD_BLEN

CON8.5

GPG9

LCD_DEN

CON8.6

GPG8

LCD_VSYNC

CON8.7

GPG7

LCD_HSYNC

CON8.8

GPG6

LCD_CLK

CON8.9

GPD15

LCD_D23(R7)

CON8.10

GPD14

LCD_D22(R6)

CON8.11

GPD13

LCD_D21(R5)

CON8.12

GPD12

LCD_D20(R4)

CON8.13

GPD11

LCD_D19(R3)

CON8.14

GPD10

LCD_D18(R2)

CON8.15

GPD9

LCD_D17(R1)

CON8.16

GPD8

LCD_D16(R0)

CON8.17

GPA15

LCD_D15(G7)

CON8.18

GPA14

LCD_D14(G6)

CON8.19

GPA13

LCD_D13(G5)

CON8.20

GPA12

LCD_D12(G4)

CON8.21

GPA11

LCD_D11(G3)

CON8.22

GPA10

LCD_D10(G2)

CON8.23

GPA9

LCD_D9(G1)

CON8.24

GPA8

LCD_D8(G0)

CON8.25

GPA7

LCD_D7(B7)

CON8.26

GPA6

LCD_D6(B6)

NuMaker-emWin-N9H30

Apr. 22, 2021 Page 7of 36 Rev 2.12

NUMAKER-EMWIN-N9H30 USER MANUAL

CON8.27

GPA5

LCD_D5(B5)

CON8.28

GPA4

LCD_D4(B4)

CON8.29

GPA3

LCD_D3(B3)

CON8.30

GPA2

LCD_D2(B2)

CON8.31

GPA1

LCD_D1(B1)

CON8.32

GPA0

LCD_D0(B0)

CON8.33

CON8.34

CON8.35

CON8.36

CON8.37

GPB2

LCD_PWM

CON8.38

GPG4

LCD_RST

CON8.39

VSS

CON8.40

VSS

CON8.41

ADC7

CON8.42

ADC3

Vsen

CON8.43

ADC6

CON8.44

ADC4

CON8.45

CON8.46

ADC5

CON8.47

VSS

CON8.48

VSS

CON8.49

GPG0

I2C0_C

CON8.50

GPG1

I2C0_D

CON8.51

GPG5

TOUCH_INT

CON8.52

CON8.53

CON8.54

CON8.55

CON8.56

CON8.57

NuMaker-emWin-N9H30

Apr. 22, 2021 Page 8of 36 Rev 2.12

NUMAKER-EMWIN-N9H30 USER MANUAL

CON8.58

CON8.59

VSS

CON8.60

VSS

CON8.61

CON8.62

CON8.63

Power 5V

CON8.64

Power 5V

Power supply switch (SW_POWER1): System will be power on if the SW_POWER1 button

is pressed.

3sets indication LEDs:

LED

Color

Descriptions

LED1

Red

The system power will

be terminated and LED1

lighting when the input

voltage is over 5.7V or

the current is over 2A.

LED2

Green

Power normal state.

LED3

Green

Controlled by GPH2 pin

6sets user SWs, Key Matrix for user definition.

Key

GPIO pin of N9H30

Function

GPF10

Row0

GPB4

Col0

GPF10

Row0

GPB5

Col1

GPE15

Row1

GPB4

Col0

GPE15

Row1

GPB5

Col1

GPE14

Row2

GPB4

Col0

GPE14

Row2

GPB5

Col1

NuMaker-emWin-N9H30

Apr. 22, 2021 Page 9of 36 Rev 2.12

NUMAKER-EMWIN-N9H30 USER MANUAL

NAND Flash (128 MB) with Winbond W29N01HVS1NA (U9).

Microphone (M1): Through the nuvoTon NAU88C22 IC sound input.

Audio CODEC IC (U10): nuvoTon NAU88C22 IC connects to N9H30 using I2S interface.

SW6/SW7/SW8: 1-2 short for RS-485_6 function and connected to 2P terminal (CON5

and J5).

SW6/SW7/SW8: 2-3 short for I2S function and connected to NAU88C22 (U10).

CMOS Sensor connector (CON10, SW9~10)

Connector

GPIO pin of N9H30

Function

CON10.1

VSS

CON10.2

VSS

CON10.3

Power 3.3V

CON10.4

Power 3.3V

CON10.5

CON10.6

CON10.7

GPI4

S_PCLK

CON10.8

GPI3

S_CLK

CON10.9

GPI8

S_D0

CON10.10

GPI9

S_D1

CON10.11

GPI10

S_D2

CON10.12

GPI11

S_D3

CON10.13

GPI12

S_D4

CON10.14

GPI13

S_D5

CON10.15

GPI14

S_D6

CON10.16

GPI15

S_D7

CON10.17

GPI6

S_VSYNC

CON10.18

GPI5

S_HSYNC

CON10.19

GPI0

S_PWDN

CON10.20

GPI7

S_nRST

CON10.21

GPG2

I2C1_C

CON10.22

GPG3

I2C1_D

CON10.23

VSS

CON10.24

VSS

NuMaker-emWin-N9H30

Apr. 22, 2021 Page 10 of 36 Rev 2.12

NUMAKER-EMWIN-N9H30 USER MANUAL

SW9~10: 1-2 short for CAN_0 function and connected to 2P terminal (CON11).

SW9~10: 2-3 short for CMOS sensor function and connected to CMOS sensor

connector (CON10).

Combination Connector

(CON8)

CMOS Sensor Connector

(CON10, SW9~10)

RS-485 Transceiver

(U11)

CAN Transceiver

(U13)

RS-232 Transceiver

(U6, U12)

NAND Flash

(U9)

Audio CODEC IC

(U10, SW6~8)

Microphone

(M1)

Power Supply Switch

(SW_POWER1)

3set Indication LEDs

(LED1~3)

6set User SWs

(K1~6)

Figure 2-1 NuMaker-emWin-N9H30 Board (Front View)

Table des matières

Autres manuels Nuvoton Matériel informatique

Nuvoton

Nuvoton NuMicro NuMaker-IoT-M487 Guide de démarrage rapide

Nuvoton

Nuvoton NuSpeech Series Manuel du produit

Nuvoton

Nuvoton NuMicro MA35D1 BSP Manuel utilisateur

Nuvoton

Nuvoton NuMicro M032 Series Manuel utilisateur

Nuvoton

Nuvoton NAU88L24 Manuel utilisateur

Nuvoton

Nuvoton NUC502ADN Manuel utilisateur

Nuvoton

Nuvoton N9H30 Series Manuel utilisateur

Nuvoton

Nuvoton NuMicro NUC980 Series Mode d’emploi

Nuvoton

Nuvoton N9H30F61IEC Manuel utilisateur

Nuvoton

Nuvoton NuMicro Nu-LB-Nano130 Manuel utilisateur

Nuvoton

Nuvoton NuMicro MA35D1 RTP Manuel utilisateur

Nuvoton

Nuvoton MPU Gang Writer G1 Manuel utilisateur

Nuvoton

Nuvoton NK-NUC980 Manuel utilisateur

Nuvoton

Nuvoton NuMaker-IIoT-NUC980 Manuel utilisateur

Nuvoton

Nuvoton NK-NUC98R Manuel utilisateur

Nuvoton

Nuvoton NK-NUC980 Manuel utilisateur

Nuvoton

Nuvoton NSP2340A1EP1 Manuel utilisateur

Nuvoton

Nuvoton ISD91300 Series Manuel du produit

Nuvoton

Nuvoton NAU88C22 Manuel utilisateur

Nuvoton

Nuvoton ISD91500 Manuel du produit

Nuvoton

Nuvoton NuEclipse Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
