NVIP-2ATM-6501/F

Quick start guide

NVIP-2ATM-6501/F Quick start guide version 1.0

IMPORTANT SAFEGUARDS AND WARNINGS

THE PRODUCT MEETS THE REQUIREMENTS CONTAINED IN THE FOLLOWING DIRECTIVES:

Information

The device, as a part of professional CCTV system used for surveillance and control, is not designed

for self installation in households by individuals without technical knowledge.

Excluding of responsibility in case of damaging data on a disk or other devices:

The manufacturer does not bear any responsibility in case of damaging or losing data on a disk or other

devices during device operation.

WARNING!

PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN

PRODUCT IN USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE

PRODUCT, OR IF IT DOES NOT ARISE FROM THE USUAL APPLICATION OF THE

PRODUCT, MANUFACTURER MUST BE CONTACTED UNDER THE RIGOR OF EXCLUDING

THE MANUFACTURER’S RESPONSIBILITY FOR THE RESULTS OF SUCH AN ACTION.

DIRECTIVE 2014/30/EU OF THE EUROPEAN PARLIMENT AND OF THE

COUNCIL of 26 February 2014 on the harmonisation of the laws of the Member States

relating to electromagnetic compatibility (OJ L 96, 29.3.2014, p. 79–106, with changes).

DIRECTIVE 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE

COUNCIL of 4 July 2012 on waste electrical and electronic equipment WEEE)

(OJ L 197, 24.7.2012, p. 38–71,with changes).

DIRECTIVE 2011/65/EU OF THE EUROPEAN PARLIAMENT AND OF THE

COUNCIL of 8 June 2011 on the restriction of the use of certain hazardous substances in

electrical and electronic equipment (OJ L 174, 1.7.2011, p. 88–110, with changes).

COMMISION DELEGATED DIRECTIVE (EU) 2015/863 of 31 March 2015 amending

Annex II to Directive 2011/65/EU of the European Parliament and of the Council as regards

the list of restricted substances.

DIRECTIVE (EU) 2017/2102 OF THE EUROPEAN PARLIAMENT AND OF THE

COUNCIL of 15 November 2017 amending Directive 2011/65/EU on the restriction of the

use of certain hazardous substances in electrical and electronic equipment.

NVIP-2ATM-6501/F Quick start guide version 1.0

IMPORTANT SAFEGUARDS AND WARNINGS

WARNING!

THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER

DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH

THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.

WARNING!

USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO USER

-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE PERSONNEL

MAY OPEN THE UNIT

INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE

PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS

1. Prior to undertaking any action please consult the following manual and read all the safety and

operating instructions before starting the device.

2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual

is necessary;

3. All the safety precautions referred to in this manual should be strictly followed, as they have a direct

influence on user’s safety and durability and reliability of the device;

4. All actions conducted by the servicemen and users must be accomplished in accordance with the

user’s manual;

5. The device should be disconnected from power sources during maintenance procedures;

6. Usage of additional devices and components neither provided nor recommended by the producer is

forbidden;

7. You are not allowed to use the camera in high humidity environment (i.e. close to swimming pools,

bath tubs, damp basements);

8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.)

is not recommended since it may lead to heat build-up and damaging the device itself as a

consequence;

9. Mounting the camera on unstable surface or using not recommended mounts is forbidden.

Improperly mounted camera may cause a fatal accident or may be seriously damaged itself. The

camera must be mounted by qualified personnel with proper authorization, in accordance with this

user’s manual.

10. Device should be supplied only from a power sources whose parameters are in accordance with

those specified by the producer in the camera technical datasheet. Therefore, it is forbidden to

supply the camera from a power sources with unknown parameters, unstable or not meeting

producer’s requirements;

Due to the product being constantly enhanced and optimized, certain parameters and functions

described in the manual in question may change without further notice.

We strongly suggest visiting the www.novuscctv.com/en website in order to access the newest full

manual

NVIP-2ATM-6501/F Quick start guide version 1.0

TABLE OF CONTENTS .................................................................................................... 4

1. FOREWORD INFORMATION................................................................................... ..5

1.1. General characteristics......................................................................................... 5

1.2. Technical specification .................................................................................... ...6

1.3. Camera dimensions .......................................................................................... ...7

1.4. Package contents .............................................................................................. ...7

2. START-UP AND INITIAL IP CAMERA CONFIGURATION ................................. 8

2.1. Description of connectors and camera equipment............................................... 8

2.2. Power supply connection .................................................................................... 8

2.3. Ethernet cable connection .................................................................................. 9

2.4. Camera mounting ................................................................................................ 9

2.5. Starting the IP camera ....................................................................................... 10

2.6. Initial configuration via the web browser.......................................................... 11

2.7. Security recommendations for network architecture and configuration ......... 12

3. NETWORK CONNECTION USING WEB BROSWER ......................................... 13

3.1. Recommended PC specification for web browser ............................................. 13

3.2. Connection with IP camera via web browser..................................................... 13

4. WWW INTERFACE - WORKING WITH IP CAMERA......................................... 17

4.1. Displaying live video. ........................................................................................ 17

5. MICRO SD CARD INSTALLATION ........................................................................ 18

6. FACTORY SETTINGS RESTORING ...................................................................... 18

6.1. Software factory settings restoring via NMS .................................................... 18

6.2. IPToolSoftware factory settings restoring via web browser…………………..19

6.3. Hardware factory settings restoring ...................... ………………..…………...19

TABLE OF CONTENTS

NVIP-2ATM-6501/F Quick start guide version 1.0

1. FOREWORD INFORMATION

1.1. General Characteristics

• Sensor resolution: 2 megapixels

• Illumination from 0.002lx

• Wide Dynamic Range (WDR) with double scan sensor

• Digital Noise Reduction (DNR)

• Defog function (F-DNR)

• Highlight Compensation (HLC)

• Back Light Compensation (BLC)

• Reduction of image flicker (Antiflicker)

• Lens type fixed focal pinhole, f = 2.8mm/F2.2

• Built-in webserver: camera configuration through the website

• Video compression: H.264, H.264+, H.264 Smart, H.265, H.265+, H.265 Smart MJPEG / G711

• Max. video resolution up to 1920 x 1080

• Multi streaming: compression, resolution, speed and quality defined individually for each video

stream

• ROI functions

• Motion detection

• Privacy Zones

• RTSP protocol support for video transmission

• Schedule

• Micro SD card up to 256GB

• Wide range of responses to alarm events: e-mail with attachment, saving file on FTP server,

saving file on microSD card

• Electronic Shutter from 1/3 s to 1/100 000 s.

• Supports up to 3 streams

• ONVIF Protocol Support

• Software: NMS (NOVUS MANAGEMENT SYSTEM) for video recording, live monitoring,

playback and remote IP devices administration

• Intelligent image analysis functions: abandoned object, object disappearance, line cross, face

detection, Scene Change, Video Blurred, Video Color Cast, intrusion detection

• Power supply: 12 VDC

FOREWORD INFORMATION

NVIP-2ATM-6501/F Quick start guide version 1.0

1.2. Technical specification

FOREWORD INFORMATION


Image Sensor 2 MPX CMOS sensor 1/2.8” SONY

Number of Eecve Pixels 1945 (H) x 1097 (V)

Min. Illuminaon 0.002 lx/F2.2 - color mode

Electronic Shuer auto/manual: 1/3 s ~ 1/100000 s

Wide Dynamic Range (WDR) yes (double scan sensor), 120dB

Digital Noise Reducon (DNR) 3D

Defog Funcon (F-DNR) yes

Highlight Compensaon (HLC) yes

Back Light Compensaon (BLC) yes

Reducon of image icker (Anicker) yes

LENS

Lens Type pinhole, f=2.8 mm/F2.2

DAY/NIGHT

Switching Mode manual, me

Switching Level Adjustment yes

Switching Delay 2 ~ 120 s

NETWORK

Stream Resoluon 1920 x 1080 (Full HD), 1280 x 720 (HD), 640 x 480 (VGA), 480 x 240,

320 x 240 (QVGA)

Frame Rate 30 fps for 1920 x 1080 (Full HD) and lower resoluons

Mulstreaming Mode 3 streams

Video/Audio Compression H.264, H.264+, H.264 Smart, H.265, H.265+, H.265 Smart, MJPEG/G.711

Number of Simultaneous Connecons max. 8

Bandwidth 24 Mb/s in total

Network Protocols Support HTTP, IPv4, IPv4/v6, UDP, HTTPS, FTP, DHCP, DDNS, NTP, RTSP, RTP, UPnP,

SNMP, QoS, IEEE 802.1X, PPPoE, SMTP, RTCP

ONVIF Protocol Support Prole S/G

Camera Conguraon from Internet Explorer browser

languages: Polish, English, and others

Compable Soware NMS, N Control 6000

Mobile applicaons SuperLive Plus (iPhone, Android)

OTHER FUNCTIONS

Privacy Zones 4 video mask type: single color or 4 video mask type: mosaic

Moon Detecon yes

Region of interest (ROI) 8

Video Content Analysis (VCA) abandoned object, object disappearance, line cross, face detecon,

Scene Change, Video Blurred, Video Color Cast, intrusion detecon

Image Processing sharpening, corridor mode, vercal ip, horizontal ip,

lens distoron correcon

System Reacon to Alarm Events e-mail with aachment, saving le on FTP server, saving le on SD card

Restoring default sengs via web browser, using reset buon, via NMS IPTool soware

NVIP-2ATM-6501/F Quick start guide version 1.0

FOREWORD INFORMATION

1.3. Camera dimensions (mm)

Camera NVIP-2ATM-6501/F

1.4. Package contents

After opening the package make sure that the following elements are inside:

• IP camera

• Short version of user’s manual

If any of this elements has been damaged during transport, pack all the elements back into the original

box and contact your supplier for further assistance.

The power supply is not included with the camera, so the user is obliged to provide it himself

A suitable power supply should meet the conditions described in section 2.2 Power supply

connection on the next page.

INTERFACES

Audio Input/Output built-in microphone

Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s

Memory Card Slot microSD - capacity up to 256GB

INSTALLATION PARAMETERS

Dimensions (mm) 30 (W) x 30 (H) x 30 (L) - sensor module

Weight 0.1 kg

Degree of Protecon IP 54 (details in the user’s manual)

Power Supply 12 VDC

Surge protecon TVS 3000 V

Power Consumpon 2 W

Operang Temperature -30°C ~ +60°C

Humidity max. 95%, relave (non-condensing)

NVIP-2ATM-6501/F Quick start guide version 1.0

START-UP AND INITIAL IP CAMERA CONFIGURATION

2. START-UP AND INITIAL IP CAMERA CONFIGURATION

CAUTION!

If the device was brought from a location with lower temperature, please wait until it reaches

the temperature of location it is currently in. Turning the device on immediately after bringing it

from a location with lower ambient temperature is forbidden, as the condensing water vapour

may cause short-circuits and damage the device as a result.

Before starting the device familiarize yourself with the description and the role of particular

inputs, outputs and adjusting elements that the device is equipped with.

2.1 Description of connectors and camera equipment

2.2 Power supply connection

The power adapter is not included with the camera, so the user is obliged to provide it himself.

The power supply should meet the following conditions:

• Direct current (DC) power supply with 12V output voltage

• Connector polarity according to the following diagram

CAUTION!

In order to provide protection against voltage surges/lightning strikes, usage of appropriate

surge protectors is advised. Any damages resulting from surges are not eligible for service re-

pairs.

12 VDC +

GND

1. 100 Mb/s Ethernet port

2. RS 485

3. Power supply 12VDC

4. Reset button

5. Microphone

NVIP-2ATM-6501/F Quick start guide version 1.0

START-UP AND INITIAL IP CAMERA CONFIGURATION

2.3. Ethernet cable connecting

To maintain tightness of ethernet cable connection, please follow instruction below:

1. Unscrew the nut (1) from the connector cover (2).

2. Route the network cable (without the RJ-45 plug) through the components (1) and (2), than crimp the

RJ-45 connector.

3. Plug the RJ-45 connector into the hermetic socket (3), screw the connector cover (2), and than the

nut (1).

NOTICE!

The camera housing is not hermetically sealed. Do not install the camera outdoors or in places

exposed to moisture.

2.4. Camera mounting

1. Remove the camera holder by unscrewing both fixing screws on the sides of the camera, indicated by

red arrows.

2. Mount the camera holder in the selected place with a suitable screw or bolt.

3. Place the camera between the fork of the holder and mount it with fixing screws, screwing them in so

that you can adjust it.

4. Adjust the camera position and tighten with the fixing screws

To set the preview from the camera, connect the power to the camera and then connect

with the camera using a PC.

NVIP-2ATM-6501/F Quick start guide version 1.0

2.5. Starting the IP camera

To run NOVUS IP camera you have to connect ethernet cable between camera and switch or computer.

You can power it from 12VDC power supply compatible with camera power supply specification.

The recommended way to start an IP camera and perform its configuration is a direct connection to the

network switch which is not connected to other devices. To obtain further information about network

configuration parameters (IP address, gateway, network mask, etc.) please contact your network

administrator.

• Connection using external power supply and network switch

• Connection using external power supply directly to the computer

START-UP AND INITIAL CAMERA CONFIGURATION

IP Camera

Network transmission

Network Switch Computer

Network transmission

IP Camera

Network transmission - cross over cable

Computer

Table des matières

Langues :

Autres manuels Novus Caméra de sécurité

Novus

Novus NVIP-8H-6202M Manuel utilisateur

Novus

Novus NVAHD-1DN3101H/IR-1 Manuel utilisateur

Novus

Novus NVIP-3SD-8200/30 Manuel utilisateur

Novus

Novus NVDN-801V-2 Manuel utilisateur

Novus

Novus NVH-SD40EH-C Manuel utilisateur

Novus

Novus NVIP-2VE-4201/PIR Manuel utilisateur

Novus

Novus NVAHD-2DN5103MV/IR-1 Manuel utilisateur

Novus

Novus NVIP-5DN3612H/IR-1P/F Manuel utilisateur

Novus

Novus NVIP-8VE-6202M-II Manuel utilisateur

Novus

Novus NVIP-5H-4231 Manuel utilisateur

Novus

Novus NVIP-1DN3000V/IR-1P-II Manuel utilisateur

Novus

Novus NVIP-5DN2004H/IR-1P-II Manuel utilisateur

Novus

Novus NVIP-5H-6412M/F Manuel utilisateur

Novus

Novus NVIP-5VE-4502M Manuel utilisateur

Novus

Novus NVIP-2DN2006H/IR-1P Manuel utilisateur

Novus

Novus NVIP-4H-4201 Manuel utilisateur

Novus

Novus NVIP-5DN3613V/IR-1P/F Manuel utilisateur

Novus

Novus NVIP-3DN7540H/IRH-2P Manuel utilisateur

Novus

Novus NVIP-12DN7021V/IR-1P Manuel utilisateur

Novus

Novus NVAHD-1DN5101H/IR-1 Manuel utilisateur

Novus

Novus NVIP-2D-6402 Manuel utilisateur

Novus

Novus NVIP-4DN2004H/IR-1P Manuel utilisateur

Novus

Novus NVDN 801V/IR Manuel utilisateur

Novus

Novus NVC-402H/IR Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
