NVIP-2D-6402
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
2
IMPORTANT SAFEGUARDS AND WARNINGS
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of the following directives and national
regulations implementing the directives:
• Electromagnetic compatibility EMC 2004/108/EC.
• Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well as
75VDC and 1500VDC.
WEEE Directive 2012/19/EU
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European 1000VAC Directive on Waste Electrical and
Electronic Equipment (2012/19/EU) and further amendments. By ensuring this product is disposed of
correctly, you will help to prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance may not be
treated as household waste. It shall be handed over to the applicable collection point for used up electrical and
electronic equipment for recycling purpose. For more information about recycling of this product, please contact
your local authorities, your household waste disposal service or the shop where you purchased the product.
RoHS Directive 2011/65/EU
Out of concern for human health protection and friendly environment, we assure that our products falling under
RoHS Directive regulations, regarding the restriction of the use of hazardous substances in electrical and
electronic equipment, have been designed and manufactured in compliance with the above mentioned
regulations. Simultaneously, we claim that our products have been tested and do not contain
hazardous substances whose exceeding limits could have negative impact on human health or natural
environment
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed for self
installation in households by individuals without technical knowledge.
Excluding of responsibility in case of damaging data on a disk or other devices:
The manufacturer does not bear any responsibility in case of damaging or losing data on a disk or other devices
during device operation.
WARNING!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN PRODUCT IN
USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR IF IT DOES
NOT ARISE FROM THE USUAL APPLICATION OF THE PRODUCT, MANUFACTURER MUST BE
CONTACTED UNDER THE RIGOR OF EXCLUDING THE MANUFACTURER’S RESPONSIBILITY FOR
THE RESULTS OF SUCH AN ACTION.
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
3
IMPORTANT SAFEGUARDS AND WARNINGS
WARNING!
THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER
DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH
THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.
WARNING!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO USER
-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE PERSONNEL
MAY OPEN THE UNIT
INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE
PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS
1. Prior to undertaking any action please consult the following manual and read all the safety and operating
instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual is
necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a direct
influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the user’s
manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer is
forbidden;
7. You are not allowed to use the camera in high humidity environment (i.e. close to swimming pools, bath tubs,
damp basements);
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.) is not
recommended since it may lead to heat build-up and damaging the device itself as a consequence;
9. Mounting the camera on unstable surface or using not recommended mounts is forbidden. Improperly
mounted camera may cause a fatal accident or may be seriously damaged itself. The camera must be mounted
by qualified personnel with proper authorization, in accordance with this user’s manual.
10. Device should be supplied only from a power sources whose parameters are in accordance with those
specified by the producer in the camera technical datasheet. Therefore, it is forbidden to supply the camera
from a power sources with unknown parameters, unstable or not meeting producer’s requirements;
Due to the product being constantly enhanced and optimized, certain parameters and functions
described in the manual in question may change without further notice.
We strongly suggest visiting the www.novuscctv.com website in order to access the newest full manual
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
4
TABLE OF CONTENTS.....................................................................................................4
1. FOREWORD INFORMATION .....................................................................................5
1.1. General characteristics.........................................................................................5
1.2. Technical specification .......................................................................................6
1.3. Camera dimension ..............................................................................................7
1.4. Package contents..................................................................................................7
2. START-UP AND INITIAL IP CAMERA CONFIGURATION .................................8
2.1. Description of connectors and control tools ........................................................8
2.2. Zoom and focus adjustment.................................................................................9
2.3. Connecting ethernet cable .................................................................................10
2.4. Cameras mounting.............................................................................................10
2.5. Starting the IP camera........................................................................................11
2.6. Initial configuration via the web browser..........................................................12
3. NETWORK CONNECTION UTILIZING WEB BROSWER ................................13
3.1. Recommended PC specification for web browser .............................................13
3.2. Connection with IP camera via web browser.....................................................13
4. USING AND CONFIGURING .....................................................................................15
4.1. Displaying live pictures......................................................................................15
5. ELECTRIC CONNECTORS AND ACCESORIES .................................................16
5.1. Connecting power supply to the camera. ..........................................................16
5.2. Connecting alarm input and output ....................................................................16
5.3. SD card installation ...........................................................................................17
6. RESTORING FACTORY DEFAULTS .....................................................................18
6.1. Restoring software factory defaults via web browser ........................................18
6.2. Restoring software factory defaults via NMSiptool...........................................18
6.3. Restoring hardware factory defaults in IP cameras...........................................19
TABLE OF CONTENTS
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
5
1. FOREWORD INFORMATION
1.1. General Characteristics
• Imager resolution: 2 megapixels
• Mechanical IR cut filter, IR operation capability
• Min. Illumination from 0 lx with IR LED on
• Wide Dynamic Range (WDR) for enhanced image quality in diverse light conditions
• Digital Noise Reduction (DNR)
Lens type: varifocal, f=2.8-12 mm/F=1.4
• Built-in LED illuminator: 30 pcs LED
• Built-in webserver: camera configuration through the website
• Compression: H.264, H.265/ MJPEG
• Max video processing resolution: 1920 x1080
• Multi streaming: compression, resolution, speed and quality defined individually for each video
stream
• ROI functions
• Motion detection
• Private Zones
• RTSP protocol support for video transmission
• Schedule
• Micro SD card up to 128 GB
• Audio input
• Audio output
• Bulid-in microphone
• BNC output
• Alarm input (NO/NC)
• Alarm Output
• Wide range of responses to alarm events: e-mail with attachment, saving file on FTP server, save
file on SD card.
• Software: NMS (NOVUS MANAGEMENT SYSTEM) for video recording, live monitoring,
playback and remote IP devices administration
• Video Content Analysis (VCA):
Exception
Line Crossing
Intrusion
• Power supply: 12VDC, PoE (Power over Ethernet)
FOREWORD INFORMATION
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
6
1.2. Technical specification
FOREWORD INFORMATION
Image Sensor 2 MPX CMOS sensor 1/2.7” APTINA
Number of Effective Pixels 1920 (H) x 1080 (V)
Min. Illumination 0.07 lx/F1.4 - color mode,
0 lx (IR on) - B/W mode
Electronic Shutter auto: 1/25 s ~ 1/100000 s
Wide Dynamic Range (WDR) yes (double scan sensor), 120dB
Digital Noise Reduction (DNR) 3D
Defog Function (F-DNR) yes
LENS
Lens Type varifocal, f=2.8 ~ 12 mm/F1.4
DAY/NIGHT
Switching Type mechanical IR cut filter
Switching Mode auto, manual, time
Switching Level Adjustment yes
Switching Schedule yes
Visible Light Sensor yes
NETWORK
Stream Resolution 1920 x 1080 (Full HD), 1280 x 720 (HD), 640 x 480 (VGA), 320 x 240 (QVGA)
Frame Rate 30 fps for 1920 x 1080 (Full HD) and lower resolutions
Multistreaming Mode 3 streams
Video/Audio Compression H.264, H.265, MJPEG/G.711
Number of Simultaneous Connections max. 4
Bandwidth 9 Mb/s in total
Network Protocols Support TCP/IP, UDP, FTP, DHCP, DDNS, NTP, RTSP, UPnP, PPPoE, SMTP
ONVIF Protocol Support Profile S (ONVIF 2.3)
Camera Configuration from Internet Explorer browser
languages: Polish, English, Russian, and others
Compatible Software NMS
OTHER FUNCTIONS
Privacy Zones 4
Motion Detection yes
Region of interest (ROI) 3
Video Content Analysis (VCA) tamper, line cross, zone entrance
Image Processing 180˚ image rotation, sharpening, mirror effect, corridor mode
Prealarm/Postalarm -/up to 120 s
System Reaction to Alarm Events e-mail with attachment, saving file on FTP server, saving file on SD card, alarm output activa-
tion
IR LED
LED Number 30
Range 30 m
Angle 90°
INTERFACES
Video Output BNC, 1.0 Vp-p, 75 Ohm
Audio Input/Output 1 x Jack (3.5 mm)/1 x Jack (3.5 mm) additionally built-in: microphone
Alarm Input/Output 1 (NO/NC)/1 relay type
Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s
Memory Card Slot microSD - capacity up to 128GB
INSTALLATION PARAMETERS
Dimensions (mm) 122 (Ф) x 96 (H)
Weight 0.45 kg
Enclosure plastic, white
Power Supply PoE, 12 VDC
Power Consumption 2.5 W,6 W (IR on)
Operating Temperature -20°C ~ 50°C
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
7
FOREWORD INFORMATION
1.3. Camera dimensions
1.4. Package contents
After you open the package make sure that the following elements are inside:
• IP camera
• Accessories bag
• Short version of user’s manual
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches
the temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
8
START-UP AND INITIAL IP CAMERA CONFIGURATION
2.FOREWORD INFORMATION
2.1 Description of connectors and control tools
1. BNC video output
2. Audio output
3. Audio input
4. Power supply 12VDC
5. 100 Mb/s Ethernet port (RJ-45 connector)
6. Alarm Connectors
1. Alarm COM
2. Alarm OPEN
3. Alarm INA
4. Alarm GND
7. RS-485 conectors
WARNING! To get access to above ports it is required to remove camera dome cover.
1. Light sensor
2. Reset button
3. microSD card slot
4. Buldi in microphone
5. IR LED
1
2
3
4
5
5
1
2
4
3
6
7
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
9
2.2 Zoom and focus adjustment
1. Remove dome cover by turning it
counterclockwise
2. Adjust zoom and focus.
3. Close camera by turning dome clockwise
2.3. Connecting ethernet cable
To maintain tightness of ethernet cable connection, please follow instruction below:
1. Loosen the nut (a) from the main element (b).
2. Run power cable (without RJ-45 connector) though both elements. Then crimp the cable with RJ-45
connector.
3. Connect the cable to the hermetic connector (c), screw main cover (b), then screw the nut (a).
START-UP AND INITIAL IP CAMERA CONFIGURATION
Zoom
Focus
ab
a
b
c
NVIP-2D-6402 - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
10
2.4. Connecting power supply to the camera.
Camera can be supplied using external power supply unit corresponding with the camera parameters or
by using RJ45 network socket and PoE (802.3at Type 1 ) power supply unit.
Information:
Power supply adapter is not included. Please use power adapter with parameters specified in user’s
manual.
CAUTION:
Do not use power supplies and POE adapters not compatible with IEEE 802.3af standard!
Damage resulting from the use of improper power supply is not covered under warranty!
In order to provide protection against voltage surges/lightning strikes, usage of appropriate surge
protectors is advised. Any damages resulting from surges are not eligible for service repairs.
2.4. Camera mounting
1. Remove dome cover by turning it counterclockwise
2. Put assembly template of the camera to the desired
mounting surface, and mark drilling holes.
3. Drill mounting, cable and heat removal holes (1) in
previously selected points.
4. Mount the camera base using included screws on smooth
surface
5. Adjust the position of the camera module.
6. Adjust focal length and focus using proper levers.
7. Put on the camera cover again, by turning it clockwise.
START-UP AND INITIAL IP CAMERA CONFIGURATION
12 VDC +
12 VDC -
Camera 12 VDC power supply
1
Table des matières
Langues :
Autres manuels Novus Caméra de sécurité
Novus
Novus NVDN-861H/IRH-2 Manuel utilisateur
Novus
Novus NVIP-4V-6511/F-II Manuel utilisateur
Novus
Novus NVAHD-2DN3201MH/IR-1-II Manuel utilisateur
Novus
Novus NVIP-2DN2006V/IR-1P Manuel utilisateur
Novus
Novus NVIP-2DN3038D/IR-1P Manuel utilisateur
Novus
Novus NVIP-2VE-4231 Manuel utilisateur
Novus
Novus NVIP-4DN3517V/IR-1P Manuel utilisateur
Novus
Novus NVIP-4C-6500/F Manuel utilisateur
Novus
Novus NVIP-5DN3612H/IR-1P/F Manuel utilisateur
Novus
Novus NVIP-2VE-6501/F-II Manuel utilisateur
Novus
Novus NVIP-2DN3034V/IR-1P Manuel utilisateur
Novus
Novus NVIP-2H-6511/F-II Manuel utilisateur
Novus
Novus NVIP-3DN7000V/IRH-2P Manuel utilisateur
Novus
Novus NVIP-8VE-6502M/F Manuel utilisateur
Novus
Novus NVIP-4VE-4231 Manuel utilisateur
Novus
Novus NVIP-5H-6201 Manuel utilisateur
Novus
Novus NVIP-6F-6301-II Manuel utilisateur
Novus
Novus NVIP-2V-6501/F Manuel utilisateur
Novus
Novus NVH-200H/230 Manuel utilisateur
Novus
Novus NVIP-8V-6402M/F Manuel utilisateur
