NovaStar LVP6082 Manuel utilisateur
User's Manual
Video Controller NovaPro HD
Rev1.4.4
XI'AN NOVASTAR TECH CO., LTD.
www.novastar.tech i
Statement
Welcome to use the product from Xi’an NovaStar Tech Co., Ltd. (hereinafter referred to as
“NovaStar”). It is our great pleasure to offer this manual to help you understand and use the
product. We strive for precision and reliability during the compilation of this manual, and the
content of this manual are subject to change without notice. If you have any problem in use
or you have any suggestion, please feel free to contact us according to the contact
information provided in this manual. We will do our utmost to satisfy your needs. We would
like to express our sincere thanks to your suggestions and make assessment for adoption as
soon as possible.
Copyright
All the intellectual property rights involved in this document are reserved to NovaStar.
Unauthorized duplication is a violation of applicable laws.
Trademark
is the trademark of NovaStar.
XI'AN NOVASTAR TECH CO., LTD.
www.novastar.tech ii
Contents
1Safety Statement...............................................................................................................................1
2Overview.............................................................................................................................................1
3Appearance........................................................................................................................................2
3.1 Front Panel..............................................................................................................................2
3.2 Rear Panel...............................................................................................................................3
4Signal Connection.............................................................................................................................5
5Description of Operation Modes....................................................................................................6
6Machine Operation...........................................................................................................................7
6.1 Description of operation action...........................................................................................7
6.2 Main Interface.........................................................................................................................7
6.3 Step 1: Input Settings............................................................................................................9
6.4 Step 2: Screen Settings..................................................................................................... 10
6.5 Step 3: Brightness Control................................................................................................ 12
6.6 Step 4: Output Settings ..................................................................................................... 12
6.7 Display Control.................................................................................................................... 15
6.8 Advanced Settings.............................................................................................................. 16
6.8.1 Picture in Picture (PIP) ........................................................................................... 17
6.8.2 Advanced Configuration......................................................................................... 18
6.8.3 Montage..................................................................................................................... 20
XI'AN NOVASTAR TECH CO., LTD.
NovaPro HD User's Manual
www.novastar.tech -iii-
6.8.4 Load Cabinet File..................................................................................................... 21
6.8.5 Alarm Threshold Settings....................................................................................... 24
6.8.6 Advanced Property.................................................................................................. 24
6.8.7 Save parameters to hardware............................................................................... 25
6.8.8 Redundancy.............................................................................................................. 25
6.8.9 DMX512 Channel Settings .................................................................................... 26
6.8.10 Factory Reset........................................................................................................... 27
6.8.11 Hardware version..................................................................................................... 27
6.9 Communication Settings................................................................................................... 27
6.10 Language Settings.......................................................................................................... 28
7Web Interface Operation.............................................................................................................. 28
7.1 Network Establishment...................................................................................................... 28
7.2 Operating Motion Description........................................................................................... 29
7.3 My Device............................................................................................................................. 30
8LCT Client Operation .................................................................................................................... 31
9Firmware Upgrade......................................................................................................................... 32
10 Troubleshooting and Precautions....................................................................................... 35
11 Technical Specifications........................................................................................................ 37
12 Installation Dimensions......................................................................................................... 39
XI'AN NOVASTAR TECH CO., LTD.
NovaPro HD User's Manual
www.novastar.tech -1-
1 Safety Statement
To avoid potential hazards, please use this equipment according to the regulations. In case
of damages, non-professionals are not allowed to disassemble it for maintenance without
permission. Please contact the after-sales department of the company.
High voltage danger: The operating voltage of this product is 100-250V AC.
Grounding: This product is grounded through grounding cord of power supply.
Please keep the grounding conductor is well grounded.
Electromagnetic interference: Keep this product far away from magnets,
motors and transformers.
Moisture proof: Keep the equipment in a dry and clean environment. In case of
liquid immersion, please pull the power plug immediately.
Keep away from flammable and explosive hazardous substance.
Prevent liquids or metal fragments from being immersed into the product in
order to avoid safety accidents.
XI'AN NOVASTAR TECH CO., LTD.
NovaPro HD User's Manual
www.novastar.tech -1-
2 Overview
NovaPro HD is a professional LED display controller. Besides the function of display control,
it also features in powerful front-end processing. It has integrated various professional
interfaces. With excellent image quality and free image control, NovaPro HD has greatly
satisfied the requirements of display industry.
Product features:
1) NovaPro HD has complete input interfaces including CVBS, VGA, SDI, DVI, HDMI and
DP. These interfaces support input resolution up to 1080p@60Hz, highest pixel clock up
to 165 MHz and output bandwidth up to 4 Gbit.
2) NovaPro HD has adopted 12 Bit digital processing internally. With advanced de-
interlacing motion self-adaptive processing technology adopted, images are clear and
fine. Each input can be fully configured with contrast, saturation, hue, color temperature.
It allows for switching between point-to-point display and point-by-point scaling of input
image according to display resolution.
3) NovaPro HD doesn’t need computer software for system configuration. System
configuration can be completed only through one knob and one button. All operations
can be done only by several steps. That's what we called “Touch Track”.
4) NovaPro HD supports multiple units splicing.
5) NovaPro HD has integrated DMX512 and Genlock input and loop interfaces. Professional
control and synchronization have been provided. With the design of dual power
redundancy backup, the system is stable andreliable. Optical fiber output has guaranteed
the stability of long-distance data transmission.
6) In addition to the operations of the controller and LCT client, you can also configure the
system with browsers on your PC or PAD, namely, Web interface operation which is
able to preview and assist with system settings in real time and confirm current working
status of the system.
7) NovaPro HD is the flagship product of NovaStar new generation controllers. Being
XI'AN NOVASTAR TECH CO., LTD.
NovaPro HD User's Manual
www.novastar.tech -2-
powerful in image processing, professional in image control and friendly in user-interface,
NovaPro HD has brought unprecedented ease and pleasure in LED display control.
3 Appearance
3.1 Front Panel
①: Power switch
Power switch indicators
Green indicator: Indicates device working status.
- Flashing normally: The device works normally.
- Flashing slowly: There is no video signal.
- Breathing: One or more Ethernet ports are in hot backup mode.
Red indicator: Indicates device power status.
②: Input source buttons and indicators.
Press the input source button to set the input source for main picture. Hold down the
button to set the input source for PIP. You can view the operation result on the
operation screen during setting.
The indictor is blue by default. It turns to green when the current input source is
selected.
③：Operation screen (Please see details in the subsequent Chapter: Main Interface).
XI'AN NOVASTAR TECH CO., LTD.
NovaPro HD User's Manual
www.novastar.tech -3-
④：Knob: Enter by pressing the knob and select or adjust by turning the knob.
⑤：ESC: Exit current operation or option.
⑥：BLK: LED Display is blank screen. Indicator light is blue by default after power on
and it turns green when BLK is enabled;
FRZ: Images on LED Display are frozen. Indicator light is blue by default after power on
and it turns green when enabled;
PIP: Display PIP. Indicator light is blue by default after power on and it turns green when
enabled;
⑦: Type A female interface is a reserved interface.
⑧: Type B female interface is USB control interface to connect PC for communication.
3.2 Rear Panel
Note: In order to improve user’s experience, layout of the interfaces may be adjusted a little.
The picture is only for reference.
Inputs
Audio
Audio Input
DP
DP Input
HDMI
HDMI Input
XI'AN NOVASTAR TECH CO., LTD.
NovaPro HD User's Manual
www.novastar.tech -4-
DVI
DVI Input
VGA
VGA Input
CVBS
PAL/NTSC TV Composite Video Inputs
3G-SDI IN
3G-SDI Input
Genlock IN
Synchronizing signal to guarantee the images on display is
synchronous with external Genlock source.
Outputs
3G-SDI LOOP
3G-SDI loop output
GenLock LOOP
Genlock loop output
DVI LOOP
DVI loop output
Monitor -DVI
Monitoring connector
Monitor -HDMI
LED Out 1, 2, 3, 4
4 Ethernet port outputs
Only Ethernet port 1 supports audio output. When the
multifunction card is connected for audio decoding, the
multifunction card must be connected to the Ethernet port 1.
OPT Output 1, 2, 3, 4
4 optical fiber outputs
Control Interface
ETHERNET
Ethernet Control (connecting PC for communication or
accessing Network)
USB Control
IN: connecting PC for communication or cascade input;
connecting USB OUT of last NovaPro HD
OUT: cascade output, Cascading USB IN of next NovaPro
XI'AN NOVASTAR TECH CO., LTD.
NovaPro HD User's Manual
www.novastar.tech -5-
HD
DMX Control
IN: connecting all consoles that support DMX512 interface
protocol.
LOOP: DMX512 signal Loop output
4 Signal Connection
Signal Connection
Connect the required hardware devices referring to the interface descriptions in previous
chapters.
Note: Please turn OFF POWER before signal connection.
Fig. 4-1 Signal Connection
