NovaStar TU15 Manuel utilisateur
TU20 Pro & TU15 Pro
LED Playback Control Processors
User Manual
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
i
Change History
Document Version
Release Date
Description
V1.0.0
2023-04-04
First release
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
ii
Contents
Change History ................................................................................................................................................................. i
1 Introduction .................................................................................................................................................................... 1
2 Getting Started...............................................................................................................................................................2
3 Usage of the Remote .....................................................................................................................................................7
Buttons on the Remote............................................................................................................................................7
Bluetooth Pairing Method......................................................................................................................................... 7
4 Screen Mirroring............................................................................................................................................................. 8
Wireless Mirroring....................................................................................................................................................8
4.1.1 Mirroring from Mobile Phone..........................................................................................................................8
4.1.2 Mirroring from PC...........................................................................................................................................9
4.1.3 Mirroring via Dongle....................................................................................................................................... 10
4.1.4 Secondary Mirroring.......................................................................................................................................10
4.1.5 Wireless Notes...............................................................................................................................................11
4.1.6 Wireless Speech............................................................................................................................................12
Wired Mirroring........................................................................................................................................................ 14
4.2.1 Connect Signal Source .................................................................................................................................. 14
4.2.2 Switch Signal Source..................................................................................................................................... 14
5 Display Effect Adjustment...............................................................................................................................................15
6 Program Playback Control ............................................................................................................................................. 17
Create a Program ....................................................................................................................................................17
Play Programs.........................................................................................................................................................18
Manage Drafts .........................................................................................................................................................18
Manage Media Library.............................................................................................................................................19
7 Settings Management ....................................................................................................................................................20
File Management..................................................................................................................................................... 20
Network Settings...................................................................................................................................................... 21
7.2.1 Wired Network................................................................................................................................................21
7.2.2 Wireless Network...........................................................................................................................................21
7.2.3 Hotspot...........................................................................................................................................................22
7.2.4 Bluetooth........................................................................................................................................................ 22
Display Effect Adjustment ........................................................................................................................................23
Sound Settings ........................................................................................................................................................ 23
General Settings......................................................................................................................................................24
7.5.1 App Management...........................................................................................................................................24
7.5.2 Date and Time................................................................................................................................................24
7.5.3 Language and Keyboard................................................................................................................................ 25
7.5.4 Home Application...........................................................................................................................................25
7.5.5 Wallpaper....................................................................................................................................................... 26
7.5.6 Image Quality Enhancement..........................................................................................................................27
7.5.7 Screensaver................................................................................................................................................... 27
7.5.8 Assistive Touch...............................................................................................................................................28
7.5.9 Power-On Delay.............................................................................................................................................28
7.5.10 Dehumidification...........................................................................................................................................29
System Settings.......................................................................................................................................................29
7.6.1 Play Program After Boot................................................................................................................................. 29
7.6.2 Factory Reset.................................................................................................................................................30
7.6.3 System Upgrade ............................................................................................................................................30
7.6.4 About..............................................................................................................................................................31
7.6.5 User Guide..................................................................................................................................................... 32
7.6.6 Device Self-Test.............................................................................................................................................32
8 Troubleshooting..............................................................................................................................................................33
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
iii
Mirroring Failed After Dongle Inserted to PC ...........................................................................................................33
Dongle Activation Failed or Activation Code Required.............................................................................................33
Wireless Mirroring Getting Stuck and Having High Latency.....................................................................................34
Short Infrared Control Distance and Slow Response of the Remote .......................................................................34
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
www.novastar.tech
1
1 Introduction
This document introduces the operating method of the TU20 Pro and TU15 Pro to help users get started with
the LED playback control processors quickly.
The TU20 Pro and TU15 Pro are playback control processors specially designed by Xi’an NovaStar Tech Co.,
Ltd. (hereinafter referred to as NovaStar) for indoor LED screens. They integrate the Android system and
sending card functions into one unit, and allow third-party apps to run on them, featuring powerful interaction
and playback control capabilities.
The TU20 Pro and TU15 Pro support wireless screen mirroring from Windows, macOS, iOS and Android
terminals at up to 60 fps with a system latency of less than or equal to 80 ms at 8 meters. For different
application scenarios, they provide 4 modes to let the document presentation, video playback and remote
meetings have the optimal display effect.
In addition, the TU20 Pro and TU15 Pro support control by the VNNOX and VNNOX Care apps.
Through VNNOX app, program editing, program publishing and screen control can be easily performed.
For related operations, please refer to the ViPlex Handy Media Player Control App User Manual.
Through VNNOX Care app, screen configuration, screen topology and automatic screen configuration
backup can be quickly completed. For related operations, please refer to the help center of VNNOX Care.
TU20 Pro and TU15 Pro share the same operations. The screenshots provided in this document take the
TU20 Pro as examples.
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
www.novastar.tech
2
2 Getting Started
Do the following steps to quickly get started with the LED playback control processors.
Step 1: Set Up the Hardware
Step 1 Open the package.
Step 2 Prepare the accessories, such as Ethernet cable, remote, and mirroring dongle.
Step 3 Build the hardware environment according to the following diagram. You can also connect common
peripherals as needed, such as mouse, keyboard, sound system, camera and infrared touch frame.
Figure 2-1 Hardware architecture
Step 4 Connect the Ethernet cables from the LED screen to the Ethernet output ports of TU20 Pro/TU15 Pro in
the order shown below.
Figure 2-2 Rear panel –TU20 Pro (6 Ethernet ports) / TU15 Pro (4 Ethernet ports)
Step 5 Connect the power cable to power on the device.
Step 2: Install Related Apps
Search for VNNOX and VNNOX Care in the app store, download and install them.
Through VNNOX app, program editing, program publishing and screen control can be easily performed.
Through VNNOX Care, screen configuration, screen layout and automatic screen configuration backup
can be quickly completed.
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
www.novastar.tech
3
Step 3 Configure the LED Screen
Step 1 Open VNNOX Care app.
Step 2 Click Screen configuration, follow the instructions to download the receiving card configuration file, and
light up the screen.
Step 3 Click Screen Connection and follow the instructions to complete screen topology.
The above is the overall operation process. For detailed steps, see the app user manual.
Step 4 Initialize the System
For the first-time use of the LED playback control processor, do the following steps to complete the
initialization settings.
Step 1 Set the system language. You can choose Chinese or English.
Figure 2-3 Choosing a language
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
www.novastar.tech
4
Step 2 (Optional) Pair the system with the remote for Bluetooth connection. To do this, hold down the menu and
Home buttons on the remote simultaneously until the Connecting to the remote window appears at the
bottom of the screen.
Figure 2-4 Pairing withthe remote
Step 3 (Optional) Select the Wi-Fi network you want to connect the system to and enter the password.
Figure 2-5 Connecting to a Wi-Fi network
Step 4 (Optional) Customize the device name. A custom name is convenient for you to use other devices to
search for.
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
www.novastar.tech
5
Figure 2-6 Customizing device name
Step 5 (Optional) Pair the system with the mirroring dongle by inserting the dongle into the USB port of the LED
screen. The dongle will be paired automatically with the system.
Figure 2-7 Pairing with the dongle
Step 6 The initialization settings are done. You can see the Beginner’s Guide or start using the LED playback
control processor directly.
TU20 Pro & TU15 Pro LED Playback Control Processors
User Manual
www.novastar.tech
6
Figure 2-8 Home screen
