DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

NT0X10AA PCP, SCAN, MISCELLANEOUS 02 CCCCCCCCCCC

NT2T00AA PCP, LINE, SINGLE PARTY C CCCCCCCCCCC

NT2T00AA

402.52 NOTE: VINTAGES F,G,H,J ARE NOT COMPATIBLE.

NT2T00AA

402.53 NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AA

403.1X NOTE: VINTAGES F,G,H,J ARE NOT COMPATIBLE.

NT2T00AA

403.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AA

404.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AA

405.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AA

406.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AB PCP, LINE, SINGLE PARTY A CCCCCCCCCCC

NT2T00AB

402.52 NOTE: VINTAGES A,B,C,G ARE NOT COMPATIBLE.

NT2T00AB

402.53 NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AB

403.1X NOTE: VINTAGES A,B,C,G ARE NOT COMPATIBLE.

NT2T00AB

403.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AB

404.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AB

405.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AB

406.XX NOTE: ALL VINTAGES COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AC PCP, LINE, SINGLE PARTY C CCCCCCCCCCC

NT2T00AC

402.52 NOTE: VINTAGES C THROUGH J ARE NOT COMPATIBLE.

NT2T00AC

402.53 NOTE: VINTAGES C THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AC

403.1X NOTE: VINTAGES C THROUGH J ARE NOT COMPATIBLE.

NT2T00AC

403.XX NOTE: VINTAGES C THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AC

404.XX NOTE: VINTAGES C THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AC

405.XX NOTE: VINTAGES C THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AC

406.XX NOTE: VINTAGES C THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AD PCP, LINE, SINGLE PARTY A CCCCCCCCCCC

NT2T00AD

402.52 NOTE: VINTAGES A THROUGH G ARE NOT COMPATIBLE.

NT2T00AD

402.53 NOTE: VINTAGES A THROUGH G COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AD

403.1X NOTE: VINTAGES A THROUGH G ARE NOT COMPATIBLE.

NT2T00AD

403.XX NOTE: VINTAGES A THROUGH G COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AD

404.XX NOTE: VINTAGES A THROUGH G COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AD

405.XX NOTE: VINTAGES A THROUGH G COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00AD

406.XX NOTE: VINTAGES A THROUGH G COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00BB PCP, LINE, SINGLE PARTY A CCCCCCCCCCC

NT2T00BB

402.52 NOTE: VINTAGES A AND B ARE NOT COMPATIBLE.

NT2T00BB

402.53 NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00BB

403.1X NOTE: VINTAGES A AND B ARE NOT COMPATIBLE.

NT2T00BB

403.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00BB

404.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00BB

405.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 1

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT2T00BB

406.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T00BC PCP, LINE, SINGLE PARTY A CCCCCCCCCCC

NT2T01AA PCP, LINE, 2-PARTY ECCCCCCCCCCC

NT2T01AB PCP, LINE, 2-PARTY A CCCCCCCCCCC

NT2T01BA PCP, LINE, 2-PARTY A CCCCCCCCCCC

NT2T01BB PCP, LINE, 2-PARTY A CCCCCCCCCCC

NT2T02BA PCP, LINE, 4-PARTY, ANI BCCCCCCCCCCC

NT2T03AA PCP, LINE, MISC. FUNCTION GCCCCCCCCCCC

NT2T03AB PCP, LINE, MISC. FUNCTION A CCCCCCCCCCC

NT2T03BB PCP, LINE, MISC. FUNCTION A CCCCCCCCCCC

NT2T03CA PCP, LINE, MISC. FUNCTION BCCCCCCCCCCC

NT2T04AA PCP, LINE, COIN, PREPAY JCCCCCCCCCCC

NT2T04BA PCP, LINE, COIN, PREPAY A CCCCCCCCCCC

NT2T05AA PCP, LINE, 8-PARTY HCCCCCCCCCCC

NT2T05AA

402.52 NOTE: VINTAGE H WITH GREEN DOT IS NOT COMPATIBLE.

NT2T05AA

402.53 NOTE: VINTAGE H WITH GREEN DOT COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AA

403.1X NOTE: VINTAGE H WITH GREEN DOT IS NOT COMPATIBLE.

NT2T05AA

403.XX NOTE: VINTAGE H WITH GREEN DOT COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AA

404.XX NOTE: VINTAGE H WITH GREEN DOT COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AA

405.XX NOTE: VINTAGE H WITH GREEN DOT COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AA

406.XX NOTE: VINTAGE H WITH GREEN DOT COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AB PCP, LINE, 8-PARTY A CCCCCCCCCCC

NT2T05AB

402.52 NOTE: VINTAGE A AND B ARE NOT COMPATIBLE.

NT2T05AB

402.53 NOTE: VINTAGE A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AB

403.1X NOTE: VINTAGE A AND B ARE NOT COMPATIBLE.

NT2T05AB

403.XX NOTE: VINTAGE A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AB

404.XX NOTE: VINTAGE A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AB

405.XX NOTE: VINTAGE A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AB

406.XX NOTE: VINTAGE A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AC PCP, LINE, 8-PARTY GCCCCCCCCCCC

NT2T05AD PCP, LINE, 8-PARTY A CCCCCCCCCCC

NT2T05AD

402.52 NOTE: VINTAGE A THROUGH J ARE NOT COMPATIBLE.

NT2T05AD

402.53 NOTE: VINTAGE A THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AD

403.1X NOTE: VINTAGE A THROUGH J ARE NOT COMPATIBLE.

NT2T05AD

403.XX NOTE: VINTAGE A THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AD

404.XX NOTE: VINTAGE A THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AD

405.XX NOTE: VINTAGE A THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05AD

406.XX NOTE: VINTAGE A THROUGH J COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05BB PCP, LINE, 8-PARTY A CCCCCCCCCCC

NT2T05BB

402.52 NOTE: VINTAGES A AND B ARE NOT COMPATIBLE.

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 2

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT2T05BB

402.53 NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05BB

403.1X NOTE: VINTAGES A AND B ARE NOT COMPATIBLE.

NT2T05BB

403.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05BB

404.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05BB

405.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T05BB

406.XX NOTE: VINTAGES A AND B COMPATIBLE IF MINIMUM NT4T05AD EQUIPPED.

NT2T07AA PCP, LINE, 2-PARTY, MF C CCCCCCCCCCC

NT2T07BA PCP, LINE, 2-PARTY, MF A CCCCCCCCCCC

NT2T08AA PCP, LINE, 2-PARTY, EXTENDED RANGE BCCCCCCCCCCC

NT2T08BA PCP, LINE, 2-PARTY, EXTENDED RANGE A CCCCCCCCCCC

NT2T09AA PCP, LINE, 8-PARTY, EXTENDED RANGE C CCCCCCCCCCC

NT2T09BA PCP, LINE, 8-PARTY, EXTENDED RANGE A CCCCCCCCCCC

NT2T10AA PCP, RECEIVER, MULTIFREQUENCY C CCCCCCCCCCC

NT2T10AB PCP, RECEIVER, MULTIFREQUENCY A CCCCCCCCCCC

NT2T10BA PCP, RECEIVER, MULTIFREQUENCY A CCCCCCCCCCC

NT2T10BB PCP, RECEIVER, MULTIFREQUENCY A CCCCCCCCCCC

NT2T11AA PCP, RECEIVER, DIGITONE D CCCCCCCCCCC

NT2T11AB PCP, RECEIVER, DIGITONE A CCCCCCCCCCC

NT2T11BA PCP, RECEIVER, DIGITONE BCCCCCCCCCCC

NT2T11BB PCP, RECEIVER, DIGITONE A CCCCCCCCCCC

NT2T12AA PCP, CONTROL, PERIPHERAL, #1 HCCCCCCCCCCC

NT2T13AA PCP, CONTROL, PERIPHERAL, #2 C CCCCCCCCCCC

NT2T13AB PCP, CONTROL, PERIPHERAL, #2 A CCCCCCCCCCC

NT2T13AC PCP, CONTROL, PERIPHERAL, #2 A CCCCCCCCCCC

NT2T14AA PCP, ACCESS, PERIPHERAL MAINT BCCCCCCCCCCC

NT2T16AA PCP, TRUNK, TEST, INCOMING HIIIIIIIIIII

NT2T16BA PCP, TRUNK, TEST, INCOMING AIIIIIIIIIII

NT2T16CA PCP, TRUNK, TEST, INCOMING ECCCCCCCCCCC

NT2T16CA

405.XX NOTE: MAY BE USED WHEN METALLIC LINE TESTING FOR SLC-96 IS NOT REQUIRED

NT2T16CA

406.XX NOTE: MAY BE USED WHEN METALLIC LINE TESTING FOR SLC-96 IS NOT REQUIRED

NT2T16CA

40X.XX NOTE: NOT COMPATIBLE WHERE SLC-96 IS INTERFACED.

NT2T16CB PCP, TRUNK, TEST, INCOMING C CCCCCCCCCCC

NT2T16CB

405.1 NOTE: MINIMUM WHEN METALLIC LINE TESTING FOR SLC-96 IS REQUIRED.

NT2T16CB

40X.XX NOTE: MINIMUM REQUIRED IN HOST AND PE BASED REMOTES.

NT2T17AA PCP, INTERFACE, NOLLER/BADGER CIIIIIIIIIII

NT2T17BA PCP, TRUNK, TEST, NOLLER BIIIIIIIIIII

NT2T17CA PCP, TRUNK, TEST, NOLLER A C C IIIIIIIII

NT2T17CB PCP, TRUNK, TEST, NOLLER A CCCCCCCCCCC

NT2T17CB

40X.XX NOTE: MINIMUM REQUIRED IN HOST AND PE BASED REMOTES.

NT2T19AA PCP, TEST, LINE & TRUNK SIIIIIIIIIII

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 3

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT2T19AB PCP, TEST, LINE & TRUNK AIIIIIIIIIII

NT2T19AC PCP, TEST, LINE & TRUNK A CCCCCCCCCCC

NT2T19AC

40X.XX NOTE: MINIMUM REQUIRED IN HOST AND PE BASED REMOTES.

NT2T20AA PCP, TRUNK, 4-WIRE E & M D CCCCCCCCCCC

NT2T20AB PCP, TRUNK, 4-WIRE E & M BCCCCCCCCCCC

NT2T20BB PCP, TRUNK, E & M, 4-WIRE R CCCCCCCCCCC

NT2T20BB

4XX.XX NOTE: B/L VTG SHOWN IS FOR STYLE C. STYLE A B/L IS VTG B.

NT2T20CA PCP, TRUNK, 4W E&M, DP, REMOTE A CCCCCCCCCCC

NT2T20CA

40X.XX NOTE: USED IN PE REMOTES ONLY.

NT2T20CB PCP, TRUNK, E & M,4-WIRE,DP,REM A CCCCCCCCCCC

NT2T20CB

40X.XX NOTE: USED IN DMS-10 HOST & PE REMOTES.

NT2T21AA PCP, TRUNK, E & M, 2-WIRE ECCCCCCCCCCC

NT2T21AB PCP, TRUNK, E & M, 2-WIRE BCCCCCCCCCCC

NT2T21BB PCP, TRUNK, E & M, 2-WIRE SCCCCCCCCCCC

NT2T21BB

4XX.XX NOTE: B/L VTG SHOWN IS FOR STYLE C. STYLE A B/L IS VTG A.

NT2T21CA PCP, TRUNK, 2W E&M, REMOTE BCCCCCCCCCCC

NT2T21CA

40X.XX NOTE: USED IN PE REMOTES ONLY.

NT2T21CA

4XX.XX NOTE: B/L VTG SHOWN IS FOR STYLE C. STYLE A B/L IS VTG A.

NT2T21CB PCP, TRUNK, 2W E&M, REMOTE A CCCCCCCCCCC

NT2T21CB

40X.XX NOTE: USED IN DMS-10 HOST & PE REMOTES.

NT2T23AA PCP, TRUNK, MISC. LOOP D C C C IIIIIIII

NT2T23AA

404.3X NOTE: & HIGHER GENERICS CAN'T BE USED IN OUTGOING TRUNK; INCOMING ONLY

NT2T23BA PCP, TRUNK, LOOP, MISC. A C C C IIIIIIII

NT2T23BA

404.3X NOTE: & HIGHER GENERICS CAN'T BE USED IN OUTGOING TRUNK; INCOMING ONLY

NT2T24AA PCP, TRUNK, LOOP, OUTGOING GCCCCCCCCCCC

NT2T24AA

4XX.XX NOTE: B/L VTG SHOWN IS FOR STYLE B. STYLE A B/L IS VTG F.

NT2T24BA PCP, TRUNK, LOOP, OUTGOING BCCCCCCCCCCC

NT2T25AA PCP, NETWORK, COMPROMISE A CCCCCCCCCCC

NT2T26AA PCP, CIRCUIT BREAKER BCCCCCCCCCCC

NT2T27AA PCP, TRUNK, E & M, 4-WIRE A CCCCCCCCCCC

NT2T27AB PCP, TRUNK, 4-WIRE E & M A CCCCCCCCCCC

NT2T27BB PCP, TRUNK, E&M, 4-WIRE, W/PAD A CCCCCCCCCCC

NT2T27CA PCP, TK, 4W E&M W/PAD, DP, REM A CCCCCCCCCCC

NT2T30AA PCP, INTERFACE, NETWORK BCCCCCCCCCCC

NT2T31AA PCP, SIGNALING CONVERTER BCCCCCCCCCCC

NT2T32AA PCP, INTERFACE, CARRIER BCCCCCCCCCCC

NT2T32AA

40X.XX NOTE: COMPATIBLE WITH DCM APPLICATIONS ONLY.

NT2T32AB PCP, INTERFACE, CARRIER C CCCCCCCCCCC

NT2T32AB

40X.XX NOTE: COMPATIBLE WITH DCM APPLICATIONS ONLY.

NT2T32AC PCP, INTERFACE, CARRIER A CCCCCCCCCCC

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 4

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT2T32AC

40X.XX NOTE: COMPATIBLE WITH DCM, REQUIRED FOR REM APPLICATIONS.

NT2T32AD PCP, INTERFACE, CARRIER A CCCCCCCCCCC

NT2T32AD

40X.XX NOTE: REQUIRED FOR OSS FEATURE, BACKWARD COMPATIBLE. MINIMUM FOR J0T13A-1L3 & LATER SHELF.

NT2T32AE PCP, INTERFACE, CARRIER A CCCCCCCCCCC

NT2T32AE

40X.XX NOTE: REQUIRED FOR OSS FEATURE, BACKWARD COMPATIBLE. MINIMUM FOR J0T13A-1L5 & LATER SHELF.

NT2T33AA PCP, TERMINATOR, 6-LOOP A CCCCCCCCCCC

NT2T34AA PCP, BUFFER, NETWORK BCCCCCCCCCCC

NT2T35AA PCP, CONVERTER, MESSAGE C CCCCCCCCCCC

NT2T36AA PCP, BUFFER, SIGNALING D CCCCCCCCCCC

NT2T37AA PCP, NETWORK, REMOTE BCCCCCCCCCCC

NT2T38AA PCP, MESSAGE, REMOTE BCCCCCCCCCCC

NT2T39AA PCP, SIGNALING, REMOTE BCCCCCCCCCCC

NT2T39AB PCP, SIGNALING, REMOTE A CCCCCCCCCCC

NT2T40AA PCP, AUXILIARY RING & TONE FCCCCCCCCCCC

NT2T40BA PCP, AUXILIARY RING & TONE A CCCCCCCCCCC

NT2T40BB PCP, AUXILIARY RING & TONE A CCCCCCCCCCC

NT2T41AA PCP, CONTROLLER, PE SHELF HCCCCCCCCCCC

NT2T41AB PCP, CONTROLLER, PE SHELF U CCCCCCCCCCC

NT2T41AC PCP, CONTROLLER, PE SHELF A CCCCCCCCCCC

NT2T42AA PCP, CONVERTER, PE SHELF D CCCCCCCCCCC

NT2T42AB PCP, CONVERTER, PE SHELF, AB A CCCCCCCCCCC

NT2T43AA PCP, LINE, ZERO DB, 2-PARTY D CCCCCCCCCCC

NT2T43AB PCP, LINE, ZERO DB, 2-PARTY BCCCCCCCCCCC

NT2T43AC PCP, LINE, ZERO DB, 2-PARTY A CCCCCCCCCCC

NT2T43BB PCP, LINE, 2-PARTY, ZERO DB C CCCCCCCCCCC

NT2T44AA PCP, LINE, ZERO DB, MISC. FUNCTION C CCCCCCCCCCC

NT2T44AB PCP, LINE, ZERO DB, MISC. FUNCTION BCCCCCCCCCCC

NT2T44AC PCP, LINE, ZERO DB, MISC. FUNCTION A CCCCCCCCCCC

NT2T44BB PCP, LINE, ZERO DB, MISC. FUNCTION GCCCCCCCCCCC

NT2T44BC PCP, LINE, ZERO DB, MISC. FUNCTION BCCCCCCCCCCC

NT2T45AA PCP, LINE, ZERO DB, COIN C CCCCCCCCCCC

NT2T45AB PCP, LINE, ZERO DB, COIN KCCCCCCCCCCC

NT2T45BB PCP, LINE, ZERO DB, COIN ZCCCCCCCCCCC

NT2T45BB

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "B". STYLE "A" B/L IS VTG "P".

NT2T46AA PCP, PROCESSOR, PERIPHERAL FCCCCCCCCCCC

NT2T46AB PCP, PROCESSOR, PERIPHERAL A CCCCCCCCCCC

NT2T47AA PCP, INTERFACE, ALARM, REMOTE A CCCCCCCCCCC

NT2T48AA PCP, SIGNALING, CAMA BCCCCCCCCCCC

NT2T48AA

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "B". STYLE "A" B/L IS VTG "A".

NT2T48BA PCP, SIGNALING, CAMA A CCCCCCCCCCC

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 5

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT2T50AA PCP, SWITCH, TIME HCCCCCCCCCCC

NT2T51AA PCP, PROCESSOR, SYSTEM GCCCCCCCCCCC

NT2T52AA PCP, PROCESSOR, B WORD ECCCCCCCCCCC

NT2T53AA PCP, PROCESSOR, A-BIT GCCCCCCCCCCC

NT2T53AA

40X.XX NOTE: USED FOR SINGLE PARTY LINE CARD APPLICATIONS ONLY.

NT2T53AA

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "B". STYLE "A" B/L IS VTG "E".

NT2T53AB PCP, PROCESSOR, A-BIT BCCCCCCCCCCC

NT2T53AB

40X.XX NOTE: USED FOR SINGLE PARTY LINE CARD APPLICATIONS ONLY.

NT2T53AC PCP, PROCESSOR, A BIT A CCCCCCCCCCC

NT2T53AC

40X.XX NOTE: USED IF DMS-1R HAS MULTI FREQUENCY RINGING.

NT2T54AA PCP, DIGITAL GROUP C CCCCCCCCCCC

NT2T55AA PCP, PROTECTION SWITCH,1 FOR N D CCCCCCCCCCC

NT2T56AA PCP, PROTECTION SWITCH, FAILSAFE D CCCCCCCCCCC

NT2T56AA

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "B". STYLE "A" B/L IS VTG "B".

NT2T67AA PCP, LINE, ZERO DB, SUPERIMPOSED FCCCCCCCCCCC

NT2T67BB PCP, LINE, ZERO DB, SUPERIMPOSED GCCCCCCCCCCC

NT2T69BA PCP, LINE, ZERO DB, SGL PARTY D CCCCCCCCCCC

NT2T69BB PCP, LINE, ZERO DB, SGL PARTY A CCCCCCCCCCC

NT2T70AA PCP, PROCESSOR, PERIPHERAL MAINT. D CCCCCCCCCCC

NT2T70AA

40X.XX NOTE: ALIT FEATURE IS NOT SUPPORTED WHEN USED IN DC TEST SHELF.

NT2T70AB PCP, PROCESSOR, PERIPHERAL MAINT. BCCCCCCCCCCC

NT2T70AB

40X.XX NOTE: MINIMUM VINTAGE B REQUIRED TO SUPPORT ALIT.

NT2T71AA PCP, TEST, PERIPHERAL MAINT. BCCCCCCCCCCC

NT2T72AA PCP, TEST, FACILITY C CCCCCCCCCCC

NT2T73AA PCP, PROCESSOR, SIGNAL C CCCCCCCCCCC

NT2T74AA PCP, PROCESSOR, CONTROL ECCCCCCCCCCC

NT2T85AA PCP, ANNOUNCER, DIGITAL A CCCCCCCCCCC

NT2T85AB PCP, ANNOUNCER, DIGITAL, AB A CCCCCCCCCCC

NT2X06AB PCP, CONVERTER, POWER, 5V/40A 03 CCCCCCCCCCC

NT2X09AA PCP, CONVERTER, POWER, MULTI O/P 05 CCCCCCCCCCC

NT2X10AB PCP, TEST, LOOP AND LINE, ODD 12 CCCCCCCCCCC

NT2X10AB

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT2X10AC PCP, LINE TEST UNIT, ANALOG 01 CCCCCCCCCCC

NT2X10AC

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT2X11AA PCP, TEST, LOOP AND LINE, EVEN 4A CCCCCCCCCCC

NT2X11AA

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT2X11AC PCP, LINE TEST UNIT, DIGITAL 01 CCCCCCCCCCC

NT2X11AC

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT2X11AD PCP, LINE TEST UNIT, DIGITAL 01 CCCCCCCCCCC

NT2X11AD

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 6

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT2X48AB PCP, RECEIVER, DIGITONE 04 CCCCCCCCCCC

NT2X48AB

40X.XX NOTE: REQUIRED TO SUPPORT ESA IN RLCM AND OPM.

NT2X57AA PCP, DISTRIBUTION, SIGNAL 01 CCCCCCCCCCC

NT2X57AA

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT2X59AA PCP, GROUP CODEC 10 CCCCCCCCCCC

NT2X70AA PCP, CONVERTER, POWER 0K CCCCCCCCCCC

NT2X70AA

40X.XX NOTE: COMPATIBLE WITH RLCM ONLY.

NT2X70AD PCP, CONVERTER, POWER 01 CCCCIIIIIII

NT2X70AD

405.XX NOTE: MAXIMUM AT 405.10.

NT2X70AD

40X.XX NOTE: COMPATIBLE WITH SLC-96 INTERFACE (SCM-10S).

NT2X70AE PCP, CONVERTER, POWER 01 CCCCCCCCCCC

NT2X70AE

404.XX NOTE: 404.40 IS MINIMUM FOR USE WITH SCM-10U.

NT2X70AE

405.2X NOTE: NT2X70AE IS MINIMUM FOR GENERIC 405.20.

NT2X70AE

406.1X NOTE: NT2X70AE IS MINIMUM FOR GENERIC 405.20.

NT2X70AE

4XX.XX NOTE: COMPATIBLE WITH SCM-10S.

NT2X77AA PCP, BALANCE NETWORK, TEST TRUNK 01 CCCCCCCCCCC

NT2X77AA

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT2X90AC PCP, TRUNK, TEST, IN/OUT 01 CCCCCCCCCCC

NT2X90AC

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT2X90AD PCP, TRUNK, TEST, IN/OUT 01 CCCCCCCCCCC

NT2X90AD

40X.XX NOTE: USED WITH REMOTE MAINTENANCE MODULE IN RLCM AND OPM.

NT3T05FA PCP, HARDWARE CLOCK & ROM BCIIIIIIIIII

NT3T05FA

402.5X NOTE: COMPATIBLE WITH J0T93A CPU SHELF ONLY.

NT3T05HA PCP, HARDWARE CLOCK & ROM BCIIIIIIIIII

NT3T05HA

402.5X NOTE: COMPATIBLE WITH J0T93A CPU OR J1T72B CPU/NETWORK SHELF.

NT3T05KA PCP, HARDWARE CLOCK & ROM A C IIIIIIIIII

NT3T05KA

402.5X NOTE: COMPATIBLE WITH J0T93A CPU SHELF ONLY.

NT3T05LA PCP, HARDWARE CLOCK & ROM AICIIIIIIIII

NT3T05LA

403.XX NOTE: MINIMUM REQUIRED TO SUPPORT THIS GENERIC.

NT3T09AA PCP, INTERFACE, SERIAL DATA GCCCCCCCCCCC

NT3T10AA PCP, CONTROLLER, MAG TAPE DIIIIIIIIIII

NT3T10AA

40X.XX NOTE: COMPATIBLE IN 200/300 GEN. WITH MAG TAPE DRIVES.

NT3T10AB PCP, CONTROLLER, MAG TAPE AIIIIIIIIIII

NT3T10AB

40X.XX NOTE: COMPATIBLE IN 200/300 GEN. WITH 800 BPI DRIVES.

NT3T10AC PCP, CONTROLLER, MAG TAPE C CCCCCCCCCCC

NT3T10AC

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "B". STYLE "A" B/L IS VTG "A".

NT3T12BA PADDLEBOARD, MAGNETIC TAPE CTR BCCCCCCCCCCC

NT3T19AA PCP, CONVERTER, 5/12 VOLT DIIIIIIIIIII

NT3T19AB PCP, CONVERTER, 5/12 VOLT C CCCCCCCCCCC

NT3T19AB

40X.XX NOTE: MINIMUM VINTAGE D IN 400 GENERICS, USED IN PERIPHERALS ONLY.

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 7

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT3T19AC PCP, CONVERTER, 5/12 VOLT N CCCCCCCCCCC

NT3T19AD PCP, CONVERTER, 5/12 VOLT A CCCCCCCCCCC

NT3T19AE PCP, 5-12V CONVERTER 01 CCCCCCCCCCC

NT3T19AE

409.1X NOTE: MINIMUM REQUIRED FOR DSI

NT3T19BA PCP, CONVERTER, 5/12 VOLT CI I CCCCCCCCC

NT3T19BA

404.XX NOTE: PROVISIONED ONLY ON THE MESSAGING SHELF

NT3T21AA PADDLEBOARD, CLOCK & CHANGEOVER A CCCCCCCCCCC

NT3T27AA PCP, MONITOR, RINGING FCCCCCCCCCCC

NT3T27AB PCP, MONITOR, RINGING BCCCCCCCCCCC

NT3T27AC PCP, MONITOR, RINGING A CCCCCCCCCCC

NT3T27AC

404.XX NOTE: REF. PCN 19930027 FOR VTG A, VTG B, FIELD CONDITIONS.

NT3T27AD PCP, MONITOR, RINGING A CCCCCCCCCCC

NT3T29AD PCP, BUS EXTENDER, CPU A C C ICCCCCCCC

NT3T29AD

404.XX NOTE: USED ORIGINALLY IN 200 & 300 GENERIC SYSTEMS.

NT3T29AE PCP, BUS EXTENDER, CPU BC C IIIIIIIII

NT3T30AA PCP, ALARM, FUSE D CCCCCCCCCCC

NT3T34BA PCP, BUS TERMINATOR, CONTROL, #1 C CCCCCCCCCCC

NT3T45BB PCP, BUS TERMINATOR, CONTROL, #5 AIIIIIIIIIII

NT3T45CA PCP, BUS TERMINATOR, CONTROL, #5 A CCCCCCCCCCC

NT3T45CA

40X.XX NOTE: USED IN J1T81 SHELF, SLOTS 11-12 (REAR).

NT3T45CB PCP, BUS TERMINATOR, CONTROL, #5 A CCCCCCCCCCC

NT3T45CB

40X.XX NOTE: USED IN J1T81 SHELF, SLOTS 11-12 (REAR).

NT3T45CC PCP, CONTROL BUS TERMINATOR #5 01 CCCCCCCCCCC

NT3T45CC

4XX.XX NOTE: MINIMUM REQUIRED FOR GROUND ISOLATION W/ NT3T80BB

NT3T45CC

4XX.XX NOTE: USED IN J1T81 SHELF, SLOTS 11-12 (REAR).

NT3T45DA PCP, BUS TERMINATOR, CONTROL, #6 BCCCCCCCCCCC

NT3T45DA

40X.XX NOTE: USED IN REAR OF NT3T80

NT3T45DB PCP, BUS TERMINATOR, CONTROL, #6 A CCCCCCCCCCC

NT3T45DB

40X.XX NOTE: USED IN REAR OF NT3T80

NT3T45DC PCP, CONTROL BUS TERMINATOR #5 01 CCCCCCCCCCC

NT3T45DC

4XX.XX NOTE: MINIMUM REQUIRED FOR GROUND ISOLATION W/ NT3T80BB

NT3T45EA PCP, BUS TERMINATOR, CONTROL, #5 C CCCCCCCCCCC

NT3T45EA

40X.XX NOTE: USED IN J1T81 SHELF, NT3T50 SLOTS 4-10, 13-18 (REAR).

NT3T45EA

4XX.XX NOTE: B/L VTG SHOWN IS FOR STYLE C. STYLE B B/L IS VTG B.

NT3T47AA PCP, CLOCK, SYNCHRONOUS DIIIIIIIIIII

NT3T47BA PCP, CLOCK, SYNCHRONOUS A CCCCCCCCCCC

NT3T47BB PCP, CLOCK, SYNCHRONOUS A CCCCCCCCCCC

NT3T47BB

40X.XX NOTE: MINIMUM REQUIRED FOR RSLE.

NT3T48AA PADDLEBOARD, CPU COMMUNICATION A CCCCCCCCCCC

NT3T50AA PCP, CONTROLLER, DATA LINK DIIIIIIIIIII

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 8

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT3T50BA PCP, CONTROLLER, DATA LINK EIIIIIIIIIII

NT3T50BA

405.1X NOTE: MINIMUM FOR SSO DCM ACCESS.

NT3T50CA PCP, CONTROLLER, DATA LINK BIIIIIIIIIII

NT3T50CB PCP, CONTROLLER, DATA LINK A CCCCCCCCCCC

NT3T50CB

405.1X NOTE: MINIMUM REQUIRED WHEN USING MODEM (2400-9600 BAUD) OR DCM.

NT3T50CC PCP, CONTROLLER, DATA LINK A CCCCCCCCCCC

NT3T50CC

40X.XX NOTE: NOT COMPATIBLE WITH CDMS, MINIMUM REQUIRED FOR SIMPLEX LINKS.

NT3T50CD PCP, CONTROLLER, DATA LINK A CCCCCCCCCCC

NT3T50CD

40X.XX NOTE: MINIMUM REQUIRED FOR LCC OR DROP & INSERT UNITS.

NT3T50CE PCP, CONTROLLER, DATA LINK A CCCCCCCCCCC

NT3T50CE

40X.XX NOTE: MINIMUM REQUIRED TO SUPPORT UPLOAD FEATURE.

NT3T51AA PCP, DISK DRIVE A CCCCCCCCCCC

NT3T51AA

402.52 NOTE: ALTERNATE FOR J1T91A DISK DRIVE, REQUIRES NT3T90AD.

NT3T51AA

402.53 NOTE: ALTERNATE FOR J1T91A DISK DRIVE, REQUIRES NT3T90AD.

NT3T51AA

403.1X NOTE: ALTERNATE FOR J1T91A DISK DRIVE, REQUIRES NT3T90BB.

NT3T51AA

403.XX NOTE: ALTERNATE FOR J1T91A DISK DRIVE, REQUIRES NT3T90BB.

NT3T51AA

404.XX NOTE: ALTERNATE FOR J1T91A DISK DRIVE, REQUIRES NT3T90BB.

NT3T51AA

405.XX NOTE: ALTERNATE FOR J1T91A DISK DRIVE, REQUIRES NT3T90BB.

NT3T51AA

406.XX NOTE: ALTERNATE FOR J1T91A DISK DRIVE, REQUIRES NT3T90BB.

NT3T53AA PCP, PROCESSOR, ALARM D CCCCCCCCCCC

NT3T54AA PCP, DISTRIBUTOR, ALARM SIGNAL D CCCCCCCCCCC

NT3T55AA PCP, CONTROL, ALARM & RINGING D CCCCCCCCCCC

NT3T56AA PCP, MANUAL CONTROL CENTER BCCCCCCCCCCC

NT3T57XX MODULE, PROGRAM, SINGLE FREQ. A CCCCCCCCCCC

NT3T57XX

4XX.XX NOTE: INCLUDES ALL SUFFIX'S FOR THE NT3T57

NT3T58XX MODULE, PROGRAM, MULTI-FREQ. A CCCCCCCCCCC

NT3T58XX

4XX.XX NOTE: INCLUDES ALL SUFFIX'S FOR THE NT3T58

NT3T59AA PCP, RINGING GENERATOR, DUAL ECCCCCCCCCCC

NT3T59AB PCP, RINGING GENERATOR A CCCCCCCCCCC

NT3T59AC PCP, RINGING GENERATOR 01 CCCCCCCCCCC

NT3T65AA PCP, CENTRAL PROCESSOR AI I CIIIIIIII

NT3T65AA

404.XX NOTE: NOT COMPATIBLE WITH CROSS MEMORY FEATURE.

NT3T65AB PCP, CENTRAL PROCESSOR AI I CCCCCCCCC

NT3T65AB

405.1X NOTE: MINIMUM REQUIREMENT AT 405.10.

NT3T65AB

404.XX NOTE: MINIMUM REQUIRED FOR CROSS MEMORY FEATURE.

NT3T65AC PCP, CENTRAL PROCESSOR AI I CCCCCCCCC

NT3T65BA PCP, CENTRAL PROCESSOR 01 IIIIICCCCCC

NT3T65BA

406.2X NOTE: USE WITH NT3T68DA

411.1X NOTE: THE 4T05AE IS REQUIRED IF THE NT3T65BA IS PROVISIONED.

411.2X NOTE: MINIMUM REQUIRED TO SUPPORT WIRELESS

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 9

DMS-10 H/W 400 Generic Compatibility Report for North America 3/9/98

C = Compatible

I= Incompatible

Description

Product Engineering

Code

402.5X

403.XX

404.XX

INS

B/L

Vtg.

405.XX

406.10

406.22

408.11

409.11

410.10

411.10

411.20

NT3T66AA PCP, MEMORY, DRAM, 4 MEGABYTE BI I CCCCCCIII

NT3T66AB PCP, MEMORY, DRAM, 4 MEGABYTE EI I CCCCCCIII

NT3T66AB

40X.XX NOTE: MINIMUM REQUIRED FOR CROSS MEMORY FEATURE.

NT3T66AB

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "C". STYLE "B" B/L IS VTG "B".

NT3T66AC PCP, MEMORY, DRAM, 1 MEGAWORD AI I CCCCCCIII

NT3T66AC

40X.XX NOTE: MINIMUM FOR MULTIPLE 3T66 MEMORY COMBINATIONS PER SHELF.

NT3T66BA PCP, MEMORY, DRAM, 8 MEGABYTE BI I CCCCCCIII

NT3T66BB PCP, MEMORY, DRAM, 8 MEGABYTE EI I CCCCCCIII

NT3T66BB

40X.XX NOTE: MINIMUM REQUIRED FOR CROSS MEMORY FEATURE.

NT3T66BB

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "C". STYLE "B" B/L IS VTG "A".

NT3T66BC PCP, MEMORY, DRAM, 2 MEGAWORD AI I CCCCCCIII

NT3T66BC

40X.XX NOTE: MINIMUM FOR MULTIPLE 3T66 MEMORY COMBINATIONS PER SHELF.

NT3T66CA PCP, MEMORY, DRAM, 12 MEGABYTE BI I CCCCCCIII

NT3T66CB PCP, MEMORY, DRAM, 12 MEGABYTE EI I CCCCCCCCC

NT3T66CB

40X.XX NOTE: MINIMUM REQUIRED FOR CROSS MEMORY FEATURE.

NT3T66CB

4XX.XX NOTE: B/L VTG SHOWN IS FOR PCB STYLE "C". STYLE "B" B/L IS VTG "A".

NT3T66CC PCP, MEMORY, DRAM, 3 MEGAWORD AI I CCCCCCCCC

NT3T66CD PCP, MEMORY, DRAM, 3 MEGAWORD 01 I I CCCCCCCCC

NT3T66CC

40X.XX NOTE: MINIMUM FOR MULTIPLE 3T66 MEMORY COMBINATIONS PER SHELF.

NT3T68AA PCP, BUS EXTENDER, CLOCK & ROM BI I CIIIIIIII

NT3T68AA

404.XX NOTE: COMP IN 404.12 ONLY, SAME FAMILY CODE REQUIRED IN MATE CPU SHELF.

NT3T68AB PCP, BUS EXTENDER, CLOCK & ROM AI I CIIIIIIII

NT3T68AB

404.XX NOTE: COMP IN 404.12 ONLY, SAME FAMILY CODE REQUIRED IN MATE CPU SHELF.

NT3T68BA PCP, BUS EXTENDER, CLOCK & ROM DI I CIIIIIIII

NT3T68BA

404.XX NOTE: REQUIRED FOR CCDB. SAME FAMILY CODE PCP REQUIRED IN MATE CPU SHELF.

NT3T68CA PCP, BUS EXTENDER, CLOCK & ROM AI I CCCCCCIII

NT3T68CA

405.1X NOTE: MINIMUM REQUIRED FOR 405.10 GENERICS.

NT3T68CA

404.XX NOTE: MINIMUM REQUIRED FOR CROSS MEMORY.

NT3T68DA PCP, BUS EXTENDER, CLOCK & ROM 02 IIIIICCCCCC

NT3T68DA

409.1X NOTE: MINIMUM REQUIRED FOR 409.1X AND HIGHER

411.1X NOTE: MINIMUM REQUIRED FOR SCM-10A

NT3T70BA PCP, CONTROLLER, SYSTEM BUS D CCCCCCIIIII

NT3T70BA

40X.XX NOTE: NOT COMPATIBLE WITH J1T72A-1 COMBINED CPU/NETWORK SHELF.

NT3T70BB PCP, CONTROLLER, SYSTEM BUS D CCCCCCIIIII

NT3T70BB

40X.XX NOTE: MINIMUM REQUIRED WITH COMBINED CPU/NETWORK SHELF.

NT3T70BC PCP, CONTROLLER, SYSTEM BUS 05 CCCCCCCCCCC

4XX.XX NOTE: NT3T70BC, REEL 05 MINIMUM FOR 408.1X AND HIGHER

NT3T70BD PCP, SYSTEM BUS CONTROLLER 04 CCCCCCCCCC C

NT3T71AA PCP, INTERFACE, MAINTENANCE C CCCCCCCCCCC

NT3T71AB PCP, MAINTENANCE INTERFACE 01 CCCCCCCCCC C

Due to variable equipment/feature combinations, this report may not highlight all conditions for compatibility. Forward inquiries to NTI Customer Service.

Northern Telecom Confidential Page 10
