Enterprise Policy Manager - Device Management Guide

Policy management on the Nortel Ethernet Switch

460, Ethernet Switch 470, and BPS

This guide contains information relating to the configuration of the Nortel

Ethernet Switch 460 (formerly BayStack 460), Ethernet Switch 470 (formerly

BayStack 470), and Business Policy Switch (BPS), to receive policy configuration

from Nortel Enterprise Policy Manager (EPM). It also includes information on the

devices’ compatibility with various policy management objects.

This guide covers the following subjects:

2Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS

318396-4.1

•“Nortel product rebranding” on page 2

•“Configuring the device for policy management” on page 3

•“Testing an Ethernet Switch or BPS device’s policy configuration” on page 5

•“Known device limitations for EPM 4.1” on page 6

•“Policy object - device compatibility” on page 7

•“EPM access requirements” on page 8

•“Hardware changes on a policy-enabled device” on page 9

•“Accessing device documentation” on page 9

•“BPS action limitations” on page 10

Nortel product rebranding

Nortel transitioned to new names for many of its products over the course of 2004.

The transition simplifies product naming in order to make it easier for customers

to understand the Nortel product and services portfolio. Table 1 lists the names of

rebranded Nortel products mentioned in this publication.

Full details of the Nortel product rebranding process can be obtained from

http://www.nortel.com/products/announcements/rebranding/index.html#faqs.

Supported software

The EPM 4.1 release has been tested to support the BoSS 3.0, 3.1 software, as

well as the BPS version 2.5 software. BoSS 3.1.1 software is required to support

UBP functionality. EPM 4.1 has been tested to support BoSS 3.6 for the Ethernet

Switch 460 and Ethernet Switch 470.

Table 1 Nortel product rebranding

Products formerly knowm as.... New Nortel Name

Optivity Policy Services (OPS) Nortel Enterprise Policy Manager (EPM)

BayStack Nortel Ethernet Switch

Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS 3

If you are working with a maintenance release in the EPM 4-series (i.e. post-4.1),

it may have been tested against a newer version of the device software. To verify

the absolute latest supported device software versions, refer to the Release Notes

for Enterprise Policy Manager manual.

Configuring the device for policy management

In order for an Ethernet Switch 460, Ethernet Switch 470, or Business Policy

Switch unit to receive policy configuration from EPM, the devices themselves

must be configured to communicate with the EPM Policy Server. Detailed

instructions for accomplishing this task are included below. Once this is

completed, the devices will report to the EPM Policy Server and they will appear

as icons in the management console. The roles they report are also displayed.

Policy management can be initiated by associating a policy with the device’s

reported role(s).

You must open the Web interface for the device and specify the address and port

number of the EPM Policy Server. You can specify more than one Policy Server.

You must also enable QoS configuration on the device and define its role

combinations.

You must know the IP address and COPS-PR Client Port values for your Policy

Server. You can obtain these values by right-clicking the Policy Server object in

the EPM management console and choosing Properties from the menu.

To configure an Ethernet Switch or BPS unit to accept policy configuration,

follow these steps:

1Launch the Web interface for the device you want to configure. Open a Web

browser and go to the IP address of the device.

2In the Access list, navigate to the following location:

Application > COPS > Configuration

3In the COPS Client Creation area, do the following:

aType the IP address of your EPM Policy Server in the IP Address field.

bType the Policy Server COPS-PR Client Port number (specified in EPM)

in the TCP Port field. The default value for this field is 3288.

4Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS

318396-4.1

cType a priority value in the Priority field.

If you are specifying more than one Policy Server, the priority value sets

the sequential order in which the client connects to the Policy Servers.

dClick the Submit button below the COPS Client Creation area.

An entry for the Policy Server is added to the COPS Configuration Table.

eRepeat steps a through d to specify additional Policy Servers (if required).

4In the Access list navigate to the following location:

Application > QoS > QoS Advanced > Agent

5In the QoS Configuration area, choose the Enabled option from the QoS

Policy Server Control drop-down list.

6Click the Submit button.

7In the Access list navigate to the following location:

Application > QoS > QoS Advanced > Devices > Interface Config

8In the Interface Group Creation area, do the following:

aType a name for a role combination in the Role Combination field. Do not

use spaces in role combination names.

The role combination is a common identifier that is used to enforce a

specific set of policies on specific network entities (for example, the print

server, the Web server, employee workstations, etc.). EPM includes a set

of preconfigured roles with policy objects linked to them. You can use

these roles for test purposes. To find the names of these roles, open the

Policy Setup view of the EPM management console.

bChoose an interface class from the Interface Class drop-down list.

Your choice of Trusted, Untrusted, or Unrestricted will depend on the

type of policy actions that will be enforced on the network traffic

controlled under the role combination.

cClick the Submit button below the Group Creation area.

The new interface group is added to the Interface Group table.

dClick the Edit button next to the new entry in the Interface Group table.

The QoS - Interface Group Port Assignment dialog box appears.

Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS 5

eEnable the check box for each port on the device that you want to include

under the new role combination, and then click the Submit button.

fRepeat steps a through e to define additional role combinations.

9Exit the device’s Web interface.

Testing an Ethernet Switch or BPS device’s policy

configuration

In order to check the policy filters installed on your COPS-PR devices, you must

meet the following requirements:

• You must have SNMP reporting enabled on your network devices.

• You must enter the SNMP string for each device on the device’s

corresponding object in the EPM management console.

• You must have the EMANATE SNMP master agent (available as a default

EPM installation option) installed with your Policy Server.

1In the Policy Setup view, drag a policy from the Available Policy Components

tree to the role that is being reported by the device. Enable the policy from the

Options menu.

For example, you can choose the Mark WWW Traffic Best Effort During

Lunch policy to match all Web traffic between 11:30 am and 1:30 pm. You

can remove the schedule from the policy to make it active all of the time.

2Click the Deploy Changes button on the toolbar to notify the Policy Server of

your changes.

3In the Device Setup view, right-click on the device and choose Show Device

Report from the menu.

4In the Device Report dialog box, click the Lookup button next to the Interface

field and choose the interface for which you want to view installed policy

filters.

If the policy was correctly installed on the device, a list of traffic filters

generated by the policy appears in the Filter Set list. If any traffic matching

the filters has passed through the device, the number of affected packets

appears under the Packets column for each filter.

6Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS

318396-4.1

Known device limitations for EPM 4.1

Users should consider the following guidelines when creating policy

configuration for the BPS or Ethernet Switch devices.

• If you are running a stack of cascaded Ethernet Switch devices, you can

configure user-based policies on the stack ONLY if the stack consists entirely

of COPS-PR compatible devices (Business Policy Switch, Ethernet Switch

460, and Ethernet Switch 470). If you are running a mixed stack that includes

Ethernet Switch 450 devices, you will not be able to configure user-based

policies on the stack.

• Maximum 24 roles per device.

• Maximum 200 IP traffic conditions per device.

• Maximum 14 802 traffic conditions per device.

• Devices with limited memory may not be able to achieve the limitations

stated above.

• The BPS 2.x series has a special limit of 24 traffic conditions that specify the

same source IP address.

To avoid device limitations

• Avoid assigning multiple traffic conditions with overlapping traffic criteria to

a single policy. This will result in excessive numbers of policy filters being

sent to the device. For example, do not assign two traffic conditions, each

specifying the same port number, to the same policy.

• When creating a traffic condition, you should limit the number of different

types of traffic flow criteria you specify. A traffic condition that specifies too

many traffic criteria will, in turn, cause the policies to which it is applied to

send an excessive number of policy filters to network devices. The network

devices may return error messages as a result.

Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS 7

Policy object - device compatibility

EPM provides a selection of policy-related objects (traffic conditions and actions)

to support traffic matching and traffic conditioning on a number of policy-enabled

network devices. This does not mean that all of the devices supported by EPM

will support all of the policy objects provided by EPM. This section lists the

traffic criteria matching and policy action types supported by BayRS devices.

Note: The information displayed here reflects the most up-to-date

information available at the time of the EPM 4.1 release. Policy filter

support capabilities may change for individual device types as their

software is upgraded. Check your device documentation for current

policy support capabilities.

Filtering capability Ether Type

VLAN ID

Inbound User Priority

Protocol

Inbound DSCP

Port Ranges

Src/Dest Address and Mask

Src/Dest Port

Policy priority support

(filter prioritization) (Yes)

DiffServ action capability Mark DSCP

Forward

Drop

Meter (2 Level)

Mark User Priority (L2)

Mark Drop Precedence (L2)

Shaping support (Yes)

COPS-PR capability Configure Roles on Device

Configure Backup PDP on Device

8Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS

318396-4.1

EPM access requirements

In order for EPM to be able to send policy configuration to your networking

devices, COPS-PR, SNMP and Telnet connections must be permitted on your

devices. The following protocols and port numbers are required for

communication between the various components of the EPM product family and

your networking devices:

• The management console uses LDAP (port 389 default) to communicate with

the directory server. It uses SNMP to communicate with Policy Servers and

networking devices. Remote access to the directory requires HTTP (port 80

default).

• The Policy Server uses LDAP (port 389 default) to communicate with the

directory server. It uses COPS-PR (port 3288 default) and SNMP (ports 161

and 162) to communicate with networking devices and the Interface Manager.

• The Interface Manager uses LDAP (port 389 default) to communicate with

the directory server. It uses COPS-PR (port 3288 default) to communicate

with the Policy Server, and uses Telnet (port 23) to communicate with

networking devices.

The LDAP, HTTP, and COPS-PR port numbers can be changed.

Reporting capability Device Reporting - View Filters (via SNMP)

Device Reporting - Filter Statistics (via SNMP)

Queue mapping capability 802 COS to DSCP

DSCP to 802 COS

DSCP to queue

802 COS to queue

Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS 9

Hardware changes on a policy-enabled device

Making hardware changes to a device that is enabled for policy management (for

example, switching off and changing blades) will cause the Policy Server to

generate errors when the device is disconnected. To avoid these errors, disable the

device for policy management through EPM before making the hardware

changes. After you have completed the hardware changes and reconfigured the

device, you can re-enable the device for policy management.

➨To disable a device for policy management, right-click its object in the EPM

management console and then choose Disable For Policy Management from

the menu.

➨To enable a device for policy management, right-click its object in the EPM

management console and then choose Enable For Policy Management from

the menu.

Fixed device reset issue

(Q01038174) BoSS version 3.1.3 had a problem that caused the device to reset

repeatedly when running QoS with OPS (EPM). Fixed in BoSS 3.1.4.2.

Accessing device documentation

A complete set of documentation for the Ethernet Switch and BPS devices,

including configuration manuals, user manuals, release notes, and known

anomalies, are available on the Nortel Networks web site at:

http://www.nortelnetworks.com

Follow the link for Technical Documentation and then choose a device as the

product family.

10 Policy management on the Nortel Ethernet Switch 460, Ethernet Switch 470, and BPS

318396-4.1

BPS action limitations

The Business Policy Switch (BPS) accepts different types of policy actions,

depending on the software version installed on the device. In some cases, the EPM

Policy Server does not send all of the action types accepted by the BPS. Use this

appendix as a reference when assigning actions to policies intended for BPS units.

Your choice of action depends on the port class, as defined on the BPS:

•Trusted ports assume that all traffic coming into the port is originating from

a trusted source. Therefore, the DSCP field of any traffic that enters the BPS

from a trusted port is never re-marked. Any policies instructing the BPS to set

the value of the DSCP field on a trusted port will generate errors. Only

policies with Drop or Forward actions are permitted on trusted ports.

•Untrusted ports assume that all traffic coming into the port is suspect.

Therefore, the DSCP field of any traffic that enters the BPS from an untrusted

port is always re-marked. Any policies instructing the BPS to not set the value

of the DSCP field on an untrusted port will generate errors. Only policies with

Meter, Mark, and Drop actions are permitted on untrusted ports.

•Unrestricted ports do not assume anything about the origin of the incoming

traffic. You may assign a policy action to re-mark the DSCP or not to re-mark

the DSCP. This allows you to manipulate the DSCP value based upon the

filter criteria, and not upon the point of origin. All policy actions are permitted

on unrestricted ports.

The following traffic classifications are handled by the BPS:

•Layer 3 - refers to IP filters, or layer 2 filters with IP classification defined in

the ether type value.

•Layer 2 - refers to filters that have no concept of IP.

•Layer 2 (Tagged) - refers to filters that are layer 2 and have the VLAN tag

specified as Tagged Only.

•Layer 2 (UnTagged) - refers to filters that are layer 2 and have the VLAN tag

specified as UnTagged Only.

This section covers the BPS interface class behavior for the following action

types:

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Nortel Changer

Nortel

Nortel Passport 8600 Series Manuel de l'opérateur

Nortel

Nortel BayStack 350 Series Manuel utilisateur

Nortel

Nortel Passport 2430 Schéma de câblage

Nortel

Nortel Passport 8250 Manuel utilisateur

Nortel

Nortel BayStack 5520-48T-PWR Manuel utilisateur

Nortel

Nortel Versalar 15000 Manuel utilisateur

Nortel

Nortel 5530 Manuel utilisateur

Nortel

Nortel 4600 Mode d’emploi

Nortel

Nortel Passport 15000 Mode d’emploi

Nortel

Nortel BayStack 450-24T Mode d’emploi

Nortel

Nortel 425-24T Manuel utilisateur

Nortel

Nortel 8000 Series Mode d’emploi

Nortel

Nortel 4050 Manuel utilisateur

Nortel

Nortel Application Switch Manuel utilisateur

Nortel

Nortel Versalar 15000 Guide de démarrage rapide

Nortel

Nortel BayStack 60-12T Manuel d'installation et d'exploitation

Nortel

Nortel 4526 Manuel utilisateur

Nortel

Nortel NN47220-101 Manuel utilisateur

Nortel

Nortel Contivity Extranet Switch 2500 Manuel utilisateur

Nortel

Nortel BayStack 380 Mode d’emploi

Nortel

Nortel BayStack 470-24T Manuel utilisateur

Nortel

Nortel Versalar 15000 Mode d'emploi

Nortel

Nortel Centillion EtherSpeed II Mode d’emploi

Nortel

Nortel 425-48T Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
