NN10265-111

Multimedia Communication Portfolio

Multimedia Communication

Server

RTP Media Portal Basics

MCS 5100 3.5 Standard 4.0 January 2006

MCS 5100 RTP Media Portal Basics

Finding the latest updates on the Nortel web site

The content of this documentation was current at the time the product was released. To

check for updates to the latest documentation and software for MCS 5100, click one of

the following links:

Link to Takes you directly to the

Latest Software Nortel page for MCS 5100 software located at

www130.nortelnetworks.com/cgi-bin/eserv/cs/

main.jsp?cscat=SOFTWARE&resetFilter=1&tranProduct=124

82.

Latest Documentation Nortel page for MCS 5100 documentation located at

www130.nortelnetworks.com/cgi-bin/eserv/cs/

main.jsp?cscat=DOCUMENTATION&resetFilter=1&tranProdu

ct=12482

NN10265-111 MCS 5100 3.5 Standard 4.0 January 2006

MCS 5100 RTP Media Portal Basics

How to get help

This section explains how to get help for Nortel products and services.

Getting help from the Nortel web site

The best way to get technical support for Nortel products is from the Nortel Technical Support

web site:

www.nortel.com/support

This site provides quick access to software, documentation, bulletins, and tools to address

issues with Nortel products. From this site, you can:

• download software, documentation, and product bulletins

• search the Technical Support Web site and the Nortel Knowledge Base for answers

to technical issues

• sign up for automatic notification of new software and documentation for Nortel

equipment

• open and manage technical support cases

Getting help over the phone from a Nortel Solutions Center

If you do not find the information you require on the Nortel Technical Support web site, and

you have a Nortel support contract, you can also get help over the phone from a Nortel

Solutions Center.

In North America, call 1-800-4NORTEL (1-800-466-7835).

Outside North America, go to the following Web site to obtain the phone number for your

region:

www.nortel.com/callus

NN10265-111 MCS 5100 3.5 Standard 4.0 January 2006

Getting help from a specialist by using an Express Routing Code

To access some Nortel Technical Solutions Centers, you can use an Express Routing Code

(ERC) to quickly route your call to a specialist in your Nortel product or service. To locate the

ERC for your product or service, go to:

www.nortel.com/erc

Getting help through a Nortel distributor or reseller

If you purchased a service contract for your Nortel product from a distributor or authorized

reseller, contact the technical support staff for that distributor or reseller.

MCS 5100 RTP Media Portal Basics

Overview

How this chapter is organized

This chapter is organized as follows:

•Functional description on page 7

•Hardware on page 8

•Software on page 12

•Operations, administration, and management on page 12

•Interfaces on page 13

—Protocols on page 13

—Network interfaces on page 14

Functional description

The Real-time Transport Protocol (RTP) Media Portal is an optional

component that addresses media plane specific issues with advanced

service delivery, Internet addressing efficiencies, and system security.

The primary function of the RTP Media Portal is to extend the reach of

multimedia services so that they are accessible to obscured endpoints,

devices residing behind a firewall, or a Network Address Translation

(NAT) and/or Network Address Port Translation (NAPT) device.

Functioning as a media NAPT point that shields Multimedia

Communications Platform (MCP) Service Network components from

external exposure, the RTP Media Portal also provides IP address/port

pair mapping between internal and external network components as

well as media anchoring and media pivot abilities for terminals.

The RTP Media Portal may be deployed in a single- or dual-network

configuration. For dual-networks, the RTP Media Portal enables

elements in the Protected MCS Network to safely communicate with

elements in the Managed IP access network.

NN10265-111 MCS 5100 3.5 Standard 4.0 January 2006

Figure 1, Network component topology, on page 8 is a graphical

depiction of the RTP Media Portal’s position in a single-network MCS

solution.

Figure 1 Network component topology

Hardware

The RTP Media Portal resides on a Motorola* CPX8216T platform, a

16-slot CompactPCI (cPCI) chassis design.

The chassis offers a High Availability platform that provides the basic

operating environment (such as power, backplane, cooling, and

mounting slots) required to sustain the resident subcomponent

single-board computers. The CPX8216T hardware architecture

partitions the chassis into separate logical operational Domains,

MCS 5100 RTP Media Portal Basics

dividing the chassis shelf into two half-shelves consisting of 8-slots

each.

Note: The chassis logical Domains are not internet Domains.

Rather, the term is used to identify Side A and Side B of the chassis.

Other terms used interchangeably include: Domain A and Domain B,

Left Domain and Right Domain, and half-shelf.

An RTP Media Portal occupies a single logical operational Domain in

the CPX8216T. A single CPX8216T chassis can host two RTP Media

Portal components (one in chassis Domain A, the other in chassis

Domain B) as shown in Figure 2, Card slot associations for the two

logical Domains in a single chassis, on page 9.

Figure 2 Card slot associations for the two logical Domains in a

single chassis

If the chassis is viewed from the front, the slots are numbered from left

to right (1-16). If viewed from the rear, the slots are numbered from right

Domain A Domain B

NN10265-111 MCS 5100 3.5 Standard 4.0 January 2006

to left (1-16). A front view of the CPX8216T is shown in Figure 3,

Motorola chassis CPX8216T - front view, on page 10.

Figure 3 Motorola chassis CPX8216T - front view

A rear view of the CPX8216T is shown in Figure 4, Motorola chassis

CPX8216T - back view, on page 11.
