297-2011-208
DMS-100 Family
M522 Add-On Module
Description, Installation, Operation, and
Maintenance Manual
Release 02.01 Standard February 1999
DMS-100 Family
M522 Add-On Module
Description, Installation, Operation, and
Maintenance Manual
NTP: 297-2011-208
Document status: Standard
Version: 02.01
Date: February 1999
© 1999 Northern Telecom
Printed in Canada
NORTHERN TELECOM CONFIDENTIAL: The information contained in this document is the property of Northern
Telecom. Except as specifically authorized in writing by Northern Telecom, the holder of this document shall keep the
information contained herein confidential and shall protect same in whole or in part from disclosure and dissemination to third
parties and use same for evaluation, operation, and maintenance purposes only.
The following are trademarks of Northern Telecom: Nortel, the Nortel globemark, DMS-100, Meridian.
iii
Publication history
297–2011–208 02.01 Standard February 1999
October 1996
Release 01.01. Standard version for NA004 and up.
February 1999
Release 02.01. Standard version changed from NA004 and up to CCM04 and
up.
iv Publication history
297–2011–208 02.01 Standard February 1999
v
Contents
297–2011–208 02.01 Standard February 1999
Publication history iii
Chapter 1: Introduction 1-1
General description 1-1
Peripheral equipment 1-2
Physical characteristics 1-3
Other documentation 1-3
Chapter 2: Specifications 2-1
Environmental and safety considerations 2-1
Temperature 2-1
Relative humidity 2-1
Electromagnetic interference 2-1
Atmospheric pollution 2-1
Vibration 2-2
Shock 2-2
Power 2-2
Chapter 3: Operations and features 3-1
Basic operations 3-1
Features operation 3-2
Available features 3-3
Programmable key numbers and the datafill 3-4
Chapter 4: Installation 4-1
Installing the M522 4-1
Unpacking or packing 4-1
Before you begin the installation 4-1
Chapter 5: Replacement parts 5-1
vi Contents
297–2011–208 02.01 Standard February 1999
Figures
Figure 1-1 M522 attached to M5316 1-2
Figure 3-1 M522 add-on module key numbering 3-4
Figure 4-1 M5216/M5316 bottom view 4-2
Figure 4-2 Connecting the ribbon cable(s) 4-3
Figure 4-3 Polarized connection detail 4-4
Figure 4-4 Attaching the base (for one M522 module) 4-5
Figure 4-5 Attaching the base (for two M522 modules) 4-5
Tables
Table 3-1 Summary of M522 keys and indicators 3-2
Table 5-1 Ordering information 5-1
1-1
Chapter 1
Introduction
297–2011–208 02.01 Standard February 1999
General description
The M522 add-on module can be attached to the M5216 or M5316 Meridian
Business Set to provide extra feature/line keys (see Figure 1-1). When one
M522 is connected, 22 additional feature/line keys are available to the
Meridian Business Set. If required, you can also connect one additional
M522 add-on module to increase the number of additional feature/line keys
to 44.
The M5216/M5316 Meridian Business Set is designed for direct connection
(through a non-loaded subscriber loop pair) to the Northern Telecom DMS–
10, DMS–100, DMS–250, or Meridian SL–100 Digital Switching systems.
For more information regarding the M5216 or M5316, refer to the
publications cited in the section “Other documentation”.
1-2 Introduction
297–2011–208 02.01 Standard February 1999
Figure 1-1
M522 attached to M5316
Peripheral equipment
The M522 connects to the M5216 or M5316 Meridian Business Set. The
M5216/M5316 interfaces with the business set (6X21AC) line card in the
Line Concentrating Module (LCM) of the DMS–10/DMS–100/Meridian SL-
100 Central Office (CO) equipment. The 6X21AC supports one business set
per line card.
Introduction 1-3
297–2011–208 02.01 Standard February 1999
Physical characteristics
The add-on module comes in three different colours which match the
M5216/M5316 colours:
• Chameleon-grey (Engineering code NT4X43AA)
• BTS light-grey (Engineering code NT4X43BA)
• Black (Engineering code NT4X43CA)
The Mean Time Between Failure (MTBF) for the M522 is at least 100 years.
Other documentation
Other information pertaining to Meridian Business Sets can be found in the
following documents:
297–2001–100 Integrated Business Network (IBN) —Description
297–1001–114 Operational Measurements (OM)
297–1001–250 Testing and Acceptance for Initial Installation
297–1001–310 Table Editors User Guide
297–1001–518 Operational Measurements—Man-Machine Interface
297–2011–180 DMS-100 Business Set—Line Engineering Rules
P0749053 M522 Installation Instructions (English/French/Spanish)
P0749052 M5216 MBS User Guide (English/French)
P0800730 M5216 MBS User Guide (Spanish)
P0749051 M5316 MBS User Guide (English/French)
P0800729 M5316 MBS User Guide (Spanish)
1-4 Introduction
297–2011–208 02.01 Standard February 1999
