Norelco 6886XL Manuel utilisateur
7886XL
7885XL
6887XL
6886XL
6885XL
Rechargeable Tripleheader ®
Cordless/Cord Razor
SHAVING SYSTEM
7
7
QUADRA
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 1 (Black plate)
2
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 2 (Black plate)
ENGLISH 4
ESPAÑOL 22
7886XL, 7885XL, 6887XL, 6886XL, 6885XL
3
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 3 (Black plate)
IMPORTANT SAFETY
INSTRUCTIONS
When using an electric razor, basic safety precautions should always be
followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for a razor that has fallen into water.
Unplug immediately.
2. Do not use razor corded while bathing or in a shower.
3. Do not place or store razor while plugged in where it can fall or be pulled
into a tub or sink. Do not place or drop into water or other liquid while
plugged in.
4. Always unplug this razor from the electrical outlet immediately after use,
except when razor is (re)charging.
5. Unplug this razor before cleaning.
6. When discarding razor, unplug razor and remove rechargeable batteries.
See Battery Removal instructions.
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Close supervision is necessary when this razor is used by, on, or near
children or invalids.
2. Use this razor for its intended household use as described in this manual.
Do not use attachments not recommended by Philips Electronics North
America Corporation.
3. Never operate this razor if it has a damaged cord or charging plug, if it is
not working properly, if it has been dropped or damaged, or dropped into
water while plugged in. Return the razor to an Authorized Norelco Service
Location for examination and repair.
4ENGLISH
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 4 (Black plate)
5
ENGLISH
4. Keep the razor, cord and charging plug away from heated surfaces.
5. Never drop or insert any object into any opening.
6. Do not charge or plug in razor outdoors or operate where aerosol (spray)
products are being used or where oxygen is being administered.
7. Do not use this razor with a damaged or broken comb, as facial injury may
occur.
8. Always attach plug to razor first, then charging plug to outlet. Be certain
that plug is inserted firmly into razor, up to mark indicated on plug.To
disconnect, turn razor off then remove charging plug from outlet.
9. Never put the razor in direct sunlight or store in a pouch at a temperature
above 140ºF.
10. Razor can be rinsed under running tap water. Do not submerge razor in
water.
11. To prevent possible damage to the cord, do not wrap cord around the
razor.
SAVE THESE
INSTRUCTIONS
IMPORTANT
The power plug contains a transformer. Do not cut off the power plug to
replace it with another plug, as this will cause a hazardous condition.
IMPORTANT
Your razor contains NICKEL-CADMIUM RECHARGEABLE
BATTERIES. See Battery Removal instruction sheet for battery disposal
information.
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 5 (Black plate)
ENGLISH
Name
Address
City
State Zip
Daytime Telephone No. ( )
Email Address
REASON FOR RETURNING:
60-DAY MONEY-BACK
GUARANTEE
To enjoy the closest and most comfortable shave from your new Norelco Men’s
Razor, the razor should be used exclusivelyfor 3 weeks.This allows your hair and
skin enough time to adapt to the Norelco Shaving System. If, after that period of
time, you are not fully satisfied with your Norelco Men’s Razor, send the product
back and we’ll refund you the full purchase price. The razor must be shipped
prepaid by insured mail, insurance prepaid, and have the sales slip, indi-
cating purchase price and the date of purchase, enclosed. The razor must
be postmarked no later than 60 days after the date of purchase. Norelco reserves
the right to verify the purchase price of the razor and limit refunds not to exceed
suggested retail price.
Send dated sales receipt, your complete name and address as indicated below,
and the razor, prepaid to:
Norelco Consumer Products Company
A Division of Philips Electronics
North America Corporation
450 North Medinah Road, Dock 16
Roselle, IL 60172-2329
Please allow 4-6 weeks for delivery of check. (Please Print)
AREA CODE
6
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 6 (Black plate)
Table of Contents
Features..........................................................8-9
LCD Display...............................................10-11
Charge Meter..................................................11
Charging ...................................................11-12
Put It To The Test & Shaving Tips................13
How To Shave With
An Electric Razor...........................................14
Trimming....................................................14-15
Cleaning.....................................................15-18
Assistance........................................................19
Accessories.....................................................19
Storage.............................................................20
Battery Removal............................................20
Warranty...........................................................21
Spanish..............................................................22
7
ENGLISH
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 1 (Black plate)
Put ItToTheTest & Shaving Tips
Quadra
Shaving System
Razor Head Assembly
Protective Razor
Head Cap
Individually Floating
Heads
Razor Head
Release Button
• Hair Chamber
captures
shaven hair
Electronic ON/OFF
Button
LCD Display
• Shows remaining power
level in batteries
• Actual shaving
“Minutes Left”
Automatic Cleaning
Indicator
• Indicates razor heads
should be cleaned
under running water
8ENGLISH
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 2 (Black plate)
Pop-Up Trimmer
Automatic
Worldwide Voltage
100V to 240V AC
Cleaning Brush
Pouch
Rechargeable - Initial
4 hour Full Charge for
up to 45 minutes of
cordless shave time
1-Hour Quick Charge
Cord/Cordless - To
shave with or
without a cord
Full 2-Year Warranty
60-Day Money-Back
Guarantee
9
ENGLISH
How the Unique Norelco Lift and Cut®
Shaving System Makes Close Comfortable:
Groove channels beard
closer to cutting system Lifter raises hair Slots to cut long hairs Holes to cut short hairs
even closer
7885XL_DFU1.QXD 2/3/04 4:16 PM Page 3 (Black plate)
LCD Display
The Display provides the following
information:
C◗Charging Indicator
As soon as you connect cord, the light in display
area goes ON, the plug symbol appears and the
minute indicator starts blinking.
C◗Full Charge Indicator
When batteries have been fully charged,“FULL”
scrolls across the display and light in display starts
blinking.
C◗Minutes Left Indicator
The number on the display shows remaining
shaving time in minutes. The “squares” in the
charge meter indicate how much power is still
left in batteries.
C◗Low Battery Indicator
When the batteries are running low, the plug
symbol will blink after you have turned the
razor OFF. If this occurs while shaving, you
should have enough power to complete your
shave.
When you turn razor ON or OFF, the light in
the LCD Display will come ON for
approximately 10 seconds.
The razor has a 1-minute demonstration
program that will run through the full display of
10 ENGLISH
