Norelco NORELCO 7775X Manuel utilisateur

7775X

Rechargeable

Cordless Tripleheader®Razor

Shaving Lotion

Dispensing

Razor

7775X DFURR 11/25/03 12:35 PM Page 1 (Black plate)

ENGLISH 4

ESPAÑOL 34

7775X

7775X DFURR 11/25/03 12:35 PM Page 3 (Black plate)

IMPORTANT SAFETY

INSTRUCTIONS

When using an electric razor, basic safety precautions should

always be followed, including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1. Do not reach for a charging stand that has fallen into water.

Unplug immediately.

2. Do not use a charging stand while bathing or in a shower.

3. Do not place or store a charging stand where it can fall or be

pulled into a tub or sink. Do not place charging stand in or

drop into water or other liquid.

4. Always unplug charging stand from the electrical outlet

immediately after using, except when razor is (re)charging.

5. Unplug charging stand before cleaning.

When discarding razor, unplug razor and remove rechargeable

batteries. See Battery Removal instructions.

WARNING

To reduce the risk of burns, fire, electric shock, or injury to

persons:

1. Close supervision is necessary when this razor is used by, on, or

near children or invalids.

2. Use this razor for its intended household use as described in

this manual. Do not use attachments not recommended by

Philips Electronics North America Corporation.

3. Never operate this razor if it has a damaged cord or plug, if it is

not working properly, if it has been dropped or damaged, or

ENGLISH4

7775X DFURR 11/25/03 12:35 PM Page 4 (Black plate)

dropped into water. Return the razor to an Authorized

Norelco Service Location for examination and repair.

4. Keep the razor and cord away from heated surfaces.

5 Never drop or insert any object into any opening.

6. Do not charge razor or plug in charging stand outdoors or

operate where aerosol (spray) products are being used or

where oxygen is being administered.

7. Do not use this razor with a damaged or broken comb, as facial

injury may occur.

8. Always place razor in stand first, then plug stand into outlet.To

disconnect, turn razor off then remove plug from stand from

outlet.

9. To prevent possible damage to the cord, do not wrap cord

around the charging stand.

10. Never put razor in direct sunlight or store in a pouch at a

temperature above 140ºF.

11. Razor is water-safe and can be rinsed under running tap water

or used in shower. Do not submerge razor in water.

SAVE THESE

INSTRUCTIONS

IMPORTANT: The power plug contains a transformer. Do not

cut off the power plug to replace it with another plug, as this will

cause a hazardous condition.

IMPORTANT

YOUR RAZOR CONTAINS NICKEL-CADMIUM

RECHARGEABLE BATTERIES. See Battery Removal instruction

sheet

for battery disposal information

ENGLISH 5

7775X DFURR 11/25/03 12:35 PM Page 5 (Black plate)

ENGLISH6

60 - DAY MONEY-BACK GUARANTEE

To enjoy the closest and most comfortable shave from your new Norelco Men’s

Razor, the razor should be used exclusivelyfor 3 weeks.This allows your hair

and skin enough time to adapt to the Norelco Shaving System. If, after that

period of time, you are not fully satisfied with your Norelco Men’s Razor, send

the product back and we’ll refund you the full purchase price.

The razor must be shipped prepaid by insured mail, insurance prepaid,

and have the sales slip, indicating purchase price and the date of

purchase, enclosed. The razor must be postmarked no later than 60 days

after the date of purchase. Norelco reserves the right to verify the purchase

price of the razor and limit refunds not to exceed suggested retail price.

Send dated sales slip, your complete name and address as indicated

below, and the razor, prepaid to:

Norelco Consumer Products Company

A Division of Philips Electronics North America Corporation

450 North Medinah Road, Dock 16

Roselle, IL 60172-2329

Please allow 4-6 weeks for delivery of check. (Please Print)

Name_________________________________________________________

Address________________________________________________________

City___________________________________________________________

State_____Zip__________________________________________________

Daytime Telephone No. (____)_____________________________________

Email Address___________________________________________________

REASON FOR RETURNING:______________________________________

______________________________________________________________

AREA CODE

7775X DFURR 11/25/03 12:35 PM Page 6 (Black plate)

Table of Contents

Features.........................................................8-9

Important .......................................................10

Introduction ..................................................10

Before First Use .....................................10-12

Advanced Multi-Functional Color

LED Display....................................................12

Charging ...................................................12-14

Recharging................................................14-15

Inserting The First Cartridge...............15-16

Replacing Cartridges.............................16-17

Put It ToThe Test & Shaving Tips ........17-18

How to Shave With An

Electric Razor..........................................18-20

Trimming...................................................20-21

Travel Lock...............................................22-23

Cleaning....................................................23-28

Replacing the Razor Heads........................28

Storage............................................................29

Assistance.......................................................29

Battery Removal...........................................30

Accessories....................................................31

Warranty ........................................................32

Spanish ............................................................34

ENGLISH 7

7775X DFURR 11/25/03 12:35 PM Page 7 (Black plate)

Features

Nivea for Men

Shaving Lotion/Gel

Applicator

Reflex Action®

System

Glide Rings

Razor Head

Assembly

Quick Clean System

Individually Floating

Heads

Razor Head Release

Button

• Hair Chamber

captures shaven hair

Electronic Locking

On/Off Button

Advanced Multi-

Function Color

LED Display

• 3 Levels Battery Capacity

• Battery Charge,Full & Low

Indicators

• Head Replacement / Cleaning Indicators

• Lotion/Gel Application Indicator

• Demo mode & travel lock

7775X

ENGLISH8

7775X DFURR 11/25/03 12:35 PM Page 8 (Black plate)

Click-On Trimmer

Attachment for

beard, moustache

and sideburns

Automatic

Worldwide Voltage

100V to 240V AC

Cleaning Brush

Travel / Storage

Pouch

Rechargeable

Cordless- Initial 4

hour full charge for

up to 40 minutes

of cordless shave

time

1-Hour Full Charge

Charging Stand

Full 2-Year

Warranty

60-Day Money-

Back Guarantee

ENGLISH 9

How the Unique Norelco Lift and Cut®

Shaving System Makes Close Comfortable:

Groove channels beard

closer to cutting system Lifter raises hair Blade cuts hair which

then drops below skin level

7775X DFURR 11/25/03 12:35 PM Page 9 (Black plate)

Important

C ◗Only use the power plug and the charging

stand provided to charge the razor.

◗The power plug transforms 100-240 AC volts

to 12 volts DC.

◗An adaptor plug may be necessary for cord

usage in some foreign countries.Your new razor

will automatically convert internally to work on

100V to 240V AC systems.

Introduction

The Cool Skin Razor comes with two different

kinds of NIVEA FOR MEN cartridges:

Moisturizing Shaving Lotion for sensitive skin and

Extra Fresh Shaving Gel for a fresh sensation

during and after shaving.This gives you the

opportunity to try them out and discover which

one suits your skin type best.

The Glide Rings on the shaving heads distribute

the unique NIVEA FOR MEN shaving lotion/gel

evenly over the skin, offering an even smoother

and closer shave, causing less skin irritation and

leaving your skin feeling refreshed.

Before first use

◗Charge the razor before you start using it (see

'Charging').

◗Remove any sticker or protective foil from the

Multi-Function Display.

ENGLISH10

7775X DFURR 11/25/03 12:35 PM Page 10 (Black plate)

Travel lock function

The razor is equipped with a travel lock

function.You can use the travel lock function

when you are going to store the razor for a

longer period or if you are going to take the razor

with you when travelling.

See 'Travel lock' section for instructions on how

to use this function.

Demonstration program

This razor has a 1-minute demonstration program

that will run through the full display of razor

functions.

1Press the on/off button for 7 seconds.

The demonstration will start automatically.

◗When the demonstration starts, all indications

light up at the same time.Then all indications of

the razor are shown separately for

3 seconds in the following order:

◗Charging/Battery Full Indication

◗Shaving lotion/gel indication

◗Cleaning reminder/Battery capacity

◗Shaving lotion/gel indication

◗Battery low indication

◗Cleaning reminder/Battery low indication

◗Shaving head check indication

◗Travel lock indication

ENGLISH 11

7775X DFURR 11/25/03 12:35 PM Page 11 (Black plate)
