Norac UC4.5 Manuel utilisateur
Kverneland
(Variable Geometry)
Installation Manual
RA1
Printed in Canada
Copyright 2012 by NORAC Systems International Inc.
Reorder P/N: UC4.5-BC-RA1-INST Rev B (Kverneland Variable Geometry)
NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and
without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information
contained in this manual. The technical information in this manual was reviewed at the time of approval for publication.
Contents
1Introduction................................................................................................................ 1
2General UC4.5 System Layout................................................................................. 2
3Kit Parts ...................................................................................................................... 3
4Existing System Check .............................................................................................. 8
5Ultrasonic Sensor Installation ................................................................................ 10
6Roll Sensor Installation............................................................................................ 17
7Electrical Installation ............................................................................................... 20
8Hydraulic Installation .............................................................................................. 24
9Software Setup......................................................................................................... 29
10Cable Drawings ........................................................................................................ 31
1
1Introduction
Congratulations on your purchase of the NORAC UC4.5 Spray Height Control System. This
system is manufactured with top quality components and is engineered using the latest
technology to provide operating reliability unmatched for years to come.
When properly used the system can provide protection from sprayer boom damage, improve
sprayer efficiency, and ensure chemicals are applied correctly.
Please take the time to read this manual completely before attempting to install the system. A
thorough understanding of this manual will ensure that you receive the maximum benefit from
the system.
Your input can help make us better! If you find issues or have suggestions regarding the parts
list or the installation procedure, please don’t hesitate to contact us.
Every effort has been made to ensure the accuracy of the information contained in
this manual. All parts supplied are selected to specially fit the sprayer to facilitate
a complete installation. However, NORAC cannot guarantee all parts fit as
intended due to the variations of the sprayer by the manufacturer.
Please read this manual in its entirety before attempting installation.
2
2General UC4.5 System Layout
Figure 1 illustrates the general layout of the UC4.5 system components:
Figure 1: General UC4.5 System Layout
3
3Kit Parts
3.1 Kit Overview
Figure 2: RA1 System Parts
4
3.2 Hydraulic Plumbing
Figure 3: RA1 Hydraulic Plumbing – Single Acting
5
Figure 4: RA1 Hydraulic Plumbing – Double Acting
6
3.3 List of Parts
Item Part Number Name Quantity
B01 101375 BOLT CARRIAGE SS 3/8X5 8
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7.5 IN 1
B10 44728 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
B11 44695-4 MOUNTING BRACKET UC3 SENSOR 6IN LG 1
C03 44656D CABLE VALVE VARIABLE RATE DT 1
C05 43210-20 CABLE UC5 NETWORK 18 AWG 20M 2
C07 43220-01 CABLE UC5 NETWORK 14 AWG 1M 1
C10 44650-51 CABLE UC4.5 POWER GENERIC PULL-TYPE 1
C11 44651-50 CABLE UC4.5 EXTENSION VALVE GENERIC 1
C12 44696 RAU VALVE DRIVER 1
C17 44658-58 CABLE UC4 INTERFACE RAU I/O 1 1
C18 44658-59 CABLE UC4 INTERFACE RAU I/O 2 1
C19 44658-61 CABLE UC4 INTERFACE RAU BYPASS 1
C30 43250-06 CABLE UC5 BATTERY PIGTAIL FUSED 1
E01 45100 UC4.5 BOOM CONTROL PANEL 1
E03 43742 UC5 ROLL SENSOR W TEMPERATURE PROBE 1
E04 43741 UC5 ROLL SENSOR VER. 2 1
E05 43750 UC5 ULTRASONIC SENSOR 3
E11 43765 UC5 NETWORK COUPLER 8-WAY 1
E12 43764 UC5 NETWORK COUPLER 2-WAY 2
E20 43764T UC5 NETWORK COUPLER 2-WAY WITH TERMINATOR 2
H10 44865-57 HYDRAULICS FITTING KIT - RA1 1
M01
UC4.5-BC-MANUAL-
OPERATOR
OPERATOR MANUAL UC4.5 SPRAY HEIGHT CONTROL 1
M02 UC4.5-BC-RA1-INST MANUAL INSTALLATION UC4.5 KVERNELAND VARIABLE GEOMETRY 1
P03 105882 UC5 NETWORK 6 PIN PLUG 2
V01 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/LS PROP DT 4 BOLT 1
7
3.4 Hydraulic Fitting Kit Details (P/N: 44865-57)
Item Part Number Name Quantity Picture
F01 44928 ORIFICE INSERT .047 IN ONE WAY 4
F02 104369 PLUG - 6MBP 2
6 M B - 6 M OR X 90
SIZE IN
1/16TH'S
GENDER: MALE
OR FEMALE
90° ANGLE
SWIVEL
TYPE
GENDER
SIZE
TYPE:
B - ORB
J - JIC
OR - FLAT
FACE
P - PIPE
Fitting Name
Example:
The hoses and some fittings required for the hydraulic installation are NOT
included in this kit. The parts needed for complete installation of the UC4.5
Sprayer Height Control system are:
Fittings (*F03) to interface the VG hoses to the 6MB ports on the NORAC
valve block (4 are required for double-acting hydraulics and 2 are required for
single-acting hydraulics).
2 fittings (*F04) and 2 hoses (*H01) to interface the pressure and tank lines to
the 6MB P and T ports on the NORAC valve block.
2 tee fittings (*F05) may be needed to tee the pressure and tank hoses if the
sprayer has steering.
Do not use high speed power tools/drills when installing hardware.
The use of dielectric grease is not recommended on any NORAC electrical
connections.
To ensure all stainless steel hardware does not gall or seize apply a light coating of
the supplied Permatex Anti-seize grease to all threaded parts upon installation.
Permatex Anti-seize lubricant is preferred, but other similar anti-seize products
may be used.
