5 - Disassembly Instructions

RM-127

Nokia Customer Care 5 - Disassembly Instructions

2 COMPANY CONFIDENTIAL Issue 1 11/2005

[This page intentionally blank]

Issue 1 11/2005 COMPANY CONFIDENTIAL 3

RM-127

5 - Disassembly Instructions Nokia Customer Care

Table of Contents Page No

Disassembly Instructions................................................................................... 5

General requirements........................................................................................ 5

Detailed disassembly instructions...................................................................... 6

Reassembly ....................................................................................................... 13

RM-127

Nokia Customer Care 5 - Disassembly Instructions

4 COMPANY CONFIDENTIAL Issue 1 11/2005

[This page intentionally blank]

Issue 1 11/2005 COMPANY CONFIDENTIAL 5

RM-127

5 - Disassembly Instructions Nokia Customer Care

Disassembly Instructions

■ General requirements

Use the correct ESD protection before handling the RM-127 product.

Use gloves to handle the RM-127 product.

Required tools:

• torx 6 screwdriver, for disassembly torx 6 torque-driver,

IMPORTANT:

Set to 23Ncm torque for reassembling B-Cover Assy and A-Cover Assy.

If new parts are used for reassembly, set to 23Ncm for A-Cover Assy but

28Ncm for B-Cover assy.

• slotted screwdriver

• tweezers

• dental tool

• SS-42 camera removal tool

• SRT-6 opening tool

• DC-plug

• RJ-107 PWB soldering jig

Note: When shielding lids are removed from the shielding frames of the PWB, new lids must be

used in order to close the shielding properly. It is not allowed to re-use the removed ones.

Note:TheRM-127phonehashighglosspaint.Thetargetcustomer-groupisexpectedtobevery

sensitive to the appearance of the phone. Therefore, extra care must be taken when handling

the covers. Use gloves when touching the product.

RM-127

Nokia Customer Care 5 - Disassembly Instructions

6 COMPANY CONFIDENTIAL Issue 1 11/2005

■ Detailed disassembly instructions

1.) You need the following tools.. 2.) Protect the window with a plastic film..

3.) Press the release button of the C-COVER

ASSY and lift it from the bottom side of the

phone.

4.) Unscrew the two Torx plus® size 6 screws in

the order shown.

For Assembly use the reverse order and a

torque of 23Ncm.

5.) Place the SRT-6 between TRIM PAINTED

and B-COVER ASSY and lift it a little bit. Move

to the shown direction and ...

6.) ... stick at the marked position the SRT-6

deeper till the TRIM PAINTED unlocks on this

side.

Issue 1 11/2005 COMPANY CONFIDENTIAL 7

RM-127

5 - Disassembly Instructions Nokia Customer Care

7.) Now place the SRT-6 between TRIM

PAINTED and B-COVER ASSY on the opposite

side and ...

8.) ... unlock it at the same way before on the

other side.

9.) Remove the TRIM PAINTED. 10.) Note the two snaps of the A-COVER ASSY.

11.) Unlock the snap of the A-COVER ASSY on

one side and .... 12.) ... do the same on the other side.

RM-127

Nokia Customer Care 5 - Disassembly Instructions

8 COMPANY CONFIDENTIAL Issue 1 11/2005

13.) To remove the A-COVER ASSY, lift it a little

bit and move it in the opposite direction than the

B-COVER ASSY.

14.) Hold the KEYMAT with your fingers and

bent the A-COVER ASSY slightly. Now press

the KEYMAT at the shown side out of the A-

COVER ASSY.

15.) Note the four snaps of the UI PWB

HOLDER.16.) Use a slotted screwdriver and release all

four snaps by sticking carefully in the holes.

17.) Remove the UI PWB Holder including the

UI MODULE from the Engine Module.18.) Hold the UI PWB HOLDER with your fin-

gers. Press the snaps down with the tweezers

and separate the UI MODULE from the UI PWB

HOLDER at the same time.

Issue 1 11/2005 COMPANY CONFIDENTIAL 9

RM-127

5 - Disassembly Instructions Nokia Customer Care

19.) Now remove the UI MODULE from the UI

PWB HOLDER.20.) Unscrew the six Torx plus® size 6 screws in

the order shown.

For assembly, use the reverse order. IMPOR-

TANT: Torque for used B-Cover Assy =

23Ncm. Torque for new B-Cover Assy =

28Ncm

21.) Remove the ENGINE MODULE from the B-

COVER ASSY.22.) Use the SRT-6 to open the connector of the

LCD MODULE.

23.) Separate the UI SHIELD ASSY including

the LCD MODULE from the ENGINE MODULE.24.) Bent the UI SHIELD ASSY slightly and

press out the LCD MODULE. Prevent deforming

the UI SHIELD ASSY.

RM-127

Nokia Customer Care 5 - Disassembly Instructions

10 COMPANY CONFIDENTIAL Issue 1 11/2005

25.) Protect the LCD MODULE with a plastic

film. 26.) Remove the VOLUME KEY ACTUATOR

including the VOLUME KEY from the B-COVER

ASSY.

27.) Separate the VOLUME KEY ACTUATOR

from the VOLUME KEY. 28.) Remove the IRDA WINDOW.

29.) Remove the VIBRA MOTOR. 30.) Remove the MICROPHONE.

31.) Remove the DC-JACK with a DC PLUG.32.) Press the SIM-GRIP to the shown direction

and lift one side of it out of the B-COVER ASSY.
