User Guide for Nokia
Camera Flash PD-2
9234566
Issue 1
9235137_PD-2_1_en.fm Page 1 Thursday, August 12, 2004 3:54 PM
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION, declare under our sole responsibility that the
product PD-2 is in conformity with the provisions of the following Council
Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2004 Nokia. All rights reserved.
Nokia and Nokia Connecting People are registered trademarks of Nokia
Corporation. Other product and company names mentioned herein may
be trademarks or tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the
right to make changes and improvements to any of the products described
in this document without prior notice. Nokia reserves the right to revise
this document or withdraw it at any time without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or
income or any special, incidental, consequential or indirect damages
howsoever caused.
The availability of particular products may vary by region. Please check
with the Nokia dealer nearest to you.
9234566/Issue 1
9235137_PD-2_1_en.fm Page 2 Thursday, August 12, 2004 3:54 PM
Introduction
3
English
1. Introduction
Nokia Camera Flash enables you to take photos and video
clips in poor lighting conditions. Nokia Camera Flash can
be connected to compatible Nokia camera phones, such
as the Nokia 7610 phone. To check the compatibility of
your Nokia phone, contact your dealer or Nokia Customer
Care.
Nokia Camera Flash includes a xenon flash tube and an
LED light. You can use the flash to take pictures of a
subject up to 3 meters away. You can use the LED to
record video clips of subjects no further away than 0.5
meter.
Do not use the flash on people or animals at close range.
9235137_PD-2_1_en.fm Page 3 Thursday, August 12, 2004 3:54 PM
Introduction
4
Note that the flash is only meant for use in poor lighting
conditions or the dark. If you use the flash in normal
indoor lighting or in daylight, some of your photos may
be overexposed.
Read this user guide carefully before using Nokia Camera
Flash. More detailed information is provided in the user
guide of your own phone. Do not use this user guide in
place of the user guide for the phone, which provides
important safety and maintenance information.
9235137_PD-2_1_en.fm Page 4 Thursday, August 12, 2004 3:54 PM
Getting started
5
English
2. Getting started
■Overview
1. Pop-PortTM connector
2. Video LED light
3. Xenon flash tube
4. Battery door release button
5. Status LED indicator
9235137_PD-2_1_en.fm Page 5 Thursday, August 12, 2004 3:54 PM
Getting started
6
To insert the battery, open the battery cover, put the
battery in (the required polarity is printed on the cover),
and close the cover. When the indicator light is red, the
battery must be replaced.
■Using Nokia Camera Flash
1. Connect Nokia Camera Flash to the phone Pop-Port.
2. To take a picture, see the user guide for the phone.
The indicator light blinks green while the flash
charges. When the light stops blinking and remains a
steady green, you can take a picture.
3. To record a video, see the user guide for the phone.
4. Do not cover the flash while using it.
9235137_PD-2_1_en.fm Page 6 Thursday, August 12, 2004 3:54 PM
Troubleshooting
7
English
3. Troubleshooting
• Q: Why do I receive a message that the enhancement
is not supported when I connect Camera Flash to a
compatible phone?
A: Camera Flash must be correctly connected to your
phone. See the image below.
• Q: What does the LED indicate?
9235137_PD-2_1_en.fm Page 7 Thursday, August 12, 2004 3:54 PM
Troubleshooting
8
A: A blinking green LED indicates the flash is charging
and is not ready for use.
A steady green indicates the flash is charged and is
ready for use.
A blinking red indicates the charging of the flash
stopped for safety reasons, such as a humid
environment.
A steady red indicates a low battery.
Note that the LED only indicates the readiness of the
flash for photos.
• Q: What is the optimal range for the flash?
A: The flash works for distances from 1 meter to 3
meters. The optimal range depends on your phone
model.
• Q: What is the optimal range for the video LED light?
A: The video LED light works for distances up to 0.5
meter. The optimal range depends on your phone
model.
9235137_PD-2_1_en.fm Page 8 Thursday, August 12, 2004 3:54 PM
Battery information
9
English
4. Battery information
This device is intended for use when supplied with power
from a CR2 3V, Lithium battery. The use of any other
types may invalidate any approval or warranty, and may
be dangerous. Always switch the device off before
removing the battery. Ensure the correct polarity is
observed when inserting batteries.
Use the battery only for its intended purpose. Never use
any charger or battery that is damaged.
Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object such as a
coin, clip, or pen causes direct connection of the positive
(+) and negative (-) terminals of the battery. This might
happen, for example, when you carry a spare battery in
your pocket or purse. Short-circuiting the terminals may
damage the battery or the connecting object.
9235137_PD-2_1_en.fm Page 9 Thursday, August 12, 2004 3:54 PM
Battery information
10
Leaving the battery in hot or cold places, such as in a
closed car in summer or winter conditions, will reduce
the capacity and lifetime of the battery. Always try to
keep the battery between 15°C and 25°C (59°F and 77°F).
A device with a hot or cold battery may not work
temporarily, even when the battery is fully charged.
Battery performance is particularly limited in
temperatures well below freezing.
Do not dispose of batteries in a fire! Dispose of batteries
according to local regulations. Please recycle when
possible. Do not dispose as household waste.
